207
• Although the LPG system has numerous safety features, it is
advisable to proceed as follows every time the vehicle is not in
use for a long period or moved in an emergency as a result of a
breakdown or accident:
unscrew the fastening devices, then remove the cover B. Close
the LPG valve rotating the ring nut C clockwise; refit the cover and
tighten the fixing devices.
• It is strictly forbidden to use any additive in the LPG.
• Periodically (at least once every six months) it is advisable to
let the LPG in the tank run out and, at the first refuelling, check
that it does not exceed the maximum capacity of 30.5 litres
(including reserve). If the level is above 30.5 litres (reserve
included) contact a Fiat Dealership immediately.
In special usage conditions:
• starting up and operation at low ambient temperature
• LPG supply with low propane content: the system may
switch temporarily to petrol operation, without any indication.
In the case of:
• low LPG levels in the tank
• request for high performance (e.g. overtaking, car fully laden,
steep hills): the system can automatically switch to petrol
operation to guarantee the required engine performance; in this
event, the performed switching is shown by the orange (petrol)
LED lit and the green (LPG) LED off on the switch. When the
above conditions stop, the system automatically restores the
LPG operation; the orange (petrol) LED turns off and the green
(LPG) LED is lit on the switch.
(CONTINUED)
VEHICLE SAFETY
• To achieve the automatic switching described above, make sure
that there is always enough fuel in the petrol tank.
• There must therefore always be enough petrol in the tank to
protect the petrol pump and to guarantee temporary switching
from LPG to petrol operation.
30) CHANGING A WHEEL
When turning the jack handle make sure that it can turn freely
without scraping your hand against the ground. The moving
components of the jack (“worm screw” and joints) can also cause
injuries: avoid touching them. If you come into contact with
lubricating grease, clean yourself thoroughly.
31) FIX&GO QUICK TYRE REPAIR KIT
• The sealant fluid is effective with external temperatures between
-40°C and +55°C. The sealant has an expiry date. It is possible to
repair tyres which have been damaged on tread up to a diameter
of 6 mm. Show the cartridge and the label to the personnel
charged with handling the tyre treated with the tyre repair kit.

IMPORTANT INFORMATION AND RECOMMENDATIONS
208
1) KEYS - REMOTE CONTROL
Used batteries should be disposed of, as specified by law, in
the special containers, otherwise take them to a Fiat
Dealership, which will deal with their disposal.
2) CLIMATE CONTROL SYSTEM
The system uses R1234yf coolant, which is compatible with
the laws in force in the countries where the vehicle is sold.
When charging, only use the gas indicated on the plate in the
engine compartment. The use of other coolants affects the
efficiency and condition of the system. The lubricant used for
the compressor is also strictly linked to the refrigerant gas type,
refer to the Fiat Dealership.
3) SERVICING - CHECKING FLUID LEVELS
• Used engine oil and oil filters contain substances which are
harmful to the environment. To change the oil and filters, we
advise you to contact a Fiat Dealership.
• Used transmission fluid contains substances that are harmful
to the environment. It is advisable to have the oil changed by a
Fiat Dealership where it will be disposed of respecting the
environment and according to legal requirements.
•Batteries contain substances which are very dangerous for the
environment. It is advisable to contact a Fiat Dealership for
battery replacement.
ENVIRONMENTAL PROTECTION
4) MAINTENANCE - BODYWORK
Detergents pollute the environment. Only wash your vehicle in
areas equipped to collect and treat wastewater from this type of
activity.
