2000 SUBARU LEGACY Owners Manual

6
Interior equipment Interior light6-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dome/Rear map reading light (if equipped) 6-2 . . . . . . . . . . . . . . . . . . . . . .
Spotlight (if equipped) 6-4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sun visors 6-5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vanity mirror (if equipped) 6-6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage compartment 6-6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glove compartment 6-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center console 6-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coin tray 6-8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overhead console (if equipped) 6-8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cup holder 6-9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette lighter (if equipped) 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ashtray 6-12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessory power socket 6-13
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Convenience hook 6-15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Floor mat (if equipped) 6-17
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Luggage cover (if equipped) 6-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cargo anchorage eyelets (if equipped) 6-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage tray (if equipped) 6-20
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6-2
Interior light
HB0377
HS6003BC
ON
DOOR
OFF
Cargo area light
The interior lig ht switc h has three p ositions: ON:
The lig ht stays on c ontinuously.
DOOR: Dome lig ht — The lig ht c omes on only when any d oor is op ened .
Carg o area lig ht (if eq uip p ed ) — The lig ht c omes on only when the rear
g ate is op ened .OFF: The lig ht stays off.
When leaving your vehic le, make sure the lig ht is t urned off to avoid b at-
tery d isc harg e.
Dome/Rear map reading light (if equipped)
CAUTION
Do not use excessive force or sharp objects to activate the
switches. Do not spray cleaner directly on the dome light lens or the
switches. Remove the lens and use a damp cloth to clean the switch sur-
faces.

Interior equipment6-3
–
CONTINUED –
HB6012BB
1 Map lig ht
2 MAP lig ht d immer switc h
3 Main d ome lig ht
4 MAP lig ht ON/OFF switc h 5
OFF switc h
6 DOOR switc h
7 ON switc h
Dome light
ON mode: Pressing the “ON ” switc h 7 will turn on main d ome lig ht.
DOOR mode: Pressing the “DOOR ” switc h 6 will allow all three lig hts
to fully illuminate when d oor is op ened and then fa d e out onc e d oor is
c losed . OFF mode: Pressing the “OFF ” switc h
5 will p revent all lig hts from
illuminating when the d oor is op ened . Rear map reading light
n Turn ON or OFF
Press the “MAP ON/OFF ” switc h 4 onc e to turn on the map lig ht at
full intensity. Press a sec ond time to turn it off. n Map light dimming
This area 2 will vary the intensity of the map lig ht d ep end ing on
whic h d imming zone area is p ressed .

6-4NOTE
The switch color will change to indicate position setting.
Green indicates current switch while the other switches will be
Red . (Map light switches will be Yellow regardless of setting).
Switch indicator lights will shut off when not in use, but will
come back on when any switches are touched. The light assembly is equipped with a time delayed-off feature.
The lights will remain on for a few seconds after all vehicle doorsare closed. If a map light is in use and the door is opened, the map light
will maintain its current setting even after the door is closed. The light assembly is equipped with a 1 hour sleep mode timer
that will turn off any light that may be accidentally left on. Touch-ing any switch will reactivate the unit and allow for continued op-
eration.
Spotlight (if equipped)
HB2006CB
HB2034CB

Interior equipment6-5
–
CONTINUED –
HB6006BB
To turn on the sp otlig ht, p ush the switc h. To turn it off, p ush the switc h
ag ain.
When leaving the vehic le, make sure the lig ht is tu rned off to avoid b at-
tery d isc harg e.
Sun visors
HB7001BA
To b loc k out g lare, swing d own the visors. To use t he sun visor at a sid e
wind ow, swing it d own and move it sid eways.

6-6

Vanity mirror (if equipped)
HB6017AA
To use the vanity mirror, swing d own the sunvisor a nd op en the vanity
mirror c over.
Vanity mirror with light (if equipped)
The lig ht b esid e the vanity mirror c omes on when th e ig nition switc h is
either in the “ACC ” or “ON ” p osition and the mirror c over is op ened .
Storage compartment
CAUTION
Always keep the storage compartment closed while driving to
reduce the risk of injury in the event of sudden stops or an acci- dent. Do not store spray cans, containers with flammable or corro-
sive liquids or any other dangerous items in the storage compart-ment.

Interior equipment6-7
–
CONTINUED –

Glove compartment
HS0090
Unlock
Lock
To op en the g love c omp artment, p ull the hand le. To c lose it, p ush the lid
firmly up ward .
To loc k the g love c omp artment, insert the key and t urn it c loc kwise.
Center console
HB6010BA
To op en the lid , p ull up the loc k release.

6-8

Coin tray
HS0096
To op en the c oin tray, p ull the up p er ed g e of the l id .
Overhead console (if equipped)
CAUTION
When your vehicle is parked in the sun or a warm day, the inside
of the overhead console heats up. Avoid storing plastic or other
heat-vulnerable or flammable articles such as a lighter in theoverhead console.
HB0269
To op en the c onsole, p ush on the lid lig htly and it will automatic ally op en.
