2003 PEUGEOT 607 Owners Manual

10-02-2003
YOUR 607 IN DETAIL53
Adjusting the bass When 'BASS' is displayed, press button F or H to vary the setting:
Ð 'BASS -9' for a minimum bass setting,
Ð 'BASS 0' for a normal setting,
Ð 'BASS +9' for a maximum bass setting.
RM2 RT2
Adjusting the treble When 'TREB' is displayed, press button F or H to vary the setting:
Ð 'TREB -9' for a minimum treble setting,
Ð 'TREB 0' for a normal setting,
Ð 'TREB +9' for a maximum treble setting.
Adjusting the loudnessThis function automatically emphasises bass and treble tones.Press button For H to switch the function on or off.
Adjusting the front/rear sound distribution (Fader)When 'FAD'is displayed, press button For Hto vary the setting.
Button Fincreases the volume in the front.
Button Hincreases the volume in the rear.

10-02-2003
YOUR 607 IN DETAIL
54
Adjusting the left/right sound distribution (Balance) When 'BAL'is displayed, press button For Hto vary the setting.
Button Fincreases the volume on the right-hand side.
Button Hincreases the volume on the left-hand side.
Automatic volume correction "CAV"This function allows the volume to be adjusted automatically depending on the level of noise produced by the speed of the vehicle. Press buttons For H to switch the function on or off.
Note: this function is only operational from 35 mph (60 km/h).
RADIO Notes on radio reception
Your radio is subject to phenomena which do not affect domestic radio sets. Both MW/LW and FM reception are subject to
various forms of interference. This is no reflection on the quality of the equipment, but is due to the nature of the signals a nd
the way in which they are transmitted.
On MW/LW, interference may be noticed when passing under high voltage power lines or bridges, or in tunnels.
On FM, interference may be the result of increasing distance from the transmitter, deflection of the signals by obstacles
(mountains, hills, buildings, etc.) or of being in an area which is not covered by a transmitter.
Selecting radio mode / Selecting a waveband Press button B.
Briefly press button Bto select the FM1, FM2, FMast and AM wavebands.
Automatic station searchBriefly press button Mor Lto search for the station immediately above or below. By continuing to press the
button in the direction selected, you will obtain continuous scrolling of the frequency.The scrolling stops at the first station found as soon as the button is released.

10-02-2003
YOUR 607 IN DETAIL
54
Adjusting the left/right sound distribution (Balance) When 'BAL'is displayed, press button For Hto vary the setting.
Button Fincreases the volume on the right-hand side.
Button Hincreases the volume on the left-hand side.
Automatic volume correction "CAV"This function allows the volume to be adjusted automatically depending on the level of noise produced by the speed of the vehicle. Press buttons For H to switch the function on or off.
Note: this function is only operational from 35 mph (60 km/h).
RADIO Notes on radio reception
Your radio is subject to phenomena which do not affect domestic radio sets. Both MW/LW and FM reception are subject to
various forms of interference. This is no reflection on the quality of the equipment, but is due to the nature of the signals a nd
the way in which they are transmitted.
On MW/LW, interference may be noticed when passing under high voltage power lines or bridges, or in tunnels.
On FM, interference may be the result of increasing distance from the transmitter, deflection of the signals by obstacles
(mountains, hills, buildings, etc.) or of being in an area which is not covered by a transmitter.
Selecting radio mode / Selecting a waveband Press button B.
Briefly press button Bto select the FM1, FM2, FMast and AM wavebands.
Automatic station searchBriefly press button Mor Lto search for the station immediately above or below. By continuing to press the
button in the direction selected, you will obtain continuous scrolling of the frequency.The scrolling stops at the first station found as soon as the button is released.

YOUR 607 IN DETAIL55
If the TA traffic programme is selected, only stations broadcasting this type of programme are selected. Searching for a station occurs first in 'LO' sensitivity (selection of the most powerful transmitters) during scanning of the
waveband, then in 'DX' sensitivity (selection of the weakest and most distant transmitters).
To make a direct search in 'DX'sensitivity, briefly press button M or Ltwice.
Manual station search Press the 'MAN'button.
Briefly press button Mor Lto increase or decrease the frequency displayed.
By continuing to press the button in the direction selected, you will obtain continuous scrolling of the frequency.
The searching stops at the first station found as soon as the button is released.Pressing the 'MAN' button again returns you to automatic station search.
Manual storing of stations in the memorySelect the station required. Press one of the buttons '1'to '6' for more than two seconds.
The sound stops, then becomes audible again, confirming that the station has been stored in the memory.
RM2
RT2
10-02-2003

10-02-2003
YOUR 607 IN DETAIL
56
Automatic storing of FM stations in the memory (autostore) Press button Bfor more than two seconds, to automatically store the 6 stations with the strongest signal in
FM. These stations are stored in the FMast waveband.
If it is not possible to find 6 stations, the remaining memories are empty.
Recalling stations stored in the memoryFor each waveband, briefly press buttons '1'to '6' to recall the corresponding station.
The list of the 6 stations stored on the waveband is displayed each time one of the buttons '1'to '6' is pressed.
RDS SYSTEM Using the RDS (Radio Data System) function on FM Radio Data System allows you to continue listening to the same station, whatever frequency it is using for the region you are going through.
RM2 audio: Press the 'RDS' button to switch the function on or off.
RT2 audio: Press the 'j
j
✱ RDS' button to switch the function on or off.
The display will show: Ð 'RDS' if the function is selected.
Ð '(RDS)' or'RDS
' if the function is selected but not available.
RDS station following
The display indicates the name of the station selected. The radio is continually searching for the station which has the best reception and which is transmitting the same programme.

10-02-2003
YOUR 607 IN DETAIL57
Traffic information programme RM2 audio:press the 'TA'button to switch the function on or off.
RT2 audio: press the '#
k
k TA '
button to switch the function on or off.
The display will show: Ð 'TA' if the function is selected.
Ð '(TA)' or'T
A' if the function is selected but not available.
Any traffic information flash will be given priority, whatever source you are listening to (radio, cassette or CD changer). Note: the volume of the traffic information announcements is independent of the volume of normal radio listening. You can
adjust it by using the volume button. The setting will be stored and will be used when the next messages are broadcast. Regional following mode When they are part of a network, certain stations broadcast regional programmes in the various areas they serve. With regional following mode you can keep listening to the same programme.
RM2 audio:press the 'RDS'button for more than two seconds to switch the function on or off.
RT2 audio: press the 'j
j
✱ RDS' button for more than two seconds to switch the function on or off.

10-02-2003
PTY function This allows you to listen to stations broadcasting a specific type of programme (news, culture, sport, rock etc.)RM2 audio: with FM selected, press the 'TA'button to switch the function on or off.
RT2 audio: with FM selected, press the '#
k
k TA '
button to switch the function on or off.
To search for a PTY programme: Ð select the PTYfunction ,
Ð briefly press button Mor Lto scroll down the list of the various programmes offered.
Ð when the programme of your choice is displayed, keep button Mor Lpressed for more than two seconds
to carry out an automatic search (after an automatic search the PTYfunction is switched off).
Audio RM2: in PTY mode the different types of programmes can be stored in the
memory. To do this, press one of the preselection buttons '1'to '6' for more than
two seconds. Briefly press the corresponding button to recall the type of pro-
gramme stored in the memory.
Audio RT2: in PTY mode the different types of programmes can be stored in the memory. To do this,
press one of the preselection buttons '1'to '6' for more than two seconds. Briefly press the corre-
sponding button to recall the type of programme stored in the memory.
EON system
This connects stations which are part of the same network. It enables the broadcast of traffic information or a PTY pro- gramme by a station, which is part of the same network as the station to which you are listening.
To do this, select the TA traffic information programme or the PTYfunction.
YOUR 607 IN DETAIL
58

10-02-2003
YOUR 607 IN DETAIL59
CASSETTE: Audio RM2 Selecting cassette mode When a cassette is inserted, the cassette player will start automatically. If a cassette is already inserted, press button C.
Ejecting the cassette Press button Eto eject the cassette from the drive.
Direction of play
The player will play sides 1 and 2 of the cassette alternately, automatically reversing the direction of play at the end of the side.To manually reverse the direction of play of the cassette, press button C.
Selecting a cassette track (blank search) Press button Mto select the next track.
Press button Lto return to the start of the current track or to select the previous track.
Fast forward and rewindFully press button Mor Lto fast forward or rewind the tape. At the end of the fast forward/rewind, the current side is played.
Noise reduction (Dolby B NR system) Press button Cfor more than 2 seconds to switch the function on or off.
Dolby noise reduction is manufactured under licence by Dolby Laboratories Licensing Corporation. 'Dolby' and the double D symbol are brand marks of Dolby Laboratories Licensing Corporation.
Recommendations concerning the use of cassettesÐ Use good quality cassettes.
Ð Avoid the use of cassettes which play for more than 90 minutes.Ð Never expose cassettes to heat or sunlight.
Ð Re-tension the tape if necessary before inserting the cassette into the player.Ð Regularly clean the playing heads with a damp-type cleaning cassette.
