2000 SUBARU FORESTER Owners Manual

Maintenance and service10-49
–
CONTINUED –

Bulb replacement
HS0216
HS0215
Bulb
1. Remove the fog lig ht p rotec tor.
2. Remove the fog lig ht assemb ly b y removing the two sc rews.
3. Disc onnec t the c onnec tor.
4. Remove the fog lig ht b ulb b y turning it c ounterc l oc kwise.
5. Rep lac e the b ulb with a new one. Then rec onnec t t he c onnec tors
and reinstall the removed p arts in the reverse ord e r of removal.
Front turn signal, parking light and front side marker light
HS0217
1. Remove the front turn sig nal lig ht assemb ly mount ing sc rew loc ated
at the top of the head lig ht assemb ly using a p hilli p s sc rewd river.
2. Move the front turn sig nal lig ht assemb ly forward until it p op s out from

10-50the fend er.
3. Remove the b ulb hold er from the front turn sig nal
lig ht assemb ly b y
turning it c ounterc loc kwise.
4. Pull the b ulb out of the soc ket. Install a new b u lb .
5. Set the b ulb hold er into the front turn sig nal li g ht assemb ly and turn it
c loc kwise until it loc ks.
6. Set the front turn sig nal lig ht assemb ly into the fend er. Tig hten the
mounting sc rew.
Rear combination lights
HS0219
HS0218
1. Unlatc h the rear c omb ination lig ht c over b y p ulli ng the knob . Op en
the c over up .
2. Remove the b ulb hold er from the rear c omb ination lig ht assemb ly b y
turning it c ounterc loc kwise.
3. Remove the b ulb from the soc ket b y p ushing it and turning c ounter-
c loc kwise. Install a new b ulb .
4. Set the b ulb hold er into the rear c omb ination lig ht assemb ly and turn
it c loc kwise until it loc ks.
5. Close the c over and latc h the loc k.

Maintenance and service10-51
–
CONTINUED –

License plate light
HS0220
1. Remove the mounting sc rews using a p hillip s sc rew d river.
2. Remove the c over and lens.
3. Pull the b ulb out of the soc ket. Install a new b u lb .
4. Reinstall the lens and c over.
5. Tig hten the mounting sc rews.

10-52
Interior light and luggage compartment light
HSA005BA
HS0223
HS0221
1. Remove the lens b y p rying the ed g e of the lens wi
th a reg ular sc rew-
d river.
2. Pull the b ulb out of the soc ket. Install a new b u lb .
3. Reinstall the lens.

Maintenance and service10-53
–
CONTINUED –

Spot light
HSA006BA
1. Remove the lens b y p rying the ed g e of the lens wi th a reg ular sc rew-
d river.
2. Remove the p late b y removing a mounting sc rew.
3 Pull the b ulb out of the soc ket. Install a new b ul b .
4. Reinstall the p late and the lens. High mount stop light
OM-H0355
1. Remove the mounting sc rew c overs b y p rying on the ed g e with a
sc rewd river.
2. Remove the mounting sc rews using a p hillip s sc rew d river and then
remove the hig h mount stop lig ht c over.
3. Pull the b ulb out of the soc ket. Install a new b u lb .

10-544. Reinstall the c over.
5. Tig hten the mounting sc rews then reinstall the c o
vers.
NOTE Other bulbs may be difficult to replace. Have your SUBARU dealer
replace these bulbs if necessary.

11
Specifications Specifications11-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions 11-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine 11-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical system 11-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Capacities 11-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires 11-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel alignment 11-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses and circuits 11-4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse panel located behind the coin tray 11-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse panel located in the engine compartment 11-6 . . . . . . . . . . . . . . . . . . .
Bulb chart 11-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle identification 11-8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

11-2Specifications
These sp ec ific ations are sub jec t to c hang e without
notic e.
Dimensions
Overall leng th 175.2 in. (4,450 mm)
Overall wid th 68.3 in. (1,735 mm)
Overall heig ht 62.8 in. (1,595 mm)
Ground c learanc e 7.5 in. (190 mm)
Front tread 58.1 in. (1,475 mm)
Rear tread 57.1 in. (1,450 mm)
Wheelb ase 99.4 in. (2,525 mm)
Engine
Eng ine mod el EJ251
Eng ine typ e Horizontally op p osed , liq uid c ooled
4 c ylind er, 4 stroke g asoline eng ine
Eng ine d isp lac ement 149.9 c u in. (2,457 c c )
Bore 3.92 in. (99.5 mm)
Stroke 3.11 in. (79.0 mm)
Comp ression ratio 10.0 : 1
Firing ord er 1 - 3 - 2 - 4
Electrical system
Battery
Typ e MT: 55D23L, AT: 75D23L
Reserve c ap ac ity MT: 99 min., AT: 118 min.
Cold c ranking amp ere MT: 356 amp ., AT: 520 amp .
Alternator 12V - 75A
Sp ark p lug s RC10YC4 (Champ ion),
RC8YC4 (Champ ion),
BKR6E-11 (NGK),
K20PR-U11 (NIPPONDENSO)
Sp ark p lug g ap 0.039 to 0.043 in. (1.0 to 1.1 mm)
