Page 249 of 436

3-38
Once the player stops and the disc is ejected, remove
the disc. After removing the disc, press the VOLUME
PWR knob off and then on again. This will clear the
disc
-sensing feature and enable discs to be loaded into
the player again.
REV: Press and hold this button to reverse quickly
within a track. Release it to play the passage. You will
hear sound at a reduced volume. The display will show
elapsed time.
FWD: Press and hold this button to advance quickly
within a track. Release it to play the passage. You will
hear sound at a reduced volume. The display will show
elapsed time.
RPT: With repeat, you can repeat one track or an
entire disc. To use repeat, do the following:
To repeat the track you are listening to, press and
release the RPT button. RPT will appear on the
display. Press RPT again to turn it off.
To repeat the disc you are listening to, press and
hold the RPT button for two seconds. Press RPT
again to turn if off.RDM: With random, you can listen to the tracks in
random, rather than sequential order, on all of the discs
or on one disc. To use random, do the following:
Press and release the RDM button to play the
tracks on all of the discs that are loaded, in random
order. RDM will appear in the display. Press RDM to
turn it off.
To play the tracks on the disc you are listening to
in random order, press and hold RDM for more
than two seconds. You will hear a beep and RDM
will appear on the display. Press RDM again to
turn if off.
AUTO EQ: Press AUTO EQ to select the desired
preset equalization setting while playing a compact disc.
The equalization will be automatically set whenever you
play a compact disc.
SEEK: Press the left arrow while playing a CD to go to
the start of the current track, if more than ten seconds
have played. Press the right arrow to go to the next track.
If you press the button more than once, the player will
continue moving backward or forward through the disc.
Page 250 of 436

3-39
SCAN: Press and hold either SEEK SCAN arrow for
more than two seconds until SCAN appears on the
display and you hear a beep. Use SEEK SCAN to
listen to each track for a few seconds. The sound will
mute while scanning. SCAN will appear on the display.
Press either SEEK SCAN arrow again, to stop scanning.
DISC SCAN: Press and hold either SEEK SCAN arrow
for more than four seconds until DISC SCAN appears
on the display and you hear a beep. Use DISC SCAN
to listen to the first track, for ten seconds of each disc
loaded. The sound will mute while scanning to the next
track. DISC SCAN will appear on the display. Press
either SEEK SCAN arrow again, to stop scanning.
RCL: Press this button to see how long the current track
has been playing. To change what is normally shown on
the display (track or elapsed time), press the button until
you see the display you want, then hold the button until
the display flashes.
AM FM: Press this button to play the radio when a disc
is in the player.Using Song List Mode
The integrated 6
-disc CD changer has a feature
called song list. This feature is capable of saving
20 track selections.
To save tracks into SONG LIST perform the
following steps:
1. The disc player must be on with at least one disc
loaded. See ªLOAD/EJECTº previously for
more information.
2. The disc changer must not be in song list mode.
S
-LIST should not appear in the display. If S-LIST
is present, press SONG LIST to turn it off.
3. Select the desired disc by pressing the numbered
pushbutton and then use the SEEK SCAN right
arrow button to locate the track that you want to
save. The track will begin to play.
4. Press and hold SONG LIST for two or more seconds
to save the track into memory. When SONG LIST
is pressed a beep will be heard immediately.
After two seconds of pressing SONG LIST
continuously, two beeps will sound, to confirm that
the track has been saved.
5. Repeat Steps 3 and 4 for saving other selections.
Page 251 of 436

3-40
To play the song list, press SONG LIST. One beep will
be heard and S
-LIST will appear on the display.
The recorded tracks will begin to play in the order that
they were saved.
You may seek through the song list by using the
SEEK SCAN arrows. Seeking past the last saved
track will return you to the first saved track.
To delete tracks from SONG LIST perform the
following steps:
1. The disc player must be turned on.
2. Press SONG LIST to turn song list on.
S
-LIST will appear on the display.
3. Press the SEEK SCAN arrows to select the
desired track to be deleted.
4. Press and hold the SONG LIST button for two
seconds. When pressing SONG LIST one beep will
be heard immediately. After two seconds of pressing
the SONG LIST button continuously, two beeps will
be heard, to confirm that the track has been deleted.After a track has been deleted, the remaining tracks are
moved up the list. When another track is added to the
song list, the tracks will be added to the end of the list.
To delete the entire SONG LIST perform the
following steps:
1. The disc player must be on.
2. Press SONG LIST to turn song list on.
S
-LIST will appear on the display.
3. Press and hold SONG LIST for more than four
seconds. A beep will be heard, followed by two
beeps after two seconds and a final beep will be
heard after four seconds. S
-LIST EMPTY will
appear on the display indicating that the song list
has been deleted.
If a disc is ejected, and the song list contains saved
tracks from that disc, those tracks are automatically
deleted from the song list.
To end SONG LIST mode, press the SONG LIST
button. One beep will be heard and S
-LIST will be
removed from the display.
Page 252 of 436

3-41 Rear Seat Audio (Option)
This feature allows rear seat passengers to listen to any
of the music sources including AM
-FM, automatic tone
control, cassette tapes or CDs. However, the rear seat
passengers can only control the music sources that the
front seat passengers are not listening to. For example,
rear seat passengers may listen to a cassette tape or CD
through headphones while the driver listens to the radio
through the front speakers. The rear seat passengers
have control of the volume for each set of headphones.
Be aware that the front seat audio controls always
override the rear seat audio controls.
This feature is intended for rear seat passengers.The following function is controlled by the primary
radio knob:
POWER
-VOL: Push this knob twice to turn the
rear seat audio system on or off. ON or OFF will be
displayed for five seconds. The rear speakers will be
muted when the power is turned on. You may operate
the rear seat audio functions when the primary radio
power is off if the ignition is on.
The following functions are controlled by the rear seat
audio system buttons:
PWR: Press this button to turn the rear seat audio
system on or off. The rear speakers will be muted when
the power is turned on. You may operate the rear seat
audio functions even when the primary radio power is off.
VOL: Press this knob lightly so it extends.
Turn the knob clockwise to increase volume and
counterclockwise to decrease volume. Push the knob
back into its stored position when you're not using it.
The upper VOL knob controls the upper headphone
and the lower VOL knob controls the lower headphone.
AM FM: Press this button to switch between AM,
FM1 and FM2. The display will show your frequency
selection. If the front passengers are already listening to
AM
-FM, the rear seat audio controller will not switch
between the bands and cannot change the frequency.
Page 253 of 436

3-42
SEEK: Press the up arrow to tune to the next higher
station and stay there. Press the down arrow to tune to
the next lower station and stay there. The display will
show your selection. The sound will mute while seeking.
The SEEK button is inactive if the AM FM mode on the
front radio is in use.
While listening to a cassette tape, press the up arrow to
hear the next selection on the tape. Press the down arrow
to go back to the previous selection. The SEEK button is
inactive if the tape mode on the front radio is in use.
While listening to a CD, press the up arrow to hear the
next selection on the CD. Press the down arrow to go
back to the start of the current selection (if more than
eight seconds have played). The SEEK button is inactive
if the CD mode on the front radio (if equipped) or the
CD changer is in use.
P.SET PROG: The front passengers must be listening to
something different for each of these functions to work:
Press this button to seek through your preset radio
stations set on your primary radio pushbuttons.
The display will show your selections.
When a cassette tape is playing, press this button
to go to the other side of the tape.TAPE CD: With a cassette tape in the player and the
radio playing, press this button to play a cassette tape.
Press TAPE CD to switch between the tape and compact
disc if both are loaded. Press AM FM to return to the
radio when a cassette tape or compact disc is playing.
The inactive tape or CD will remain safely inside the
radio for future listening.
Theft-Deterrent Feature
THEFTLOCK is designed to discourage theft of
your radio. The feature works automatically by learning
a portion of the Vehicle Identification Number (VIN).
If the radio is moved to a different vehicle, it will not
operate and LOCKED will be displayed.
When the radio and vehicle are turned off, the blinking
red light indicates that THEFTLOCK is armed.
With THEFTLOCK activated, your radio will not
operate if stolen.
Page 254 of 436
3-43 Audio Steering Wheel Controls
(If Equipped)
If your vehicle has this feature, you can control certain
radio functions using the buttons on your steering wheel.
SEEK: Press the up arrow to tune to a higher radio
station and the down arrow to tune to a lower radio
station. The sound will mute while seeking. When
playing a cassette tape or compact disc, press SEEK
to hear the next selection.
AM/FM: Press this button to choose AM or FM.
PRESET: Press this button to play a station you
have programmed on the radio preset buttons.
VOL: Press the up or down arrow to increase or
decrease volume.
PLAY: Press this button to play a loaded cassette tape
or compact disc when the radio is playing.
MUTE: Press this button to silence the system.
Press it again to turn on the sound. This button may
be used when listening to the radio, a cassette tape or
a compact disc.
Page 255 of 436

3-44 Understanding Radio Reception
AM
The range for most AM stations is greater than for FM,
especially at night. The longer range, however, can
cause stations to interfere with each other. AM can
pick up noise from things like storms and power lines.
Try reducing the treble to reduce this noise if you ever
get it.
FM Stereo
FM stereo will give you the best sound, but FM signals
will reach only about 10 to 40 miles (16 to 65 km).
Tall buildings or hills can interfere with FM signals,
causing the sound to come and go.
Tips About Your Audio System
Hearing damage from loud noise is almost undetectable
until it is too late. Your hearing can adapt to higher
volumes of sound. Sound that seems normal can be
loud and harmful to your hearing. Take precautions by
adjusting the volume control on your radio to a safe
sound level before your hearing adapts to it.To help avoid hearing loss or damage:
Adjust the volume control to the lowest setting.
Increase volume slowly until you hear comfortably
and clearly.
NOTICE:
Before you add any sound equipment to your
vehicle
-- like a tape player, CB radio, mobile
telephone or two
-way radio -- be sure you
can add what you want. If you can, it's very
important to do it properly. Added sound
equipment may interfere with the operation of
your vehicle's engine, Delphi Delco Electronics
radio or other systems, and even damage them.
Your vehicle's systems may interfere with the
operation of sound equipment that has been
added improperly.
So, before adding sound equipment, check with
your dealership and be sure to check Federal
rules covering mobile radio and telephone units.
Page 256 of 436

3-45 Care of Your Cassette Tape Player
A tape player that is not cleaned regularly can cause
reduced sound quality, ruined cassettes or a damaged
mechanism. Cassette tapes should be stored in their
cases away from contaminants, direct sunlight and
extreme heat. If they aren't, they may not operate
properly or may cause failure of the tape player.
Your tape player should be cleaned regularly after every
50 hours of use. Your radio may display CLN to indicate
that you have used your tape player for 50 hours without
resetting the tape clean timer. If this message appears
on the display, your cassette tape player needs to be
cleaned. It will still play tapes, but you should clean it as
soon as possible to prevent damage to your tapes and
player. If you notice a reduction in sound quality, try a
known good cassette to see if it is the tape or the tape
player at fault. If this other cassette has no improvement
in sound quality, clean the tape player.
The recommended cleaning method for your
cassette tape player is the use of a scrubbing action,
non
-abrasive cleaning cassette with pads which scrub
the tape head as the hubs of the cleaner cassette turn.
The recommended cleaning cassette is available through
your dealership (GM Part No. 12344789).When using a scrubbing action, non
-abrasive cleaning
cassette, it is normal for the cassette to eject because
your unit is equipped with a cut tape detection feature
and a cleaning cassette may appear as a broken tape.
To prevent the cleaning cassette from being ejected,
use the following steps.
1. Turn the ignition to RUN or ACCESSORY.
2. Turn the radio off.
3. Press and hold the TAPE CD button for five seconds.
READY will appear on the display for five seconds.
4. Insert the scrubbing action cleaning cassette.
5. Eject the cleaning cassette after the manufacturer's
recommended cleaning time.
When the cleaning cassette has been ejected, the cut tape
detection feature is active again.
You may also choose a non
-scrubbing action, wet-type
cleaner which uses a cassette with a fabric belt to clean
the tape head. This type of cleaning cassette will not
eject on its own. A non
-scrubbing action cleaner may
not clean as thoroughly as the scrubbing type cleaner.
The use of a non
-scrubbing action, dry-type cleaning
cassette is not recommended.
