2000 TOYOTA CAMRY alarm

Door lock control (Lock and unlock) and panic control (Theft alarm and flash) is performed by remote control, without the
ignition key inserted in the door key cylinder, using low±power electrical waves emitted by a transmitter.
1. WIRELESS DOOR LOCK OR UNLOCK NORMAL OPERATION
With the ignition key not inserted into the ignition key cylinder (Unlock warning SW off) and all the doors completely closed,
when the lock or unlock button (Transmitter) is pushed, the wireless door lock ECU receives the electrical waves from the
transmitter, causing it to operate.
As a result, the ECU judges whether the door is locked or unlocked based on the signal from the door lock motor and door
unlock detection SW, and sends a signal to the theft deterrent ECU and integration relay to switch the condition from lock to
unlock or vice versa, causing the door lock motor to operate.
2. VISUAL CONFIRMATION OF LOCK OR UNLOCK
If all doors indicate that they are locked after the lock command, parking lights and taillight will flash once. If any door
indicates that it is open after the unlock command, parking lights and taillights will flash twice.
3. WIRELESS DOOR UNLOCK OPERATION
Pushing the unlock button (Transmitter) once, driver's door is unlocked. Furthermore, pushing the button again within 3
seconds, the other doors are unlocked.
4. AUTOMATIC LOCK OPERATION
With the ignition key not inserted into the ignition key cylinder (Unlock warning SW off) and all the doors completely closed,
after pushing the button (Transmitter) to unlock all the doors, if a door is not opened within 30 seconds, all the doors will be
automatically relocked.
5. WIRELESS CONTROL STOP FUNCTION
If a door is open (Door courtesy SW on), a signal is input from the door courtesy SW to the wireless door lock ECU, stopping
wireless door lock or unlock.
If the ignition key is in the ignition key cylinder (Unlock warning SW on), the unlock warning SW inputs a signal to the
wireless door lock ECU, stopping wireless door lock or unlock.
6. DOOR LOCK MOTOR PROTECTIVE FUNCTION
If the door lock or unlock condition does not change after wireless door lock or unlock operation, 2 seconds later, the
integration relay ECU sends current three times to the door lock motor. If the door lock condition still has not changed as a
result, the wireless door lock ECU stops reception and stops door lock and unlock function.
7. REMOTE PANIC OPERATION
Panic will function when doors are locked or unlocked, open or closed. When the panic button (Transmitter) is pushed once,
theft alarm sounds and headlights and taillight flash. Then, the panic or the unlock button (Transmitter) is pushed once more,
sounding and flashing will stop. Panic will not function when ignition key is in ignition key cylinder.
D12, D13, D14, D15 DOOR COURTESY SW FRONT LH, RH, REAR LH, RH
1±GROUND : Continuity with the door open
U1 UNLOCK WARNING SW
2±1 : Continuity with the ignition key in the cylinder
W6 WIRELESS DOOR LOCK ECU
8±GROUND : Always approx. 12 volts
1±GROUND : Always continuity
14±GROUND : Continuity with each of the door open
10±GROUND : Continuity with the ignition key in the cylinder
SYSTEM OUTLINE
SERVICE HINTS

Door lock control (Lock and unlock) and panic control (Theft alarm and flash) is performed by remote control, without the
ignition key inserted in the door key cylinder, using low±power electrical waves emitted by a transmitter.
1. WIRELESS DOOR LOCK OR UNLOCK NORMAL OPERATION
With the ignition key not inserted into the ignition key cylinder (Unlock warning SW off) and all the doors completely closed,
when the lock or unlock button (Transmitter) is pushed, the wireless door lock ECU receives the electrical waves from the
transmitter, causing it to operate.
As a result, the ECU judges whether the door is locked or unlocked based on the signal from the door lock motor and door
unlock detection SW, and sends a signal to the theft deterrent ECU and integration relay to switch the condition from lock to
unlock or vice versa, causing the door lock motor to operate.
2. VISUAL CONFIRMATION OF LOCK OR UNLOCK
If all doors indicate that they are locked after the lock command, parking lights and taillight will flash once. If any door
indicates that it is open after the unlock command, parking lights and taillights will flash twice.
3. WIRELESS DOOR UNLOCK OPERATION
Pushing the unlock button (Transmitter) once, driver's door is unlocked. Furthermore, pushing the button again within 3
seconds, the other doors are unlocked.
4. AUTOMATIC LOCK OPERATION
With the ignition key not inserted into the ignition key cylinder (Unlock warning SW off) and all the doors completely closed,
after pushing the button (Transmitter) to unlock all the doors, if a door is not opened within 30 seconds, all the doors will be
automatically relocked.
5. WIRELESS CONTROL STOP FUNCTION
If a door is open (Door courtesy SW on), a signal is input from the door courtesy SW to the wireless door lock ECU, stopping
wireless door lock or unlock.
If the ignition key is in the ignition key cylinder (Unlock warning SW on), the unlock warning SW inputs a signal to the
wireless door lock ECU, stopping wireless door lock or unlock.
6. DOOR LOCK MOTOR PROTECTIVE FUNCTION
If the door lock or unlock condition does not change after wireless door lock or unlock operation, 2 seconds later, the
integration relay ECU sends current three times to the door lock motor. If the door lock condition still has not changed as a
result, the wireless door lock ECU stops reception and stops door lock and unlock function.
7. REMOTE PANIC OPERATION
Panic will function when doors are locked or unlocked, open or closed. When the panic button (Transmitter) is pushed once,
theft alarm sounds and headlights and taillight flash. Then, the panic or the unlock button (Transmitter) is pushed once more,
sounding and flashing will stop. Panic will not function when ignition key is in ignition key cylinder.
D12, D13, D14, D15 DOOR COURTESY SW FRONT LH, RH, REAR LH, RH
1±GROUND : Continuity with the door open
U1 UNLOCK WARNING SW
2±1 : Continuity with the ignition key in the cylinder
W6 WIRELESS DOOR LOCK ECU
8±GROUND : Always approx. 12 volts
1±GROUND : Always continuity
14±GROUND : Continuity with each of the door open
10±GROUND : Continuity with the ignition key in the cylinder
SYSTEM OUTLINE
SERVICE HINTS

I00228
0.25 ± 0.05 sec.
0.25 ± 0.05 sec.
ON
OFF
Horns Sounding and Lights Flashing
Pattern
0.2 ± 0.05 sec.
0.55 ± 0.05 sec. ON
OFF
Output of Key Lock Pattern
± DIAGNOSTICSTHEFT DETERRENT SYSTEM
DI±829
1064 Author: Date:
(3) About 30 seconds after the process±(2), on the pre-
vious page the Theft Deterrent mode will automati-
cally start.
HINT:
If, while following above steps, you use the key or the remote
control to lock the door, the system will be set to ACTIVE ARM-
ING MODE.
3. THEFT DETERRENT OPERATION
When the system is set to the theft deterrent mode and any of
the following conditions are met, the system sounds the horns
and flashes the headlights and the taillights for about 1 minute.
At the same time locks all doors (If all doors are not locked at
once, the system repeats door locking operation every 0.55 se-
conds during the one±minute alarm time).
Condition
(1) Any of the doors (Including the engine hood and
luggage compartment door) is unlocked or opened
without the key. *1
(2) The battery terminal is disconnected and recon-
nected. *2
(3) The system receives panic signal from remote key-
less entry. *3
*1: Only active arming mode.
*2: When the ignition key is not inserted in the key
cylinder.

I00229
0.75 ± 0.1 sec.
1.25 ± 0.1 sec.
ON
OFF
Blinking Pattern Security only: DI±830
± DIAGNOSTICSTHEFT DETERRENT SYSTEM
1065 Author: Date:
4. CANCELLATION OF THEFT DETERRENT OPERA-
TION OR MODE
The theft deterrent operation of mode can be cancelled when
any of the following conditions is met.
No.ConditionCancel of OperationCancel of Mode
1Unlock front doors with the keyEffectiveEffective
2Unlock doors with remote keyless entryEffectiveEffective
3Insert key into ignition key cylinder and turn
it to ACC or ON positionEffectiveEffective
4About 1 minute passes after theft deterrent
operation beginsAutomatic stop *1±
5Unlock the luggage compartment door with
the key or keyless entry.UneffectiveEffective
6Unlock the luggage compartment door with
the keyless entry.UneffectiveEffective
7
If the system receives panic signal again or
unlock signal when the system is activated
by panic signal
Effective *2Uneffective
6If the system receives unlock signal when
the system is activated by panic signalEffectiveEffective
*1: The system is set to the theft deterrent mode again in
about 2 seconds after the operation stops, if all doors are
closed.
*2: The alarm caused by the panic signal malces the sys-
tem in the previous condition.
5. INDICATOR LIGHT (LED)
The indicator light functions as shown below according to the
system condition in the theft deterrent mode. It remains OFF in
the initial state.
System ConditionIndicator Light
During set preparation timeON
When the mode is set*OFF
When alarm is activatedON
When the system is temporally cancelled*OFF
*: The indicator flashes with the output from the immobiliser.
6. KEEPING POWER SUPPLY FUNCTION IN CASE OF
DOME FUSE OPEN
Even if the dome fuse blows open on the theft deterrent mode,
the system will keep working on the theft deterrent mode.

Toyota Supports ASE CertificationPage 1 of 2
AX006±99Title:
RS3000 TVIP PROGRAMMING CHANGES
FOR GBS
Models:
All Models
Technical Service
BULLETIN
April 23, 1999

Starting with 1999 MY, the programming in the RS3000 ECU for the Glass Breakage
Sensor (GBS) to trigger the alarm has been changed to improve the Toyota Vehicle
Intrusion Protection (TVIP) system's theft warning feature when glass breakage or impact
to the glass is detected.
Previous operation of GBS (for 1998 MY and prior):
Upon (first) detection of breakage of the vehicle's glass, the GBS will sound the
security system for 5 seconds (3 horn honks).
If there is a second detection of glass breakage, within 5 seconds of the first
detection, the security system will sound for the full duration of 59 seconds.
Improved operation of GBS (from 1999 MY):
Upon (first) detection of breakage of the vehicle's glass, the GBS will sound the
security system for 20 seconds.
If there is a second detection of glass breakage, the security system will sound for the
full duration of 59 seconds, regardless of time between the first and second
detections.
After the first detection, any subsequent detection will trigger the alarm for the full
duration of 59 seconds as long as the security system is armed. The GBS trigger
cycle will reset once the security system is disarmed and then rearmed.
This improvement is intended to enhance the previous trigger cycle of the security
system and ward off an intruder.
The color of the previous (1998 MY and prior) RS3000 ECU was black. The new
RS3000 ECU color is gray.
All Models
PREVIOUS PART NUMBERCURRENT PART NUMBERPART NAME
08585±00921SAMERS3000 Base Kit
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot applicable to warranty ±±±±
ACCESSORIES
Introduction
Affected
Vehicles
Parts
Information
Warranty
Information
