1988 FORD BRONCO Owners Manual

250
*
[RE24200( ALL)10/89]
Also retighten to the specified torque at 500
miles (800 km) of operation after any wheel
change or any time the lug nuts are loosened.
*
[RE24301( ALL)05/95]
RWARNING
Failure to retighten wheel lug nuts at
mileages specified could allow wheels to
come off while the vehicle is in motion.
[RE24330(B )02/89]
eight pica chart:0020314-A*
[RE24397(BEF )02/95]
If the Engine Cranks But Does
Not Start or Does Not Start After
a Collision
*
[RE24400(BEF )04/95]
The Fuel Pump Shut-off Switch
*
[RE24500(BEF )03/95]
If the engine cranks but does not start or if you
have had a collision, the fuel pump shut-off
switch may have been triggered. The shut-off
switch is a device that stops the fuel pump
when your vehicle has been involved in a
substantial jolt.
*
[RE24600(BEF )01/95]
For information on how to check and reset the
fuel pump shut-off switch, seeFuel pump shut-off
switchin the Index.
File:ltreb.ex
Update:Fri Jun 9 15:25:48 1995
ProCarManuals.com

251
*
[RE24700( ALL)05/95]
Towing Your Vehicle
*
[RE24875( ALL)]
If you need to have your vehicle towed, contact
a professional towing service or, if you are a
member, your roadside assistance center.
Recommended towing options include wheel lift
towing or flat bed towing.
[RE24925(ALL )02/95]
half page art:0001463-A*
[RE24950( ALL)]
When calling for a tow truck, tell the operator
what kind of vehicle you have. A towing
File:ltreb.ex
Update:Fri Jun 9 15:25:48 1995
ProCarManuals.com

252manual is available from Ford Motor Company
for all authorized tow truck operators. Have
your tow truck driver refer to this manual for
the proper hook-up and towing procedures for
your vehicle.
*
[RE26300(B F )06/94]
Towing Four-Wheel Drive Vehicles With a
Lever-Operated Transfer Case
*
[RE26400(B F )06/94]
q
Place transmission gearshift (automatic or
manual) in N (Neutral).
*
[RE26425(B F )06/94]
q
Lock steering wheel straight ahead if vehicle
is to be towed with rear wheels off the
ground.
*
[RE26450(B F )12/89]
q
Set manual locking hubs in FREE position or
disengage the automatic locking hubs by
shifting the transfer case to 2H and drive the
vehicle in the opposite direction for a
minimum of 10 feet (3 meters) in a straight
line.
*
[RE26475(B F )06/94]
NOTE: Confirm by observation that the front
driveshaft is not rotating prior to
towing with the rear wheels off the
ground.
*
[RE26500(B F )06/94]
q
Place transfer case in N (Neutral).
*
[RE26615(B F )03/91]
NOTE: The transfer case neutral setting is
located between 4H and 4L. In order to
place the transfer case in neutral, first
place the lever in the 4H position, then
push down (toward the ground) on the
shift knob and at the same time pull
slightly rearward until the lever is
between the 4H and 4L position. With
the ignition in the on position, both
4x4 and LOW RANGE indicator lights
will be off when the transfer case is in
neutral. These lights will also be off
when the transfer case is in the 2H
position.
File:ltreb.ex
Update:Fri Jun 9 15:25:48 1995
ProCarManuals.com

253
*
[RE26650(B F )06/94]
There are no wrecker or recreational vehicle
towing restrictions on method or distance if the
above preparations are made.
*
[RE26700(B F )06/94]
q
Vehicle speed should not exceed 55 mph
(88 km/h). This applies with the front wheels
off the ground, the rear wheels off the
ground, or both front and rear wheels on the
ground.
*
[RE26800(B F )06/94]
Towing Four-Wheel Drive Vehicles With
Touch Drive Electric Shift Transfer Case
*
[RE26900(B F )06/94]
q
Place transmission gearshift (automatic or
manual) in N (Neutral).
*
[RE27000(B F )05/90]
q
Place transfer case in 2H.
*
[RE27050(B F )05/90]
NOTE: Both the4 x 4 and LOW RANGE
indicator lights in the instrument panel
will be off when the transfer case is in
2H.
*
[RE27200(B F )06/94]
q
Lock steering wheel straight ahead if vehicle
is to be towed with rear wheels off the
ground.
*
[RE27301(B F )06/94]
q
When towing your vehicle with the rear
wheels off the ground, the front axle
automatic locking hubs must first be
disengaged by shifting the transfer case to 2H
and moving the vehicle forward for a
minimum of 10 feet (3 meters) in a straight
line. Do not exceed a vehicle speed of
55 mph (88 km/h) while towing.
*
[RE27350(B F )06/94]
NOTE: Confirm by observation that the front
driveshaft is not rotating prior to
towing with the rear wheels off the
ground.
File:ltreb.ex
Update:Fri Jun 9 15:25:48 1995
ProCarManuals.com

254
*
[RE27400(B F )11/92]
q
When towing your vehicle with the rear
wheels on the ground or all four wheels on
the ground and the driveshafts connected, do
not exceed 35 mph (56 km/h) or
transmission damage could result. If a
distance of 50 miles (80 km) is exceeded,
disengage the automatic locking hubs and
disconnect the rear driveshaft from the axle
and secure. (Max speed 55 mph [88 km/h]
with driveshafts disconnected.)
*
[RE27500(BEF )03/91]
RWARNING
Never use a tow bar that attaches to the
bumper when you tow your vehicle. This
could damage the bumper and cause an
accident.
File:ltreb.ex
Update:Fri Jun 9 15:25:48 1995
ProCarManuals.com

255
Customer Assistance
%*
[HS00205( ALL)06/94]
Roadside Assistance
*
[HS00210( ALL)05/95]
Ford Motor Company has set up a 24-hour,
seven-day-a-week hotline with trained operators
that put you in touch with the help you need if
you experience a problem with your vehicle.
This complimentary service is provided to you
throughout your warranty period of 3 years or
36,000 miles (3 years or 60,000 km), whichever
comes first. To purchase Roadside Assistance
coverages beyond this period, through Ford
Auto Club, contact your Ford or
Lincoln-Mercury dealer (not available in
Canada).
*
[HS00215( ALL)06/94]
Roadside Assistance will cover the following:
*
[HS00220( ALL)06/94]
q
Mount your spare if you have a flat tire.
*
[HS00225( ALL)06/94]
q
Jump-start your battery if it is dead.
*
[HS00230( ALL)06/94]
q
Unlock your vehicle if you are locked out.
*
[HS00235( ALL)06/94]
q
Bring you fuel if you run out.
*
[HS00240( ALL)06/94]
q
Tow your vehicle if you are stranded. Even
non-warranty related tows, like accidents or
getting stuck in mud or snow, are covered
(some exclusions apply, such as impound
towing and repossession).
File:lthsb.ex
Update:Fri Jun 9 15:25:09 1995
ProCarManuals.com

256
*
[HS00245( ALL)06/94]
How to use Roadside Assistance
*
[HS00250( ALL)06/94]
Your Roadside Assistance identification card can
be found in the Owner Guide portfolio in your
glove compartment. Complete the card and place
it in your wallet for quick reference.
*
[HS00255( ALL)04/95]
To receive roadside assistance in the United
States call 1-800-241-FORD (in Canada call
1-800-665-2006).
*
[HS00260( ALL)04/95]
Should you need to arrange for roadside
assistance yourself, Ford Motor Company will
reimburse the reasonable cost. To obtain
information about reimbursement call
1-800-241-FORD (in Canada call 1-800-665-2006).
*
[HS00300( ALL)01/95]
If You Have a Service Problem
*
[HS00400( ALL)01/95]
Ford Motor Company has authorized Ford and
Lincoln-Mercury dealerships that can service
your vehicle for you. This chapter tells you how
to get service or maintenance for your vehicle.
%*
[HS00525( ALL)03/95]
Service/Maintenance Concerns (U.S. or
Canada)
*
[HS00600(BEF )04/95]
Ford recommends taking your vehicle to your
selling dealer who wants to ensure your
continued satisfaction. You may, however, take
your vehicle to any authorized Ford or
Lincoln-Mercury dealer. In most cases, your
dealer will be able to resolve your concern.
*
[HS00700( ALL)03/95]
If you are not satisfied with the service you
received from your dealership's service
department, talk to the service manager at the
dealership. If you still are not satisfied, talk to
the owner or general manager of the dealership.
In most cases, you will have your concern
resolved at this level.
File:lthsb.ex
Update:Fri Jun 9 15:25:09 1995
ProCarManuals.com

257
*
[HS01000( ALL)03/95]
If you are away from home when your vehicle
needs to be serviced, or if you need more help
than the dealer gave you, contact the Ford
Customer Assistance Center to find an
authorized dealership that may be able to help.
*
[HS01010( ALL)04/95]
In the U.S., contact:
%*
[HS01025( ALL)03/95]
one inch art:0060100-E
*
[HS01050( ALL)03/95]
If you live in Canada and have any questions or
concerns that the dealership cannot answer,
contact the Customer Assistance Centre.
%*
[HS01075( ALL)04/95]
one inch art:0060101-C
*
[HS01200( ALL)04/95]
Please have the following information available
when contacting Ford Customer Assistance:
*
[HS01300( ALL)04/95]
q
your telephone number (both business and
home)
*
[HS01400( ALL)04/95]
q
the name of the dealer and the city where the
dealership is located
*
[HS01500( ALL)03/95]
q
the year and make of your vehicle
*
[HS01550( ALL)03/95]
q
the date purchased
*
[HS01600( ALL)03/95]
q
the current mileage on your vehicle
