2003 LEXUS LS430 Identifying condition

TESTER CONNECTION STANDARD SPECIFIED CONDITION STANDARD (FRONT RH)
Fig. 34: Identifying Suspension Control ECU A20 Or A22 Connector Terminals

Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
TESTER CONNECTION STANDARD SPECIFIED CONDITION STANDARD (FRONT LH)
Tester ConnectionSpecified Condition
A20-20 (SBR1) - H14-1 (SHB)Below 1 ohms
A20-21 (SGR1) - H14-4 (SHG)Below 1 ohms
A20-20 (SBR1) - Body ground10 Kohms or higher
A20-21 (SGR1) - Body ground10 Kohms or higher
Tester ConnectionSpecified Condition
A20-18 (SBL1) - H13-1 (SHB)Below 1 ohms
A20-22 (SGL1) - H13-4 (SHG)Below 1 ohms
A20-18 (SBL1) - Body ground10 Kohms or higher
A20-22 (SGL1) - Body ground10 Kohms or higher

Fig. 35: Identifying Front Height Control Sensor Sub-Assy Connector Terminals
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
TESTER CONNECTION STANDARD SPECIFIED CONDITION STANDARD (REAR RH)
Tester ConnectionSpecified Condition
A22-25 (SGR2) - H31-3 (SHG)Below 1 ohms
A22-26 (SBR2) - H31-1 (SHB)Below 1 ohms
A22-25 (SGR2) - Body ground10 Kohms or higher
A22-26 (SBR2) - Body ground10 Kohms or higher

Fig. 36: Identifying Height Control Sensor Sub-Assy Rear RH Connector Terminals
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
TESTER CONNECTION STANDARD SPECIFIED CONDITION STANDARD (REAR LH)
NG: REPAIR OR REPLACE HARNESS OR CONNECTOR
Tester ConnectionSpecified Condition
A22-23 (SGL2) - H30-1 (SHG)Below 1 ohms
A22-24 (SBL2) - H30-3 (SHB)Below 1 ohms
A22-23 (SGL2) - Body ground10 Kohms or higher
A22-24 (SBL2) - Body ground10 Kohms or higher

Fig. 38: Identifying Suspension Control ECU A21 Or A22 Connector Terminals
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
HEIGHT CONTROL SENSOR FRONT RH: (C1711)
TESTER CONNECTION STANDARD SPECIFIED CONDITION
Tester ConnectionSpecified Condition
A21-20 (SHFR) - H14-2 (SHFR)Below 1 ohms
A21-20 (SHFR) - Body ground10 Kohms or higher

Fig. 39: Identifying Height Control Sensor Front RH Connector Terminals
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
HEIGHT CONTROL SENSOR FRONT LH: (C1712)
TESTER CONNECTION STANDARD SPECIFIED CONDITION
Tester ConnectionSpecified Condition
A21-22 (SHFL) - H13-2 (SHFL)Below 1 ohms
A21-22 (SHFL) - Body ground10 Kohms or higher

Fig. 40: Identifying Height Control Sensor Front LH Connector Terminals
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
HEIGHT CONTROL SENSOR REAR RH: (C1713)
TESTER CONNECTION STANDARD SPECIFIED CONDITION
Tester ConnectionSpecified Condition
A22-28 (SHRR) - H31-2 (SHRR)Below 1 ohms
A22-28 (SHRR) - Body ground10 Kohms or higher

Fig. 41: Identifying Height Control Sensor Rear RH Connector Terminals
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
HEIGHT CONTROL SENSOR REAR LH: (C1714)
TESTER CONNECTION STANDARD SPECIFIED CONDITION
NG: REPAIR OR REPLACE HARNESS OR CONNECTOR
Tester ConnectionSpecified Condition
A22-30 (SHRL) - H30-2 (SHRL)Below 1 ohms
A22-30 (SHRL) - Body ground10 Kohms or higher

Fig. 42: Identifying Height Control Sensor Rear LH Connector Terminals
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
OK:Go to next step
6.CHECK HEIGHT CONTROL SENSOR SUB-ASSY
HEIGHT CONTROL SENSOR FRONT RH: (C1711)
a. Measure the resistance according to the value (s) in the table below.
TESTER CONNECTION STANDARD SPECIFIED CONDITION
RESULT DESCRIPTION
Tester ConnectionSpecified Condition
1 (SHB) - 4 (SHG)3.0 to 5.6 Kohms
1 (SHB) - 2 (SHFR)0.4 to 3.9 Kohms
