2000 LEXUS GS400 Service Repair Manual

I04249

Combination Meter ECU Plate
Connector ºCºConnector ºDº
Connector ºEº
Connector ºJº Connector Gº
Connector ºFº
Connector ºTº Connector
ºOº, ºPº, ºQº, ºRº Connector ºLº Connector ºKºConnector ºDº Connector ºEº Connector ºJº Connector ºCºConnector ºFºConnctor ºGº Connector ºKº Connector ºLº
Connector ºTº
Q3 Q4Q1
Q2
O2
O1 O4O3
R3 R2R1
R4 P1
P2P3 P4
1 13 1 13 1 20
1 12133
112 112
Buzzer BE±86
± BODY ELECTRICALCOMBINATION METER
2387 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)

I04252
Engine
Coolant
Temperature
Receiver
Gauge
Tachometer
Speedometer
Fuel
Receiver
GaugeRight Turn Indicator Left Turn Indicator
ODO/TRIP Switch
RESET Switch TECOS+
TESIN+
TECOS± TESIN±
TACOS+
TASIN±
TASIN+
TACOS±
SPCOS±
SPSIN+
SPSIN±
SPCOS+
FUCOS±
FUSIN+TURN L
Power
Earth
TURN R
ODO/TRIP
RESET
HEAT±
Signal
Earth
Thermistor
SRS +B
C/C ±
C/C +
HEAT±
SRS +B Power
Earth O1
O2
O3
O4
P1
P2
P3
P4
Q1
Q2
Q3
Q4
R1
R2
R3G2 G1
G3
G4
G5
G6
G7
G8
L1
L2
L3
L4
L8
L12
K1
K3
K4
R4FUSIN±
FUCOS+C/C ±
C/C +K8
K12 Combination Meter ECU
Meter Circuit Plate ± 1
± BODY ELECTRICALCOMBINATION METER
BE±87
2388 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)

I04253

Meter Circuit Plate ± 2
Combination Meter ECU
SLIP Indicator
TRAC OFF Indicator
Window Washer Level Warning
ABS Warning
VSC Warning
Brake Fluid Level Warning
ECT SNOW Indicator
Low Oil Pressure Warning
ECT PWR Indicator
Discharge Warning
CRUISE MAIN Indicator
Seat Belt Warning
Rear Light Indicator
Headlight Leveling Indicator
SRS Warning
Open Door Warning
Fog Light IndicatorA/T 2 Indicaor
Engine Oil Level Indicator
Malfunction Indicator
Fuel Level Indicator
Headlight Indicator (USA)
Taillight Indicator (CANADA) ODO/
TRIP
Display
PanelIG+
SLIP
TRC OFF
WASHER
ABS
VSC
BRAKE
ECT SNOW
OIL P
ECT PWR
CHARGE
CRUISE
SEAT BELT
Rr LIGHT
HEAD LVL
AIRBAG
SRS +B
DOOR
FR FOG
COM1
SEG30
TEST1
TEST2
TEST3
GroundCHECK
ENG
IG+
FUEL
IG+
BEAM±
BEAM+ SRS +BTAIL A/T R
A/T L
A/T N
A/T D
OIL LVLDIM+
A/T 2
A/T 3
A/T 4F12
A/T PF11
F10
F9
F8
F5
F4
F2
F1
C7
C5
C3
D12
D8 E11
E10
E9
E8
E7
E6
J1
J33
D6
D4Hi±Beam Indicator
D2 E20
E19
E18
E17
E16
E15
E14
E13
E12
E3
E1 E5
E4A/T 3 Indicaor
A/T 4 Indicaor
A/T P Indicaor
A/T R Indicaor
A/T L Indicaor
A/T N Indicaor
A/T D Indicaor
T1
T2
T3
T4
~~
D10 BE±88
± BODY ELECTRICALCOMBINATION METER
2389 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)

BE0HJ±08
I04254
Meter Glass Decoration Plate Fuel Receiver Gauge
and Engine Coolant
Temperature Gauge SpeedometerTachometer
Cold Cathode Tube with PlateMeter Body ECU Plate Meter Cover
Buzzer
Telltale Light Assembly Connector
Clips
± BODY ELECTRICALCOMBINATION METER
BE±89
2390 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
COMPONENTS

BE0HK±04
I04255
I04256
I04257
I04258
BE±90
± BODY ELECTRICALCOMBINATION METER
2391 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
DISASSEMBLY
1. DISCONNECT TELLTALE LIGHT ASSEMBLY CON-
NECTOR
2. REMOVE METER COVER
(a) Disengage a claw.
(b) Remove the 4 screws and the meter cover.
3. REMOVE ECU PLATE
(a) Disconnect the 4 flat circuit plates.
(b) Remove the 16 clips and the ECU plate.
4. REMOVE BUZZER

I04259
I04260
I04261
I04262
I04263
± BODY ELECTRICALCOMBINATION METER
BE±91
2392 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
5. REMOVE METER GLASS
Remove the 3 screws and the meter glass.
6. REMOVE DECORATION PLATE
7. REMOVE SPEEDOMETER
Remove the 2 screws.
8. REMOVE TACHOMETER, FUEL RECEIVER GAUGE
AND ENGINE COOLANT TEMPERATURE RECEIVER
GAUGE
Remove the 4 screws.
9. REMOVE COLD CATHODE TUBE WITH PLATE

I04078
Connector ºBº Connector ºAº
BE0HL±03
BE±92
± BODY ELECTRICALCOMBINATION METER
2393 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
INSPECTION
1. INSPECT COMBINATION METER CIRCUIT
Connector disconnected:
Disconnect connector ºAº and ºBº from the combination meter
and inspect the connectors on the wire harness side as shown
in the table.
Tester connectionConditionSpecified condition
A1 ± GroundIgnition switch ONBattery positive voltage
A3 ± A4ConstantContinuity
A7 ± GroundLight control switch HEAD and headlight dimmer
switch HIContinuity
A8 ± Ground
B22 ± GroundConstantContinuity
A10 ± GroundWindow washer level warning switch Float downContinuity
B1 ± GroundIgnition switch ONBattery positive voltage
B4 ± B6ConstantApprox. 10 kW
B13 ± GroundConstantBattery positive voltage
B14 ± GroundConstantBattery positive voltage
B15 ± GroundLight control switch in HEADBattery positive voltage
If circuit is not as specified, wiring diagram and inspect the cir-
cuits connected to other parts.

I04079
Connector ºCº Connector ºDº
Connector ºFº Connector ºEº
Connector ºGº
1 131 13
1 201 12
± BODY ELECTRICALCOMBINATION METER
BE±93
2394 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
2. INSPECT COMBINATION METER CIRCUIT PLATE
Warning light circuit plate:
(a) Remove meter cover.
(b) Disconnect connectors ºCº, ºDº, ºEº, ºFº and ºGº from the
meter circuit plate and inspect the connectors on the wire
harness side as shown in the table.
Tester connectionCheck indicator lightSpecified condition
D10 (+) ± D12 (±)Fuel level warning lightContinuity
D6 (+) ± D8 (±)Headlight indiactor light (USA)
Taillight indiactor light (CANADA)Continuity
D2 (+) ± D4 (±)Hi±beam indicator lightContinuity
C3 (+) ± C7 (±)Engine oil level warning lightContinuity
C3 (+) ± C5 (±)Malfunction indicator lightContinuity
E19 (±) ± E20 (+)Slip warning lightContinuity
E18 (±) ± E20 (+)TRAC OFF indicator lightContinuity
E17 (±) ± E20 (+)Window washer level warning lightContinuity
E16 (±) ± E20 (+)ABS warning lightContinuity
E15 (±) ± E20 (+)VSC OFF indicator lightContinuity
E14 (±) ± E20 (+)Brake warning lightContinuity
E13 (±) ± E20 (+)ECT SNOW indicator lightContinuity
E12 (±) ± E20 (+)Low oil pressure warning lightContinuity
E11 (±) ± E20 (+)ECT PWR indicator lightContinuity
E10 (±) ± E20 (+)Discharge warning lightContinuity
E9 (±) ± E20 (+)CRUISE MAIN indicator lightContinuity
E8 (±) ± E20 (+)Seat belt warning lightContinuity
E7 (±) ± E20 (+)Rear Lights warning lightContinuity
E6 (±) ± E20 (+)Headlight leveling indiactorContinuity
E4 (+) ± E5 (±)SRS warning lightContinuity
E3 (±) ± E4 (+)Open door warning lightContinuity
F4 (±) ± F12 (+)A/T shift indicator light (L)Continuity
F11 (±) ± F12 (+)A/T shift indicator light (2)Continuity
F10 (±) ± F12 (+)A/T shift indicator light (3)Continuity
F8 (±) ± F12 (+)A/T shift indicator light (P)Continuity
