SF067-05
B09118

Gasket
Throttle Body
Water Bypass
HoseAir Assist
Hose
N´m (kgf´cm, ft´lbf)

Non-reusable part: Specified torque
29 (300, 22)
Air Cleaner Hose
w/ Resonator Vacuum Hose
Accelerator Cable
IAC Valve
GasketThrottle BodyThrottle Body
Bracket
Throttle
Position
Sensor
Connector
IAC Valve
Connector V-Bank Cover
Vacuum Hose
19.5 (200, 14)
Brake Booster
Vacuum Hose
Fuel Vapor
Feed Hose
Throttle Cable
SF-44
- SFIIDLE AIR CONTROL (IAC) VALVE
1153 Author
: Date
:
2001 AVALON (RM808U)
COMPONENTS

SF073-04
B09080
PS Pressure Tube
19.5 (200, 14)39 (400, 19)
Throttle Position
Sensor Connector
Accelerator Cable
IAC Valve Connector
Water Bypass
Hose
Vacuum Hose

Gasket PCV Hose
Air Intake Chamber
Assembly
43 (440, 32)
Throttle Body Bracket
No.1 Engine
Hanger
Ground Cable
Ground Cable
Ground Strap
VSV Connector for No.2 ACIS Purge Hose
Air Assist Hose and Pipe
19.5 (200, 14)

Retainer
Injector Connector Delivery Pipe10 (100, 7)
Spacer

O-Ring

Grommet
Injector

Insulator

O-RingV-Bank Cover
Brake Booster
Vacuum HoseVSV Connector
for No.1 ACIS
VSV Connector
for EVAP
DLC1
Fuel Hose Clamp
Fuel Inlet Hose
N´m (kgf´cm, ft´lbf): Specified

Non-reusable partAir Cleaner Hose
w/ Resonator
Throttle Cable
SF-20
- SFIINJECTOR
1129 Author
: Date
:
2001 AVALON (RM808U)
COMPONENTS

SF06S-03
B09135
Ground Cable
PCV Hose
Air Intake Chamber
Assembly
ECT Sensor
Connector ECT Sender
Gauge Connector
IAC Valve
Connector
VSV Connector for No.2 ACIS
Engine Coolant
Reservoir HoseThrottle Position
Sensor Connector Brake Booster
Vacuum Hose Throttle Body Bracket
Water Outlet PS Pressure Tube
19.5 (200, 14)
39 (400, 19)
15 (150, 11)
43 (440, 32)
Ground Strap
DLC1
Gasket
15 (150, 11)
Grand Strap
Connector

Gasket
39 (400, 29)
V-Bank Cover
Accelerator CableAir Cleaner Hose
w/ Resonator
Purge Hose
Vacuum Hose
Fuel Hose
Clamp
Heater Hose
Intake Manifold Assembly
Injector Connector x 9
Knock Sensor
Connector
Upper Radiator
Hose

Gasket
: Specified torque

Non-reusable part
N´m (kgf´cm, ft´lbf)

Retainer
Knock Sensor
Water Bypass
Hose
VSV Connector for
EVAP
No.1 Engine
Hanger
VSV Connector
for No.1 ACIS
Throttle Cable
Ground Cable
SF-76
- SFIKNOCK SENSOR
1185 Author
: Date
:
2001 AVALON (RM808U)
KNOCK SENSOR
COMPONENTS

SF0ZS-03
B09088

Gasket
Throttle Body
Water Bypass
HoseAir Assist
Hose
29 (300, 22)
19.5 (200, 14)
Air Cleaner Hose
w/ Resonator Vacuum Hose
Accelerator CableThrottle Body
Bracket
V-Bank Cover
IAC Valve
ConnectorThrottle
Position
Sensor
Connector
: Specified torque

Non-reusable part
N´m (kgf´cm, ft´lbf)
Vacuum Hose
Brake Booster
Vacuum Hose
Fuel Vapor
Feed Hose
Throttle Cable
SF-34
- SFITHROTTLE BODY
1143 Author
: Date
:
2001 AVALON (RM808U)
COMPONENTS

SF0ZT-02
A10518
5 mm
Hexagon
Wrench
B09090
B09091(d)
(b)
(c)
(e)
B09092
(j)(g)
(h) (f)
(k) (i)
SF-36
- SFITHROTTLE BODY
1145 Author
: Date
:
2001 AVALON (RM808U)
REMOVAL
1. DRAIN ENGINE COOLANT
2. REMOVE V-BANK COVER
(a) Using a 5 mm hexagon wrench, remove the 3 cap nuts.
(b) Loosen the V-bank cover fastener counterclockwise.
HINT:
At the time of installation, please refer to the following items.
Press down the V-bank cover fastener.
(c) Remove the V-bank cover.
3. REMOVE AIR CLEANER HOSE WITH RESONATOR
(a) Disconnect the PCV hose.
(b) Disconnect the vacuum hose (from the VSV for the active
engine control mount).
(c) Loosen the 3 hose clamps, and remove the air cleaner
hose with the resonator.
4. DISCONNECT ACCELERATOR CABLE AND
THROTTLE CABLE
5. REMOVE THROTTLE BODY
(a) Remove the bolt holding the throttle body to the throttle
body bracket.
Torque: 19.5 N´m (200 kgf´cm, 14 ft´lbf)
(b) Disconnect the throttle position sensor connector.
(c) Disconnect the IAC valve connector.
(d) Disconnect the wire clamp.
(e) Disconnect the brake booster vacuum hose.
(f) Disconnect the water bypass hose (from the intake man-
ifold).
(g) Disconnect the water bypass hose (from the water inlet
housing).
(h) Disconnect the air assist hose.
(i) Disconnect the fuel vapor feed hose (from the emission
control valve set).
(j) Disconnect the vacuum hose (from the No.1 ACIS VSV).
(k) Disconnect the vacuum hose (from the vacuum tank for
the ACIS).

SA0VR-02
F04047Non-reusable part

N´m (kgf´cm, ft´lbf) : Specified torque
Shock Absorber
Drive Shaft
Hub BoltTie Rod End
ABS Speed Sensor
Brake Caliper

Cotter Pin
Lower Suspension Arm

Cotter Pin
Bearing
Snap Ring
Dust Deflector
Cotter Pin
Lock Cap
Disc
Axle Hub Lower Ball JointDust Cover Steering Knuckle
211 (2,150, 156)
107 (1,090, 79)
49 (500, 36)
8.0 (82, 71 in.´lbf)
294 (3,000, 217)
127 (1,300, 94)
123 (1,250, 90)
8.3 (85, 74 in.´lbf)
SA-8
- SUSPENSION AND AXLEFRONT AXLE HUB
1342 Author
: Date
:
2001 AVALON (RM808U)
FRONT AXLE HUB
COMPONENTS

SA0VS-02
W03084
W03093
W03139
- SUSPENSION AND AXLEFRONT AXLE HUB
SA-9
1343 Author
: Date
:
2001 AVALON (RM808U)
REMOVAL
1. REMOVE FRONT WHEEL
Torque: 103 N´m (1,050 kgf´cm, 76 ft´lbf)
2. CHECK BEARING BACKLASH AND AXLE HUB DEVI-
ATION
(a) Remove the 2 bolts, brake caliper and disc.
(b) Support the brake caliper securely.
(c) Using a dial indicator, check the backlash near the center
of the axle hub.
Maximum: 0.05 mm (0.0020 in.)
If the backlash exceeds the maximum, replace the bearing.
(d) Using a dial indicator, check the deviation at the surface
of the axle hub outside the hub bolt.
Maximum: 0.05 mm (0.0020 in.)
If the deviation exceeds the maximum, replace the axle hub.
(e) Install the disc, brake caliper and 2 bolts.
Torque: 107 N´m (1,090 kgf´cm, 79 ft´lbf)
3. REMOVE DRIVE SHAFT LOCK NUT
(a) Remove the cotter pin and lock cap.
(b) While applying the brakes, remove the nut.
Torque: 294 N´m (3,000 kgf´cm, 217 ft´lbf)
(c) Remove the 2 bolts, brake caliper and disc.
(d) Support the brake caliper securely.
4. DISCONNECT ABS SPEED SENSOR AND WIRE HAR-
NESS CLAMP
Remove the bolt and disconnect the ABS speed sensor and
wire harness clamp.
Torque: 8.0 N´m (82 kgf´cm, 71 in.´lbf)
5. LOOSEN 2 NUTS ON LOWER SIDE OF SHOCK AB-
SORBER
HINT:
Do not remove the bolts.
Torque: 211 N´m (2,150 kgf´cm, 156 ft´lbf)
HINT:
At the this time of installation, coat the nut's thread with engine
oil.

SA0VY-02
FA1535
SST
W03093
W03142
F07389
SA-16
- SUSPENSION AND AXLEFRONT DRIVE SHAFT
1350 Author
: Date
:
2001 AVALON (RM808U)
REMOVAL
NOTICE:

The hub bearing could be damaged if it is subjected
to the vehicle weight, such as when moving the ve-
hicle with the drive shaft removed.
Therefore, if it is absolutely necessary to place the ve-
hicle weight on the hub bearing, first support it with
SST.
SST 09608-16042 (09608-02021, 09608-02041)

After disconnecting the drive shaft from the axle hub,
work carefully so as not to damage the ABS speed
sensor rotor serration on the drive shaft.
1. REMOVE FRONT WHEEL
Torque: 103 N´m (1,050 kgf´cm, 76 ft´lbf)
2. REMOVE FRONT FENDER APRON SEAL
3. DRAIN ATF
4. REMOVE DRIVE SHAFT LOCK NUT
(a) Remove the cotter pin and lock cap.
(b) While applying brakes, remove the nut.
Torque: 294 N´m (3,000 kgf´cm, 217 ft´lbf)
5. DISCONNECT TIE ROD END FROM STEERING
KNUCKLE (See page SA-9)
6. DISCONNECT LOWER SUSPENSION ARM FROM
LOWER BALL JOINT (See page SA-9)
7. DISCONNECT DRIVE SHAFT FROM AXLE HUB
Using a plastic hammer, disconnect the drive shaft from the axle
hub.
NOTICE:
Be careful not to damage the boot and ABS speed sensor
rotor.
8. LH drive shaft:
REMOVE DRIVE SHAFT
(a) Using a hub nut wrench and hammer handle or an equiva-
lent, remove the drive shaft.
NOTICE:
Be careful not to damage the dust cover and oil seal.
