Indicator and warning light package
1. Washer fluid level indicator!P. 1 1 7
2. Anti-lock braking system warning light
(if so equipped)!P. 111
3. Low-fuel warning light!P. 111
4. Brake warning light!P. 1 1 55. Supplemental Restraint System (SRS) - air bag
warning light!P. 1 1 4
6. Seat belt reminder/warning light!P. 1 1 6
7. Turn signal indicators/hazard warning light!P. 1 1 0
8. Trunk-ajar warning light!P 111
9. Front fog light indicator (if so equipped)!P. 1 1 2
10. Door-ajar warning light!P. 1 1 0
D50A439D
INSTRUMENTS AND CONTROLS 105
4

11. High beam indicator!P. 1 1 0
12. Cruise control indicator!P. 111
13. Theft-alarm indicator (if so equipped)!P. 1 1 0
14. Malfunction indicator light
(SERVICE ENGINE SOON)!P. 1 1 3
15. Oil pressure warning light!P. 1 1 2
16. Charging system warning light!P. 1 1 2
17. Overheating warning light!P. 1 1 4
18. Traction control system warning light
(if so equipped)!P. 1 1 6
19. Automatic transaxle indicator
(Vehicles with Autostick automatic transaxle-if so
equipped)!P. 1 1 6
Speedometer
The speedometer indicates vehicle speed.
·The outer scale indicates miles per hour.
·The inner scale indicates kilometers per hour.
Tachometer
The tachometer indicates engine revolutions per minute.
This allows the driver to determine the most efficient
gear range and engine speed combinations.
D04A0500
2.4 liter
engine3.0 liter
engine
106 INSTRUMENTS AND CONTROLS

CAUTION!
The red zone indicates an engine speed in excess of
safe operation.
Select the correct gear to control engine speed so the
tachometer indicator does not enter the red zone.
Fuel gauge
The gauge shows the amount of fuel in the fuel tank
when the ignition key is turned to the ``on'' position.
The arrow A indicates that the fuel lid (fuel filler port) is
located on the right side of the vehicle. (Refer to ªFuel
fillerº on page 39.)
NOTE: Just after refueling, it takes a little time until the
correct fuel level is indicated after turning on the ignition
switch.
D05A0430
INSTRUMENTS AND CONTROLS 107
4

Odometer/Trip odometer
When the ignition switch is turned to the ªONº position,
an ªODOº or ªTRIPº indication is given.
Every time the reset button (3) is pressed lightly (less
than one second), the indicators will change from ªODOº
to ªTrip Aº to ªTrip Bº.
1. Odometer
2. Trip odometer3. Reset button
ODO --- Odometer
The odometer indicates the total distance the vehicle has
travelled.
TRIP --- Trip odometer
The trip odometer indicates the distance traveled during
a particular trip or period.
As a feature, there are two trip odometer displays:
and.
D03F0320
1
D03F0120
108 INSTRUMENTS AND CONTROLS

Tripcan be used to measure the distance traveled
since the current trip began and Trip
can be used to
measure the distance from an intermediate location.
To return either Trip
or Tripdisplay to zero,
press the reset button (3) for more than one second. Only
the currently displayed value will be reset.
If Trip
is displayed, for example, only Tripwill
be reset.
NOTE
1. Display TRIPand TRIPeach have a maxi-
mum distance of 9999.9 mile (16 093.28 km)
2. When disconnecting the battery for a long time, the
memory of trip meter display
andwill clear,
and the display returns to ª0º.
Engine coolant temperature gauge
This gauge indicates the engine coolant temperature.
When the engine temperature is low, the indicator will
remain at the ªCº (cold) position. The indicator will
gradually rise as the engine is warmed up.
The indicator will normally stay near the center while
driving, but may rise slightly in congested traffic or when
the engine is under a heavy load.
D06A0460
INSTRUMENTS AND CONTROLS 109
4

CAUTION!
While driving, care should always be taken to main-
tain normal engine operating temperature. If the
indicator enters the ªHº (hot) position while driving,
the engine is overheating. (Refer to ªEngine over-
heatingº on page 272.)
Turn signal indicators/hazard warning lights
The arrow will flash in unison with the
corresponding exterior turn signals when
the turn signal lever is operated.
Both arrows will flash intermittently when the hazard
warning flasher switch is pressed.
NOTE: If the signal indicator blinks too fast, the cause
may be a faulty turn-signal connection or faulty lamp
bulb.
High beam indicator
A blue light illuminates when the head-
lights are on high beam.
Theft-alarm indicator
When the theft-alarm system has been
armed, the indicator located in the instru-
ment cluster will illuminate and go off in 20
seconds, indicating the system is armed. (See ªTheft-
alarm systemº on page 48.)
Door-ajar warning light and chime
This light illuminates when either door or
the trunk is open or not completely closed.
When the vehicle is moving at more than 5
mph (8 km/h) and the door is open or ajar,
a chime will sound to inform the driver that
the door is not properly shut.
CAUTION!
Before driving, check to ensure that the door-ajar
warning light is off.
110 INSTRUMENTS AND CONTROLS

Trunk-ajar warning light and chime
This light illuminates when the trunk lid is
open or not completely closed.
When the vehicle is moving at more than 5
mph (8 km/h) and the trunk lid is open or
ajar, a chime will sound to inform the driver that the
trunk lid is not properly shut.
Anti-lock braking system warning light (if so
equipped)
This light comes on in the event of a mal-
function in the anti-lock braking system.
Always be sure that the light goes out
before beginning to drive.
It also comes on when the ignition key is turned to the
ªONº position and should go out shortly after starting
the engine.
If the light illuminates during driving;
1. Stop the vehicle in a safe place and turn off the engine.
Test the system by restarting the engine and driving at a
speed of about 12 mph (20 km/h) or higher.
If the light goes out, there is no abnormal condition.2. If the light does not go out or if it illuminates again,
the anti-lock braking system is not functioning, and only
the standard braking system is functioning.
If this occurs, take your vehicle to an authorized dealer
and have the system checked.
NOTE: If the light remains illuminated after the engine
is started, it indicates that a fault has occured in the
Anti-lock brake system. The standard brake system will
function normally. (Refer to ªAnti-lock braking systemº
on page 169).
Cruise/speed control indicator
This indicator will illuminate when the
cruise/speed control main switch is ªONº.
Low-fuel warning light and chime
When the fuel level in the fuel tank gets
low, the light illuminates and the chime will
also sound. It is recommended that fuel be
added as soon as this light illuminates.
INSTRUMENTS AND CONTROLS 111
4

CAUTION!
Do not drive with an extremely low fuel level;
running out of fuel could cause damage to the
catalytic converter.
Front fog light indicator
This indicator illuminates while the fog
lights are on.
NOTE:Fog lights will not be operational when high
beam (headlights) are selected.
Charging system warning light
This light illuminates in the event of a
malfunction in the charging system.
This light illuminates when the ignition key
is turned to the ªONº position (engine off). When the
engine is started, the light should go off. Always be sure
that the light goes out before beginning to drive.
CAUTION!
If the charging light remains on after the engine has
started, the battery charging system may be malfunc-
tioning. In this case, take your vehicle to an autho-
rized dealer and have the system checked.
Oil pressure warning light
This light illuminates when the engine oil
pressure is below normal. If the light stays
on while driving, stop the engine as soon as possible and
do not drive until the cause of the low oil pressure is
corrected.
