TROUBLE DIAGNOSIS
LAN-81
[CAN]
C
D
E
F
G
H
I
J
L
MA
B
LAN

2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of ABS actuator and electric unit (control unit).
2. Check the resistance between the ABS actuator and electric unit (control unit) harness connector termi-
nals.
Models with ABS
Models with VDC
OK or NG
OK >> GO TO 3.
NG >> Repair the ABS actuator and electric unit (control unit) branch line.
3. CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the ABS actuator and electric unit (control unit). Refer to
BRC-12, "
Schematic" (Models with ABS), BRC-48, "Schematic" (Models with VDC).
OK or NG
OK >>
Present error: Replace the ABS actuator and electric unit (control unit). Refer to BRC-35,
"Removal and Installation" (Models with ABS), BRC-88, "Removal and Installation" (Models
with VDC).

Past error: Error was detected in the ABS actuator and electric unit (control unit) branch line.
NG >> Repair the power supply and the ground circuit.
IPDM E/R Branch Line CircuitBKS002EI
INSPECTION PROCEDURE
1. CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the following terminals and connectors for damage, bend and loose connection (unit side and con-
nector side).
–IPDM E/R
–Harness connector E253
–Harness connector E11
OK or NG
OK >> GO TO 2.
NG >> Repair the terminal and connector.
ABS actuator and electric unit (control unit) harness connector
Resistance (Ω)
Connector No. Terminal No.
E240 22 9 Approx. 54 – 66
ABS actuator and electric unit (control unit) harness connector
Resistance (Ω)
Connector No. Terminal No.
E241 7 9 Approx. 54 – 66

LAN-82
[CAN]
TROUBLE DIAGNOSIS

2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of IPDM E/R.
2. Check the resistance between the IPDM E/R harness connector terminals.
OK or NG
OK >> GO TO 3.
NG >> Repair the IPDM E/R branch line.
3. CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the IPDM E/R. Refer to PG-24, "
Schematic" .
OK or NG
OK >>
Present error: Replace the IPDM E/R. Refer to PG-28, "Removal and Installation of IPDM E/R"
.

Past error: Error was detected in the IPDM E/R branch line.
NG >> Repair the power supply and the ground circuit.
CAN Communication CircuitBKS002EJ
INSPECTION PROCEDURE
1. CONNECTOR INSPECTION
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Disconnect all the unit connectors on CAN communication system.
4. Check terminals and connectors for damage, bend and loose connection.
OK or NG
OK >> GO TO 2.
NG >> Repair the terminal and connector.
2. CHECK HARNESS CONTINUITY (SHORT CIRCUIT)
Check the continuity between the data link connector terminals.
OK or NG
OK >> GO TO 3.
NG >> Check the harness and repair the root cause.
3. CHECK HARNESS CONTINUITY (SHORT CIRCUIT)
Check the continuity between the data link connector and the ground.
OK or NG
OK >> GO TO 4.
NG >> Check the harness and repair the root cause.
IPDM E/R harness connector
Resistance (Ω)
Connector No. Terminal No.
E9 48 49 Approx. 108 – 132
Data link connector
Continuity
Connector No. Terminal No.
M32 6 14 No
Data link connector
GroundContinuity
Connector No. Terminal No.
M326No
14 No

TROUBLE DIAGNOSIS
LAN-83
[CAN]
C
D
E
F
G
H
I
J
L
MA
B
LAN

4. CHECK ECM AND IPDM E/R TERMINATION CIRCUIT
1. Remove the ECM and the IPDM E/R.
2. Check the resistance between the ECM terminals.
3. Check the resistance between the IPDM E/R terminals.
OK or NG
OK >> GO TO 5.
NG >> Replace the ECM or the IPDM E/R.
5. CHECK SYMPTOM
Connect all the connectors. Check if the symptoms described in the “Symptom (Results from interview with
customer)” are reproduced.
Inspection result
Reproduced>>GO TO 6.
Non-reproduced>>Start the diagnosis again. Follow the trouble diagnosis procedure when past error is
detected.
6. CHECK UNIT REPRODUCTION
Perform the reproduction test as per the following procedure for each unit.
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Disconnect one of the unit connectors of CAN communication system.
NOTE:
ECM and IPDM E/R have a termination circuit. Check other units first.
4. Connect the battery cable to the negative terminal. Check if the symptoms described in the “Symptom
(Results of interview with customer)” are reproduced.
NOTE:
Although unit-related error symptoms occur, do not confuse them with other symptoms.
Inspection result
Reproduced>>Connect the connector. Check other units as per the above procedure.
Non-reproduced>>Replace unit whose connector was disconnected.
ECM
Resistance (Ω)
Terminal No.
94 86 Approx. 108 – 132
IPDM E/R
Resistance (Ω)
Terminal No.
48 49 Approx. 108 – 132
LKIA0037E
