2004 CHRYSLER SEBRING COUPE Owners Manual

2. Remove the light case mounting nuts. Disconnect the
connector.
3. Slide the light unit outward to remove it. Remove each
bulb socket assembly by turning it counterclockwise.Remove the bulb from the socket by turning it counter-
clockwise while pressing it inward.
N20I0160N20I0100
A - Stop and tail light
B - Rear turn signal light
C - Back up light
D - Rear side marker light
EMERGENCIES 297
8

High-mounted stop light
Remove the socket assembly and bulb together by turn-
ing it counterclockwise.
Remove the bulb from the socket by pulling out.
License plate light
Remove the lens mounting screws, remove the socket
assembly and the bulb together by turning it counter-
clockwise. And remove the bulb by pulling out.
N10V0700N10J0310
298 EMERGENCIES

Trunk light
Pull both clips away from the center as shown and
remove the light unit. Then remove the bulb by pulling
out.
Dome light
1. Insert a flat blade screwdriver into the notch of the
light assembly and pry gently downward to remove it.
Type 1
NOTE
: Wrap a cloth around the tip of the screwdriver to
avoid scratching the light assembly.
N10O0230
Clips
N10M0380
EMERGENCIES 299
8

2. Remove the light bulb from the light holder.Reading lights
Insert a straight blade screwdriver into the notch of the
light assembly and pry gently to remove the lens.
Remove the light bulb from the light holder.
NOTE: Wrap a cloth around the tip of the straight blade
screwdriver in order to avoid scratching the lens.
N10M0410N11I0040
300 EMERGENCIES

Rear personal light
Insert the tip of a flat blade screwdriver at the edge of the
lens, pry gently to remove the lens, and then remove the
bulb from the light holder.
NOTE: Wrap a cloth around the tip of the screwdriver in
order to avoid scratching the lens.
N10Q0090
EMERGENCIES 301
8

MAINTENANCE
CONTENTS
mView of engine compartment..............305
mService precautions.....................306
mEmission-control system maintenance.......307
mEmissions Testing......................308
mOnboard Diagnostic System (OBD II)........308
mReplacement Parts......................309
NFuel system (tank, filler tube, connections,
and fuel tank filler cap).................309
NFuel hoses...........................309
NAir cleaner filter......................310
NEvaporative emission control system
(except evaporative emission canister).......310
NSpark plugs..........................311
NIgnition cables........................311NDistributor cap and rotor................311
mGeneral maintenance....................312
NEngine oil and oil filter..................312
mEngine coolant.........................316
NTo check the coolant level................316
NTo add coolant........................316
mBrake fluid...........................317
mClutch fluid (manual transaxle)............318
NTo check the clutch fluid.................318
NTo replace the fluid....................318
mBattery..............................319
NDuring cold weather...................319
9

NDisconnection and connection.............319
mAutomatic transaxle.....................321
NTo check the fluid level..................322
NProcedure for checking the fluid level.......322
mManual transaxle.......................323
mDisc brake pads, rear drum brake linings
and rear wheel cylinders.................323
mBrake hoses...........................323
mBall joint, steering linkage seal and drive
shaft boots...........................323
mSupplemental Restraint System (SRS)........323
mDoor hinges, rear hatch hinges, hood lock
release mechanism and safety catch
.........324
mExhaust system........................324
mWindshield wiper blades.................325
NWindshield washers....................325
mParking brake.........................326
mDrive belt (for generator, water pump, power
steering pump)
........................327
mTiming belt...........................328
mTi re s................................328
NTire inflation pressures..................328
NRadial ply tires.......................330
N
Tire pressure for sustained high-speed driving...330
NOversize tires........................330
NTire maintenance......................331
NCargo loads..........................331
NTread wear indicators...................331
NTire rotation.........................332
NTire chains...........................333
NSnow tires...........................333
mRegular Maintenance Schedule.............334
mSevere Maintenance Schedule..............343
304 MAINTENANCE
