2019 TOYOTA LAND CRUISER Owners Manual (in English)

LC200_OM_OM60Q99U_(U)
3854-6. Driving tips
4
Driving
●Park the vehicle and move the shift lever to P without setting the
parking brake. The parking brake may freeze up, preventing it from
being released. If the vehicle is parked without setting the pa rking
brake, make sure to block the wheels.
Failure to do so may be dangerou s because it may cause the vehi-
cle to move unexpectedly, pos sibly leading to an accident.
● If the vehicle is parked without setting the parking brake, confirm
that the shift lever c annot be moved out of P
*.
*: The shift lever will be locked if it is attempted to be shifte d from P to any
other position without depressing the brake pedal. If the shift lever can be
shifted from P, there may be a problem with the shift lock syst em. Have
the vehicle inspected by your Toyota dealer immediately.
Use the correct tire ch ain size when mounting the snow chains.
Chain size is regulate d for each tire size.
Side chain
(0.20 in. [5 mm] in diameter)
Cross chain
(0.25 in. [6.3 mm] in diameter)
Regulations regarding the use of tire chains vary depending on loca-
tion and type of road. Always chec k local regulations before installing
chains.
■ Tire chain installation
Observe the following precautions when installing and removing chains:
● Install and remove tire chains in a safe location.
● Install tire chains on the rear tires. Do not install tire chains on the front tires.
● Install tire chains on rear tires as tightly as possible. Retig hten chains after
driving 1/4 - 1/2 mile (0.5 - 1.0 km).
● Install tire chains following the instructions provided with th e tire chains.
When parking the vehicle
Selecting tire chains
1
2
Regulations on the use of tire chains

386
LC200_OM_OM60Q99U_(U)
4-6. Driving tips
WARNING
■Driving with snow tires
Observe the following precautions to reduce the risk of acciden ts.
Failure to do so may result in a loss of vehicle control and ca use death or
serious injury.
● Use tires of the specified size.
● Maintain the recommended level of air pressure.
● Do not drive in excess of 75 mph (120 km/h), regardless of the type of
snow tires being used.
● Use snow tires on all, not just some wheels.
■ Driving with tire chains
Observe the following precautions to reduce the risk of acciden ts.
Failing to do so may result in the vehicle being unable to be d riven safely,
and may cause death or serious injury.
● Do not drive in excess of the speed limit specified for the tir e chains being
used, or 30 mph (50 km/h), whichever is lower.
● Avoid driving on bumpy road surfaces or over potholes.
● Avoid sudden acceleration, abrupt steering, sudden braking and shifting
operations that cause sudden engine braking.
● Slow down sufficiently before entering a curve to ensure that v ehicle con-
trol is maintained.
● Do not use LDA (Lane Departure Alert) system. (if equipped)
NOTICE
■Repairing or replacing snow tires
Request repairs or replacement of snow tires from Toyota dealer s or legiti-
mate tire retailers.
This is because the removal and attachment of snow tires affect s the opera-
tion of the tire pressure warning valves and transmitters.
■ Fitting tire chains
The tire pressure warning valves and transmitters may not funct ion correctly
when tire chains are fitted.

387
LC200_OM_OM60Q99U_(U)
5Interior features
5-1. Using the air conditioning system and defogger
Front automatic air conditioning system ........ 388
Rear air conditioning system............................. 399
Heated steering wheel/ seat heaters/
seat ventilators ................ 403
5-2. Using the interior lights Interior lights list ................ 407• Interior lights ................. 408
• Personal lights .............. 409 5-3. Using the storage features
List of storage features ..... 410• Glove box...................... 411
• Console box .................. 412
• Overhead console......... 413
• Cup holders .................. 414
• Bottle holders ................ 416
• Card holders ................. 417
• Auxiliary boxes.............. 417
Luggage compartment features ........................... 418
5-4. Using the other interior features
Other interior features ....... 420 • Cool box........................ 420
• Sun visors ..................... 422
• Vanity mirror ................. 422
• Clock ............................. 423
• Outside temperature display........................... 423
• Power outlets ................ 424
• Wireless charger ........... 426
• Armrest ......................... 434
• Coat hooks.................... 434
• Assist grips ................... 435
Garage door opener.......... 436

388
LC200_OM_OM60Q99U_(U)
5-1. Using the air conditioning system and defogger
Front automatic air conditioning system
■Adjusting the temperature setting
Press to increase the temperature and to decrease the
temperature.
If the “A/C” indicator is turned off, the system will blow ambi ent tempera-
ture air or heated air.
Air outlets and fan speed are automatically adjusted according
to the temperature setting.
Press to display the air conditioning control screen.
Control panel

LC200_OM_OM60Q99U_(U)
3895-1. Using the air conditioning system and defogger
5
Interior features
■Changing the air flow mode
Press .
The air flow mode switches
each time the button is pressed.
Air flows to the upper body
Air flows to the upper body
and feet
Air flows to the feet
Air flows to the feet and the
windshield defogger oper-
ates
Select the air flow mode
* (left-
hand side)
Air flows to the feet and the
windshield defogger operates
Select the air flow mode
* (right-
hand side)
Display the option control
screen ( P. 390)
Adjust the fan speed setting
Display the rear air conditioning control screen ( P. 3 9 2 )
To adjust or select settings, touch the screen button.
*: Air flows to the upper body
 Air flows to the upper body and feet
 Air flows to the feet
1
2
3
4
Control screen
1
2
3
4
5
6

3905-1. Using the air conditioning system and defogger
LC200_OM_OM60Q99U_(U)
Select to set cooling and dehu-
midification function on/off
Adjust the temperature for
driver, front passenger and rear
seats separately (Individual
mode) (P. 3 9 1 )
Prevent ice from building up on
the windshield and wiper
blades (if equipped) ( P. 394)
Remove pollen from the air (Mi cro dust and pollen filter) (P. 394)
■Using the automatic mode
Press .
Adjust the temperature setting.
To stop the operation, press .
■
Automatic mode indicator
If the fan speed setting or air flow modes are operated, the au to-
matic mode indicator goes off. However, automatic mode for func -
tions other than that o perated is maintained.
Option control screen
1
2
3
Air conditioning controls
4
1
2

LC200_OM_OM60Q99U_(U)
3915-1. Using the air conditioning system and defogger
5
Interior features
To turn on the individual mode, perform any of the following pr oce-
dures:
● Press “4-ZONE” on the option control screen.
● Adjust the passenger’s side temperature setting.
● Change the rear air conditioning setting
The indicator comes on when the individual mode is on.
To return to the simultaneous mode, press “4-ZONE”.
In the simultaneous mode, only or on the driver’s side can
be used to adjust the temperature for all seats.
Adjusting the temperature for driver and passenger seats sepa-
rately (Individual mode)

3925-1. Using the air conditioning system and defogger
LC200_OM_OM60Q99U_(U)
Press on the control
screen to display the rear air con-
ditioning control screen.
Adjust the temperature set-
ting (left-hand rear seat)
Adjust the fan speed setting
Adjust the temperature set-
ting (right-hand rear seat)
Select to set automatic mode
Turn the fan off
■Using the automatic modePress “REAR AUTO”.
The air conditioning system will operate, and air outlets and s peed will
be set automatically.
Press “ ” to increase the temperature and “ ” to decrease the
temperature.
Air outlets for the right-hand and left-hand may be set separat ely
depending on the temperature setting.
■
Adjusting the temperature setting
Press “ ” (increase) “ ” or (decrease).
Operating the switch will enter the individual mode. ( P. 391)
■
Adjusting the fan speed setting
Press (increase) or (decrease).
The fan speed is shown on the display. (7 levels)
Press “REAR OFF” to turn the fan off.
■
Turning the rear air conditioning system off
Press “REAR OFF”.
Changing the rear seat settings
1
2
3
4
5
1
2
