Page 529 of 2062

Downloaded from www.Manualslib.com manuals search engine A00653
w/o Tachometer
w/ Tachometer
DI0VF−02
Q08498
TOYOTA Hand−Held Tester
DLC3
− DIAGNOSTICSAUTOMATIC TRANSMISSION
DI−265
1996 TOYOTA T100 (RM449U)
PRE−CHECK
1. DIAGNOSIS SYSTEM
(a) Description
When troubleshooting OBD II vehicles, the only dif-
ference from the usual troubleshooting procedure
is that you connect to the vehicle an OBD II scan
tool complying with SAE J1978 or TOYOTA hand−
held tester, and read off various data output from
the vehicle’s ECM.
OBD II regulations require that the vehicle’s on−
board computer lights up the Malfunction Indicator
Lamp (MIL) on the instrument panel when the com-
puter detects a malfunction in the computer itself or
in drive system components which affect vehicle
emissions. In addition to the MIL lighting up when
a malfunction is detected, the applicable DTCs pre-
scribed by SAE J2012 are recorded in the ECM
memory.
(3RZ−FE: See page DI−13)
(5VZ−FE: See page DI−140)
If the malfunction only occurs in 3 trips, the MIL goes off but the
DTCs remain recorded in the ECM memory.
To check the DTCs, connect an OBD II scan tool or
TOYOTA hand−held tester to DLC3 on the vehicle.
The OBD II scan tool or TOYOTA hand−held tester
also enables you to erase the DTCs and check
freeze frame data and various forms of engine data
(For instruction book).
DTCs include SAE controlled codes and Manufac-
turer controlled codes.
SAE controlled codes must be set as prescribed by
the SAE, while Manufacturer controlled codes can
be set freely by the manufacturer within the pre-
scribed limits (See DTC chart on page DI−276).
Page 530 of 2062

Downloaded from www.Manualslib.com manuals search engine N09214
DI−266
− DIAGNOSTICSAUTOMATIC TRANSMISSION
1996 TOYOTA T100 (RM449U)
The diagnosis system operates in normal mode
during normal vehicle use, and also has a check
mode for technicians to simulate malfunction symp-
toms and perform troubleshooting. Most DTCs use
2 trip detection logic(*) to prevent erroneous detec-
tion. By switching the ECM to check mode when
troubleshooting, the technician can cause the MIL
to light up and for a malfunction that is only detected
once or momentarily (TOYOTA hand−held tester)
(See page DI−265).
*2 trip detection logic:
When a logic malfunction is first detected, the mal-
function is temporarily stored in the ECM memory.
If the same malfunction is detected again during the
2nd test drive, this 2nd detection causes the MIL to
light up.
(b) Inspect the DLC3.
The vehicle’s ECM uses the V.P.W. (Variable Pulse Width)
for communication to comply with SAE J1850. The termi-
nal arrangement of DLC3 complies with SAE J1962 and
matches the V.P.W. format.
Terminal No.Connection / Voltage or ResistanceCondition
2Bus Line / Pulse generationDuring communication
4Chassis Ground ↔ Body / 1 Ω or lessAlways
5Signal Ground ↔ Body / 1 Ω or lessAlways
16Battery Positive ↔ Body / 9 − 14 VAlways
HINT:
If your display shows ”UNABLE TO CONNECT TO VEHICLE”
when you have connected the cable of OBD II scan tool or TOY-
OTA hand−held tester to DLC3, turned the ignition switch ON
and operated the scan tool, there is a problem on the vehicle
side or tool side.
If communication is normal when the tool is connected to
another vehicle, inspect DLC3 on the original vehicle.
If communication is still not possible when the tool is con-
nected to another vehicle, the problem is probably in the
tool itself, so consult the Service Department listed in the
tool’s instruction manual.
Page 531 of 2062

Downloaded from www.Manualslib.com manuals search engine A00653
w/o Tachometer
w/ Tachometer
Q08498
TOYOTA Hand−Held Tester
DLC3
− DIAGNOSTICSAUTOMATIC TRANSMISSION
DI−267
1996 TOYOTA T100 (RM449U)
2. INSPECT DIAGNOSIS (NORMAL MODE)
(a) Check the MIL.
(1) The MIL comes on when the ignition switch is turned
ON and the engine is not running.
HINT:
If the MIL does not light up, troubleshoot the combination meter
(See page BE−38).
(2) When the engine is started, the MIL should go off.
If the lamp remains on, the diagnosis system has
detected a malfunction or abnormality in the sys-
tem.
(b) Check the DTC.
NOTICE:
TOYOTA hand−held tester only: When the diagnostic sys-
tem is switched from normal mode to check mode, it erases
all DTCs and freezed frame data recorded in normal mode.
So before switching modes, always check the DTCs and
freezed frame data, and note them down.
(1) Prepare an OBD II scan tool (complying with SAE
J1978) or TOYOTA hand−held tester.
(2) Connect the OBD II scan tool or TOYOTA hand−
held tester to DLC3 at the lower of the instrument
panel.
(3) Turn the ignition switch ON and turn the OBD II scan
tool or TOYOTA hand−held tester switch ON.
(4) Use the OBD II scan tool or TOYOTA hand−held
tester to check the DTCs and freezed frame data
and note them down (For operating instructions,
see the OBD II scan tool’s instruction book).
(5) See page DI−276 to confirm the details of the
DTCs.
NOTICE:
When simulating symptoms with an OBD II scan tool (ex-
cluding TOYOTA hand−held tester) to check the DTCs, use
normal mode. For codes on the DTCs chart subject to ”2
trip detection logic”, turn the ignition switch off after the
symptoms have been simulated the 1st time. Then repeat
the simulation process again. When the program has been
simulated twice, the MIL lights up and the DTCs are re-
corded in the ECM.
Page 532 of 2062

Downloaded from www.Manualslib.com manuals search engine FI3605
ON
OFFFlashing
0.13 Second
DI−268
− DIAGNOSTICSAUTOMATIC TRANSMISSION
1996 TOYOTA T100 (RM449U)
3. INSPECT DIAGNOSIS (CHECK MODE)
HINT:
TOYOTA hand−held tester only: Compared to the normal
mode, the check mode has high sensing ability to detect mal-
functions. Furthermore, the same diagnostic items which are
detected in Normal mode can also be detected in Check mode.
(a) Check the DTC.
(1) Check the initial conditions.
Battery positive voltage 11 V or more
Throttle valve fully closed
Transmission in P position
Air conditioning switched off
(2) Turn the ignition switch OFF.
(3) Prepare a TOYOTA hand−held tester.
(4) Connect the TOYOTA hand−held tester to DLC3 at
the lower of the instrument panel.
(5) Turn the ignition switch ON and switch the TOYOTA
hand−held tester ON.
(6) Switch the TOYOTA hand−held tester from Normal
mode to Check mode (Check that the MIL flashes).
(7) Start the engine (MIL goes out after the engine
starts).
(8) Simulate the conditions of the malfunction de-
scribed by the customer.
NOTICE:
Leave the ignition switch ON until you have checked the
DTCs, etc.
(9) After simulating the malfunction conditions, use the
TOYOTA hand−held tester diagnosis selector to
check the DTCs and freeze frame data, etc.
HINT:
Take care not to turn the ignition switch OFF, as turning it off
switches the diagnosis system from Check mode to Normal
mode, so all DTCs, etc. are erased.
(10) After checking the DTC, inspect the applicable cir-
cuit.
(b) Clear the DTC.
The following actions will erase the DTC and freezed
frame data. Operating an OBD II scan tool (complying
with SAE J1978) or TOYOTA hand−held tester to erase
the codes (See the OBD II scan tool’s instruction book for
operating instructions.).
NOTICE:
If the TOYOTA hand−held tester switches the ECM from
normal mode to check mode or vice−versa, or if the ignition
switch is turned from ON to ACC or OFF during check
mode, the DTCs and freezed frame data will be erased.
Page 533 of 2062

Downloaded from www.Manualslib.com manuals search engine − DIAGNOSTICSAUTOMATIC TRANSMISSION
DI−269
1996 TOYOTA T100 (RM449U)
4. ROAD TEST
NOTICE:
Perform the test at normal operating ATF temperature 50 − 80°C (122 − 176°F).
(a) D position test
Shift into the D position and fully depress the accelerator pedal and and check the following points:
(1) Check up−shift operation.
1 → 2, 2 → 3 and 3 → O/D up−shift takes place, at the shift point shown in the automatic shift
schedule (See page SS−49).
HINT:
There is no O/D up−shift or lock−up when the coolant temperature is below 60°C (140°F).
Evaluation:
ProblemPossible cause
If there is no 1→2 up−shiftShift solenoid valve No.2 is stuck
1−2 shift valve is stuck
If there is no 2 →3 up−shiftShift solenoid valve No.1 is stuck
2−3 shift valve is stuck
If there is no 3 →O/D up−shift3−4 shift valve is stuck
If the shift point is defectiveThrottle valve, 1−2 shift valve, 2−3 shift valve, etc. are defective
If the lock up is defectiveShift solenoid valve SL is stuck
Lock−up relay valve is stuck
(2) Check for shift shock and slip.
Check for shock and slip at the 1 → 2, 2 → 3 and 3 → O/D up−shifts.
Evaluation:
ProblemPossible cause
If the shock is excessive
Line pressure is too high
Accumulator is defective
Check ball is defective
(3) Check for abnormal noises and vibration.
Run at the D position lock−up or O/D gear and check for abnormal noises and vibration.
HINT:
The check for the cause of abnormal noises and vibration must be done very thoroughly as it could also be
due to loss of balance in the differential torque converter clutch, etc.
(4) Check kick−down operation.
While running in the D position, 2nd, 3rd and O/D gears, check to see that the possible kick−down
vehicle speed limits for 2 → 1, 3 → 2 and O/D → 3 kick−downs conform to those indicated on
the automatic shift schedule (See page SS−49).
(5) Check abnormal shock and slip at kick−down.
(6) Check the lock−up mechanism.
Drive in D position, O/D gear, at a steady speed (lock−up ON).
Lightly depress the accelerator pedal and check that there is lock−up.
If there is a big jump in engine speed, there is no lock−up.
(b) 2 position test
Shift into the 2 position and fully depress the accelerator pedal and check the following points:
(1) Check up−shift operation.
Check to see that the 1 → 2 up−shift takes place and that the shift point conforms to the automatic
shift schedule (See page SS−49).
Page 534 of 2062

Downloaded from www.Manualslib.com manuals search engine AT3417
OK if hot
Add if hot DI−270
− DIAGNOSTICSAUTOMATIC TRANSMISSION
1996 TOYOTA T100 (RM449U)
HINT:
There is no O/D up−shift and lock−up in the 2 position.
(2) Check engine braking.
While running in the 2 position and 2nd gear, release the accelerator pedal and check the engine
braking effect.
Evaluation:
ProblemPossible cause
If there is no engine braking effect2nd coast brake defective
(3) Check for abnormal noises during acceleration and deceleration, and for shock at up−shift and
down−shift.
(c) L position test
Shift into the 2 position and fully depress the accelerator pedal and check the following points:
(1) Check no up−shift.
While running in the L position, check that there is no up−shift to 2nd gear.
(2) Check engine braking.
While running in the L position, release the accelerator pedal and check the engine braking ef-
fect.
Evaluation:
ProblemPossible cause
If there is no engine braking effect1st and reverse brake is defective
(3) Check for abnormal noises during acceleration and deceleration.
(d) R position test
Shift into the R position and fully depress the accelerator pedal and check for slipping.
CAUTION:
Before conducting this test ensure that the test area is free from personnel and obstruction.
(e) P position test
Stop the vehicle on a grade (more than 5°) and after shifting into the P position, release the parking
brake. Then, check to see that the parking lock pawl holds the vehicle in place.
5. BASIC INSPECTION
(a) Check the fluid level.
HINT:
Drive the vehicle so that the engine and transmission are
at normal operating temperature.
Fluid temp.: 70 − 80°C (158 − 176°F)
Only use the COOL range on the dipstick as a rough refer-
ence when the fluid is replaced or the engine does not
run.
(1) Park the vehicle on a level surface and set the park-
ing brake.
(2) With the engine idling and the brake pedal de-
pressed, shift the shift lever into all positions from P
to L position and return to P position.
(3) Pull out the dipstick and wipe it clean.
(4) Push it back fully into the pipe.
(5) Pull it out and check that the fluid level is in the HOT
range.
Page 535 of 2062

Downloaded from www.Manualslib.com manuals search engine AT1347
AT6683
AT3417
OK if hot
Add if hot
AT4252
0 − 1 mm (0 − 0.04 in.)
Q03104No.1 Gear Shifting Rod
− DIAGNOSTICSAUTOMATIC TRANSMISSION
DI−271
1996 TOYOTA T100 (RM449U)
If the level is at the low side, add new fluid.
Fluid type: ATF DEXRON®II
NOTICE:
Do not overfill.
(b) Check the fluid condition.
If the fluid smells burnt or is black, replace it.
(c) Replace the ATF.
(1) Remove the drain plug and drain the fluid.
(2) Reinstall the drain plug securely.
(3) With the engine OFF, add new fluid through the oil
filler pipe.
Fluid type: ATF DEXRON®II
Capacity:
A340E: 1.6 liters (1.7 US qts, 1.4 Imp. qts)
A340F: 2.0 liters (2.1 US qts, 1.8 Imp. qts)
(4) Start the engine and shift the shift lever into all posi-
tions from P to L position and then shift into P posi-
tion.
(5) With the engine idling, check the fluid level. Add
fluid up to the COOL level on the dipstick.
(6) Check the fluid level at the normal operating tem-
perature, 70 − 80°C (158 − 176°F), and add as nec-
essary.
NOTICE:
Do not overfill.
(d) Check the fluid leaks.
Check for leaks in the transmission.
If there are leaks, it is necessary to repair or replace O−
rings, FIPGs, oil seals, plugs or other parts.
(e) INSPECT AND ADJUST THROTTLE CABLE
(1) Check that the accelerator pedal is fully released.
(2) Check that the inner cable is not slack.
(3) Measure the distance between the outer cable end
and stopper on the cable.
Standard distance: 0 − 1 mm (0 − 0.04 in.)
If the distance is not standard, adjust the cable by the adjusting
nuts.
(f) Inspect and adjust the shift lever position.
When shifting the shift lever from the N position to other
positions, check that the lever can be shifted smoothly
and accurately to each position and that the position indi-
cator is not aligned with the correct position.
If the indicator is not aligned with the correct position, carry out
the following adjustment procedures.
(1) Remove the nut on the No.1 gear shifting rod.
(2) Push the No.1 gear shifting rod fully downward.
Page 536 of 2062

Downloaded from www.Manualslib.com manuals search engine Q06793
N
R
P
AT5115
Neutral Basic line
Bolt
Groove
DI−272
− DIAGNOSTICSAUTOMATIC TRANSMISSION
1996 TOYOTA T100 (RM449U)
(3) Return the No.1 gear shifting rod 2 notches to N
position.
(4) Set the shift lever to N position.
(5) While holding the shift lever lightly toward the R
position side, adjust the No.1 gear shifting rod nut.
(6) Tighten the No.1 gear shifting rod nut.
Torque: 25 N·m (260 kgf·cm, 19 ft·lbf)
(7) Start the engine and make sure that the vehicle
moves forward when shifting the lever from the N to
D position and reverses when shifting it to the R
position.
(g) Inspect and adjust the park/neutral position.
Check that the engine can be started with the shift lever
only in the N or P position, but not in other positions.If it
is not as stated above, carry out the following adjustment
procedure.
(1) Loosen the park/neutral position switch bolt and set
the shift lever to the N position.
(2) Align the groove and neutral basic line.
(3) Hold in position and tighten the bolt.
Torque: 13 N·m (130 kgf·cm, 10 ft·lbf)
(h) Check the idle speed.
Idle speed (In N position and air conditioner OFF):
3RZ−FE: 700 ± 50 rpm
5VZ−FE: 700 ± 50 rpm
6. MECHANICAL SYSTEM TESTS
(a) Measure the stall speed.
The object of this test is to check the overall performance of the transmission and engine by measuring
the stall speeds in the D and R positions.
NOTICE:
Do the that at normal operating fluid temperature 50 − 80°C (122 − 176°F)
Do not continuously run this test longer than 5 seconds.
To ensure safety, conduct this test in a wide, clear, level area which provides good traction.
The stall test should always be carried out in pairs. One technician should observe the condi-
tions of wheels or wheel stoppers outside the vehicle while the other is doing the test.
(1) Chock the 4 wheels.
(2) Connect an OBD II scan tool or TOYOTA hand−held tester to DLC3.
(3) Fully apply the parking brake.
(4) Keep your left foot pressed firmly on the brake pedal.
(5) Start the engine.
(6) Shift into the D position. Press all the way down on the accelerator pedal with your right foot.
Quickly read the stall speed at this time.
Stall speed:
3RZ−FE: 1,950 ± 150 rpm
5VZ−FE: 2,150 ± 150 rpm
(7) Do the same test in R position.
Stall speed:
3RZ−FE: 1,950 ± 150 rpm
5VZ−FE: 2,150 ± 150 rpm
