2019 MASERATI LEVANTE Owners Manual

8 – Features and Specifications Refillings ............................................. 406
Fuel Consumption ...................................... 410
Technical Data ......................................... 411
Tire Inflation Pressure ................................... 420
405

Refillings NOTE:
Maserati reserves the right to change or revise specifications without prior notification.
CAUTION!
To guarantee vehicle’s integrity and maintain performance level always use genuine parts approved and recommended by
Maserati.
Refillings and Recommended Products Parts to be refilled Quantity Product specifications
Fuel tank 21 Gallons/80 liters (including
4.2 Gallons/16 liters of
reserve) Premium unleaded fuel with no less than 91 CLC or AKI (95
RON/85 MON).
Engine (3.8 V8) 8.8 Quarts/8.3 litres (max)
(MIN – MAX difference: 1.5
Quarts/1.4 litres) Synthetic multigrade lubricants SAE 5W-40 that meet API
SL/CF and ACEA A3, B3, B4 specifications.
Recommended oil: PENNZOIL Platinum Maserati 5W-40 (1).
Engine (3.0 V6) 8.8 Quarts/8.3 liters (max)
MIN – MAX difference: 1.1
Quarts/1 liter Synthetic multigrade lubricants SAE 10W-60 that meet API
SN/CF and ACEA A3, B3, B4 specifications.
Recommended oil: PENNZOIL Platinum Maserati 10W-60 (2).
Windshield and headlight
washer fluid tank 5.3 Quarts/5 liters Mix of water and solvent, in the proportions indicated on
the product package. If the temperature is below –4°F
(–20°C), use pure solvent.
Solvent: Mix of CUNA NC 956-II surfactants and alcohols.
Recommended fluid: WUERTH Windshield Washer Fluid with
antifreeze or AREXONS DP1.Windshield washer fluid
tank 3.7 Quarts/3.5 litersFeatures and Specifications
8
406

Parts to be refilled Quantity Product specifications
Engine cooling circuit (3.8
V8) 15 Quarts/14.2 liters (for
dual-zone air conditioning
system)
15.85 Quarts/15 liters (for
four-zone air conditioning
system) Mixture of water and coolant, proportionally 50/50%.
Coolant: protective, antifreeze action and ethylene
glycol-based with organic inhibitors compatible with
regulations:
• ASTM D 3306, ASTM D 2570
• ASTM D 4340, ASTM D 2809
• SAE J 1034
• CUNA NC 956/16.
Recommended fluid: PETRONAS Paraflu Up 50/50.Engine cooling circuit (3.0
V6) 9.7 Quarts/9.2 liters (for
dual-zone air conditioning
system)
10.56 Quarts/10 liters (for
four-zone air conditioning
system)
Automatic transmission
cooling circuit 2.64 Quarts/2.5 liters
(3) Automatic transmission 8 Quarts/7.6 liters SHELL ATF L- 12108 or ZF Lifeguard 8.
(3) Differential 0.95 Quarts/0.9 liters Synthetic Axle Lubricant SAE 75W-85 – FE Hypoid Gear
Lubricant.
(3) Front differential 0.47 Quarts/0.45 liters SHELL TF 0951B.
(3) Transfer case 0.65 Quarts/0.62 liters SHELL TF 0870.
Braking system 0.93 Quarts/0.88 liters +/- 4% Synthetic fluid: FMVSS 116 - DOT 4, ISO 4925 Class 4,
ENSAYOS INTA-UNE 26-109-88, SAE J1703, SAE J1704, CUNA
NC 956-01.
Recommended fluid: PETRONAS Tutela TOP 4/S.
CAUTION!
For each oil refilling and/or replacement, please contact an Authorized Maserati Dealer .Features and Specifications
8
407

Parts to be refilled Quantity Product specifications
Air conditioning system dual-zone: 24.7 oz +/-0.7 oz
(700 g +/-20 g)
four-zone: 30 oz +/-0.7 oz
(850 g +/-20 g) Refrigerant: r134a.
(1) In countries where it is not available, recommended oil “PENNZOIL Platinum 5W-40”.
(2) In countries where it is not available, recommended oil “PENNZOIL Platinum 10W-60”.
(3) No change and/or topping up expected in scheduled maintenance.
WARNING!
California Proposition 65
Operating, servicing and maintaining a passenger vehicle or off-road vehicle can expose you to chemicals including such
as, engine exhaust, carbon monoxide, phthalates and lead, that which are known to the State of California to cause
cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the
engine except as necessary, service your vehicle in a well-ventilated area and wear gloves or wash your hands frequently
when servicing your vehicle. For more information go to: www.P65Warnings.ca.gov/passenger-
vehicle
Engine Oil Identification Symbol This symbol means that the oil has been certified by the American Petroleum Institute (API). Maserati only
recommends API Certified engine oils.
CAUTION!
Do not use chemical flushes in your engine oil as the chemicals can damage your engine. Damage caused by use of
non-approved chemicals is not covered by the new Vehicle Limited Warranty.Features and Specifications
8
408

Engine Oil Viscosity (SAE Grade) SAE 5W-40 (for V8 engine) or 10W-60 (for V6 engine) engine oil is recommended for all operating temperatures.
The engine oil filler cap also shows the recommended engine oil viscosity for your engine. For information on engine oil
filler cap location, refer to chapter “Maintenance Procedures” in section “Maintenance and Care”.
Lubricants that do not have both the engine oil certification mark and the correct SAE viscosity grade number should not
be used.
Features and Specifications
8
409

Fuel Consumption NOTE:
• The technical data, values and specifications in this Owner’s Manual are provided as guidance only. The vehicle specific
data can deviate from the information provided, for example, as a result of optional or special equipment ordered with
the vehicle, vehicle loads, and country specific measurement methods.
• The specifications described below can change without prior notification.
• Actual mileage will vary depending upon driving style, vehicle load, road conditions and ambient temperature.
The fuel consumption values shown (Miles Per Gallon - MPG) are established using EPA test guidelines.
Levante TROFEO Levante GTS Levante S Levante
City (*) (*) 14 MPG 14 MPG
Highway (*) (*) 19 MPG 20 MPG
Combined (*) (*) 16 MPG 16 MPG
(*) Data not available at the time of publication.
CAUTION!
• Actual fuel economy results will vary for many reasons, including driving conditions and how you drive and maintain
your vehicle.
• The type of route, traffic and weather conditions, driving style, general condition of the vehicle, equipment/accessories in
the vehicle, use of the air conditioning system, vehicle load and other items or situations which may negatively affect the
vehicle aerodynamics or wind resistance lead to consumption ratios differing from the indicated ones.Features and Specifications
8
410

Technical Data NOTE:
The technical data, values and specifications in this Owner’s Manual are provided as guidance only. The vehicle specific
data can vary from the information provided, for example, as a result of optional or special equipment ordered with the
vehicle, vehicle loads, and country specific measurement methods.
Engine Data Data Levante TROFEO Levante GTS Levante S Levante
Cylinder number and position 8 - 90° V 8 - 90° V 6 - 60° V 6 - 60° V
Number of valves per cylinder 4 4 4 4
Bore x stroke 86.5 x 80.8 mm 86.5 x 80.8 mm 86.5 x 84.5 mm 86.5 x 84.5 mm
Total displacement 3799 cu.cm 3799 cu.cm 2979 cu.cm 2979 cu.cm
Compression ratio 4.44 : 1 4.44 : 1 9.7 : 1 9.7 : 1
Maximum power output (EC) 441 kW – 591 hp 404 kW – 550 hp 316 kW – 424 hp 257 kW – 345 hp
- corresponding RPM 6750 rpm 6000 rpm 5750 rpm 5750 rpm
Peak and overboost torque (EC) 538 lb-ft (730 N-m) 538 lb-ft (730 N-m) 428 lb-ft (580 N-m) 369 lb-ft (500 N-m)
- corresponding RPM 2500 – 5000 rpm 2500 – 5000 rpm 2000 – 4750 rpm 1750 – 4750 rpm
Values obtained with 94 AKI (98 RON) unleaded gasoline.
Engine Properties
Timing The timing system uses two overhead camshafts with timing variator.
Timing system control Timing chain.
Supply Over-supplied with turbocharger and related intercooler for each bank.
Injection – Ignition High-pressure (200 bar) direct fuel injection system. Static ignition with digital electronic
control system included and controlled by a single microprocessor ECU. Features and Specifications
8
411

Brakes Self-ventilating disc brakes on the four wheels. The Electric Parking Brake (EPB) acts on the rear wheels.
Levante TROFEO - GTS - S Levante
Front disc diameter Drilled disc: 15 in (380 mm) 13.6 in (345 mm)
Rear disc diameter Drilled disc: 13 in (330 mm) 13 in (330 mm)
Transmission Automatic transmission with 8 speeds, torque converter, lock-up clutch and anti-slip function.
Sequential and traditional control type.
TRANSAXLE-type transmission.
Traction system equipped with rear self-locking differential.
Suspension Front suspensions with double wishbone independent wheels.
Multilink system rear suspensions on independent wheels.
The air suspension system features air spring units at both axles and a closed air supply unit.
Steering Electric Power Steering (EPS) system, axis parallel type.
Steering diameter = 13.72 yd (12.55 m).
No. of steering wheel turns = 1.41 (to the left and right).Features and Specifications
