2019 MASERATI LEVANTE Owners Manual

Tire Information Label
This paper label is applied on the
driver's side rear door pillar.
NOTE:
For further informations see “Tire
Safety Information” in section
"Driving".
Paint Identification Label
The label is applied on the lower left
side of the hood. Fuel Warning Label
The label is applied inside the fuel
filler door.
NOTE:
To ensure optimum performance and
fuel economy, please ensure to refill
your vehicle using Premium Unleaded
Fuel ONLY, with a minimum of 91 AKI. Introduction
1
21

Introduction
22

2 – Before Starting Keys .................................................. 24
Sentry Key Immobilizer System ............................. 26
Vehicle Security Alarm .................................... 27
Illuminated Entry/Exit .................................... 30
Unlock the Vehicle with Key fob ............................ 33
Requiring and Setting Additional Key fobs .................... 34
Remote Start System ..................................... 37
Doors Locking .......................................... 39
Passive Entry System ..................................... 42
Power Windows ......................................... 46
Power Sunshades on Rear Door Windows
(for versions/markets, where provided) ...................... 48
Power Liftgate Operation ................................. 50
Hood Operation ........................................ 56
Occupants Restraint Systems ............................... 57
Supplemental Restraint System (SRS) — Air Bags ................ 65
Child Restraint Systems ................................... 74
Transporting Pets ........................................ 79
Park Assist ............................................. 79
Rear Parking Camera ..................................... 85
Surround View Camera System (optional) ..................... 87
Safety Tips ............................................. 89
23

Keys The vehicle is equipped with a Remote
Keyless Entry transmitter and a Keyless
Ignition Node, to enter, start and
protect the vehicle.
Keyless Ignition Device This device allows the driver to
operate the ignition switch with the
push of a button, as long as the Remote Keyless Entry (RKE) transmitter
is inside the vehicle.
The Keyless Ignition Node (KIN) has
three operating setups indicated on
the outer ring. Pressing and releasing
the middle button, you can switch
from one setup to the next without
starting the engine, the switched on
indication will turn amber.
The engine will start by pushing the
center button START/STOP with the
brake pedal pressed and the device set
in any of the three operating setups. In case the ignition switch does not
change by pushing a button, the RKE
transmitter (key fob) may have a low
or discharged battery. If this occurs it is
necessary to replace the battery in
order to operate the ignition switch
(see “Requiring and Setting Additional
Key fobs” in this section).
It is still possible to operate the
ignition device using the key fob RKE
transmitter with discharged battery by
pressing the nose side (side opposite of
the emergency key) of the key fob on
the START/STOP button.Before Starting
2
24

Key fob This vehicle is provided with two
programmed key fobs.
The key fob contains a Remote Keyless
Entry (RKE) transmitter and an
emergency key.
The emergency key allows you to
open the vehicle by inserting into the
lock of the opening handle on the
driver's door, in case the battery of the
vehicle or the key fob go dead. You can keep the emergency key with
you when using valet parking.
To remove the emergency key:
• hold the mechanical latch on the
back of the key fob sideways;
• simultaneously remove the
emergency key by sliding laterally
towards the end of the key fob.
NOTE:
You can insert either side of the
emergency key into the lock cylinder.
Shift Ignition Device to OFF
Alert Opening the driver's door to exit the
vehicle when the ignition device is set
in ACC or RUN (engine not running), a
beep will remind you to cycle the
ignition to OFF . In addition to the acoustic signal a
dedicated message is displayed on the
instrument cluster.
If the ignition device is left in the ACC
or RUN position, when vehicle is
locked the system will turn off the
instrument cluster and automatically
set ignition device to OFF .
With the MTC+ System, the power
window switches, radio, power
sunroof (optional), and power outlets
will remain active for up to 10 minutes
after the ignition switch is cycled to
the OFF position. Opening either front
door will cancel this feature, it is
possible to set the timing of this
feature.
NOTE:
Refer to “MTC+ Settings” in Section
“Dashboard Instruments and
Controls” for further information.
WARNING!
• When leaving the vehicle, always
remove the key fob and lock your
vehicle.
• Do not allow children to be in a
vehicle unattended or with access to
an unlocked vehicle. A child or
(Continued)Before Starting
2
25

(Continued)
others could be seriously or fatally
injured. Children should be warned
not to touch the parking brake
trigger, brake pedal or the shift
lever.
• Do not leave the key fob in or near
the vehicle, and do not leave the
ignition switch in the ACC or RUN
mode. A child could operate power
windows, other controls, or move
the vehicle.
• Do not leave children or animals
inside parked vehicles in hot
weather. Interior heat build-up may
cause serious injury or death.
• An unlocked car is an invitation to
thieves. Always remove the key fob
from vehicle, cycle the ignition
switch to OFF and lock all doors
when leaving the vehicle
unattended. Sentry Key ®
Immobilizer
System The Sentry Key ®
Immobilizer System
prevents unauthorized vehicle
operation by disabling the engine. The
system does not need to be armed or
activated. Operation is automatic,
regardless of whether the vehicle is
locked or unlocked.
The system uses a key fob with Remote
Keyless Entry (RKE) transmitter, an
ignition switch and a RF (Radio
Frequency) receiver to prevent
unauthorized vehicle operation.
Therefore, only key fobs expressly
programmed can be used to start and
operate the vehicle.
After placing the ignition in the RUN
position, the Vehicle Security Light (see
picture) will light up for a three
seconds bulb check. If the light remains on after the bulb
check, it indicates that there is a
problem with the electronics: this
condition will result in the engine
being shut off after two seconds.
If the Vehicle Security Light turns on
during normal vehicle operation
(engine running for longer than 10
seconds), an electronic fault is
detected. Should this occur, contact
the Authorized Maserati Dealer as
soon as possible for assistance.
CAUTION!
The Sentry Key ®
Immobilizer system is
not compatible with some remote
starting systems that can be installed
in after-market.
Use of these systems may result in
vehicle starting problems and loss of
security protection.
All key fobs provided with the new
vehicle
have been updated with the
vehicle electronics and are therefore
able to guarantee correct functioning
and protection.Before Starting
2
26

Radio Frequency RKE
Transmitter - Regulatory
Information The “Regulatory Information” for all
the radio frequency and radar devices
can be consulted by accessing the
"Services" section on the website
www.maserati.com.
Replacement Key fobs NOTE:
Only key fobs that are updated with
the vehicle electronics can be used to
start and operate the vehicle.
WARNING!
• Always remove the key fobs from
the vehicle and lock all doors when
leaving the vehicle unattended.
• Always remember to cycle the
ignition switch to OFF.
Duplication of key fobs may be
performed
by an Authorized Maserati
Dealer only .
This procedure consists of
programming a key fob that has never
been programmed to the vehicle’s
electronics. NOTE:
• When having the Sentry Key ®
Immobilizer System serviced, bring
all key fobs provided with the
vehicle with you to the Authorized
Maserati Dealer .
• When selling the vehicle, it is
necessary to provide the new owner
with all key fobs.
Vehicle Security Alarm The vehicle security alarm monitors
the vehicle doors and liftgate for
unauthorized entry and the
START/STOP button for unauthorized
operations.
The system includes a dual function
anti-intrusion sensor and vehicle
anti-lift sensor. The anti-intrusion
sensor monitors the vehicle interior
for motion.
The vehicle anti-lift sensor monitors
the vehicle for any lifting or tilting
actions (tow away, tire removal, ferry
transport, etc). A siren with battery
backup which senses interruptions of
power and communications is also
included.
While the vehicle security alarm is
enabled, interior door locks switches,
power liftgate and fuel filler door
release are disabled. If something
triggers the alarm, the vehicle security
alarm will provide the following
audible and visible signals:
intermittent buzzer, position lights
and/or turn signals and the vehicle
security light on the dashboard will
flash.
This light will fast flash for
approximately 15 seconds, when the
vehicle security alarm is being armed,Before Starting
2
27

and will then flash slowly until the
vehicle is disarmed.
Rearming the System If something triggers the security
alarm, and no quick action is taken to
disarm it, the vehicle security alarm
will turn off the beeper after 29
seconds, and turn off all of the visual
signals after 31 more seconds; the
vehicle security alarm will then rearm
itself.
Arming the System Follow these steps to arm the vehicle
security alarm.
• Make sure the vehicle ignition switch
is OFF .
• Perform one of the following
methods to lock the vehicle:
• Press the
lock button on the
interior power door lock switch located on the driver door trim
panel with the driver and/or
passenger door open.
• Press the button on the exterior
“Passive Entry” door handle having
a valid key fob RKE transmitter in
the same exterior zone (see
“Passive Entry System” in this
section for further information). • Press the
lock button on the key
fob RKE transmitter.
• If any door is open, close it.
In any of these situations, if one or
more windows are open, they will
remain open.
When arming the alarm system in any
of the described ways, the power
liftgate will remain open if it was left
open. In this condition, it will be
necessary to first close the power
liftgate as described under "PowerBefore Starting
