AUTOMATIC TRANSAXLE - Troubleshooting23-59
ring
brake
CONVERTER STALL TEST
Stall test consist of determining maximum engine
speed obtained at full throttle in “D” and “R”
positions. This test checks torque converter stator
overrunning clutch operation, and holding ability of
transaxle clutches and low-reserve brake.
Caution
During this test, make sure that no one stand in
front of or behind vehicle.
1. Check transaxle fluid level. Fluid should be at
normal operating temperature [70-80°C (160-
18O”F)j. Engine coolant should also be at normal
operating temperature
[80-90°C (180-19O”F)l.
2. Apply chocks to both rear wheels.
3. Attach engine tachometer.
4. Apply parking and service brakes fully.
5. Start engine.
6. With selector lever in “D” position, depress
accelerator pedal fully to read engine maximum
rpm. Do not hold throttle wide open any longer
than is necessary to obtain maximum engine
rpm reading, and never longer than 5 seconds at
a time. If more than one stall test is required,
operate engine at approximatey 1,000 rpm in
TRANSAXLE CONTROL
neutral for 2 minutes to cool transaxle fluid
between tests.
Stall speed: 1,800-3,200
rpm
7.Place selector lever to “R” position and perform
stall test by the same procedure as in foregoing
item.
Stall Speed Above Specification in “D”
If stall speed is higher than specification, rear clutch
or overrunning clutch of transaxle is slipping. In this
case, perform hydraulic test to locate cause of
slippage.
Stall Speed Above Specification in “I?”
If stall speed is higher than specification, front
clutch of transaxle or low-reverse brake is slipping. In this case, perform hydraulic test to locate cause
of slippage.
Stall Speed Below Specification in “D” and “R”
If stall speed is lower than specification, insufficient
engine output or faulty torque converter is sus-
pected. Check for engine misfiring, ignition timing,
valve clearance etc. If these are good, torque
converter is faulty. Svmotom
Probable cause
Remedy
Selector lever operation is Incorrect adjustment of sleeve
1 Adjust
stiff
Starter motor does not oper-
Incorrect adjustment of control cable
Excessive wear of detent plate
Worn contact surfaces of pushbutton and sleeve
Malfunction in park/neutral position switch Replace
Replace
ate with the selector lever in
the
“N” or “P” position Malfunction of starter relayI
Incorrect adjustment of control cable
AdjustI
W
ill not shift to 4-speed
( Malfunction of OD switch) ReplaceI
TSB Revision

SERVICE BRAKES - Hydraulic Unit 35-121
HYDRAULIC UNIT hl35OXAB
L
IEMOVAL AND INSTALLATION


Flared brake line nuts
I13-17 NmA9- 12ftlbs.I@
9-14 Nm7-10
ft.lbs.6
i
17-26 Nm12-19
ft.lbs.
_ _
17-26 Nm/12-19 ft.lbs.
\
17-26 Nm /12-19 ft.lbs.
Removal Steps
1.Dust shield
2. Engine coolant reservoir
3. Engine coolant reservoir bracket
I)+ 4. Brake hose connectionI)+ 5. Brake tube connection
*I)6. Relay box cover7.Connector
8. Bracket installation bolt
l + 9. Bracket A
+*10. Hydraulic unit11.Bracket D
12.Bracket B13.Bracket C
16.
Motor relay17.Valve relay Pre-removal
and Post-installation
l Draining and Supplying of Brake
l Removai and Installation of the 17-26
Nm,12-19 ft.lbs.
TSB RevisionI

35-122SERVICE BRAKES - Hydraulic Unit

9-14 Nm
17-26 Nm12-19 ft.lbs.
8
17-26 Nm12-19 ft.lbs.
16
17-26 Nm
,
17-26 Nm
12-19 ft.lbs.
17-26
Nm12-19
ft.lbs.
12-19
ft.lbs.
Removal Steps
I. Dust shield
2. Engine coolant reservoir
l +3. Engine coolant reservoir bracket
4. Brake hose connection
W 5. Brake tube connection 6. Relay box cover
7. Connector
8. Bracket installation bolt
l +9. Bracket A4*IO. Hydraulic unit
11. Bracket D12. Bracket B13. Bracket C16. Motor relay
17. Valve relay Pre-removal and Post-installation Op-
eration
eDraining and Supplying of Brake Fluid
*Removal and Installation of the Solash
(Refer to GROUP 42-Fender.)I
TSB Revision

SERVICE BRAKES -Hydraulic Unit 35-123

w1480636
Pre-removal and Post-installation Op-
Flared brake line nuts 13-17 Nm
9-12 ft.lbs.
14FO38
17-26 Nm12- 19
ft.lbs.7- 10
ft.lbs.
Removal steps
I. Dust shield
2. Engine coolant reservoir
3. Engine coolant reservoir
++ 5. Bracket tube connection 8. Bracket installation bolt
~~ 9. Bracket A4*10. Hydraulic unit
14. Hydraulic unit bracket
15. Relay box cover
16.Motor relay17.Valve relay18.Bracket tube19.2 way connector bracket
8
