2003 TOYOTA SOLARA Owners Manual (in English)

’03 SOLARA_U (L/O 0207)
932003 MY SOLARA (OM33573U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Lights, Wipers and Defogger
Headlights and turn signals 94
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flashers 97
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . .
Instrument panel light control 98
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front fog lights 98
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Interior light 99
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . .
Ignition switch light 99
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . .
Personal lights 100
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Windshield wipers and washer 101
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window and outside rear view mirror defoggers 101
. . . . . . . . . . .
SECTION 1 4

’03 SOLARA_U (L/O 0207)
942003 MY SOLARA (OM33573U)
HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob.
Position 1—Parking, tail, license plate,
side marker and instrument panel lights
Position 2—Headlights and all of the
above
Automatic light cut off system
The lights automatically turn off when the
driver ’s door is opened with the ignition
turned off.
To turn the lights on again, turn the key
to the “ON” position or actuate the head-
light switch. If you are going to park for
over one week, make sure the headlight
switch is off.
NOTICE
To prevent the battery from being dis-
charged, do not leave the lights on
for a long period when the engine is
not running.
Daytime running light (DRL) system
Daytime Running Light System (DRL) can
make it easier for others to see the front
of your vehicle during the day. The DRL
system can be helpful in many different
driving conditions, but they can be espe-
cially helpful in the short periods after
dawn and before sunset.
The DRL system will make your headlights
come on at a reduced brightness when:
The light switch is in “DRL” position.
The ignition is on with the engine run-
ning.
The headlight switch is off.
The parking brake is released.
To turn on the other exterior lights and
instrument panel lights, twist the knob to
the position 1.
Twist the knob to the position 2 to turn
the headlights to full intensity for night
driving. To turn off the DRL system, twist the knob
to the position 3 (“DRL OFF”) or turn the
switch off.
Headlights and turn signals
( f o r th e U.S.A .)

’03 SOLARA_U (L/O 0207)
952003 MY SOLARA (OM33573U)
HighLow beams—For high beams, turn
the headlights on and push the lever away
from you (position 1). Pull the lever to-
ward you (position 2) for low beams.
The headlight high beam indicator light
(blue light) on the instrument panel will
tell you that the high beams are on.
Flashing the high beam headlights
(position 3)—Pull the lever all the way
back. The high beam headlights turn off
when you release the lever.
You can flash the high beam headlights
with the knob turned to “DRL” or “DRL
OFF”.TURN SIGNALS
To signal a turn, push the headlight/
turn signal lever up or down to position
1.
The key must be in the “ON” position.
The lever automatically returns after you
make a turn, but you may have to return
it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position
2) and hold it.
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal
bulb is burned out.HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob.
Position 1—Parking, tail, license plate,
side marker and instrument panel lights
Position 2—Headlights and all of the
above
Position 3 (“AUTO”)—Headlights and/or all
of the lights in position 1
They automatically turn on or off depend-
ing on the darkness of the surroundings.
Manually twist the knob to the position 2
to turn on the headlights if they are need-
ed immediately when entering a dark tun-
nel, parking structure, etc.
Headlights and turn signals
(for Canada)

’03 SOLARA_U (L/O 0207)
962003 MY SOLARA (OM33573U)
The automatic light control sensor is on
the top of the passenger ’s side instrument
panel.
Do not place anything on the instrument
panel, and/or do not affix anything on the
windshield to block this sensor. Automatic light cut off system
The lights automatically turn off when the
driver ’s door is opened with the ignition
key turned off.
To turn the lights on again, turn the key
to the “ON” position or actuate the head-
light switch. If you are going to park for
over one week, make sure the headlight
switch is off.
NOTICE
To prevent the battery from being dis-
charged, do not leave the lights on
for a long period when the engine is
not running.
Daytime running light (DRL) system
Daytime Running Light System (DRL) can
make it easier for others to see the front
of your vehicle during the day. The DRL
system can be helpful in many different
driving conditions, but they can be espe-
cially helpful in the short periods after
dawn and before sunset.
The DRL system will make your headlights
come on at a reduced brightness when:
The ignition is on with the engine run-
ning.
The headlight switch is off.
The parking brake is released.
To turn on the other exterior lights and
instrument panel lights, twist the knob to
the position 1.
Twist the knob to the position 2 to turn
the headlights to full intensity for driving
at night.

’03 SOLARA_U (L/O 0207)
972003 MY SOLARA (OM33573U)
HighLow beams—For high beams, turn
the headlights on and push the lever away
from you (position 1). Pull the lever to-
ward you (position 2) for low beams.
The headlight high beam indicator light
(blue light) on the instrument panel will
tell you that the high beams are on.
Flashing the high beam headlights
(position 3)—Pull the lever all the way
back. The high beam headlights turn off
when you release the lever.
You can flash the high beam headlights
with the knob turned to “OFF”.TURN SIGNALS
To signal a turn, push the headlight/
turn signal lever up or down to position
1.
The key must be in the “ON” position.
The lever automatically returns after you
make a turn, but you may have to return
it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position
2) and hold it.
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal
bulb is burned out.To turn on the emergency flashers,
push the switch.
All the turn signal lights will flash. To turn
them off, push the switch once again.
Turn on the emergency flashers to warn
other drivers if your vehicle must be
stopped where it might be a traffic hazard.
Always pull as far off the road as pos-
sible.
The turn signal light switch will not work
when the emergency flashers are operat-
ing.
Emergency flashers

’03 SOLARA_U (L/O 0207)
982003 MY SOLARA (OM33573U)
NOTICE
To prevent the battery from being dis-
charged, do not leave the switch on
longer than necessary when the en-
gine is not running.
To adjust the brightness of the instru-
ment panel lights, turn the knob.To turn on the front fog lights, twist
the band of the headlight and turn sig-
nal switch lever. They will come on
only when the headlights are on low
beam.
Instrument panel light control Front fog lights

’03 SOLARA_U (L/O 0207)
992003 MY SOLARA (OM33573U)
To turn on the interior light, slide the
switch.
The interior light switch has the following
positions:
“ON”—Keeps the light on all the time.
“OFF”—Turns the light off.
“DOOR”—Turns the light on when either
door is opened. The light goes off when
both doors are closed. ILLUMINATED ENTRY SYSTEM
With the switch in the “DOOR” position,
the light comes on when either door is
opened. After both doors are closed, the
light remains on for about 15 seconds and
then goes out.
However, in the following cases, the light
goes out immediately:
Both doors are closed when the igni-
tion key is in “ACC” or “ON”
Both doors are closed and locked
When either door is unlocked with the
wireless remote control transmitter, the
light comes on for about 15 seconds,
even if the door is not opened.
For easy access to the ignition switch,
the ignition switch light comes on when
either doors are opened.
The light remains on for about 15 seconds
after both doors are closed.
When either door is unlocked with the
wireless remote control transmitter, the
light comes on for about 15 seconds,
even if the door is not opened.
When both doors are locked or the igni-
tion switch is turned to “ACC” or “ON”
after both doors are closed, the light
fades out.
Interior light Ignition switch light

’03 SOLARA_U (L/O 0207)
1002003 MY SOLARA (OM33573U)
Coupe
Convertible
Coupe—
To turn on the personal light, push the
switch. To turn it off, push the switch
once again.
Convertible—
The personal lights operate separately
with each outer switch.
To turn on the light, push the switch on
your side. To turn the light off, push the
switch once again.
The center switch has the following posi-
tions:
“DOOR”—Turn both lights on when either
door is opened.
“OFF”—The lights are off unless you oper-
ate either outside switch.
ILLUMINATED ENTRY SYSTEM
(convertible)
With the switch in the “DOOR” position,
the light comes on when either door is
opened. After both doors are closed, the
light remains on for about 15 seconds and
then goes out. However, in the following cases, the light
goes out immediately:
Both doors are closed when the igni-
tion key is in the “ACC” or “ON” posi-
tion.
Both doors are closed and locked.
When either door is unlocked with the
wireless remote control transmitter, the
light comes on for about 15 seconds,
even if the door is not opened.
Personal lights
