Page 417 of 502

Changing a wheel can be dangerous, especially when carried out at the side of a road. Please
observe the following steps in order to reduce the risk of serious injuries:
as soon as possible and when safe to do so. Park the vehicle at a safe distance
from moving traffic in order to carry out the wheel change.
work during the wheel change.
board or similar support for the vehicle jack.
urself when you feel confident with carrying out the procedure. If not,
seek expert assistance.
ver
to the position P or select a gear on a manual gearbox in order to reduce the risk of unintended
vehicle movement.
immediately after changing a wheel.
n the case of vehicles with a Tyre Pressure Loss Indicator, the system must be re-synchronised
immediately after a wheel change⇒ Tyre Pressure Loss Indicator .
Preparations for changing a wheel
First read and observe the introductoryinformation and safety warnings⇒Introduction
Checklist
The following actions must always be carried out in the given order in preparation for changing the
wheel ⇒ :
If your vehicle has a flat tyre, park the vehicle on a firm and level surface at a safe distance from
moving traffic.
Switch on the electronic parking brake Parking and manoeuvring.
DSG® dual clutch gearbox: move the selector lever to position P DSG® dual clutch gearbox.
Switch off the engine and remove the key from the ignition.
Page 418 of 502
Manual gearbox: select a gear.
Ask all vehicle occupants to leave the vehicle and stand at a safe distance away from moving traffic.
Switch on the hazard warning lights and set up the warning triangle In an emergency. Observe any
legal requirements.
Chock the wheel diagonally opposite the wheel being worked on with a stone, collapsible chocks or
another suitable object.
When towing a trailer: unhitch the trailer from the vehicle and park it properly .
Remove any items of luggage from the luggage compartment.
Remove the spare wheel or temporary spare wheel and the vehicle toolkit from the luggage
compartment.
Remove the hubcaps Hubcaps.
WARNING
Ignoring any of the items on this important safety checklist can lead to accidents and severe injuries.
Wheel bolts
Page 419 of 502
Fig. 203 Changing a wheel: loosening the wheel bolts.
Fig. 204 Changing a wheel: tyre valve ① and locations of the anti-theft wheel bolt ② or ③.
First read and observe the introductoryinformation and safety warnings⇒Introduction
Use a suitable box spanner to loosen the wheel bolts.
Slacken the wheel bolts only by approximately one turn before raising the vehicle with the vehicle
jack.
If a wheel bolt is very tight, you may be able to loosen it by pushing down the end of the spanner
carefully with your foot. Hold on to the car for support and take care not to slip.
Loosening the wheel bolts
it will go ⇒ Fig. 203 .
-clockwise ⇒ .
Loosening the anti-theft wheel bolt
-theft wheel bolt out of the vehicle toolkit.
anti-theft wheel bolt as far as it will go.
-clockwise ⇒ .
Screwing in the anti-theft wheel bolt (wheel cover)
Page 420 of 502

On wheels with a wheel cover, the anti-theft wheel bolt must be screwed into position
⇒ Fig. 204② or ③ according to the position of the tyre valve ①. The wheel cover can otherwise
not be fitted.
Tightening torque of wheel bolts
Specified tightening torque for wheel bolts for steel or alloy wheels:
Nm
If the wheel bolts are corroded and difficult to turn, they must be replaced before the tightening
torque is checked and the wheel hub threads cleaned.
Never grease or oil the wheel bolts or the threads of the wheel hub.
The tightening torque should be checked with a properly functioning torque wrench immediately
after changing a wheel.
WARNING
Incorrectly tightened wheel bolts can loosen while the vehicle is in motion and cause accidents,
serious injury, and loss of control of the vehicle.
easily.
bolts.
the wheel bolts only by approximately one turn before raising the vehicle with the vehicle
jack.
loosen while the vehicle is in motion, even if they have been tightened with the specified tightening
torque.
-on rings.
while the vehicle is in motion. The wheel bolts and the threads could be damaged if the tightening
torque is too high. Check the tightening torque regularly using a torque wrench.
WARNING
The wrong wheel bolts can loosen while the vehicle is in motion and cause accidents, serious injury,
and loss of control of the vehicle.
Page 421 of 502
-piece wheel bolts: use only two-piece wheel bolts.
Lifting the vehicle with the jack
Fig. 205 Jacking points.
Fig. 206 Jack fitted at the rear on the left-side of the vehicle.
First read and observe the introductoryinformation and safety warnings⇒Introduction
The jack may be positioned only at the reinforcements on the underbody, which are located behind
the markings on the body ⇒ Fig. 205 . Always use the jacking point closest to the wheel you are
working on ⇒ .
Checklist
For your own safety, carry out the following points in the specified order ⇒ :
Choose a firm and level surface suitable for lifting the vehicle.
Switch off the engine. Select a gear on vehicles with a manual gearbox or move the selector lever to
position P on vehicles with DSG® dual clutch gearbox DSG® dual clutch gearbox and switch on the
electronic parking brake Parking and manoeuvring.
Chock the wheel diagonally opposite using collapsible chocks or other suitable objects.
Page 422 of 502

When towing a trailer : unhitch the trailer from the vehicle and park it properly.
Loosen the wheel bolts Wheel bolts.
Find the jacking point under the vehicle which is closest to the wheel that is being changed.
Insert the crank into the opening on the jack (depends on the vehicle equipment).
Crank up the jack until it just fits under the jacking point of the vehicle.
Ensure that the entire surface of the foot of the jack is resting securely on the floor, and that the
foot of the jack is positioned fully underneath the point of application and .
Position the jack and simultaneously continue to crank the claw up until it is in position around the
vertical rib underneath the vehicle .
Crank the jack further until the wheel is just clear of the ground.
WARNING
Incorrect use of the vehicle jack could cause the vehicle to slip off the jack. This could lead to severe
injuries. Observe the following points in order to reduce the risk of injuries:
jacks could slip out of position – this includes vehicle jacks supplied with other Volkswagen models.
the vehicle to slip off the jack. If necessary, use a large, sturdy board or similar support for the
vehicle jack.
side member securely ⇒ Fig. 206 .
lace any part of your body (e.g. an arm or leg) underneath the vehicle if the latter is
supported only by the vehicle jack.
Page 423 of 502
vehicle.
cle when the engine is running, or if the vehicle is tilted to one side or on a
gradient.
cause the vehicle to fall off the vehicle jack.
WARNING
Ignoring any of the items on this important safety checklist can lead to accidents and severe injuries.
Changing a wheel
Fig. 207 Changing a wheel: removing the wheel bolts with the screwdriver handle.
First read and observe the introductoryinformation and safety warnings⇒Introduction
Removing a wheel
⇒ Preparations for changing a wheel .
⇒ Wheel bolts .
⇒ Lifting the vehicle with the jack .
⇒ Fig. 207 , completely unscrew the loosened
wheel bolts and place them on a clean surface.
Fitting the spare wheel or temporary spare wheel
y attention to the tyre direction of rotation ⇒ Tyre lettering and tyre type .
Page 424 of 502

-theft wheel bolt using the adapter at position ⇒ Fig. 204② or ③ and tighten it
slightly in a clockwise direction.
l the other wheel bolts in clockwise direction and tighten them slightly.
⇒ . Do not
tighten the bolts in order but always in diagonally opposite sequence.
⇒ Hubcaps .
WARNING
Incorrect tightening torque or incorrect use of wheel bolts can lead to a loss of control of the vehicle,
and cause accidents and serious injuries.
ep all wheel bolts and threads in the wheel hubs clean and free from oil and grease. The
wheel bolts must be easy to turn and be tightened to the specified torque.
not use
for loosening or tightening them.
After changing a wheel
First read and observe the introductoryinformation and safety warnings⇒Introduction
luggage compartment ⇒ Vehicle toolkit .
⇒ Tightening torque of wheel
bolts .
as possible.
After changing a wheel, the indicator lamp for the tyre monitoring system may indicate a fault in the
system ⇒ Troubleshooting for Tyre Pressure Loss Indicator .
Breakdown set
Introduction
This chapter contains information on the followingsubjects:
⇒ Contents of the breakdown set
⇒ Preparations
⇒ Sealing and inflating tyres
