2000 YAMAHA TDR 125 Owners Manual

6-4
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EVERY
6,000 km 12,000 km
No.
ITEM CHECKS AND MAINTENANCE JOBS
Initialor or
(1,000 km)6 months 12 months
(Whichever (Whichever
comes first) comes first)
9Check swingarm pivoting point for play.
10 * Swingarm9Correct if necessary.
ÖÖ
9Lubricate with lithium soap base grease every
24,000 km or 24 months (whichever comes first).
9Check chain slack.
11 Drive chain9
Adjust if necessary. Make sure that the rear wheel is properly aligned.Every 1,000 km and after washing
9Clean and lubricate.the motorcycle or riding in the rain
9Check bearing play and steering for roughness.
12 * Steering bearings9Correct accordingly.
ÖÖ
9Lubricate with lithium soap base grease every 24,000 km or
24 months (whichever comes first).
13 * Chassis fasteners9
Make sure that all nuts, bolts and screws are properly tightened.ÖÖ9Tighten if necessary.
14 Sidestand9Check operation.
ÖÖ
9Lubricate and repair if necessary.
15 * Sidestand switch9Check operation.
ÖÖÖ
9Replace if necessary.
16 * Front fork9Check operation and for oil leakage.
ÖÖ
9Correct accordingly.
17 *Rear shock absorber9Check operation and shock absorber for oil leakage.
ÖÖ
assembly9Replace shock absorber assembly if necessary.
Rear shock absorber9Check operation.
18 * assembly pivoting9Lubricate with lithium grease every 24,000 km ÖÖ
pointsor 24 months (whichever comes first).
19 * Carburetor9Check engine idling speed and starter operation.
ÖÖÖ
9Adjust if necessary.
5AE-9-E3 (ENG) 4/11/0 11:06 AM Page 47

6-5
PERIODIC MAINTENANCE AND MINOR REPAIR
6
7
8
9
EVERY
6,000 km 12,000 km
No.
ITEM CHECKS AND MAINTENANCE JOBS
Initialor or
(1,000 km)6 months 12 months
(Whichever (Whichever
comes first) comes first)
9Check operation.
20 * Autolube pump9Correct if necessary.ÖÖÖ
9Bleed if necessary.
9Check oil level and vehicle for oil leakage.
21 Transmission oil9Correct accordingly.
ÖÖÖ
9Change oil at initial 1,000 km and thereafter every
24,000 km or 24 months (whichever comes first).
9Check coolant level and vehicle for coolant leakage.
22 * Cooling system9Correct if necessary.
ÖÖ
9Change coolant every 24,000 km or 24 months (whichever
comes first).
* Since these items require special tools, data and technical skills, they should be serviced by a Yamaha dealer.EAU02970
NOTE
8The air filter needs more frequent service if you are riding in unusually wet or dusty areas.
8Hydraulic brake system
9When disassembling the master cylinder or caliper, always replace the brake fluid. Check the brake fluid level
regularly and fill as required.
9Replace the oil seals on the inner parts of the master cylinder and caliper every two years.
9Replace the brake hoses every four years or if cracked or damaged.
5AE-9-E3 (ENG) 4/11/0 11:06 AM Page 48

6-6
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
5
6
7
8
9
1
1. Cowling B
1
1. Panel A
EAU01139
Cowling and panel removal
and installation
The cowlings and panels illustrated
need to be removed to perform some
of the maintenance described in this
chapter.
Refer to this section each time a
cowling or panel has to be removed
or reinstalled.
1
1. Cowling A
5AE-9-E3 (ENG) 4/11/0 11:06 AM Page 49

6-7
2
1
1
12
EAU01088Cowling A, B
To remove
1. Remove the seat.
2. Remove the radiator cover
screws and the radiator cover.
1. Radiator cover
2. Screw (´2)1. Screw (´10) 1. Screw (´2)
2. Panel A
3. Remove the screws and pull out-
ward on the areas shown.
To install
1. Place the cowling in the original
position and install the screws.
2. Place the radiator cover in the
original position and install the
screws.
3. Install the seat.EAU01691
Panel A
To remove
1. Remove the seat. (See page
3-13 for removal and installation
procedures.)
2. Remove the screw.
To install
1. Place the panel in the original
position and install the screw.
2. Install the seat.
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
5
6
7
8
9
5AE-9-E3 (ENG) 4/11/0 11:06 AM Page 50

6-8
1
EAU01651
Spark plug inspection
The spark plug is an important
engine component and should be
inspected periodically, preferably by
a Yamaha dealer. The condition of
the spark plug can indicate the condi-
tion of the engine. The ideal color on
the white insulator around the center
electrode is a medium-to-light tan
color for a motorcycle that is being
ridden normally. Do not attempt to
diagnose any problems yourself.
Instead, take the motorcycle to a
Yamaha dealer. The spark plug
should be periodically removed and
inspected because heat and depositswill cause the spark plug to slowly
break down and erode. If electrode
erosion becomes excessive, or if car-
bon and other deposits are exces-
sive, the spark plug should be
replaced with the specified plug.
Before installing the spark plug, mea-
sure the electrode gap with a wire
thickness gauge and adjust it to
specification.When installing the plug, the gasket
surface should always be cleaned
and a new gasket used. Any grime
should be wiped off from the threads
and the spark plug tightened to the
specified torque.NOTE:
If a torque wrench is not available
when installing a spark plug, a good
estimate of the correct torque is 1/4
to 1/2 turn past finger tight. The spark
plug should be tightened to the speci-
fied torque as soon as possible.
1. Spark plug wrench
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
5
6
7
8
9 Specified spark plug:
BR9ES (NGK)
Spark plug gap:
0.7 ~ 0.8 mm
Tightening torque:
Spark plug:
20 Nm (2.0 m0kg)
1
1. Spark plug gap
5AE-9-E3 (ENG) 4/11/0 11:06 AM Page 51

6-9
1
1. Transmission oil filler cap
2. With the engine stopped, check
the oil level through the level
window located at the right side
crankcase cover.
NOTE:
Wait a few minutes until the oil level
settles before checking.
3. The oil level should be above the
minimum level mark on the level
window. If the level is low, add
sufficient oil to raise it to the
proper level.Transmission oil replacement
1. Warm up the engine for several
minutes.
2. Stop the engine. Place an oil pan
under the engine and remove the
oil filler cap.
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
5
6
7
8
9
12
EAU01080Transmission oil
Oil level measurement
1. Place the motorcycle on a level
place and hold it an upright posi-
tion. Warm up the engine for
several minutes.
NOTE:
Be sure the motorcycle is positioned
straight up when checking the oil
level. A slight tilt toward the side can
result in false readings.
1. Level window
2. Minimum level
5AE-9-E3 (ENG) 4/11/0 11:06 AM Page 52

6-10
1
3. Remove the drain bolt and drain
the oil.
4. Reinstall the drain bolt and tight-
en it to the specified torque.
5. Fill the engine with oil. Install the
oil filler cap and tighten it.
EC000078
cC
8
8
Do not put in any chemical
additives. Transmission oil
also lubricates the clutch and
additives could cause clutch
slippage.
8 8
Be sure no foreign material
enters the crankcase.
6. Start the engine and warm up for
a few minutes. While warming
up, check for oil leakage. If oil
leakage is found, stop the engine
immediately and check for
cause.
1. Drain bolt
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
5
6
7
8
9 Tightening torque:
Drain bolt:
15 Nm (1.5 m0kg)
Recommended oil:
See page 8-1
Oil quantity:
Total amount: 0.8 L
Periodic oil change: 0.75 L
1
2
1. Maximum level mark
2. Minimum level mark
EAU01621*Cooling system
1. Check the coolant level in the
reservoir tank when the engine is
cold as the coolant level will vary
with engine temperature. The
coolant level should be between
the minimum and maximum
marks on the tank.
2. If the coolant level is at or below
the minimum mark, fill with tap
water (soft water) to bring the
level up to the specified level.
Change the coolant every two
years.
3. If your motorcycle overheats, see
page 6-38 for details.
5AE-9-E3 (ENG) 4/11/0 11:06 AM Page 53

EAU01622*Changing the coolant
1. Put the motorcycle on a level
place.
2. Remove the seat (See page
3-13 for seat removal proce-
dures.)
3. Remove cowling B and radiator
cover. (See page 6-7 for removal
and installation procedures.)
6-11
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
5
6
7
8
94. Remove the radiator cap.
EW000067
w
Do not remove the radiator cap
when the engine is hot.
EC000080
cC
Hard water or salt water is harmful
to the engine. You may use dis-
tilled water if you can’t get soft
water.
1
