2004 CHRYSLER SEBRING COUPE Owners Manual

To turn off the function, press the display switch (C) more
than 6 seconds, less than 9 seconds. When the green
indicator (A) goes off, the automatic anti-glare will not
function.
To turn the function back on, press the display switch (C)
more than 6 seconds, less than 9 seconds.
NOTE:
²
Do not spray glass cleaner on the sensor (B), as
reduced sensitivity could result.
Electrochromic mirror operation (if so equipped)
A-Garage door opener button
Press the button to operate devices such as garage
door openers, motorized gates, or home lighting.!P.
130
NOTE:Garage door button must be programmed.B-Display switch
Press the switch to change the mode of compass,
outside temperature and anti-glare operation.!P.
176.
C-Dome light switch!P. 175.
D-Display.
The compass and outside temperature are displayed.
To turn on/off the display, press the display switch
(C) less than 3 seconds.!P. 177.I08A0560
STARTING AND DRIVING 177
5

How to change the display mode
The mode will change in order by pressing the display
switch for the following seconds.1. When the ignition key is ªACCº or ªONº position,
automatic anti-glare operate and current outside tem-
perature and compass are displayed.
I08A0600
178 STARTING AND DRIVING

2. If you press the display switch less than 3 seconds, you
can turn on/off the display.3. If you press the display switch more than 3 seconds,
less than 6 seconds, you can alternate the temperature
reading between Fahrenheit and Celsius.!P. 180.
I08A0660
I08A0590
STARTING AND DRIVING 179
5

4. If you press the display switch more than 6 seconds,
less than 9 seconds, you can turn on/off the automatic
anti-glare.!1755. If you press the display switch more than 9 seconds,
less than 12 seconds, you can adjust for compass vari-
ance.!181
I08A0670I08A0610
180 STARTING AND DRIVING

6. If you press the display switch more than 12 seconds,
you can recalibrate compass variance.!184Outside temperature (if so equipped)
When the ignition key is in the ªACCº or ªONº position,
the current outside temperature is displayed.I08A0590
I08A0600
STARTING AND DRIVING 181
5

To alternate the temperature reading between
Fahrenheit and Celsius
Press the display switch above 3 seconds, less than 6
seconds until the display blinks ÉF and ÉC.
Press the display switch to toggle between the Fahrenheit
and Celsius readings within 5 seconds.
After 5 seconds of inactivity, the original item (Outside
temperature/Compass) is again displayed.
NOTE
²
The outside temperature can be displayed from
-40ÉF (-40ÉC)
²If the outside temperature is below -40ÉF (-40ÉC) or
over 140ÉF (60É C) an error message ªSCº or ªOCº
will be shown in the display. If an error message
(ªSCº or ªOCº) will be shown in the display, have
the system checked at an authorized dealer.
²If the outside temperature drops below about 37ÉF
(3ÉC)
²The outside temperature displayed may differ from
the actual temperature on account of surrounding
conditions, driving conditions, etc.
I08A0590
182 STARTING AND DRIVING

Compass operation
When the ignition key is in the ªACCº or ªONº position,
the vehicle's current directional heading (N, NE, E, SE, S,
SW, W and NW) will be displayed.
Magnetic variation of compass
Under certain circumstances, as during a long distance
cross-country trip, it will be necessary to adjust for
magnetic variation of compass. Magnetic variation of
compass is the difference between earth's magnetic northand true geographic north. If not adjusted to account for
magnetic variation of compass, your compass could give
false readings.
To adjust for magnetic variation of compass
1. Press the display switch more than 9 seconds, less than
12 seconds. The current zone number will appear in the
display.
I08A0600
I08A0610
STARTING AND DRIVING 183
5

2. Find your current location and variance zone number
on the zone map.
3. Press the display switch until the new zone number
appears in the display. After 5 seconds of inactivity, the
original item (Outside temperature/Compass) displayed
again.NOTE
²
Do not attach ski racks, antennas, or any other object
to the vehicle by means of a magnet. Such magnets
will affect the operation of the compass.
²If the compass deviates from the correct indication
soon after repeated adjustment, have the compass
checked at an authorized dealer.
²The compass may not indicate the correct compass
point in the places shown below:
²Vehicles in tunnels or parked in buildings
²Expressways, near railroads, underneath railroad
cables, or over subways
²Near transformer stations or high voltage power
lines
In these cases, the correct direction will be displayed once
the vehicle returns to a place where the earth's magnetic
field is stable.
D11C0690
184 STARTING AND DRIVING
