IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)

INSPECTION IN AUTO ACTIVE TEST MODE
When auto active test mode is actuated, the following eight steps are repeated three times.
NOTE:
A dotted line shows a position of HIGH beam of Halogen headlamp.
NOTE:
When high beam headlamp of xenon type operates, the headlamp perform the HIGH-LOW changeover operation without illuminating
the headlamp bulb.
SKIB8863E
Operation
orderTest item Operation time / frequency
1 Rear window defogger 10 seconds
2 Front wiper LO 5 seconds
HI 5 seconds
3 Parking, license plate and tail lamps 10 seconds
4 Front fog lamp 10 seconds
5 Headlamp (LO) 10 seconds
6
Headlamp (HI)
NOTEON 2 seconds ⇔ OFF 2 seconds (5 times)
7 A/C compressor (magnet clutch) ON 2 seconds ⇔ OFF 2 seconds (5 times)
8 Cooling fanLO 2 seconds
MID 2 seconds
HI 2 seconds
MID 2 seconds

LO 2 seconds
A Oil pressure warning lamp Oil pressure warning lamp is blinking when the auto active test operating.

IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
PG-23
C
D
E
F
G
H
I
J
L
MA
B
PG

Concept of Auto Active Test

IPDM E/R actuates auto active test mode when it receives door switch signal from BCM via CAN commu-
nication line. Therefore, when auto active test mode is activated successfully, CAN communication
between IPDM E/R and BCM is normal.

If any of systems controlled by IPDM E/R cannot be operated, possible cause can be easily diagnosed
using auto active test.
Diagnosis chart in auto active test mode
Symptom Inspection contents Possible cause
Any of front wiper, park-
ing, license plate and
tail lamps, front fog
lamp, and headlamp
(HI, LO) do not operate.Perform auto active
test. Does system in
question operate?YES

BCM signal input system malfunction
NO

Lamp/wiper motor malfunction

Lamp/wiper motor ground circuit malfunction

Harness/connector malfunction between IPDM E/R and system in ques-
tion

IPDM E/R (integrated relay) malfunction
Rear window defogger
does not operate.Perform auto active
test. Does rear win-
dow defogger oper-
ate?YES

BCM signal input circuit malfunction
NO

Rear window defogger relay malfunction

Harness/connector malfunction between IPDM E/R and rear window
defogger relay

Open circuit of rear window defogger

IPDM E/R malfunction
A/C compressor does
not operate.Perform auto active
test. Does magnetic
clutch operate?YES

BCM signal input circuit malfunction

CAN communication signal between BCM and ECM.

CAN communication signal between ECM and IPDM E/R
NO

Magnetic clutch malfunction

Harness/connector malfunction between IPDM E/R and magnetic clutch

IPDM E/R (integrated relay) malfunction
Cooling fan does not
operate.Perform auto active
test. Does cooling fan
operate?YES

ECM signal input circuit

CAN communication signal between ECM and IPDM E/R
NO

Cooling fan motor malfunction

Harness/connector malfunction between IPDM E/R and cooling fan
motor

IPDM E/R (integrated relay) malfunction
Oil pressure warning
lamp does not operate.Perform auto active
test. Does oil pres-
sure warning lamp
blink?YES

Harness/connector malfunction between IPDM E/R and oil pressure
switch

Oil pressure switch malfunction

IPDM E/R malfunction
NO

CAN communication signal between BCM and Unified Meter and A/C
Amp.

Combination meter

PG-64
HARNESS

FRO2B1 EC Heated Oxygen Sensor 1 Heater Bank 1
FRO2B2 EC Heated Oxygen Sensor 1 Heater Bank 2
FTS CVT CVT Fluid Temperature Sensor Circuit
H/AIM LT Headlamp Aiming Control System
H/LAMP LT Headlamp
HLC WW Headlamp Washer
HORN WW Horn
HO2S1 EC Heated Oxygen Sensor 1
HSEAT SE Heated Seat
I/KEY BL Intelligent Key System
IATSEN EC Intake Air Temperature Sensor
IGNSYS EC Ignition System
ILL LT Illumination
INF/D AV Vehicle Information and Integrated Switch System
INJECT EC Injector
INT/L LT Vanity Mirror Lamp
IVC EC Intake Valve Timing Control Solenoid Valve
IVCB1 EC Intake Valve Timing Control Solenoid Valve Bank 1
IVCB2 EC Intake Valve Timing Control Solenoid Valve Bank 2
KEYLES BL Remote Keyless Entry System
KS EC Knock Sensor
L/USSV CVT Lock-Up Select Solenoid Valve
LPSV AT Line Pressure Solenoid Valve
LPSV CVT Line Pressure Solenoid Valve
M/SEAT SE Air Massage Seat
MAFS EC Mass Air Flow Sensor
MAIN AT Main Power Supply and Ground Circuit
MAIN EC Main Power Supply and Ground Circuit
METER DI Speedometer, Tachometer, Temp. and Fuel Gauges
MIL/DL EC MIL & Data Link Connector
MIRROR GW Power Door Mirror
MMSW CVT Manual Mode Switch
NATS BL Nissan Anti-Theft System
NONDTC AT Non-Detective Items
NONDTC CVT Non-Detective Items
O2S1B1 EC Heated Oxygen Sensor 1 Bank 1
O2S1B2 EC Heated Oxygen Sensor 1 Bank 2
OVRCSV AT Overrun Clutch Solenoid Valve
PHASE EC Camshaft Position Sensor (PHASE)
PHSB1 EC Camshaft Position Sensor (PHASE) (Bank1)
PHSB2 EC Camshaft Position Sensor (PHASE) (Bank2)
PNP/SW CVT Park/Neutral Position Switch
PNP/SW EC Park/Neutral Position Switch
POS EC Crankshaft Position Sensor (CKPS) (POS) Code Section Wiring Diagram Name
