2000 SUBARU FORESTER Owners Manual

Seat, seat belt and SRS airbag2-37
–
CONTINUED –

SRS airbag system monitors
HS0154
SRS airbag system warning light
A d iag nostic system c ontinually monitors the read in
ess of the SRS air-
b ag system while the vehic le is b eing d riven. The S RS airb ag system
warning lig ht “AIRBAG ” will show normal system op eration b y lig hting for
ab out 6 sec ond s when the ig nition key is turned to the “ON ” p osition.
The following c omp onents are monitored b y the ind ic ator:
Front sub sensor (Rig ht hand sid e)
Front sub sensor (Left hand sid e)
Airb ag c ontrol mod ule (inc lud ing imp ac t sensors)
Airb ag mod ule (Driver ’s sid e)
Airb ag mod ule (Passeng er ’s sid e)
All related wiring
In the event of a malfunc tion ind ic ated b y any of f ollowing , the vehic le
should b e taken p romp tly to your nearest SUBARU d ea ler to have the
system c hec ked . Unless c hec ked and rep aired , the SR S airb ag s will not
func tion reliab ly: Flashing or flic kering of the ind ic ator lig ht.
No illumination of the warning lig ht when the ig nit ion switc h is first
turned to the “ON ” p osition.
Continuous illumination of the warning lig ht.
Illumination of the warning lig ht while d riving .

2-38
SRS airbag system servicing
WARNING
When discarding an airbag module or scrapping the entire car
damaged by a collision, consult your SUBARU dealer. The SRS airbag has no user-serviceable parts. Do not use
electrical test equipment on any circuit related to the SRS airbag
system. For required servicing of the SRS airbag, see your near-
est SUBARU dealer. Tampering with or disconnecting the sys-
tem’ s wiring could result in accidental inflation of the SRS airbag
or could make the system inoperative, which may result in seri-
ous injury. The wiring harnesses of the SRS airbag system arecovered with yellow insulation and the system connectors areyellow for easy identification.
CAUTION
If you need service or repair in areas listed below, we recommend
that you have an authorized SUBARU dealer perform the work. The
SRS airbag control module, impact sensors and airbag modules
are stored in these areas.
Under the center console
Inside each front fender
Steering wheel and column and nearby areas
Instrument panel and nearby areas
In the event that the SRS airbag is deployed, replacement of the sys-
tem should be performed only by an authorized SUBARU dealer.When the components of the SRS airbag system are replaced, useonly genuine SUBARU parts.
To ensure their long -term reliab ility, the SRS airb ag s must b e insp ec ted
b y a SUBARU d ealer ten years after the d ate of manu fac ture, whic h is
shown on the c ertific ation lab el attac hed to the d r iver’s d oor.

Seat, seat belt and SRS airbag2-39
–
CONTINUED –
NOTE In the following cases, contact your SUBARU dealer as soon as pos- sible.
The front part of the vehicle was involved in an accident in
which the SRS airbags did not deploy. The pad section of the steering wheel or front passenger ’s air-
bag cover is scratched, cracked, or otherwise damaged.
Precautions against vehicle modification
WARNING
To avoid accidental activation of the system or rendering the
system inoperative, which may result in serious injury, no modifi-cations should be made to any components or wiring of the SRSairbag system.This includes following modifications: Installation of custom steering wheel
Attachment of additional trim materials to the dashboard
Installation of additional electrical/electronic equipment such
as a mobile two-way radio on or near the SRS airbag system
components and/or wiring is not advisable. This could interferewith proper operation of the SRS airbag system.
CAUTION
Do not perform any of the following modifications. Such modifi-cations can interfere with proper operation of the SRS airbag sys-tem.
Attachment of any equipment (brush bar, winches, snow
plow, skid plate, etc.) other than SUBARU genuine accessoryparts to the front end Modification of the suspension system or front end structure
Installation of a tire of different size and construction from
the original tires listed on the tire placard attached to the doorjamb

2-40Always c onsult your SUBARU d ealer if you want to in
stall any ac c essory
p arts to your vehic le.

3
Instruments and controls Gauges3-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speedometer 3-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Odometer/Trip meter 3-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer 3-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel gauge 3-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature gauge 3-4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning and indicator lights 3-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat belt warning light and chime 3-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SRS airbag system warning light 3-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charge warning light 3-6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil pressure warning light 3-6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system warning light 3-6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CHECK ENGINE warning light/Malfunction indicator lamp 3-7 . . . . . .
ABS warning light (for vehicles with ABS) 3-8 . . . . . . . . . . . . . . . . . . . . . . . . .
AT OIL TEMPerature warning light (for AT vehicles) 3-9 . . . . . . . . . . . . . .
Door open warning lights 3-10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front-wheel drive warning light (for AT vehicles) 3-10 . . . . . . . . . . . . . . . . .
Turn signal indicator lights 3-10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High beam indicator 3-10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hazard warning flasher 3-11
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Light control switch 3-11
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn signals lever 3-14
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Illumination brightness control 3-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking light switch 3-15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog light switch (if equipped) 3-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiper and washer 3-16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield wiper and washer switches 3-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window wiper and washer switch (if equipped) 3-19 . . . . . . . . . . . . .
Windshield wiper deicer (if equipped) 3-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window defogger switch 3-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horn 3-22
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mirrors 3-23
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside mirror 3-23
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside mirrors 3-23
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-2
Gauges
HS0050

Speedometer
The sp eed ometer shows the vehic le sp eed . Odometer/Trip meter
HS0051
Tripmeter
Odometer
This meter d isp lays the od ometer and trip meter whe n the ig nition switc h
is in the “ON ” p osition.
To c hang e the mod e ind ic ation, b riefly p ush the kno b .
The od ometer shows the total d istanc e that the vehi c le has b een d riven.
The trip meter shows the d istanc e that the vehic le has b een d riven sinc e
you last set it to zero.
To set the trip meter to zero, selec t the ind ic atio n of the trip meter b y

Instruments and controls3-3
–
CONTINUED –
p ushing the knob and keep the knob p ushed for more
than 2 sec ond s.
NOTE If the connection between the combination meter and battery is bro-
ken for any reason such as vehicle maintenance or fuse replace-ment, the data recorded on the trip meter will be lost. Tachometer
CAUTION
Do not operate the engine with the pointer of the tachometer in
the red zone. In this range, fuel injection will be cut by the enginecontrol module to protect the engine from overrevving. The en-gine will resume running normally after the engine speed is re-duced below the red zone.
The tac hometer shows the eng ine sp eed in thousand s of revolutions p er
minute. Fuel gauge
HS0155Low fuel warning light
The fuel g aug e shows the ap p roximate amount of fuel remaining in the
tank.
The g aug e d oes not return to “E ” even thoug h the ig nition switc h is in the
“ ACC ” or “LOCK ” p osition.

3-4
The g aug e may move slig htly d uring b raking , turning
or ac c eleration d ue
to fuel movement in the tank.
Low fuel warning light
The low fuel warning lig ht c omes on when the tank i s nearly emp ty
(ab out 2.3 U.S. g al., 9.0 liters, 1.9 Imp . g al.). I t only op erates when the
ig nition switc h is in the “ON ” p osition.
Temperature gauge
CAUTION
If the pointer exceeds the normal operating range, safely stop the
vehicle as soon as possible.
See “ In case of emergency ” in this manual.
HS0052
Normal operating range
The temp erature g aug e shows eng ine c oolant temp erat
ure when the
ig nition switc h is in the “ON ” p osition.
The c oolant temp erature will vary in ac c ord anc e wit h the outsid e temp er-
ature and d riving c ond itions.
We rec ommend that you d rive mod erately until the p o inter of the temp era-
ture g aug e reac hes near the mid d le of the rang e. En g ine op eration is op ti-
mum with the eng ine c oolant at this temp erature ran g e and hig h revving
op eration when the eng ine is not warmed up enoug h s hould b e avoid ed .
