2000 SUBARU LEGACY Owners Manual

11-30
Recommended clutch fluid
FMVSS No. 116, fresh DOT 3 or 4 brake fluid
Brake booster
If the b rake b ooster d oes not op erate as d esc rib ed b elow, have it
c hec ked b y your SUBARU d ealer.
1. With the eng ine off, d ep ress the b rake p ed al seve ral times, ap p lying
the same p ed al forc e eac h time. The d istanc e the p e d al travels should
not vary.
2. With the b rake p ed al d ep ressed , start the eng ine. The p ed al should
move slig htly d own to the floor.
3. With the b rake p ed al d ep ressed , stop the eng ine a nd keep the p ed al
d ep ressed for 30 sec ond s. The p ed al heig ht should n ot c hang e.
4. Start the eng ine ag ain and run for ab out one minu te then turn it off.
Dep ress the b rake p ed al several times to c hec k the b rake b ooster.
Brake b ooster op erates p rop erly if the p ed al stroke d ec reases with eac h
d ep ression.

Maintenance and service11-31
–
CONTINUED –
Brake pedal
Chec k the b rake p ed al free p lay and reserve d istanc
e ac c ord ing to the
maintenanc e sc hed ule in the “Warranty and Maintenanc e Booklet ”.
Checking the brake pedal free play
OM-H0224
0.04 —
0.12 in
(1.0 — 3.0 mm)
Stop the eng ine and firmly d ep ress the b rake p ed al several times.
Lig htly p ress the b rake p ed al d own with one fing er to c hec k the free
p lay with a forc e of less than 2 lb (10 N, 1 kg ).
If the free p lay is not within p rop er sp ec ific ation , c ontac t your
SUBARU d ealer. Checking the brake pedal reserve distance
OM-H0225
More than 2.56 in (65 mm)
Dep ress the p ed al with a forc e of ap p roximately 66 lb (294 N, 30 kg )

11-32and measure the d istanc e b etween the up p er surfac e
of the p ed al
p ad and the floor.
When the measurement is smaller than the sp ec ific at ion, or when the
p ed al d oes not op erate smoothly, c ontac t with your SUBARU d ealer.
Clutch pedal (Manual transmission vehicles)
Chec k the c lutc h p ed al free p lay and reserve d istan c e ac c ord ing to the
maintenanc e sc hed ule in the “Warranty and Maintenanc e Booklet ”.
Checking the clutch function
Chec k the c lutc h eng ag ement and d iseng ag ement.
1. With the eng ine id ling , c hec k that there are no a b normal noises
when the c lutc h p ed al is d ep ressed , and that shifti ng into 1st or re-
verse feels smooth.
2. Start the vehic le b y releasing the p ed al slowly t o c hec k that the en-
g ine and transmission smoothly c oup le without any s ig n of slip p ag e.
Checking the clutch pedal free play
OM-H0224
0.16 —
0.51 in
(4.0 — 13.0 mm)
Lig htly p ress the c lutc h p ed al d own with your fing e r until you feel re-
sistanc e, and c hec k the free p lay.
If the free p lay is not within p rop er sp ec ific ation , c ontac t your
SUBARU d ealer.

Maintenance and service11-33
–
CONTINUED –
Replacement of brake pad and lining
CAUTION
If you continue to drive despite the scraping noise from the audi-
ble brake pad wear indicator, it will result in the need for costlybrake rotor repair or replacement.
OM-H0163
The front d isc b rakes and the rig ht rear d isc b rake have an aud ib le wear
ind ic ators on the b rake p ad s. If the b rake p ad s wea r c lose to their ser-
vic e limit, the wear ind ic ator makes a very aud ib le sc rap ing noise when
the b rake p ed al is ap p lied .
If you hear this sc rap ing noise eac h time you ap p ly the b rake p ed al,
have the b rake p ad s servic ed b y your SUBARU d ealer as soon as p os-
sib le.
Breaking-in of new brake pads and linings
When rep lac ing the b rake p ad or lining , use only g e nuine SUBARU
p arts. After rep lac ement, the new p arts must b e b ro ken in as follows:
n Brake pad and lining
While maintaining a sp eed of 30 to 40 mp h (50 to 65 km/h), step on
the b rake p ed al lig htly. Rep eat this five or more t imes.

11-34n
Parking brake lining
WARNING
A safe location and situation should be selected for break-in driv- ing.
CAUTION
Pulling the parking brake lever too forcefully may cause the rear
wheels to lock. To avoid this, be certain to pull the lever up slowly
and gently.
1. Drive the vehic le at a sp eed of ab out 22 mp h (35 km/h).
2. With the p arking b rake release b utton p ushed in, p ull the p arking
b rake lever SLOWLY and GENTLY. (Pulling with a forc e of ap p roxi-
mately 33 lb [ 147 N, 15 kg ] .)
3. Drive the vehic le for ab out 220 yard s (200 meters ) in this c ond ition.
4. Wait 5 to 10 minutes for the p arking b rake to c oo l d own. Rep eat
this p roc ed ure.
5. Chec k the p arking b rake stroke. If the p arking b r ake stroke is out
of the sp ec ified rang e, ad just it b y turning the ad justing nut loc ated
on the p arking b rake lever.
Parking b rake stroke: 7 — 8 notc hes / 44 lb (196 N, 20 kg )
Parking brake stroke
Chec k the p arking b rake stroke ac c ord ing to the mai ntenanc e sc hed ule
in the “Warranty and Maintenanc e Booklet ”. When the p arking b rake is
p rop erly ad justed , b raking p ower is fully ap p lied b y p ulling the lever up
seven to eig ht notc hes g ently b ut firmly (ab out 44 lb , 196 N, 20 kg ). If the
p arking b rake lever stroke is not within the sp ec if ied rang e, have the
b rake system c hec ked and ad justed at your SUBARU d e aler.

Maintenance and service11-35
–
CONTINUED –
HB4001CB
Tires and wheels
WARNING
When replacing a tire, make sure you use only the same size,
circumferences, construction, brand, speed symbol and load in- dex as the original tires listed on the tire placard. Using othersizes, circumferences or construction may result in severe me-
chanical damage to the drivetrain of your vehicle and may affectride, handling, braking, speedometer/odometer calibration, and
clearance between the body and tires. It also may be dangerousand lead to loss of vehicle control. Do not use a combination of radial, belted bias or bias tires
since it may cause dangerous handling characteristics and leadto an accident. Do not let air out of warm tires to adjust pressure. Doing so
will result in low tire pressure.
The tires should b e c hec ked freq uently for p rop er t ire p ressure, wear,
and c uts.

11-36
Tire pressure
For the b est b alanc e b etween fuel ec onomy, tire lif e, rid e c omfort, and
hand ling , tire p ressure should b e maintained in ac c ord anc e with sp ec ifi-
c ations. Chec k the tire p ressure when the tires are c old . Cold means that
the vehic le has b een p arked for three hours or has b een d riven less than
1 mile (1.6 km).
HB0382
The rec ommend ed tire p ressure and sizes are p rovid e d on the tire p lac -
ard , whic h is loc ated und er the d oor latc h on the d river’s sid e.
Tire rotation
Tire wear will vary with eac h wheel. To inc rease th e life of tires and keep
wear uniform, it is b est to rotate them every 7,500 mile (12,500 km).
When rotating tires, rep lac e any unevenly worn or d amag ed tire. After
rotating the tires, ad just tire p ressure and b e sur e to c hec k wheel nut
tig htness.

Maintenance and service11-37
–
CONTINUED –
OM-H0231
New tread Worn tread
OM-H0230
Tread wear indicator
A tire should b e rep lac ed when the tread wear ind ic ator ap p ears as a
solid b and ac ross the tread . The ind ic ators ap p ear when the remaining
tread has b een worn to 0.063 in (1.6 mm) or less. Wheel covers Removing the wheel cover
OM-H2454
Insert the wheel nut wrenc h into the notc h p rovid ed , and p ry the
wheel c over off.
