2004 CHRYSLER SEBRING COUPE Owners Manual

To adjust seat forward or backward
Type 1 (Manual)
Pull the seat adjusting lever and slide the seat forward or
backward to the desired position. Release the adjusting
lever to lock the seat in position.
WARNING!
To ensure the seat is locked securely, attempt to
move the seat forward or backward without using
the adjusting lever.
Type 2 (Power, driver's side only±if so equipped)
Push the switch to adjust the seat forward or backward to
the desired position. Release the switch, and the seat will
lock at that position.
G21B0620
G22B0190
SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 57
3

1. Backward
2. Forward
CAUTION!
Operate the power seat with care not to have the
hand or foot caught by the seat.
To recline the seatback
In order to recline the seatback, first lean your body
forward slightly and pull the seatback lock lever up, and
then lean backward to the desired position and release
the lever. The seatback will lock in that position.
G21C0700
58 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS

Memory reclining knob
When you fold down the seatback by using the memory
reclining knob, the angle of the seatback will be memo-
rized.
Pull the memory reclining knob and fold the seatback
down.Just by pushing the seatback up into position will lock it
in the memorized position.
G21C0870
Memory reclining
knob
G21C0880
SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 59
3

WARNING!
To minimize risk of severe or fatal personal injury in
the event of a collision or sudden stop, both the
driver and passenger seatbacks should always re-
main in a nearly upright position while the vehicle is
in motion.
The protection provided by the seat belts will be
reduced significantly the more the seatback is re-
clined.
There is greater risk that the seat belts will not be
properly positioned on your body and/or you will
slide under the belt in an accident the more the
seatback is reclined, resulting in severe or fatal
injury.
CAUTION!
Pull the seatback lock lever, and the seatback will
return to its original position. When operating the
lever, sit close to the seatback or check with your
hand on it.
60 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS

To adjust seat height (Driver's side only)
Type 1 (Manual)
Turn the knob to raise or lower the whole seat cushion.
1. Raise
2. Lower
Type 2 (Power, driver 's side only-if so equipped)
Front and/or rear parts of the seat cushion height can be
adjusted.
Front part of the seat cushion
Push the switch to raise or lower the front part of the seat
cushion.
1. Raise
2. Lower
G21D0830
G22D0300
SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 61
3

Rear part of the seat cushion
Push the switch to raise or lower the rear part of the seat
cushion.
1. Raise
2. Lower
Whole seat cushion
Push the center of the switch to raise or lower the whole
seat cushion.
1. Raise
2. Lower
G22D0310G22D0320
62 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS

To adjust lumbar support (Driver's side only, if so
equipped)
A lumbar support is included in the seatback of the
driver's seat. The support has a three position adjust-
ment.For access to the rear seat (passenger side entry)
To permit rear seat entry or exit, the front seatback will
fold down and the seat will move forward when the
seatback lock lever is pulled up or when the pedal in back
of the front passenger seat is depressed.
To return the seat, push the seatback backward until there
is a ªclickº and the seat locks in position.
NOTE:The driver 's side seatback will fold down only.
G21E0230
Weak
Strong
G01J0310
SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 63
3

REAR SEATS
Rear seat capacity
WARNING!
²The rear seating capacity of this vehicle is three
people.
²The rear seat occupants should always wear their
seat belts when the vehicle is in motion.
Fold down rear seatbacks
The rear seatbacks can be folded forward to provide
additional cargo area.
Pull the left and/or right release knobs, and fold the rear
seatbacks forward.
HEAD RESTRAINTS
Padded head restraints for the front seats reduce the risk
of whiplash injury in the event of a rear impact.
G02C0750
G26A0140T
Lock knob
64 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS
