FUEL CONSUMPTION
The fuel consumption figures given in the table below are determined on the basis of the type-approval tests laid down by
specific European Directives.
The following procedures are used to measure the fuel consumption:
urban cycle: begins with cold starting, followed by driving simulating the use of the vehicle in town;
extra-urban cycle: driving that simulates using the vehicle out of town with frequent acceleration in all gears; the speed
varies from 0 to 120 km/h;
combined consumption: calculated with a weighting of approximately 37% of the urban cycle and 63% of the extra-urban
cycle.
IMPORTANT The type of route, traffic situations, weather conditions, driving style, general conditions of the vehicle, trim
level/equipment/accessories, climate control system, vehicle load, roof rack, other situations that affect aerodynamics or air
drag may lead to different fuel consumption levels than those measured.
Fuel consumption according to the current European directive (litres/100km)
NOTE Consumption of methane-fuelled Natural Power versions is intended in m
3/100 km.
Versions Urban Extra-urban Combined
1.4 Euro 68.9 5.8 6.9
1.3 Multijet 80 HP / 95 HP Euro 6
4.7
(*) / 4.8 (**)3.5(*) / 3.6 (**)3.9(*) / 4.0 (**)
1.3 Multijet 80 HP / 95 HP NO
START & STOP Euro 65.6(*) / 5.7 (**)3.7(*) / 3.8 (**)4.4(*) / 4.5 (**)
1.3 MultiJet 80 HP Euro 6(#)4.5(*) / 4.7 (**)3.4(*) / 3.5 (**)3.8(*) / 3.9 (**)
1.4 Natural Power
8.9(°) / 8.6 (°°)5.5(°)/ 5.5(°°)6.8(°)/ 6.6(°°)
(*)Cargo versions
(**)Combi versions
(#) Versions with COMFORT-MATIC transmission (consumption related to AUTO-ECO logic)
(°) Running on petrol
(°°) Methane fuel supply (m
3/100 km)
167

CO2EMISSIONS
The CO2emission figures in the table below refer to combined fuel consumption.
VersionsCO2emissions according to the current European directive
(g/km)
1.4 Euro 6161
1.3 Multijet 80 HP / 95 HP Euro 6
104
(*)/ 106(**)
1.3 Multijet 80 HP / 95 HP NO START & STOP Euro 6
115(*)/ 118(**)
1.3 MultiJet 80 HP Euro 6(#)100(*)/ 103(**)
1.4 Natural Power
157(°)/ 119(°°)
(*) Cargo versions
(**) Combi versions
(#) Versions with COMFORT-MATIC transmission
(°) Running on petrol
(°°) Running on methane
168
TECHNICAL DATA

PRESCRIPTIONS FOR HANDLING THE VEHICLE AT THE END OF
ITS LIFE
Fiat has been committed for many years to safeguarding the environment through the constant improvement of its production
processes and manufacturing products that are increasingly "eco-compatible". To assure customers of the best possible
service in terms of respecting environmental laws and in response to European Directive 2000/53/EC governing vehicles at the
end of their life, Fiat is offering their customers the opportunity of handing over their vehicle (*) at the end of its life without
incurring any additional costs.
The European Directive sets out that when the vehicle is handed over, the last keeper or owner should not incur any expenses
as a result of it having a zero or negative market value. In particular, in almost all European Union countries, until 1st January
2007, vehicles registered after 1st July 2002 will be collected free of charge, whilst from 2007 collection will be free of charge
irrespective of the year of registration as long as the vehicle contains its basic components (in particular, the engine and
bodywork) and has no additional waste.
To hand your vehicle over at the end of its life without extra cost, contact a Fiat Dealership or authorised collection and
scrapping centres. These centres have been carefully chosen to offer high quality service for the collection, treatment and
recycling of vehicles at their end of life, respecting the surrounding environment.
You can find further information on these collection and scrapping centres either from a Fiat or Fiat Commercial Vehicle
Dealership or by calling the freephone number 00800 3428 0000 or by going on the Fiat website.
(*) Vehicle for transporting passengers with a maximum of nine seats and a total permitted weight of 3.5 t
169

MULTIMEDIA
This chapter describes the main
functions of the radio which may be
fitted on the vehicle.RADIO.............................................171
OFFICIAL TYPE APPROVALS .........181
170
MULTIMEDIA

RADIO
(for versions/markets, where provided)
The radio has been designed according
to the specifications of the passenger
compartment, with a personalised
design matching the style of the
dashboard perfectly.
TIPS
Road safety
Please, learn how to use all different
radio functions (e.g. save stations)
before beginning to drive.
Reception conditions
Reception conditions change
constantly while driving. Reception may
be interfered with by the presence of
mountains, buildings or bridges,
especially when you are far away from
the broadcaster.
IMPORTANT The volume may be
increased when receiving traffic
information and news.
153)
Care and maintenance
Clean the cover with a soft anti-static
cloth only. Cleaning and polishing
products may damage the surface.ANTITHEFT PROTECTION
The radio is equipped with an anti-theft
protection system based on the
exchange of information between the
radio and the electronic control unit
(Body Computer) present on the
vehicle.
This system guarantees maximum
safety and prevents the secret code
from being entered each time the radio
power supply is disconnected.
If the check has a positive outcome, the
radio will start to function, whereas if
the comparison codes are not the
same or if the electronic control unit
(Body Computer) is replaced, the
device will ask the user to enter the
secret code according to the procedure
described in the paragraph below.
Entering the secret code
When the radio is switched on, if the
secret code is requested, the display
will show the word "Code" for about 2
seconds followed by four dashes "- -
- -".
The code is made up of four digits from
1 to 6, each corresponding to one of
the dashes.
To enter the first digit, press the
corresponding button of the preset
stations (from 1 to 6). Enter the other
code digits in the same way.If the four digits are not entered within
20 seconds, the display will show
"Enter code----".Ifthis occurs, it is
not considered an incorrect code entry.
After entering the fourth digit (within
20 seconds), the radio will work.
If an incorrect code is entered, the radio
will emit a sound and the display
shows the text "Radio blocked/wait" to
notify the user of the need to enter
the correct code.
Each time the user enters an incorrect
code, the waiting time will gradually
increase (1 min, 2 min, 4 min, 8 min, 16
min, 30 min,1h, 2h, 4h, 8h, 16h, 24h)
up to a maximum of 24 hours. The
waiting time will be shown on the
display with the text "Radio blocked/
wait". After the text has disappeared it
is possible to start the code entering
procedure again.
Vehicle radio passport
This document certifies ownership of
the car radio. The car radio passport
shows the radio model, serial number
and secret code.
IMPORTANT Keep the radio passport in
a safe place so that you can give the
information to the relevant authorities if
the radio is stolen.
171

In case of loss of the car radio
passport, contact the Fiat Dealership,
taking an ID document and the vehicle
ownership documents.
SETUP
The system consists of:
radio supply leads;
front door panel speaker cables;
rear speaker wires (located next to
parcel shelf) (for versions/markets,
where provided)
radio housing;
antenna wires.
SYSTEM TECHNICAL
SPECIFICATIONS
The system consists of:
radio supply leads;
front door panel speaker cables;
rear speaker wires (located next to
parcel shelf) (for versions/markets,
where provided)
2 tweeter located on rear-view mirror
trim;
2 mid-woofer Ø130 mm located on
the door;
rear speakers (optional, for
versions/markets, where provided);
2 full-range Ø100 mm speakers
located on the parcel shelf;
anti-theft protection system;
aerial;
radio with CD MP3 player.
172
MULTIMEDIA

QUICK GUIDE
183F0T0016
173

174
MULTIMEDIA
General functions
Button Functions Mode
ON/OFFIgnition Short button/knob press
Switching off Long button/knob press
Volume adjustment Left/right button/knob rotation
MUTEVolume activation/deactivation (Mute/Pause) Short button press
FM ASFM1, FM2, FM Autostore radio source selection Brief cyclical button press
AMMW1, MW2 radio source selection Brief cyclical button press
CDSelction of radio/CD/CD CHANGER source Brief cyclical button press
AUDIOAudio adjustments: low tones (BASS), high tones
(TREBLE), RH/LH balance (BALANCE), front/rear
balance (FADER)Menu activation: short button press
Adjustment type selection: press
orbuttons.
Value adjustment: pressorbuttons.
MENUAdvanced functions adjustmentMenu activation: short button press
Adjustment type selection: press
orbuttons.
Value adjustment: pressorbuttons.
