2000 SUZUKI SWIFT SF310 Service Workshop Manual

IMPORTANT
WARNING / CAUTION / NOTE
Please read this manual and follow its instructions
carefully. To emphasize special information, the
words WARNING, CAUTION and NOTE have spe-
cial meanings. Pay special attention to the messages
highlighted by these signal words.
NOTE:
Indicates special information to make mainte-
nance easier or instructions clearer.
WARNING:
Indicates a potential hazard that could result
in death or injury.
CAUTION:
Indicates a potential hazard that could result
in vehicle damage.
WARNING:
This service manual is intended for authorized
SUZUKI dealers and qualified service me-
chanics only. Inexperienced mechanics or
mechanics without the proper tools and
equipment may not be able to properly per-
form the services described in this manual.
Improper repair may result in injury to the me-
chanic and may render the vehicle unsafe for
the driver and passengers.

()x()x()x()x()x()x()x()x()x
()x()x()x()x()x()x()x()x()x
FOREWORD
This SUPPLEMENTARY SERVICE MANUAL is a supplement to SF SERIES SERVICE MANU-
ALS mentioned in next page and has been prepared exclusively for the following applicable mod-
el.
Applicable model: SF310 / SF413 of and after the vehicle identification numbers below.
Vehicle Identification Number (Vehicle Specification)
TSMMAA44S00600001 (SF310 3 door H / B 2WD)
TSMMAB44S00600001 (SF310 5 door H / B 2WD)
TSMMAA35S00600001 (SF413 3 door H / B 2WD)
TSMMAB35S00600001 (SF413 5 door H / B 2WD)
TSMMAB35S10600001 (SF413 5 door H / B 2WD)
TSMMSF35S00600001 (SF413 3 door H / B 4WD)
TSMMSG35S00600001 (SF413 5 door H / B 4WD)
TSMMAH35S00600001 (SF413 4 door N / B 2WD)
TSMMAH35S10600001 (SF413 4 door N / B 2WD)
When servicing the above applicable models, refer to this SUPPLEMENTARY SERVICE MANU-
AL first. If necessary information is not found in this SUPPLEMENTARY SERVICE MANUAL, re-
fer to RELATED MANUALS specified next page.
All information, illustrations and specifications contained in this literature are based on the latest
product information available at the time of publication approval. And used as the main subject
of description is the vehicle of standard specifications among others. Therefore, note that illustra-
tions may differ from the vehicle being actually serviced.
The right is reserved to make changes at any time without notice.
OVERSEAS SERVICE DEPARTMENT
 COPYRIGHT SUZUKI MOTOR CORPORATION 2000

RELATED MANUALS
Related manuals listed below are in the chronological order with the latest one at the top. For the efficient use of
manuals, start with one at the top of the list (i.e., the latest one). If desired section, item or description is not found
in it, try next one in the list and do the same one by one till what is being searched is found.
MODEL
NO.RELATED SERVICE MANUALAPPLICABILITY
SF310 /
SF4131
SF310 / SF413
WIRING DIAGRAM MANUAL
(99512-80E10-019)This manual is prepared exclusively for the appli-
cable model mentioned in FOREWORD of this
supplementary service manual.
SF
SERIES1
SF SERIES SUPPLEMENTARY
SERVICE MANUAL
(99501-80E00-xxx)This manual describes the updated information
from the SF310 and SF413 Service Manuals
below.
SF310
(1 000 cc)
1
SF310 SUPPLEMENTARY
SERVICE MANUAL
(99501-60B00-xxx)This manual describes the items that are updated
(modified and added) from the Service Manual
(99500-60B01).
(1,000 cc)
2SF310 SERVICE MANUAL
(99500-60B01-xxx)This manual is the base manual for the above
manual.
1
SF413 SUPPLEMENTARY
SERVICE MANUAL
(99501-63B30-xxx)
[Pub. No. G4203GE]This manual describes the items that are updated
(modified and added) from the Service Manual
(99500-63B01).
SF413
(1,300 cc)2
SF413 SUPPLEMENTARY
SERVICE MANUAL
(99501-63B20-xxx)
[Pub. No. G4202GE]This manual describes the items for 4WD model
that are updated (modified and added) from the
Service Manual (99500-63B01).
(, )
2
SF413 SUPPLEMENTARY
SERVICE MANUAL
(99501-63B10-xxx)This manual describes the items for SEDAN mod-
el that are updated (modified and added) from the
Service Manual (99500-63B01).
3
SF413 SERVICE MANUAL
(99500-63B01-xxx)
[Pub. No. G4200GE]This manual is the base manual for the above
manuals.
SF
SERIES
(A / C)
1AIR CONDITIONING BASIC
MANUAL (99520-02130-xxx)This manual is the base manual of A / C system.

6
6
6-1
6A
6A1
6B
6C
6E1
6E1
6E2
6F
6F
6F1
6G
6H
6K
GENERAL INFORMATION
General Information
Maintenance and Lubrication
1A
1B
TABLE OF CONTENTS SECTION
0A
0B
7B
8
8A
8G HEATING AND AIR CONDITIONING
Heater and Ventilation
Air Conditioning (Oprional)
ENGINE
General Information and Diagnosis
(TBI for G10)
General Information and Diagnosis
(TBI for G13)
General lnformation and Diagnosis
(SFI for G13)
Engine Mechanical (G10 Engine)
Engine Mechanical
(G13 1-cam 16-valves Engine)
Engine Cooling
Engine Fuel
Engine and Emission Control System
(TBI for G10)
Engine and Emission Control System
(TBI for G13)
Engine and Emission Control System
(SFI for G13)
Ignition System (TBI for G10)
Ignition System (TBI for G13)
Ignition System (SFI for G13)
Cranking System
Charging System
Exhaust System
TRANSMISSION, CLUTCH AND
DIFFERENTIAL
Automatic Transmission
BODY ELECTRICAL SYSTEM
Wiring Diagram
IMMOBILIZER CONTROL SYSTEM
1B
0B
0A
1A
6
6B
6C
6E1
6A1
6F
6G
6H
6K
7B
8
8A
8G
6-1
6A
6E2
6F1
6
6E1
6F
NOTE:
The screen toned Section 8A is contained in WIRING DIAGRAM MANUAL mentioned in
RELATED MANUALS.

GENERAL INFORMATION 0A-1
0ASECTION 0A
GENERAL INFORMATION
CONTENTS
HOW TO USE THIS MANUAL0A- 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PRECAUTIONS0A- 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Precaution for Vehicles Equipped with a Supplemental Restraint (Air Bag) System 0A- 3. . . . . . . . . . . . . . . .
General Precautions0A- 6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Precautions for Catalytic Converter 0A- 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Precautions for Electrical Circuit Service 0A- 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Circuit Inspection Procedure 0A-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Intermittent and Poor Connection 0A-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Precaution for Installing Mobile Communication Equipment 0A-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Precaution in Servicing Full-Time 4WD Vehicle 0A-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IDENTIFICATION INFORMATION0A-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle Identification Number0A-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identification Whether Vehicle Equipped with WU-TWC or Not 0A-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Identification Number0A-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transmission Identification Number 0A-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
WARNING, CAUTION AND INFORMATION LABELS0A-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
VEHICLE LIFTING POINTS0A-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ABBREVIATIONS AND SYMBOLS MAY BE USED IN THIS MANUAL0A-22 . . . . . . . . . . . . . . . . . . . . . . . . . . .
FASTENER INFORMATION0A-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Metric Fasteners0A-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fasteners Strength Identification 0A-25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Standard Tightening Torque0A-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1. Flywheel bolts or drive plate bolts for A / T vehicle
6) Install oil pump. Refer to “Oil pump”.
7) Install flywheel (for M / T vehicle) or drive plate
(for A / T vehicle).
Using special tool, lock flywheel or drive plate, and
tighten flywheel or drive plate bolts to specified
torque.
Special Tool
(A): 09924-17810
Tightening Torque
(c): 78 N
.m (7.8 kg-m, 56.0 lb-ft)
0A-2 GENERAL INFORMATION
HOW TO USE THIS MANUAL
1) There is a TABLE OF CONTENTS FOR THE WHOLE MANUAL
on the third page of this manual, whereby you can easily find the
section that offers the information you need. Also, there is a
CONTENTS on the first page of EACH SECTION, where the
main items in that section are listed.
2) Each section of this manual has its own pagination. It is indicated
at the top of each page along with the Section name.
3) The SPECIAL TOOL usage and TIGHTENING TORQUE
SPECIFICATION are given as shown in figure below.
4) A number of abbreviations are used in the text.
For their full explanations, refer to “ABBREVIATIONS AND
SYMBOLS MAY BE USED IN THIS MANUAL” of this section.
5) The SI, metric and foot-pound systems are used as units in this
manual.
6) DIAGNOSIS are included in each section as necessary.
7) At the end of each section, there are descriptions of SPECIAL
TOOLS, REQUIRED SERVICE MATERIALS and TIGHT-
ENING TORQUE SPECIFICATIONS that should be used for the
servicing work described in that section.

1. Air bag wire harness
2. Driver air bag (inflator) module
3. Passenger air bag (inflator) module
4. SDM
GENERAL INFORMATION 0A-3
PRECAUTIONS
PRECAUTION FOR VEHICLES EQUIPPED
WITH A SUPPLEMENTAL RESTRAINT (AIR
BAG) SYSTEM
WARNING:

The configuration of air bag system parts are as shown in
the figure. When it is necessary to service (remove, rein-
stall and inspect) these parts, be sure to follow proce-
dures described in Section 9J. Failure to follow proper
procedures could result in possible air bag deployment,
personal injury, damage to parts or air bag being unable
to deploy when necessary.

If the air bag system and another vehicle system both
need repair, Suzuki recommends that the air bag system
be repaired first, to help avoid unintended air bag deploy-
ment.

Do not modify the steering wheel, dashboard, or any other
air bag system component. Modifications can adversely
affect air bag system performance and lead to injury.

If the vehicle will be exposed to temperatures over 93C,
200F (for example, during a paint baking process), re-
move the air bag system components (air bag (inflator)
modules, sensing and diagnostic module) beforehand to
avoid component damage or unintended deployment.
DIAGNOSIS

When troubleshooting air bag system, be sure to follow
“DIAGNOSIS” in Section 9J. Bypassing these procedures
may result in extended diagnostic time, incorrect diagnosis,
and incorrect parts replacement.

Never use electrical test equipment other than that specified
in this manual.
WARNING:
Never attempt to measure the resistance of the air bag (in-
flator) modules (driver and passenger). It is very dangerous
as the electric current from the tester may deploy the air
bag.

1. Slit on workbench
2. Workbench vise
3. Lower mounting bracket
ALWAYS CARRY AIR BAG (INFLATOR) MODULE
WITH TRIM COVER (AIR BAG OPENING) AWAY
FROM BODY.
ALWAYS PLACE AIR BAG (INFLATOR) MODULE
ON WORKBENCH WITH TRIM COVER (AIR BAG
OPENING) UP, AWAY FROM LOOSE OBJECTS.
0A-4 GENERAL INFORMATION
HANDLING AND SERVICING
WARNING:

Many of service procedures require disconnection of
“AIR BAG” fuse and air bag (inflator) modules (driver and
passenger) from deployment loop to avoid an accidental
deployment.
Driver and Passenger Air Bag (Inflator) Modules

For handling and storage of a live air bag (inflator) module,
select a place where the ambient temperature below 65C
(150F), without high humidity and away from electric
noise.

When carrying a live air bag (inflator) module, make sure
the bag opening is pointed away from you. In case of an
accidental deployment, the bag will then deploy with mini-
mal chance of injury. Never carry the air bag (inflator)
module by the wires or connector on the underside of the
module. When placing a live air bag (inflator) module on
a bench or other surface, always face the bag up, away
from the surface. As the live passenger air bag (inflator)
module must be placed with its bag (trim cover) facing up,
place it on the workbench with a slit or use the workbench
vise to hold it securely at its lower mounting bracket. This
is necessary so that a free space is provided to allow the
air bag to expand in the unlikely event of accidental de-
ployment. Otherwise, personal injury may result.

Never dispose of live (undeployed) air bag (inflator) mod-
ules (driver and passenger). If disposal is necessary, be
sure to deploy them according to deployment procedures
described in Section 9J before disposal.

The air bag (inflator) module immediately after deploy-
ment is very hot. Wait for at least half an hour to cool it off
before proceeding the work.

After an air bag (inflator) module has been deployed, the
surface of the air bag may contain a powdery residue.
This powder consists primarily of cornstarch (used to lu-
bricate the bag as it inflates) and by-products of the chem-
ical reaction. As with many service procedures, gloves
and safety glasses should be worn.
SDM

During service procedures, be very careful when handling
a Sensing and Diagnostic Module (SDM). Never strike or
jar the SDM. Never power up the air bag system when the
SDM is not rigidly attached to the vehicle. All SDM and
mounting bracket fasteners must be carefully torqued
and the arrow must be pointing toward the front of the ve-
hicle to ensure proper operation of the air bag system. The
SDM could be activated when powered while not rigidly at-
tached to the vehicle which could cause deployment and
result in personal injury.
