1999 DODGE NEON window

INSTALLATION
(1) Install new motor on regulator by positioning
motor gearbox so that it engages regulator sector
teeth.
(2) A slight rotational or rocking movement may
be necessary to bring three motor gearbox screw
holes into proper position.
(3) Install three gearbox screws and one tie down
bracket screw, if applicable. Tighten to 5.6 to 8 N´m
(50 to 70 in. lbs.) torque.
(4) Install regulator, using the switch, test opera-
tion of motor.
4 DOOR WINDOW MOTOR
REMOVAL
(1) Move the window so it is not in the full up or
down position, if possible.(2) Remove door trim panel, refer to Group 23
Body for removal procedures.
(3) Disconnect wiring connector from motor.
(4) Remove the three nuts attaching the window
regulator motor/housing to the door inner panel. This
will allow the motor/housing to be moved to the lower
door inner panel opening since the cables will flex
(Fig. 6).
(5) Turn the motor/housing to gain access to the
three nuts attaching the motor to the housing.
(6) Remove the three nuts attaching the motor to
the housing.
(7) Remove the motor from the housing. Be careful
not to pull the cable drum from the housing, as the
motor shaft will tend to pull the drum with it.INSTALLATION
For installation, reverse above procedures.
Fig. 5 2 Door Motor Removal
Fig. 6 4 Door Motor Removal
PLPOWER WINDOWS 8S - 3
REMOVAL AND INSTALLATION (Continued)

WIRING DIAGRAMS
CONTENTS
page page
AIR CONDITIONING-HEATER.......... 8W-42-1
AIRBAG SYSTEM................... 8W-43-1
ANTI-LOCK BRAKES................. 8W-35-1
AUDIO SYSTEMS................... 8W-47-1
CHARGING SYSTEM................. 8W-20-1
COMPONENT INDEX................. 8W-02-1
CONNECTOR/GROUND LOCATIONS..... 8W-90-1
CONNECTOR PIN-OUTS.............. 8W-80-1
FRONT LIGHTING................... 8W-50-1
FUEL/IGNITION SYSTEMS............ 8W-30-1
FUSE BLOCK....................... 8W-11-1
GENERAL INFORMATION............. 8W-01-1
GROUND DISTRIBUTION............. 8W-15-1
HORN/CIGAR LIGHTER............... 8W-41-1INSTRUMENT CLUSTER.............. 8W-40-1
INTERIOR LIGHTING................. 8W-44-1
POWER DISTRIBUTION.............. 8W-10-1
POWER DOOR LOCKS............... 8W-61-1
POWER MIRRORS.................. 8W-62-1
POWER SUNROOF.................. 8W-64-1
POWER WINDOWS.................. 8W-60-1
REAR LIGHTING.................... 8W-51-1
REAR WINDOW DEFOGGER........... 8W-48-1
SPLICE INFORMATION............... 8W-70-1
SPLICE LOCATIONS................. 8W-95-1
STARTING SYSTEM................. 8W-21-1
TURN SIGNALS..................... 8W-52-1
WIPERS........................... 8W-53-1
PLWIRING DIAGRAMS 8W - 1

8W-02 COMPONENT INDEX
Component Page
A/C Compressor Clutch..................8W-42
A/C Compressor Clutch Relay.............8W-42
A/C Cycling Switch.....................8W-42
A/C Heater Blower Motor................8W-42
A/C Heater Control.....................8W-42
A/C Pressure Switches...................8W-42
ABS Warning Lamp Relay................8W-35
Airbag Control Module...................8W-43
Airbags..............................8W-43
Antenna..............................8W-47
Ash Receiver Lamp.....................8W-44
Automatic Shut Down Relay..............8W-30
Back-Up Lamp Switch...................8W-51
Back-Up Lamps........................8W-51
Battery..............................8W-20
Battery Temperature Sensor..............8W-30
Blower Motor Resistor Block..............8W-42
Brake Warning Lamp Switch...........8W-40, 50
Camshaft Position Sensor................8W-30
Center High Mounted Stop Lamp..........8W-51
Cigar Lighter Relay.....................8W-41
Cigar Lighter/Power Outlet...............8W-41
Circuit Breakers.......................8W-11
Clockspring.....................8W-30, 41, 61
Clutch Pedal Position Switch...........8W-10, 21
Combination Flasher....................8W-52
Controller Anti-Lock Brake...............8W-35
Crankshaft Position Sensor...............8W-30
Data Link Connector....................8W-30
Daytime Running Lamp Module...........8W-50
Diode No. 1........................8W-15, 42
Diode No. 2......................8W-10, 11, 44
Diode No. 3......................8W-11,44,70
Dome Lamp...........................8W-44
Door Ajar Switches.....................8W-44
Door Jamb Switches....................8W-44
Door Lock Motors......................8W-61
Door Lock Motors......................8W-61
Door Lock Switches.....................8W-61
Duty Cycle Evap/Purge Solenoid...........8W-30
EGR Transducer Solenoid................8W-30
Engine Coolant Temperature Sensor........8W-30
Engine Oil Pressure Switch...............8W-40
Engine Starter Motor....................8W-21
Engine Starter Motor Relay...............8W-21
Fog Lamp Relays....................8W-50, 51
Fog Lamp Switches..................8W-50, 51
Fog Lamps.........................8W-50, 51
Fuel Injectors..........................8W-30
Fuel Pump Module.....................8W-30
Fuel Pump Relay.......................8W-30
Fuse Block............................8W-11Component Page
Fuses (FB)............................8W-11
Fuses (PDC)...........................8W-10
Fusible Link........................8W-20, 21
Generator.............................8W-20
Glove Box Lamp And Switch..............8W-44
Grounds..............................8W-15
Halo Lamp............................8W-44
Headlamp Dimmer And Optical Horn Switch .8W-50
Headlamp Leveling Motors...............8W-50
Headlamp Leveling Switch...............8W-50
Headlamp Switch.......................8W-50
Headlamps............................8W-50
High Speed Warning Module..............8W-40
Horn Relay...........................8W-41
Horn Switches.........................8W-41
Horns................................8W-41
IAT/Map Sensor........................8W-30
Idle Air Control Motor...................8W-30
Ignition Coil Pack......................8W-30
Ignition Switch........................8W-10
Illumination Lamps.....................8W-40
Immobilizer...........................8W-61
Immobilizer Engine Sensor............8W-30, 61
Indicator Lamps........................8W-40
Instrument Cluster.....................8W-40
Intermittent Wipe/Wash Switch............8W-53
Key-In Switch.........................8W-40
Knock Sensor..........................8W-30
License Lamps.........................8W-51
Map/Reading Lamps....................8W-44
Noise Supressor.....................8W-10, 30
Oxygen Sensors........................8W-30
Park Brake Switch...................8W-40, 50
Park/Neutral Position Switch...........8W-30, 51
Park/Turn Signal Lamps..............8W-50, 52
Power Distribution Center................8W-10
Power Folding Mirror Relay...............8W-62
Power Mirror Fuse Holder................8W-62
Power Mirrors.........................8W-62
Power Steering Pressure Switch...........8W-30
Power Sunroof Motor....................8W-64
Power Window Motors...................8W-60
Power Window Switches.................8W-60
Powertrain Control Module...............8W-30
PRNDL Lamp.........................8W-44
Radiator Fan Motor.....................8W-42
Radio................................8W-47
Rear Window Defogger..................8W-48
Rear Window Defogger Switch.............8W-48
Remote Keyless Entry Module.............8W-61
Remote Keyless Entry Program
Module Connector....................8W-61
PL8W - 02 COMPONENT INDEX 8W - 02 - 1

8W-10 POWER DISTRIBUTION
Component Page
A/C Compressor Clutch.............8W-10-14, 15
A/C Compressor Clutch Relay........8W-10-14, 15
Automatic Shut Down Relay............8W-10-16
Battery...........................8W-10-5, 6
Capacitor..........................8W-10-16
Circuit Breaker.......................8W-10-8
Clutch Pedal Position Switch.......8W-10-9, 10, 11
Controller Anti-Lock Brake.......8W-10-12, 14, 15
Data Link Connector..................8W-10-16
Diode No. 1......................8W-10-14, 15
Diode No. 2.........................8W-10-13
Dome Lamp........................8W-10-13
Downstream Heated Oxygen Sensor......8W-10-16
Engine Starter Motor..................8W-10-7
Engine Starter Motor Relay......8W-10-7, 9, 10, 11
Fog Lamp Relay.....................8W-10-17
Fuel Injector No. 1...................8W-10-16
Fuel Injector No. 2...................8W-10-16
Fuel Injector No. 3...................8W-10-16
Fuel Injector No. 4...................8W-10-16
Fuel Pump Module...................8W-10-16
Fuel Pump Relay....................8W-10-16
Fuse 1 (FB)..........................8W-10-8
Fuse 2 (FB)..........................8W-10-8
Fuse 2 (PDC).....................8W-10-5, 6, 7
Fuse 3 (FB)..........................8W-10-8
Fuse 3 (PDC).....................8W-10-5, 6, 8
Fuse 4 (FB)..........................8W-10-8
Fuse 5 (FB)..........................8W-10-8
Fuse 5 (PDC)....................8W-10-5, 6, 12
Fuse 6 (FB)..........................8W-10-8
Fuse 7 (FB)..........................8W-10-8
Fuse 8 (FB)..........................8W-10-8
Fuse 8 (PDC)....................8W-10-5, 6, 12
Fuse 9 (FB).......................8W-10-9, 10
Fuse 10 (FB)...................8W-10-9, 10, 11
Fuse 10 (PDC)...................8W-10-5, 6, 12
Fuse 11 (FB)...................8W-10-9, 10, 11
Fuse 11 (PDC)....................8W-10-5, 6, 7
Fuse 12 (FB)........................8W-10-11
Fuse 13 (PDC)...................8W-10-5, 6, 13
Fuse 14 (FB)...................8W-10-9, 10, 11
Fuse 15 (FB)...................8W-10-9, 10, 11
Fuse 16 (FB)...................8W-10-9, 10, 11Component Page
Fuse 16 (PDC).....................8W-10-6, 17
Fuse 18 (PDC)................8W-10-5, 6, 14, 15
Fuse 20 (PDC)................8W-10-5, 6, 14, 15
Fuse 21 (PDC)...................8W-10-5, 6, 16
Fuse 23 (PDC)................8W-10-5, 6, 14, 15
Fuse 25 (PDC)................8W-10-5, 6, 14, 15
Fuse Block...................8W-10-8, 9, 10, 11
G101...............................8W-10-9
G204...............................8W-10-7
Generator..........................8W-10-16
Glove Box Lamp And Switch............8W-10-13
Headlamp Switch.....................8W-10-8
High Speed Warning Module...........8W-10-13
Horn..............................8W-10-14
Horn No. 1.........................8W-10-15
Horn No. 2.........................8W-10-15
Horn Relay......................8W-10-14, 15
Ignition Coil Pack....................8W-10-16
Ignition Switch.............8W-10-7, 8, 9, 10, 11
Immobilizer......................8W-10-10, 11
Instrument Cluster.................8W-10-7, 13
Left Fog Lamp......................8W-10-17
Left Visor/Vanity Lamps...............8W-10-13
Map/Reading Lamps..................8W-10-13
Noise Supressor.....................8W-10-16
Power Distribution
Center.....8W-10-5, 6, 7, 8, 12, 13, 14, 15, 16, 17
Power Mirror Switch..................8W-10-13
Powertrain Control Module...........8W-10-9, 16
Radiator Fan Motor..................8W-10-12
Radio..............................8W-10-13
Rear Fog Lamp Switch................8W-10-17
Rear Window Defogger Switch..........8W-10-12
Right Fog Lamp.....................8W-10-17
Right Visor/Vanity Lamps..............8W-10-13
Solid State Fan Relay.................8W-10-12
Stop Lamp Switch.................8W-10-14, 15
Time Delay Relay....................8W-10-13
Time Out Relay......................8W-10-13
Trunk Lamp........................8W-10-13
Turn Signal/Hazard Switch..........8W-10-14, 15
Underhood Lamp....................8W-10-13
Upstream Heated Oxygen Sensor........8W-10-16
PL8W - 10 POWER DISTRIBUTION 8W - 10 - 1

BATTERY
1
22FUSE
40A
A2
12
PK/BK
40A
FUSE
3
3
4
A3
12
RD/WT
CENTER DISTRIBUTION
POWER7
88FUSE
30A 30A
FUSE
5
5
6
A16
14
GYA4
14
BK/RD
A0 8RD
12
1111FUSE
30A 20A
FUSE
18
18
1714
1313FUSE
10A 40A
FUSE
10
10
9
A20
12
RD/DGM1
18
PKA1
14
RD
19
2020FUSE
10A
L9
18
BK/WT
26
2525FUSE
15A 20A
FUSE
21
21
22
15A
FUSE
23
23
24
F32
18
PK/DB
IGNITION
SWITCH
TO TO
S213 SOLID
STATE
FAN
RELAY
TO
REAR
WINDOW
DEFOGGER
SWITCH
TO
TO
BRAKE ANTI-LOCK CONTROLLER
TO
S203A/C
COMPRESSOR
CLUTCH
RELAY
TO
IGNITION
SWITCH
TOTURN
SIGNAL/
HAZARD
SWITCH
TO
STOP
LAMP/
VEHICLE
SPEED
CONTROL
SWITCH
TOFUEL
PUMP/
ASD
RELAYS
(IN PDC)
TO
HORN
RELAY
(IN PDC)
TO
PK18 M1
UNDER
HOOD
LAMP
TO
(IN PDC)(IN PDC)
TO
RELAY MOTOR STARTERENGINE
S105
TO
RD/WT16 A14
(8W-20-2)
(8W-10-7) (8W-10-8) (8W-10-12)(8W-10-12)
(8W-10-7) (8W-10-14)(8W-10-13) (8W-10-12)(8W-10-14)
(8W-10-14) (8W-10-16) (8W-10-14)
PL8W-10 POWER DISTRIBUTION
EXCEPT BUILT-UP-EXPORT8W - 10 - 5
8194J988W-1

BATTERY
1
22FUSE
40A
A2
12
PK/BK
40A
FUSE
3
3
4
A3
12
RD/WT
CENTER DISTRIBUTION
POWER7
88FUSE
30A 30A
FUSE
5
5
6
A16
14
GYA4
14
BK/RD
A0 8RD
12
1111FUSE
30A
10A
FUSE
18
18
17
14
1313FUSE
10A 40A
FUSE
10
10
9
A20
12
RD/DGM1
18
PK
A1
14
RD
19
2020FUSE
10A
L9
18
BK/WT
26
2525FUSE
15A 20A
FUSE
21
21
22
15A
FUSE
23
23
24
F32
18
PK/DB
IGNITION
SWITCH
TO TO
S213 SOLID
STATE
FAN
RELAY
TO
REAR
WINDOW
DEFOGGER
SWITCH
TO
TO
BRAKE ANTI-LOCK CONTROLLER
TO
S203
A/C
COMPRESSOR
CLUTCH
RELAY
TO
IGNITION
SWITCH
TO
TURN
SIGNAL/
HAZARD
SWITCH
TO
STOP
LAMP
SWITCH
TO
FUEL
PUMP/
ASD
RELAYS
(IN PDC)
TO
HORN
RELAY
(IN PDC)
TO
15
1616FUSE
20A
TO
(IN PDC)RELAYLAMPFOG
73
PK18 M1
TO
LAMP UNDERHOOD
F61
18
WT/OR
REAR
FOG
LAMP
SWITCH
TO
A14
16
RD/WT
TO
S105
(IN PDC)(IN PDC)
TO
RELAY MOTOR STARTERENGINE
70
(8W-20-2)
(8W-10-7) (8W-10-8) (8W-10-12)(8W-10-12)
(8W-10-7)
(8W-10-15)(8W-10-13) (8W-10-12)
(8W-10-15)(8W-10-15) (8W-10-16) (8W-10-15)(8W-10-17)
8W - 10 - 6 8W-10 POWER DISTRIBUTION
BUILT-UP-EXPORTPL
J988W-18195

3FUSE40A
3
BATT A0
A3
12
RD/WT
3C102
A3
12
RD/WT
1FUSE15A3FUSE20A4FUSE10A
BLOCK
FUSE
A3
12
RD/WTA3
12
RD/WT
S213 POWER
DISTRIBUTION
CENTER
4
212324
8
SWITCH HEADLAMP IGNITION
SWITCH
4
3
0 2 1
BATT A2
A22
12
BK/OR
S217
8FUSE
10A
2825
10A
FUSE
5
27
25A
FUSE
7
26
10A
FUSE
6CIRCUIT
BREAKER
30A
41
42
A22
12
BK/OR
BK/OR12 A22
FUSE
BLOCK
2215A
FUSE
2
5
678
4321
3 ACC 1 START
2 RUN
0 OFF
BK/OR12 A22
WINDOWSPOWER
OTHER(8W-11-7)
(8W-11-8)
(8W-11-9)(8W-11-11) (8W-11-11)(8W-11-2)
(8W-11-3)
(8W-11-4) (8W-50-2)
(8W-50-3)
(8W-50-4) (8W-10-5)
(8W-10-6) (8W-10-7)
(8W-11-15)
(8W-11-16) (8W-11-12)
(8W-11-13)(8W-11-12)
(8W-11-13)(8W-11-12)
(8W-11-13)(8W-11-12)
(8W-11-13)(8W-11-2)
(8W-11-3)
(8W-11-4) (8W-10-5)
(8W-11-7)
(8W-11-8)
(8W-11-9) (8W-10-7)
8W - 10 - 8 8W-10 POWER DISTRIBUTIONPL
J988W-18197

5FUSE30A
5
A16
14
GY
4
3
BATT A0
1
RADIATOR
FAN
MOTOR
C25
14
LG
810 8FUSE
30A10FUSE40A
A4
14
BK/RD
4C102
A4
14
BK/RD
4
SWITCH DEFOGGER
WINDOW
REAR
25
CONTROLLER
ANTI-LOCK
BRAKE
A20
12
RD/DG
679
RELAY FAN
STATE
SOLIDCENTER DISTRIBUTION
POWER
(8W-42-5)
(8W-48-2)
(8W-48-3)(8W-35-2) (8W-42-5)(8W-10-5)
(8W-10-5)
(8W-10-6)
8W - 10 - 12 8W-10 POWER DISTRIBUTIONPL
J988W-18201
