Wheels NOTE:
• Maserati recommends Maserati Genuine Tires marked with “MGT” logo specifically designed for its models.
• In order to maintain high performance and safety level, Maserati recommends to use tires equivalent to the original
size.
• Optionally tires may have "ZR" in the size description combined with speed index (e.g. 265/45 ZR20 104Y).
• In case of staggered tires, front and rear rims cannot be swapped.
• Only 19” rear tires can be equipped with special chain with front anchorage. Snow chains cannot be used (all tires).
WARNING!
• The maximum speed reachable with the tires is indicated by the tire manufacturer. Always comply with the regulations
in force in the Country you are driving in.
• Never exceed the maximum speed indicated for the tires: failure to respect the max. speed may damage these tires.
Danger: risk of accident!
Standard Wheel Dimension
Allowed tires size Levante (Basic version - GranLusso) Levante (GranSport)
Light alloy rims 19” x 8,5J (front and rear) 20” x 9J (front and rear)
- Front tires - All season 265/50 R19 110W 265/45 R20 104W
- Rear tires - All season 265/50 R19 110W 265/45 R20 104W
Spare rim 18” x 6B
- Spare tire 195/75 R18Features and Specifications
8
413

Allowed tires size Levante S (Basic version - GranLusso) Levante S (GranSport)
Light alloy rims 19” x 8,5J (front)
19” x 10,5J (rear) 20” x 9J (front)
20” x 10,5J (rear)
- Front tires - All season 265/50 R19 110W 265/45 R20 104W
- Rear tires - All season 295/45 R19 113W 295/40 R20 106W
Spare rim 18” x 6B
- Spare tire 195/75 R18
Allowed tires size Levante TROFEO Levante GTS
Light alloy rims 21” x 9J (front)
21” x 10,5J (rear) 20” x 9J (front)
20” x 10,5J (rear)
- Front tires 265/40 R21 101Y 265/45 R20 104Y
- Rear tires 295/35 R21 103Y 295/40 R20 106Y
Spare rim 18” x 6B
- Spare tire 195/75 18
Optional Wheel Dimension
Allowed tires size Levante (Basic version - GranLusso) Levante (GranSport)
Light alloy rims 19” x 8,5J (front and rear)
- Front tires 265/50 R19 110Y
- Rear tires 265/50 R19 110Y
- Front tires - All season (Standard tire)
- Rear tires - All season (Standard tire)
Light alloy rims 19" x 8,5J (front)
19” x 10,5J (rear) 19" x 8,5J (front)
19” x 10,5J (rear)
- Front tires 265/50 R19 110Y 265/50 R19 110YFeatures and Specifications
8
414

Allowed tires size Levante (Basic version - GranLusso) Levante (GranSport)
- Rear tires 295/45 R19 113Y 295/45 R19 113Y
- Front tires - All season 265/50 R19 110W 265/50 R19 110W
- Rear tires - All season 295/45 R19 113W 295/45 R19 113W
Light alloy rims 20” x 9J (front and rear) 20” x 9J (front and rear)
- Front tires 265/45 R20 104Y 265/45 R20 104Y
- Rear tires 265/45 R20 104Y 265/45 R20 104Y
- Front tires - All season 265/45 R20 104W (Standard tire)
- Rear tires - All season 265/45 R20 104W (Standard tire)
Light alloy rims 20” x 9J (front)
20” x 10,5J (rear) 20” x 9J (front)
20” x 10,5J (rear)
- Front tires 265/45 R20 104Y 265/45 R20 104Y
- Rear tires 295/40 R20 106Y 295/40 R20 106Y
- Front tires - All season 265/45 R20 104W 265/45 R20 104W
- Rear tires - All season 295/40 R20 106W 295/40 R20 106W
Light alloy rims 21” x 9J (front and rear) 21” x 9J (front and rear)
- Front tires 265/40 R21 101Y 265/40 R21 101Y
- Rear tires 265/40 R21 101Y 265/40 R21 101Y
- Front tires - All season 265/40 R21 105W 265/40 R21 105W
- Rear tires - All season 265/40 R21 105W 265/40 R21 105W
Light alloy rims 21” x 9J (front)
21” x 10,5J (rear) 21” x 9J (front)
21” x 10,5J (rear)
- Front tires 265/40 R21 101Y 265/40 R21 101Y
- Rear tires 295/35 R21 103Y 295/35 R21 103Y
- Front tires - All season 265/40 R21 105W 265/40 R21 105WFeatures and Specifications
8
415

Allowed tires size Levante (Basic version - GranLusso) Levante (GranSport)
- Rear tires - All season 295/35 R21 107W 295/35 R21 107W
Allowed tires size Levante S (Basic version - GranLusso) Levante S (GranSport)
Light alloy rims 19” x 8,5J (front)
19” x 10,5J (rear)
- Front tires 265/50 R19 110Y
- Rear tires 295/45 R19 113Y
- Front tires - All season (Standard tire)
- Rear tires - All season (Standard tire)
Light alloy rims 20” x 9J (front)
20” x 10,5J (rear) 20” x 9J (front)
20” x 10,5J (rear)
- Front tires 265/45 R20 104Y 265/45 R20 104Y
- Rear tires 295/40 R20 106Y 295/40 R20 106Y
- Front tires - All season 265/45 R20 104W (Standard tire)
- Rear tires - All season 295/40 R20 106W (Standard tire)
Light alloy rims 21” x 9J (front)
21” x 10,5J (rear) 21” x 9J (front)
21” x 10,5J (rear)
- Front tires 265/40 R21 101Y 265/40 R21 101Y
- Rear tires 295/35 R21 103Y 295/35 R21 103Y
- Front tires - All season 265/40 R21 105W 265/40 R21 105W
- Rear tires - All season 295/35 R21 107W 295/35 R21 107WFeatures and Specifications
8
416

Allowed tires size Levante TROFEO Levante GTS
Light alloy rims 20" x 9J (front)
20” x 10,5J (rear)
- Front tires (Standard tire)
- Rear tires (Standard tire)
- Front tires - All season 265/45 R20 104W
- Rear tires - All season 295/40 R20 106W
Light alloy rims 21” x 9J (front)
21” x 10,5J (rear) 21” x 9J (front)
21” x 10,5J (rear)
- Front tires (Standard tire) 265/40 R21 101Y
- Rear tires (Standard tire) 295/35 R21 103Y
- Front tires - All season 265/40 R21 105W 265/45 R21 105W
- Rear tires - All season 295/35 R21 107W 295/35 R21 107W
Light alloy rims 22” x 9J (front)
22” x 10,5J (rear) 22” x 9J (front)
22” x 10,5J (rear)
- Front tires 265/35 R22 265/35 R22
- Rear tires 295/30 R22 295/30 R22
- Front tires - All season 265/35 R22 265/35 R22
- Rear tires - All season 295/30 R22 295/30 R22Features and Specifications
8
417

Performance NOTE:
The specifications described can change without prior notification.
Levante TROFEO Levante GTS Levante S Levante
Maximum speed 190 mph (305 km/h) 183 mph (294 km/h) 164 mph (264 km/h) 156 mph (251 km/h)
Accelerations from 0 to
60 mph 3.8 seconds 4.1 seconds 5.0 seconds 5.8 seconds
(*) Values obtained with 94 AKI (98 RON) unleaded gasoline.
Weights NOTE:
The specifications described can change without prior notification.
Levante TROFEO - GTS Levante S - Levante
Unladen vehicle weight with tank and reservoirs
filled, tools and accessories (*) 5070 lb / 2300 kg
(2624 lb / 1190 kg front axle -
2447 lb / 1110 kg rear axle) 4994 lb / 2265 kg
(2540 lb/1152 kg front axle -
2454 lb/1113 kg rear axle)
Approved Gross Vehicle Weight Rating (GVWR) 6228 lb / 2825 kg
(2932 lb / 1330 kg front axle -
3296 lb / 1495 kg rear axle) 6116 lb / 2780 kg
(2827 lb/1285 kg front axle -
3289 lb/1495 kg rear axle)
Maximum load on the roof rails 176 lb / 80 kg
(*) Base configuration without options.Features and Specifications
8
418

Trailer Towing Weights
NOTE:
• On the TROFEO version you can not install the trailer tongue.
• Follow trailer manufacturer recommendations, never exceed trailer tow weights provided.
Towable loads: trailer with brakes 5952 lb/2700 kg (GTS: 3306 lb/1500 kg)
Towable loads: trailer without brakes 1500 lb (680 kg )
Maximum load on tow hitch 474 lb (215 kg)
Dimensions Wheel base 118.2 in (3004 mm )
Overall length 197 in (5003 mm)
Overall width without mirrors 77.5 in (1968 mm)
Overall width with mirrors 85 in (2158 mm)
Front track 63.9 in (1624 mm)
Rear track 65.9 in (1676 mm)
Front overhang 38 in (966 mm)
Rear overhang 40.6 in (1033 mm)
Overall height (*) 66.1 in (1679 mm)
Ground clearance (*) 8 in (205 mm)
Trunk compartment volume 14.9 cu.ft. (422 l )
Cargo area length 41 in (1040 mm)
Cargo area length with rear seatbacks folded down 79.8-71 in (2027-1803 mm)
Cargo area width 46.7-39.5 in (1186-1002 mm)
(*) In “Normal” ride height and with standard rims and tires. Features and Specifications
8
419

Tire Inflation Pressure Cold tire inflation pressure value under the following loading conditions listed in the table below:
• PLC (Partial Loading Condition): considering 2 passengers + luggage.
• FLC (Full Loading Condition): considering 4 or 5 passengers + luggage.
• CC (Comfort Condition) : not more than 80 mph (130 km/h).
NOTE:
• For more information about the pressure check methods, see “Tires – General Information” in section “Driving”.
• Tire inflation pressure values are also indicated on the information label applied to the driver's side rear door pillar.
WARNING!
• Improperly inflated tires are dangerous.
• Under-inflation increases tire flexing and can result in tire overheating and failure.
• Over-inflation reduces a tire's ability to cushion shock. Objects on the road and potholes can cause damage that results
in tire failure.
• Over-inflated or under-inflated tires can affect vehicle handling and can fail suddenly, resulting in loss of vehicle control.
• Unequal tire pressures can cause steering problems.
• Unequal tire pressures from one side of the vehicle to the other can cause the vehicle to drift to the right or left.
• Always drive with each tire inflated to the recommended cold tire inflation pressure.Features and Specifications
