2000 TOYOTA CAMRY dimensions

B01238
(1)(2)
(3) (4)
(5) (6)
(7)
Long
Short
(7)
InsideLead Terminal
B01239
40 mm
Wooden Block
Contact Plate
20 mm37 mm
(kgf/cm2) =100 kgf
Ram diameter (cm)
2x 3.14 (p)2
Ram diameter (in.)
2x 3.14 (p)2(psi) =221 lbf
(kPa) = x 98.1
x 6.9 (kgf/cm2)
(kPa) = (psi)
± STARTING (5S±FE)STARTER
ST±15
1722 Author: Date:
HINT:
Match the protrusion of the insulator with the indentation of the
housing.
(6) Wave washer
(7) Terminal nut
NOTICE:
Be careful to install the terminal insulators
(inside) and wave washers in the correct direction.
(e) Temporarily install these new terminal C kit parts:
(1) Terminal insulator (inside)
(2) Contact plate
(3) Terminal bolt
(4) O±ring
(5) Terminal insulator (outside)
(6) Wave washer
(7) Terminal nut
NOTICE:
Be careful to install the terminal insulators
(inside) and wave washers in the correct direction.
(f) Temporarily tighten the terminal nuts.
(g) Tighten terminal nuts.
(1) Put a wooden block on the contact plate and press
it down with a hand press.
Dimensions of wooden block:
20 x 37 x 40 mm (0.79 x 1.46 x 1.57 in.)
Press force:
981 N (100 kgf, 221 lbf)
NOTICE:

Check the diameter of the hand press ram. Then cal-
culate the gauge pressure of the press when 981 N
(100 kgf, 221 lbf) of force is applied.
Gauge pressure:

B01238
(1)(2)
(3) (4)
(5) (6)
(7)
Long
Short
(7)
InsideLead Terminal
B01239
40 mm
Wooden Block
Contact Plate
20 mm37 mm
(kgf/cm2) =100 kgf
Ram diameter (cm)
2x 3.14 (p)2
Ram diameter (in.)
2x 3.14 (p)2(psi) =221 lbf
(kPa) = x 98.1
x 6.9 (kgf/cm2)
(kPa) = (psi)
± STARTING (1MZ±FE)STARTER
ST±15
1742 Author: Date:
HINT:
Match the protrusion of the insulator with the indentation of the
housing.
(6) Wave washer
(7) Terminal nut
NOTICE:
Be careful to install the terminal insulators
(inside) and wave washers in the correct direction.
(e) Temporarily install these new terminal C kit parts:
(1) Terminal insulator (inside)
(2) Contact plate
(3) Terminal bolt
(4) O±ring
(5) Terminal insulator (outside)
(6) Wave washer
(7) Terminal nut
NOTICE:
Be careful to install the terminal insulators
(inside) and wave washers in the correct direction.
(f) Temporarily tighten the terminal nuts.
(g) Tighten terminal nuts.
(1) Put a wooden block on the contact plate and press
it down with a hand press.
Dimensions of wooden block:
20 x 37 x 40 mm (0.79 x 1.46 x 1.57 in.)
Press force:
981 N (100 kgf, 221 lbf)
NOTICE:

Check the diameter of the hand press ram. Then cal-
culate the gauge pressure of the press when 981 N
(100 kgf, 221 lbf) of force is applied.
Gauge pressure:

CIGARETTE LIGHTER SERVICE ± EL002-98 April 10, 1998
Page 2 of 2
2. If the lighter element is original
equipment and the lighter socket is
bent or pulled out of the dash, please
ask the customer about the accessory
plug being used in the lighter socket.
a. The attached specifications in
the drawing provide the
maximum recommended size
of accessory plug. If the
customer is using an
accessory plug larger than
recommended, please advise
the customer to use a plug of
appropriate size.
b. Using a power plug larger
than the given dimensions
may damage the lighter
socket.
c. If the vehicle has a power
point socket, advise the
customer to use this socket
instead of the lighter socket.
All models, all model years
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
> 2 Terminals
< 20.5 mm
(0.81º)
25 ± 30 mm
(0.79 ± 1.18º)
<13 mm
(0.51º) 13 mm
(0.51º)
25 ± 30 mm
(0.79 ± 1.18º)
< 20.5 mm
(0.81º)
> 8.5 mm
(0.33º)> 15 mm
(0.59º)
Recommended Accessory Plug ShapeService
Procedure
(Continued)
Affected
Vehicles
Warranty
Information

TSB
When inspecting or making brake booster push rod adjustments with SST 09737±00010,
it is necessary to assure proper tool configuration prior to use. The SST has a reversible
center plunger that allows it to function on a wide range of Toyota vehicles. Prior to using,
verify that it is configured correctly for the application by checking the master cylinder
outer diameter at the point illustrated below. The dimensions for the SST, Part Number
09737±00010, are also shown in the illustrations below.
PART NUMBER PART NAME
09737±00010 Brake Booster Push Rod Gauge (SST)
OPCODE DESCRIPTION TIME OPN T1 T2
N/A Not applicable to warranty ± ± ± ±
SPECIAL SERVICE TOOLS
September 26, 1997
Title:
BRAKE BOOSTER PUSH ROD GAUGE (SST)
Models:
All Models
Page 1 of 1
SS002±97
Introduction
Parts
Information
Warranty
Information
