BR−60
− BRAKEABS ACTUATOR
1665 Author: Date:
1996 TOYOTA T100 (RM449U)
(d) Push the REAR switch while pressing the POWER
SWITCH, and check that the brake pedal cannot be de-
pressed.
NOTICE:
Do not keep the POWER SWITCH pushed down for more
than 10 seconds.
(e) Release the REAR switch then the POWER SWITCH,
and check that the brake pedal can be depressed.
(f) Push and hold in the MOTOR switch for a few seconds,
and check that the pedal returns.
(g) Release the brake pedal.
(h) Push and hold in the MOTOR switch for a few seconds.
(i) Depress the brake pedal and hold it for about 15 seconds.
As you hold the pedal down, push the MOTOR switch for
a few seconds. Check that the brake pedal does not pul-
sate.
(j) Release the brake pedal.
7. PUSH MOTOR SWITCH
(a) Push and hold on the MOTOR switch for a few seconds.
(b) Stop the engine.
8. DISCONNECT ACTUATOR CHECKER (SST) FROM
ACTUATOR
Remove the ”SHEET L” (SST) and disconnect the actuator
checker (SST) and sub−wire harness (SST) from the actuator,
control relay and body side wire harness.
SST 09990−00150, 09990−00200, 09990−00210,
09990−00370
9. CONNECT CONNECTOR TO ACTUATOR
10. CLEAR DTC (See page DI−321)

Downloaded from www.Manualslib.com manuals search engine BR09Z−02
F14858
− BRAKEABS ACTUATOR
BR−61
1996 TOYOTA T100 (RM449U)
COMPONENTS

Downloaded from www.Manualslib.com manuals search engine BR0A0−02
F14859
BR−62
− BRAKEABS ACTUATOR
1996 TOYOTA T100 (RM449U)
REMOVAL
1. DISCONNECT BRAKE LINES
Using SST, disconnect the 5 brake lines from the ABS actuator.
SST 09023−00100
Torque: 15 N·m (155 kgf·cm, 11 ft·lbf)
2. REMOVE ABS ACTUATOR ASSEMBLY
(a) Disconnect the 2 connectors from the actuator.
(b) Remove the 2 bolts, 2 nuts and ABS actuator assembly.
Torque: 19 N·m (195 kgf·cm, 14 ft·lbf)
3. REMOVE ABS ACTUATOR
(a) Remove the 3 nuts and ABS actuator from the actuator
bracket.
Torque: 5.4 N·m (55 kgf·cm, 48 in.·lbf)
(b) Remove the 3 holders and cushions from the ABS actua-
tor.

Downloaded from www.Manualslib.com manuals search engine BR0A1−01
− BRAKEABS ACTUATOR
BR−63
1996 TOYOTA T100 (RM449U)
INSTALLATION
Installation is in the reverse order of removal (See page BR−62).
1. AFTER INSTALLATION, FILL BRAKE RESERVOIR BRAKE FLUID AND BLEED BRAKE SYSTEM
(See page BR−4)
2. CHECK FOR LEAKS.

Downloaded from www.Manualslib.com manuals search engine BR0A2−04
R14754
4WD:
2WD:
Speed Sensor
Sensor Rotor
N·m (kgf·cm, ft·lbf) : Specified torque
5.0 (51, 44 in.·lbf)
8.0 (82, 71in.·lbf)
Speed Sensor
8.0 (82, 71in.·lbf)
5.0 (51, 44 in.·lbf)
BR−64
− BRAKEFRONT SPEED SENSOR
1669 Author: Date:
1996 TOYOTA T100 (RM449U)
FRONT SPEED SENSOR
COMPONENTS

Downloaded from www.Manualslib.com manuals search engine BR0A3−01
R07884
− BRAKEFRONT SPEED SENSOR
BR−65
1996 TOYOTA T100 (RM449U)
REMOVAL
1. DISCONNECT SPEED SENSOR CONNECTOR
2. REMOVE SPEED SENSOR
(a) 4WD:
Remove the 3 clamp bolts holding the sensor harness
from the frame, upper arm and steering knuckle.
(b) 2WD:
Remove the 2 clamp bolts holding the sensor harness
from the frame and upper arm.
Torque: 5.0 N·m (51 kgf·cm, 44 in.·lbf)
(c) Remove the speed sensor from the steering knuckle.
Torque: 8.0 N·m (82 kgf·cm, 71 in.·lbf)

Downloaded from www.Manualslib.com manuals search engine BR0A4−03
BR−66
− BRAKEFRONT SPEED SENSOR
1996 TOYOTA T100 (RM449U)
INSTALLATION
Installation is reverse in the order of removal (See page BR−65).
AFTER INSTALLATION, CHECK SPEED SENSOR SIGNAL (See page DI−341)

Downloaded from www.Manualslib.com manuals search engine BR0A5−04
R14755
Speed Sensor
Sensor Rotor
N·m (kgf·cm, ft·lbf) : Specified torque
13 (130, 9)
8.0 (82, 71 in.·lbf)
− BRAKEREAR SPEED SENSOR
BR−67
1672 Author: Date:
1996 TOYOTA T100 (RM449U)
REAR SPEED SENSOR
COMPONENTS
