2004 CHRYSLER SEBRING COUPE Owners Manual

To calibrate the compassIf the display reads ªCALº (A), there may be a strong
magnetic field interfering with the compass. In this case,
the compass may need calibration.
If the ªCALº is displayed, drive the vehicle in a circle at
about 5 mph (8km/h) or less until the ªCALº goes off.
I08A0650
D11C0110
STARTING AND DRIVING 185
5

If the ªCALº is not displayed, but compass calibration is
required, press and hold the display switch for 12 sec-
onds, or until ªCALº is displayed. With ªCALº dis-
played, drive the vehicle in a circle at less than 5mph
(8km/h) or less until the ªCALº goes off.
Cleaning of the mirror
When cleaning the mirror, use a paper towel or similar
material dampened with glass cleaner. Do not spray glass
cleaner directly on the mirror as that may cause the liquid
cleaner to enter the mirror housing.
Electric remote-controlled outside mirrors
The outside rearview mirrors can be adjusted when the
ignition key is in the ªONº or ªACCº position.
Place the lever to the same side as the mirror whose
adjustment is desired:
L - Left outside mirror adjustment
R - Right outside mirror adjustment
I08B2160
186 STARTING AND DRIVING

NOTE
²
After adjustment, return the lever to the centered
position.
Press the left, right, up or down switches to adjust the
mirrors as desired.
1. Up
2. Down
3. Right
4. Left
CRUISE/SPEED CONTROL
Cruise/speed control is an automatic speed control sys-
tem. It lets you keep the same driving speed. Cruise/
speed control can be used at 25mph (40km/h) or more. It
is especially useful for freeway driving. Cruise/speed
control does not work at speeds below about 25mph
(40km/h).
A-Main switch
B-Cruise/speed control lever
I10A1190
STARTING AND DRIVING 187
5

CAUTION!
²For safety reasons, the main switch (A) should be
set to the OFF position when you are not using the
cruise/speed control system.
²Cruise/speed control is not recommended when
driving conditions will not allow you to stay at the
same speed, such as in heavy traffic or on roads
that are winding, icy, snow-covered, wet, or slip-
pery, or on a steep downhill.
²For vehicles with manual transaxles, if you shift to
ªNº (Neutral) in cruise/speed control mode with-
out pressing the clutch first, the engine will run
too fast and might be damaged.
NOTE
²
Cruise/speed control may not be able to keep your
speed on uphills or downhills.
²Your speed may drop on a steep uphill. You must
use the accelerator if you want to stay at your set
speed.
²Your speed may increase to more than the set speed
on a steep downhill. You must use the brake to
control your speed. If your speed increases too
much, turn off the cruise/speed control. (Refer to
the section ªTo deactivateº on page 190.)
To activate
1. Momentarily push in the main switch (A) at the end of
the cruise/speed control lever.
I10A1490
188 STARTING AND DRIVING

2. When the main switch (A) is ON, the ªCRUISEº
control light on the instrument cluster will illuminate.3. Pull the lever (B) down while driving at the desired
speed.
To increase the set speed
There are 2 ways to increase the set speed.
I10A1670I10A1500
STARTING AND DRIVING 189
5

Cruise/speed control lever
Pull the cruise/speed control lever up and hold it. Your
speed will then gradually increase. When you reach your
desired speed, release the switch. Your cruising speed is
now set.
To increase your speed in small amounts, pull the cruise/
speed control lever up for less than 1 second and release
it. Each time you pull the lever up, your vehicle will go
about 1 mph (1.6km/h) faster.
Accelerator
Press the accelerator pedal to reach your desired speed.
Pull the cruise/speed control lever down for a moment,
then release it.
To decrease the set speed
There are 2 ways to reduce the set speed.
I10A1530I10A1550
190 STARTING AND DRIVING

Cruise/speed control lever
Pull the cruise/speed control lever down and hold it
while driving at the set speed, and you will slow down
(coast) gradually. When your desired low speed is
reached, release the lever.
To slow down in small amounts, press the cruise/speed
control lever down for less than 1 second and release it.
Each time you press the lever down, your vehicle will
slow down by about 1 mph (1.6km/h).
Brake pedal
Press the brake pedal (which disengages the cruise/
speed control), then pull the cruise/speed control lever
down momentarily to set a new desired cruise speed.
I10A1540I10A1110
STARTING AND DRIVING 191
5

To accelerate for passing
Press the accelerator pedal as you would normally. When
you release the pedal, the cruise/speed control will
return to your set speed.
To deactivate
The cruise/speed control can be turned off as follows:
1. Push the main switch (A) at the end of the lever (Main
switch OFF).
2. Pull the cruise/speed control lever (B) toward you.
The cruise/speed control can be turned off automatically
in any of the following ways:
I10A1520I10A1510
192 STARTING AND DRIVING
