2019 TOYOTA LAND CRUISER Owners Manual (in English)

LC200_OM_OM60Q99U_(U)
4175-3. Using the storage features
5
Interior features
Your vehicle is equipped with either a front auxiliary box or w ireless
charger.
For vehicles with wireless charger, refer to page 426.
Card holders
Sun visorInstrument panel
Auxiliary boxes
Front (if equipped)Rear (type A)
Press the lid to open.
Rear (type B)
Press the button to open.

418
LC200_OM_OM60Q99U_(U)
5-3. Using the storage features
Luggage compartment features
Raise the hook to use.
The cargo hooks are provided for
securing loose items.
To hang the cargo net, use the
cargo net hooks and rear tie-down
hooks.
The cargo net itself is not included
as an original equipment.
Remove the cover. Hold the warn-
ing reflector with the bands.
The warning reflector itself is not
included as an original equipment.
Cargo hooks
Cargo net hooks
Warning reflector holder

LC200_OM_OM60Q99U_(U)
4195-3. Using the storage features
5
Interior features
Remove the cover. Hold the first-
aid kit with a band.
The first-aid kit itself is not included
as an original equipment.
First-aid kit holder
WARNING
●To avoid injury, always return the cargo hooks to their positions when not
in use.
● Keep the auxiliary box closed. In the event of sudden braking o r sudden
swerving, an accident may occur due to an occupant being struck by an
open auxiliary box or the items stored inside.
NOTICE
■ To prevent damage to the cargo net hooks
Avoid hanging things other than a cargo net on it.

420
LC200_OM_OM60Q99U_(U)
5-4. Using the other interior features
Other interior features
While the engine is running, the cool box, which is cooled by t he air
conditioning , can be used.
Lift the lid while pulling up the
lower lever to release the lock.
Turns the cool box on/off
When on, the indicator light comes
on.
If the front air conditioning system
is not in use, the front air condition-
ing system is automatically turned
on when the cool box is turned on.
■ While the cool box is on
The front air conditioning system cannot be turned off.
■ When the outside temperature is 32 F (0 C) or below
The cool box may not operate.
Cool box (if equipped)
1
2

LC200_OM_OM60Q99U_(U)
4215-4. Using the other interior features
5
Interior features
WARNING
Keep the cool box closed while driving.
Injuries may result in the event of sudden braking, sudden swerving or an
accident.
NOTICE
To prevent battery discharge, do not leave the cool box on long er than nec-
essary when the engine is not running.

422
LC200_OM_OM60Q99U_(U)
5-4. Using the other interior features
Main sun visor
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
To use the side extender, place
the visor in the side position,
then slide it backward.
Sub sun visor
Flip down with the main sun visor
in position or .
Slide the cover to open.
The light turns on when the cover
is opened.
If the vanity lights remain on when the engine switch is turned off, the lights
will go off automatically after 20 minutes.
Sun visors
1
2
3
23
Vanity mirror
NOTICE
To prevent battery discharge, do not leave the vanity lights on for extended
periods when the engine is not running.

LC200_OM_OM60Q99U_(U)
4235-4. Using the other interior features
5
Interior features
Refer to “NAVIGATION SYSTEM
OWNER’S MANUAL” for adjust-
ment.
■The clock is displayed when
The engine switch is in ACCESSORY or IGNITION ON mode.
The displayed temperature
ranges from -22 F (-30C) up to
122 F (50 C).
■The outside temperature is displayed when
The engine switch is in IGNITION ON mode.
■ When --- is displayed
The system may be malfunctioning. Take your vehicle to your Toyota dealer.
■ Display
In the following situations, the correct outside temperature ma y not be dis-
played, or the display may take longer than normal to change.
● When stopped, or driving at low speeds (less than 12 mph [20 km/h])
● When the outside temperature has changed suddenly (at the entra nce/exit
of a garage, tunnel, etc.)
Clock
Outside temperature display

424
LC200_OM_OM60Q99U_(U)
5-4. Using the other interior features
The power outlet can be used fo r the following components:
12 V DC: Accessories that run on less than 10 A
120 V AC: Accessories t hat use less than 100 W
■Center of console
Front (12 V DC)
Press the lid to open.
Rear (12 V DC)
Power outlets
