Page 41 of 2062

TOYOTA T100 1996 Factory Service Manual Downloaded from www.Manualslib.com manuals search engine MA002−05
MA−2
− MAINTENANCEINSIDE VEHICLE
37 Author: Date:
1996 TOYOTA T100 (RM449U)
INSIDE VEHICLE
GENERAL MAINTENANCE
These are mai

Downloaded from www.Manualslib.com manuals search engine MA002−05
MA−2
− MAINTENANCEINSIDE VEHICLE
37 Author: Date:
1996 TOYOTA T100 (RM449U)
INSIDE VEHICLE
GENERAL MAINTENANCE
These are maintenance and inspection items which are considered to be the owner’s responsibility.
They can be done by the owner or they can have them done at a service shop.
These items include those which should be checked on a daily basis, those which, in most cases, do not
require (special) tools and those which are considered to be reasonable for the owner to do.
Items and procedures for general maintenance are as follows.
1. GENERAL NOTES
Maintenance items may vary from country to country. Check the owner’s manual supplement in which
the maintenance schedule is shown.
Every service item in the periodic maintenance schedule must be performed.
Periodic maintenance service must be performed according to whichever interval in the periodic main-
tenance schedule occurs first, the odometer reading (miles) or the time interval (months).
Maintenance service after the last period should be performed at the same interval as before unless
otherwise noted.
Failure to do even one item can cause the engine to run poorly and increase exhaust emissions.
2. LIGHTS
(a) Check that the headlights, stop lights, taillights, turn signal lights, and other lights are all working.
(b) Check the headlight aim.
3. WARNING LIGHTS AND BUZZERS
Check that all warning lights and buzzers function properly.
4. HORN
Check that it is working.
5. WINDSHIELD GLASS
Check for scratches, pits or abrasions.
6. WINDSHIELD WIPER AND WASHER
(a) Check operation of the wipers and washer.
(b) Check that the wipers do not streak.
7. WINDSHIELD DEFROSTER
Check that air comes out from the defroster outlet when operating the heater or air conditioner.
8. REAR VIEW MIRROR
Check that it is mounted securely.
9. SUN VISORS
Check that they move freely and are mounted securely.
10. STEERING WHEEL
Check that it has the specified freeplay. Be alert for changes in steering condition, such as hard steering,
excessive freeplay or strange noises.
11. SEATS
(a) Check that the seat adjusters operate smoothly.
(b) Check that all latches lock securely in any position.
(c) Check that the head restraints move up and down smoothly and that the locks hold securely in any
latch position.
(d) For fold−down seat backs, check that the latches lock securely.
12. SEAT BELTS
(a) Check that the seat belt system such as the buckles, retractors and anchors operate properly and
smoothly.
(b) Check that the belt webbing is not cut, frayed, worn or damaged.

Page 42 of 2062

TOYOTA T100 1996 Factory Service Manual Downloaded from www.Manualslib.com manuals search engine − MAINTENANCEINSIDE VEHICLE
MA−3
38 Author: Date:
1996 TOYOTA T100 (RM449U)
13. ACCELERATOR PEDAL
Check the pedal for smooth operation

Page 43 of 2062

TOYOTA T100 1996 Factory Service Manual Downloaded from www.Manualslib.com manuals search engine MA003−05
MA−4
− MAINTENANCEUNDER HOOD
39 Author: Date:
1996 TOYOTA T100 (RM449U)
UNDER HOOD
GENERAL MAINTENANCE
1. GENERAL NOTES
Mai

Downloaded from www.Manualslib.com manuals search engine MA003−05
MA−4
− MAINTENANCEUNDER HOOD
39 Author: Date:
1996 TOYOTA T100 (RM449U)
UNDER HOOD
GENERAL MAINTENANCE
1. GENERAL NOTES
Maintenance items may vary from country to country. Check the owner’s manual supplement in which
the maintenance schedule is shown.
Every service item in the periodic maintenance schedule must be performed.
Periodic maintenance service must be performed according to whichever interval in the periodic main-
tenance schedule occurs first, the odometer reading (miles) or the time interval (months).
Maintenance service after the last period should be performed at the same interval as before unless
otherwise noted.
Failure to do even one item can cause the engine to run poorly and increase exhaust emissions.
2. WINDSHIELD WASHER FLUID
Check that there is sufficient fluid in the tank.
3. ENGINE COOLANT LEVEL
Check that the coolant level is between the FULL and LOW lines on the see−through reservoir.
4. RADIATOR AND HOSES
(a) Check that the front of the radiator is clean and not blocked with leaves, dirt or bugs.
(b) Check the hoses for cracks, kinks, rot or loose connections.
5. BATTERY ELECTROLYTE LEVEL
Check that the electrolyte level of all battery cells is between the upper and lower level lines on the case.
6. BRAKE AND CLUTCH FLUID LEVELS
Check that the brake and clutch fluid levels are near the upper level line on the see−through reservoirs.
7. ENGINE DRIVE BELTS
Check all drive belts for fraying, cracks, wear or oiliness.
8. ENGINE OIL LEVEL
Check the level on the dipstick with the engine turned off.
9. POWER STEERING FLUID LEVEL
(a) Check the level on the dipstick.
(b) The level should be in the HOT or COLD range depending on the fluid temperature.
10. AUTOMATIC TRANSMISSION FLUID LEVEL
(a) Park the vehicle on a level surface.
(b) With the engine idling and the parking brake applied, shift the selector into all positions from the P to
L, and then shift into the P position.
(c) Pull out the dipstick and wipe off the fluid with a clean rag. Re−insert the dipstick and check that the
fluid level is in the HOT range.
(d) Do this check with the fluid at normal driving temperature (70 − 80°C, 158 − 176°F).
HINT:
Wait until the engine cools down (approx. 30 min.) before checking the fluid level after extended driving at
high speeds, in hot weather, in heavy traffic or pulling a trailer.
11. EXHAUST SYSTEM
(a) Visually inspect for cracks, holes or loose supports.
(b) If any change in the sound of the exhaust or smell of the exhaust fumes is noticed, have the cause
located and corrected.

Page 44 of 2062

TOYOTA T100 1996 Factory Service Manual Downloaded from www.Manualslib.com manuals search engine MA004−03
P08488
Back Front
− MAINTENANCEENGINE
MA−5
40 Author: Date:
1996 TOYOTA T100 (RM449U)
ENGINE
INSPECTION
HINT:
Inspect these

Page 45 of 2062

TOYOTA T100 1996 Factory Service Manual Downloaded from www.Manualslib.com manuals search engine MA−6
− MAINTENANCEENGINE
41 Author: Date:
1996 TOYOTA T100 (RM449U)
10. INSPECT FUEL LINES AND CONNECTIONS
Visually inspect the fuel li

Page 46 of 2062

TOYOTA T100 1996 Factory Service Manual Downloaded from www.Manualslib.com manuals search engine MA0055
MA014−01
− MAINTENANCEBRAKE
MA−7
42 Author: Date:
1996 TOYOTA T100 (RM449U)
BRAKE
INSPECTION
1. INSPECT BRAKE LINE PIPES AND H

Page 47 of 2062

TOYOTA T100 1996 Factory Service Manual Downloaded from www.Manualslib.com manuals search engine B02088
MA015−02
B02089
B02090
MA−8
− MAINTENANCECHASSIS
43 Author: Date:
1996 TOYOTA T100 (RM449U)
CHASSIS
INSPECTION
1. INSPECT STEE

Page 48 of 2062

TOYOTA T100 1996 Factory Service Manual Downloaded from www.Manualslib.com manuals search engine B02091
Z04824
A/T
OK if coolOK if hot
Add if coolAdd if hot
B02092
B02093
− MAINTENANCECHASSIS
MA−9
44 Author: Date:
1996 TOYOTA T100 (
