TROUBLE DIAGNOSIS
AT-51
D
E
F
G
H
I
J
K
L
MA
B
AT

5. CHECK LOCK-UP (D4 TO D4 L/U)
Check lock-up (D
4 to D4 L/U).
Specified speed when lock-up occurs (Throttle position: half throttle). Refer to AT- 5 4 , "
Vehicle Speed at When
Lock-up Occurs/Releases" .
Read vehicle speed, throttle opening when lock-up duty becomes 94%. Refer to AT- 7 0 , "
DATA
MONITOR MODE" .
Does A/T perform lock-up at specified speed?
YES >> GO TO 6.
NO >>

Mark the box AT- 1 9 1 , "A/T Does Not Perform Lock-up" on the AT- 3 8 , "DIAGNOSTIC WORK-
SHEET" .

Continue “Road Test”.
6. CHECK LOCK-UP HOLD
Check lock-up hold.
When lock-up duty becomes 94%. Refer to AT- 7 0 , "
DATA MONITOR MODE" .
Does A/T hold lock-up condition for more than 30 seconds?
YES >> GO TO 7.
NO >>

Mark the box AT- 1 9 3 , "A/T Does Not Hold Lock-up Condition" on the AT- 3 8 , "DIAGNOSTIC
WORKSHEET" .

Continue “Road Test”.
7. CHECK SHIFT-DOWN (D4 L/U TO D4 )
Release accelerator pedal.
When lock-up duty becomes 4%. Refer to AT- 7 0 , "
DATA MONITOR MODE" .
Is lock-up released when accelerator pedal is released?
YES >> GO TO 8.
NO >>

Mark the box AT- 1 9 5 , "Lock-up Is Not Released" on the AT- 3 8 , "DIAGNOSTIC WORKSHEET"
.

Continue “Road Test”.
8. CHECK SHIFT-DOWN (D4 TO D3 )
Decelerate vehicle by applying foot brake lightly.
Read gear position and engine speed. Refer to AT- 7 0 , "
DATA MONITOR MODE" .
Does engine speed return to idle smoothly when A/T is shifted from D
4 to D3 ?
YES >> 1. Stop vehicle.
2. Go to AT- 5 1 , "
Cruise Test — Part 2" .
NO >>

Mark the box AT- 1 9 5 , "Engine Speed Does Not Return To Idle (Light Braking D4 → D3 )" on the
AT- 3 8 , "
DIAGNOSTIC WORKSHEET" .

Continue “Road Test”.
Cruise Test — Part 2BCS00107
1. CHECK STARTING GEAR (D1 ) POSITION
1. Move selector lever to “D” position.
2. Accelerate vehicle by half throttle again.
Read gear position. Refer to AT- 7 0 , "
DATA MONITOR MODE" .
Does vehicle start from D
1 ?
YES >> GO TO 2.
NO >>

Mark the box AT- 1 8 2 , "Vehicle Cannot Be Started From D1" on the AT- 3 8 , "DIAGNOSTIC
WORKSHEET" .

Continue “Road Test”.

AT-52
TROUBLE DIAGNOSIS

2. CHECK SHIFT-UP AND SHIFT-DOWN (D3 TO D4 TO D2 )
1. Accelerate vehicle to 80 km/h (50 MPH).
2. Release accelerator pedal and then quickly depress it fully.
Read gear position and throttle opening. Refer to AT- 7 0 , "
DATA MONITOR MODE" .
Does A/T shift from D
4 to D2 as soon as accelerator pedal is depressed fully?
YES >> GO TO 3.
NO >>

Mark the box AT- 1 8 4 , "A/T Does Not Shift: D1 → D2 or Does Not Kickdown: D4 → D2" on the
AT- 3 8 , "
DIAGNOSTIC WORKSHEET" .

Continue “Road Test”.
3. CHECK SHIFT-UP (D2 TO D3 )
Check shift-up (D
2 to D3 )
Specified speed when shifting from D
2 to D3 (Throttle position: full throttle). Refer to AT- 5 4 , "Vehicle Speed
Which Gear Shifting Occurs" .
Read gear position, throttle opening and vehicle speed. Refer to AT- 7 0 , "
DATA MONITOR MODE" .
Does A/T shift from D
2 to D3 at the specified speed?
YES >> GO TO 4.
NO >>

Mark the box AT- 1 8 6 , "A/T Does Not Shift: D2 → D3" on the AT- 3 8 , "DIAGNOSTIC WORK-
SHEET" .

Continue “Road Test”.
4. CHECK SHIFT-UP (D3 TO D4 ) AND ENGINE BRAKE
Release accelerator pedal after shifting from D
2 to D3 .
Read gear position, throttle opening and vehicle speed. Refer to AT- 7 0 , "
DATA MONITOR MODE" .
Does A/T shift from D
3 to D4 and does vehicle decelerate by engine brake?
YES >> 1. Stop vehicle.
2. Go to AT- 5 2 , "
Cruise Test — Part 3" .
NO >>

Mark the box AT- 1 8 8 , "A/T Does Not Shift: D3 → D4" on the AT- 3 8 , "DIAGNOSTIC WORK-
SHEET" .

Continue “Road Test”.
Cruise Test — Part 3BCS00108
1. CHECK SHIFT-DOWN (D4 TO 33 )
1. More selector lever to “D” position.
2. Accelerate vehicle using half-throttle to D
4 .
3. Release accelerator pedal.
4. Move gear selector lever from “D” position to “3” position while driving in D
4 .
Read gear position. Refer to AT- 7 0 , "
DATA MONITOR MODE" .
Does A/T shift from D
4 to 33 ?
YES >> GO TO 2.
NO >>

Mark the box AT- 1 9 7 , "A/T Does Not Shift: D4 → 33 , When A/T Selector Lever “D” → “3”" on
the AT- 3 8 , "
DIAGNOSTIC WORKSHEET" .

Continue “Road Test”.

TROUBLE DIAGNOSIS
AT-53
D
E
F
G
H
I
J
K
L
MA
B
AT

2. CHECK ENGINE BRAKE
Check engine brake.
Does vehicle decelerate by engine brake?
YES >> GO TO 3.
NO >>

Mark the box AT- 2 0 3 , "Vehicle Does Not Decelerate By Engine Brake (D4 → 33 )" on the AT-
38, "DIAGNOSTIC WORKSHEET" .

Go to AT- 2 0 3 , "Vehicle Does Not Decelerate By Engine Brake (D4 → 33 )" .

Continue “Road Test”.
3. CHECK SHIFT-DOWN (33 TO 22 )
Move selector lever from “3” to “2” position while driving in 3
3 .
Read gear position. Refer to AT- 7 0 , "
DATA MONITOR MODE" .
Does A/T shift from 3
3 to 22 ?
YES >> GO TO 4.
NO >>

Mark the box AT- 1 9 8 , "A/T Does Not Shift: 33 → 22 , When Selector Lever “3” → “2” Position"
on the AT- 3 8 , "DIAGNOSTIC WORKSHEET" .

Continue “Road Test”.
4. CHECK ENGINE BRAKE
Check engine brake.
Does vehicle decelerate by engine brake?
YES >> GO TO 5.
NO >>

Mark the box AT- 2 0 5 , "Vehicle Does Not Decelerate By Engine Brake (33 → 22 )" on the AT- 3 8 ,
"DIAGNOSTIC WORKSHEET" .

Continue “Road Test”.
5. CHECK SHIFT-DOWN (22 TO 11 )
Move selector lever from “2” to “1” position while driving in 2
2 .
Read gear position. Refer to AT- 7 0 , "
DATA MONITOR MODE" .
Does A/T shift from 2
2 to 11 position?
YES >> GO TO 6.
NO >>

Mark the box AT- 2 0 0 , "A/T Does Not Shift: 22 → 11 , When Selector Lever “2” → “1” Position"
on the AT- 3 8 , "DIAGNOSTIC WORKSHEET" .

Continue “Road Test”.
6. CHECK ENGINE BRAKE
Check engine brake.
Does vehicle decelerate by engine brake?
YES >> 1. Stop vehicle.
2. Perform self-diagnosis. Refer to AT- 6 9 , "
SELF-DIAGNOSTIC RESULT MODE" , AT- 7 6 , "Diag-
nostic Procedure Without CONSULT-II" .
NO >>

Mark the box AT- 2 0 8 , "Vehicle Does Not Decelerate By Engine Brake (22 → 11 )" on the AT- 3 8 ,
"DIAGNOSTIC WORKSHEET" .

Continue “Road Test”.

TROUBLE DIAGNOSIS
AT-67
D
E
F
G
H
I
J
K
L
MA
B
AT

CONSULT-II Function (A/T) BCS0010D
CONSULT-II can display each diagnostic item using the diagnostic test models shown following.
FUNCTION
NOTICE:
1. The CONSULT-II electrically displays shift timing and lock-up timing (that is, operation timing of each sole-
noid).
Check for time difference between actual shift timing and the CONSULT-II display. If the difference is
noticeable, mechanical parts (except solenoids, sensors, etc.) may be malfunctioning. Check mechanical
parts using applicable diagnostic procedures.
2. Shift schedule (which implies gear position) displayed on CONSULT-II and that indicated in Service Man-
ual may differ slightly. This occurs because of the following reasons:
–Actual shift schedule has more or less tolerance or allowance,
–Shift schedule indicated in Service Manual refers to the point where shifts start, and
–Gear position displayed on CONSULT-II indicates the point where shifts are completed.
3. Shift solenoid valve “A” or “B” is displayed on CONSULT-II at the start of shifting. Gear position is dis-
played upon completion of shifting (which is computed by TCM).
CONSULT-II REFERENCE VALUE
Diagnostic test mode Function Reference page
Work supportThis mode enables a technician to adjust some devices faster and more accurately by
following the indications on CONSULT-II.—
Self-diagnostic results Self-diagnostic results can be read and erased quickly.AT- 6 9
Data monitor Input/Output data in the ECM can be read.AT- 7 0
CAN diagnostic support
monitorThe results of transmit/receive diagnosis of CAN communication can be read.AT- 7 2
Function testPerformed by CONSULT-II instead of a technician to determine whether each system
is “OK” or “NG”.—
DTC work support Select the operating condition to confirm Diagnosis Trouble Codes.AT- 7 2
TCM part number TCM part number can be read. —
Item name Condition Display value (Approx.)
VHCL/S SE-A/T
During drivingApproximately matches the speedometer
reading.
VHCL/S SE-MTR
THROTTLE POSIReleased accelerator pedal. 0.0/8
Fully depressed accelerator pedal. 8.0/8
FLUID TEMP SE When ATF temperature is 20°C (68°F). 1.5 V
When ATF temperature is 80°C (176°F). 0.5 V
BATTERY VOLT When turning ignition switch to ON. Battery voltage
ENGINE SPEED Engine runningApproximately matches the tachometer
reading.
TURBINE REV During driving (lock-up ON) Approximately matches the engine speed.
OVERDRIVE SWWhen setting selector lever to “3” and “2” posi-
tions.ON
When setting selector lever to other positions. OFF
PN POSI SWWhen setting selector lever to “N” or “P” posi-
tion.ON
When setting selector lever to other positions. OFF
R POSITION SWWhen setting selector lever to “R” position. ON
When setting selector lever to other positions. OFF

TROUBLE DIAGNOSIS
AT-69
D
E
F
G
H
I
J
K
L
MA
B
AT

CONSULT-II SETTING PROCEDURE
Refer to GI-34, "CONSULT-II Start Procedure" .
SELF-DIAGNOSTIC RESULT MODE
After performing AT- 7 6 , "Diagnostic Procedure Without CONSULT-II" , place check marks for results on the
AT- 3 8 , "
DIAGNOSTIC WORKSHEET" . Reference pages are provided following the items.
Operation Procedure
1. Touch “SELF-DIAG RESULTS” on “SELECT DIAG MODE”
screen.
Display shows malfunction experienced since the last erasing
operation.
Display Items List
BCIA0031E
Items (CONSULT-II screen terms) Malfunction is detected when... Reference page
CAN COMM CIRCUIT

When TCM is not transmitting or receiving CAN communication signal
for 2 second or more.AT- 1 3 3
VHCL SPEED SEN-A/T
TCM does not receive the proper voltage signal from the sensor.AT- 8 0
VHCL SPEED SEN-MTR
TCM does not receive the proper voltage signal from the sensor.AT- 8 6
TURBINE SENSOR
TCM does not receive proper voltage signal from sensorAT- 1 2 0
SHIFT SOLENOID/V A
TCM detects an improper voltage drop when it tries to operate the sole-
noid valve.AT- 9 0
SHIFT SOLENOID/V B
TCM detects an improper voltage drop when it tries to operate the sole-
noid valve.AT- 9 5
OVERRUN CLUTCH S/V
TCM detects an improper voltage drop when it tries to operate the sole-
noid valve.AT- 1 0 0
T/C CLUTCH SOL/V
TCM detects an improper voltage drop when it tries to operate the sole-
noid valve.AT- 1 0 5
BATT/FLUID TEMP SEN
TCM receives an excessively low or high voltage from the sensor.AT- 11 0
ENGINE SPEED SIG
TCM does not receive the proper voltage signal from the ECM.AT- 11 6
A/T 1ST GR FNCTN
A/T cannot be shifted to the 1st gear position even if electrical circuit is
good.AT- 1 3 6
A/T 2ND GR FNCTN
A/T cannot be shifted to the 2nd gear position even if electrical circuit is
good.AT- 1 4 0
A/T 3RD GR FNCTN
A/T cannot be shifted to the 3rd gear position even if electrical circuit is
good.AT- 1 4 3
A/T 4TH GR FNCTN
A/T cannot be shifted to the 4th gear position even if electrical circuit is
good.AT- 1 4 6
A/T TCC S/V FNCTN
A/T cannot perform lock-up even if electrical circuit is good.AT- 1 5 1
LINE PRESSURE S/V
TCM detects an improper voltage drop when it tries to operate the sole-
noid valve.AT- 1 2 6
CONTROL UNIT (RAM)
TCM memory (RAM) is malfunctioningAT- 1 5 6
CONTROL UNIT (ROM)
TCM memory (ROM) is malfunctioningAT- 1 5 7
No failure
(NO SELF DIAGNOSTIC FAILURE
INDICATED FURTHER TESTING
MAY BE REQUIRED)

No failure has been detected. —

TROUBLE DIAGNOSIS
AT-71
D
E
F
G
H
I
J
K
L
MA
B
AT

OVERDRIVE SW (ON/OFF) X —3rd position switch (Signal input with
CAN communication.)
PN POSI SW (ON/OFF) X —
R POSITION SW (ON/OFF) X —
D POSITION SW (ON/OFF) X —
2 POSITION SW (ON/OFF) X —
1 POSITION SW (ON/OFF) X —
ASCD-CRUISE (ON/OFF) X —
Signal input with CAN communication.
ASCD-OD CUT (ON/OFF) X —
KICKDOWN SW (ON/OFF) X —
Not mounted but displayed.
POWERSHIFT SW (ON/OFF) X —
CLOSED THL/SW (ON/OFF) X —
Signal input with CAN communication.
W/O THRL/P-SW (ON/OFF) X —
*SHIFT S/V A (ON/OFF) — —
Displays status of check signal (reinput
signal) for TCM control signal output.
Remains unchanged when solenoid
valves are open or shorted. *SHIFT S/V B (ON/OFF) — —
*OVERRUN/C S/V (ON/OFF) — —
HOLD SW (ON/OFF) X — Not mounted but displayed.
BRAKE SW (ON/OFF) X —Stop lamp switch (Signal input with CAN
communication.)
GEAR — XGear position recognized by the TCM
updated after gear-shifting
SLCT LVR POSI — XSelector lever position is recognized by
the TCM.
For fail-safe operation, the specific value
used for control is displayed.
VEHICLE SPEED (km/h) — X Vehicle speed recognized by the TCM.
THROTTLE POSI (0.0/8) — XDegree of opening for accelerator recog-
nized by the TCM
For fail-safe operation, the specific value
used for control is displayed.
LINE PRES DTY (%) — X
TCC S/V DUTY (%) — X
SHIFT S/V A (ON/OFF) — X
SHIFT S/V B (ON/OFF) — X
OVERRUN/C S/V (ON/OFF) — X
SELF-D DP LMP (ON/OFF) — X
TC SLIP RATIO (0.000) — —
TC SLIP SPEED (rpm) — —Difference between engine speed and
torque converter input shaft speed
Voltage (V) — —Displays the value measured by the volt-
age probe. Monitor item (Unit)SELECT MONITOR ITEM
Remarks
TCM INPUT
SIGNALSMAIN SIG-
NALSSELEC-
TION FROM
MENU

AT-76
TROUBLE DIAGNOSIS

Diagnostic Procedure Without CONSULT-IIBCS0010E
TCM SELF-DIAGNOSTIC PROCEDURE (WITHOUT CONSULT-II)
Description
If a malfunction occurs in electrical system, check the self-diagnostic result after confirming A/T CHECK indi-
cator lamp works. To detect a malfunction, entering a self-diagnosis start signal retrieves information on mal-
functions from memory and indicates malfunction by blinking A/T CHECK indicator lamp.
Diagnostic Procedure
1. CHECK A/T CHECK INDICATOR LAMP
1. Park vehicle on flat surface.
2. Move selector lever to “P” position.
Start engine and warm it up to normal engine operating temperature.
3. Turn ignition switch OFF.
4. Wait 5 seconds.
5. Turn ignition switch ON. (Do not start engine.)
Does A/T CHECK indicator lamp come on for about 2 seconds?
YES >> GO TO 2.
NO >> Stop procedure. Perform AT- 1 7 3 , "
A/T CHECK Indicator Lamp Does Not Come On" before pro-
ceeding.
2. JUDGEMENT PROCEDURE STEP 1
1. Turn ignition switch OFF.
2. Push and hold shift lock release button.
3. Depress the brake pedal, then move gear selector lever from “P” to “3” position.
4. Turn ignition switch ON. (Do not start engine.)
5. Wait 3seconds.
6. Move selector lever to “2” position.
7. Release brake pedal.
8. Move selector lever to “1” position.
9. Depress brake pedal.
10. Depress accelerator.
11. The A/T CHECK indicator lamp will begin to flash.
>> GO TO 3.
3. CHECK SELF-DIAGNOSTIC CODE
Check A/T CHECK indicator lamp. Refer to AT- 7 7 , "
Judgement of Self-Diagnosis Code" .
>>DIAGNOSIS END

AT-78
TROUBLE DIAGNOSIS

7th judgement flicker is longer than others.
Torque converter clutch solenoid valve circuit is short-circuited or
disconnected.

Go to AT- 1 0 5 , "
TORQUE CONVERTER CLUTCH SOLENOID
VA LV E" .8th judgement flicker is longer than others.
A/T fluid temperature sensor is disconnected or TCM power
source circuit is damaged.

Go to AT-110, "
BATT/FLUID TEMP SEN (A/T FLUID TEMP
SENSOR CIRCUIT AND TCM POWER SOURCE)" .
9th judgement flicker is longer than others.
Engine speed signal circuit is short-circuited or disconnected.

Go to AT- 11 6 , "
ENGINE SPEED SIGNAL" .10th judgement flicker is longer than others.
Turbine revolution sensor (power train revolution sensor) circuit is
short-circuited or disconnected.

Go to AT-120, "
TURBINE REVOLUTION SENSOR" . A/T CHECK indicator lamp:
SCIA3237ESCIA3238E
SCIA3239ESCIA3240E
