2019 VOLVO XC60 TWIN ENGINE Owners Manual

CLIMATE CONTROL
}}
* Option/accessory.215
Activating and deactivating front
seat ventilation*
The seats can be ventilated to provide increasedcomfort in warm weather.
The ventilation system consists of fans in theseats and backrest that draw air through the seatupholstery. The cooler the passenger compart-ment is, the greater the cooling effect of the ven-tilation. The system can be activated when theengine is running.
Steering wheel and seat buttons in the climate row.
1. Tap the left- or right-side steering wheel andseat button in the center display's climatebar to open the controls for steering wheeland seat heating.
If the vehicle is not equipped with heatedseats or heated steering wheel, the buttonfor seat ventilation is directly accessible inthe climate bar.
2.Tap the seat ventilation button repeatedly toselect one of the four levels: Off, High,Medium or Low.
>The level is changed and the set level isdisplayed in the button.

Related information
Climate system controls (p. 212)
Activating and deactivating the
heated steering wheel*
The steering wheel can be heated for addedcomfort in cold weather.
Steering wheel and seat buttons in the climate row.
1. Tap the driver's side steering wheel and seatbutton in the climate bar in the center displayto open the controls for steering wheel andseat heating.
If the vehicle is not equipped with heated orventilated seats, the button for steeringwheel heating is directly accessible in the cli-mate bar.
2.Tap the steering wheel heating buttonrepeatedly to select one of the four levels:Off, High, Medium or Low.
>The level is changed and the set level isdisplayed in the button.

||
CLIMATE CONTROL
* Option/accessory.216

Related information
Climate system controls (p. 212)
Activating and deactivating automatic steer-ing wheel heating* (p. 216)
Activating and deactivating
automatic steering wheel heating*
The steering wheel can be heated for addedcomfort in cold weather.
Steering wheel heating can be set to automati-cally activate when the engine is started. Whenset to automatically activate, heating will beturned on at low ambient temperatures.
1.Tap Settings in the Top view in the centerdisplay.
2.Tap Climate.
3.Select Auto Steering Wheel HeatingLevel to activate/deactivate automatic startof heated steering wheel.
4.Select Low, Medium or High to select levelafter the function has been activated.

Related information
Activating and deactivating the heated steer-ing wheel* (p. 215)
Activating auto climate control
If auto climate control is activated, several cli-mate system functions are controlled automati-cally.
Auto climate button in Climate view.
1. Open Climate view in the center display.
2.Tap or press and hold AUTO.
Tap - air recirculation, air conditioning andair distribution are controlled automati-cally.
Press and hold - air recirculation, air con-ditioning and air distribution are controlledautomatically. Temperature and blowerspeed are changed to standard settings:22 °C (72 °F) and speed 3.
>Auto climate mode is activated and thebutton lights up.

CLIMATE CONTROL
217

NOTE
It is possible to change the temperature andblower speed without deactivating automaticclimate control. Automatic climate control isdeactivated when the air distribution ischanged manually or when the max defrosteris activated.

Related information
Climate system controls (p. 212)
Activating and deactivatingrecirculation
The climate system's recirculation function helpsshut out smog, smoke, exhaust fumes, etc. byreusing the air in the passenger compartment.
Air recirculation button in Climate view.
1. Open Climate view in the center display.
2.Tap Recirc.
>Air recirculation is activated/deactivatedand the button lights up/goes out.

CAUTION
If the air in the vehicle is recirculated too long,there is a risk of fogging on the inside of thewindows.
NOTE
Recirculation cannot be activated when themax defroster is on.

Related information
Climate system controls (p. 212)
Activating and deactivating the recirculationtimer setting (p. 218)

CLIMATE CONTROL
* Option/accessory.218
Activating and deactivating therecirculation timer setting
The climate system's recirculation function helpsshut out smog, smoke, exhaust fumes, etc. byreusing the air in the passenger compartment.
When the recirculation timer is activated, air recir-culation will switch off automatically after 20minutes.
1.Tap Settings in the Top view in the centerdisplay.
2.Tap Climate.
3.Tap Recirculation Timer to activate/deacti-vate the recirculation timer.

Related information
Activating and deactivating recirculation(p. 217)
Activating and deactivating maxdefroster
Max defroster is used to quickly remove conden-sation and ice from windows.
Activating and deactivating max
defroster from the center console
A button in the center console offers quickaccess to the max defroster.
On vehicles with heated windshields*, the maxdefroster can only be activated separately fromClimate view in the center display.
Button in center console.
Vehicles without a heated windshield:
–Tap the button.
>The max defroster is activated/deacti-vated and the button lights up/goes out.
Vehicles with a heated windshield:
–Press the button repeatedly to switchbetween the three levels:
Activated windshield heating
Activated windshield heating and maxdefroster
Deactivated.
>The heated windshield and max defrosterare activated/deactivated and the buttonlights up/goes out.

NOTE
The max defroster starts after a slight delay toavoid a brief increase in blower speed if theheated windshield function has been deacti-vated by pressing the button twice in quicksuccession.

CLIMATE CONTROL
}}
* Option/accessory.219

Activating and deactivating max
defroster from the center display
Max defroster in Climate view.
1. Open Climate view in the center display.
2.Tap Max.
>The max defroster is activated/deacti-vated and the button lights up/goes out.
Max defroster deactivates automatic cli-mate control and air recirculation, acti-vates the air conditioning, and changesblower speed to 5 and temperature to HI.
When max defroster is deactivated, theclimate system reverts to the previous set-tings.

NOTE
The volume increases when the blower speedis changed to 5.
Related information
Climate system controls (p. 212)Activating and deactivating the
heated windshield*
Windshield heating is used to quickly removecondensation and ice from the windshield.

Activating and deactivating windshield
heating from the center console
A button in the center console is used to quicklyaccess windshield heating.
Button in center console.
–Press the button repeatedly to switchbetween the three levels:
Activated windshield heating
Activated windshield heating and maxdefroster
Deactivated.
>The heated windshield and max defrosterare activated/deactivated and the buttonlights up/goes out.

||
CLIMATE CONTROL
* Option/accessory.220

Activating and deactivating windshield
heating from the center display
Windshield heating button in Climate view.
1. Open Climate view in the center display.
2.Tap Electric.
>Windshield heating is activated/deacti-vated and the button lights up/goes out.

NOTE
Triangular areas at the far sides of the wind-shield are not heated and will take slightlylonger to defrost/de-ice.

NOTE
The heated windshield may affect the per-formance of transponders and other commu-nication equipment.
Related information
Climate system controls (p. 212)
Activating and deactivating automatic wind-shield heating* (p. 220)
Activating and deactivating
automatic windshield heating*
Windshield heating is used to quickly removecondensation and ice from the windshield.
Windshield heating can be set to automaticallyactivate when the engine is started. With auto-matic start activated, heating will be activatedwhen there is a risk of ice or condensation on thewindows or mirrors. Heating is automaticallyswitched off when the window or door mirror issufficiently warm and the condensation or ice isgone.
1.Tap Settings in the Top view in the centerdisplay.
2.Tap Climate.
3.Select Auto Front Defroster to activate/deactivate automatic windshield heating.

Related information
Activating and deactivating the heated wind-shield* (p. 219)

CLIMATE CONTROL
221
Activating and deactivating theheated rear window and doormirrors
The heated rear window and door mirrors areused to quickly remove condensation and icefrom the glass.

Activating and deactivating the heated
rear window and door mirrors from the
center console
A button in the center console offers quickaccess to the heated rear window and door mir-rors functions.
Button in center console.
–Tap the button.
>Heated windows and door mirrors areactivated and the button lights up/goesout.
Activating and deactivating the heated
rear window and door mirrors from the
center display
Rear window/door mirror heating button in Climate view.
1. Open Climate view in the center display.
2.Tap Rear.
>Heated windows and door mirrors areactivated and the button lights up/goesout.

Related information
Climate system controls (p. 212)
Automatically activating and deactivating theheated rear window and door mirrors(p. 221)
Automatically activating anddeactivating the heated rear windowand door mirrors
The heated rear window and door mirrors areused to quickly remove condensation and icefrom the glass.
It is possible to select whether rear window anddoor mirror heating should be automatically acti-vated or deactivated when the engine is started.With automatic start activated, heating will beactivated when there is a risk of ice or condensa-tion on the windows or mirrors. Heating is auto-matically switched off when the window or doormirror is sufficiently warm and the condensationor ice is gone.
1.Tap Settings in the Top view in the centerdisplay.
2.Tap Climate.
3.Select Auto Rear Defroster to activate/deactivate automatic rear window and doorheating.

Related information
Activating and deactivating the heated rearwindow and door mirrors (p. 221)

CLIMATE CONTROL
222
Setting the blower speed for the
front seats3
The blower can be set to several different auto-matically controlled speeds for the front seat.
Blower control buttons in Climate view.
1. Open Climate view in the center display.
2.Tap the desired blower speed: Off, 1-5 orMax.
>The blower speed will be changed and thebuttons for the set speed will light up.

CAUTION
The air conditioning will not engage if theblower is turned off completely, which maycause fogging on the inside of the windows.
NOTE
The climate system automatically adapts air-flow as needed within the set blower speed,which means that airflow speed may varyslightly within the same blower speed.

Related information
Climate system controls (p. 212)
Setting the temperature for the
front seats4
The temperature can be set to the desired num-ber of degrees for the front seat climate zones.
Temperature buttons in the climate bar.
1. Tap the left- or right-side temperature but-tons in the center display's climate bar toopen the control.
3The same setting applies to the rear seats with the 2-zone climate system.
