2018 CADILLAC CT6 Warranty Guide

Cadillac Limited Warranty and Owner Assistance Information (GMNA-
Localizing-U.S.-11348300) - 2018 - crc - 2/6/17
20 EMISSION CONTROL SYSTEMS WARRANTY
Your Rights and Obligations (For
Vehicles Subject to California
Exhaust Emission Standards)
The California Air Resources Board
and General Motors are pleased to
explain the emission control system
warranty on your vehicle. In
California, new motor vehicles must
be designed, built, and equipped to
meet the state's stringent anti-smog
standards. Cadillac must warrant the
emission control system on your
vehicle for the periods of time and
mileage listed provided there has been
no abuse, neglect, or improper
maintenance of your vehicle. Your
vehicle's emission control system may
include parts such as the fuel
injection system, ignition system,
catalytic converter, and engine
computer. Also included are hoses,
belts, connectors, and other
emission-related assemblies.
Where a warrantable condition exists,
Cadillac will repair your vehicle at no
cost to you including diagnosis, parts,
and labor.California Emission Defect and
Emission Performance Warranty
Coverage
For cars and trucks with light duty or
medium duty emissions:
.
For 3 years or 50,000 miles,
whichever comes first:
‐If your vehicle fails a smog
check inspection, Cadillac will
make all necessary repairs and
adjustments to ensure that your
vehicle passes the inspection.
This is your Emission Control
System Performance Warranty.
‐ If any emission-related part on
your vehicle is defective,
Cadillac will repair or replace it.
This is your Short-term
Emission Control Systems
Defects Warranty.
. For 7 years or 70,000 miles,
whichever comes first:
‐If an emission-related part listed
in this booklet specially noted
with coverage for 7 years or
70,000 miles is defective,
Cadillac will repair or replace it. This is your Long-term Emission
Control System Defects
Warranty.
. For 8 years or 80,000 miles,
whichever comes first for vehicles
with a Gross Vehicle Weight
Rating (GVWR) of 8,500 lbs.
or less:
‐If the catalytic converter,
vehicle/powertrain control
module, transmission control
module, or other onboard
emissions diagnostic device,
including emissions-related
software, is found to be
defective, Cadillac will repair or
replace it under the Federal
Emission Control System
Warranty.
. For 15 years or 150,000 miles,
whichever comes first for a
Transitional Zero Emission
Vehicle (TZEV):
‐If any emission-related part*
listed in this booklet is
defective, Cadillac will repair or
replace it. This is your (TZEV)
Emission Control System
Defects Warranty.

Cadillac Limited Warranty and Owner Assistance Information (GMNA-
Localizing-U.S.-11348300) - 2018 - crc - 2/6/17
EMISSION CONTROL SYSTEMS WARRANTY 21
* TZEV Hybrid Batteries and Hybrid
A/C Compressors are covered for
10 years or 150,000 miles, whichever
comes first.
Any authorized Cadillac dealer or CT6
PLUG-IN Certified Cadillac dealerwill,
as necessary under these warranties,
replace, repair, or adjust to GM
specifications any genuine GM parts
that affect emissions.
The applicable warranty period shall
begin on the date the vehicle is
delivered to the first retail purchaser
or, if the vehicle is first placed in
service as a demonstrator or company
vehicle prior to sale at retail, on the
date the vehicle is placed in such
service.
Owner's Warranty Responsibilities
As the vehicle owner, you are
responsible for the performance of the
scheduled maintenance listed in your
owner manual. GM recommends that
you retain all maintenance receipts for
your vehicle, but GM cannot deny
warranty coverage solely for the lack
of receipts or for your failure to
ensure the performance of all
scheduled maintenance.You are responsible for presenting
your vehicle to a GM dealer selling
your vehicle line as soon as a problem
exists. The warranted repairs should
be completed in a reasonable amount
of time, not to exceed 30 days.
As the vehicle owner, you should also
be aware that GM may deny warranty
coverage if your vehicle or a part has
failed due to abuse, neglect, improper
or insufficient maintenance,
modifications not approved by GM,
or if the defect is not
emissions-related.
If you have any questions regarding
your rights and responsibilities under
these warranties, you should contact
the Customer Assistance Center at
1-800-458-8006, or in California,
write to:
State of California Air Resources
Board
Mobile Source Operations Division
P.O. Box 8001
El Monte, CA 91731-2990

Cadillac Limited Warranty and Owner Assistance Information (GMNA-
Localizing-U.S.-11348300) - 2018 - crc - 2/6/17
22 EMISSION WARRANTY PARTS LIST
Emission-related defects in the
emission parts listed here are covered
under the Emission Control System
Warranty. The terms are explained in
theEmission Control Systems Warranty
0 18 under “Federal Emission Control
System Warranty ”and the “California
Emission Control System Warranty.”
Important: Certain parts may be
covered beyond these warranties if
shown with asterisk(s) as follows:
. (*) 7 years/70,000 miles, whichever
comes first, California Emission
Control System Warranty
coverage.
. (**) 8 years/80,000 miles,
whichever comes first, Federal
Emission Control System Warranty
coverage for light duty vehicles.
(Also applies to California certified
light duty and medium duty
vehicles.)
All listed parts 15 years/150,000 miles,
whichever comes first, on California
TZEV (NU6) vehicles registered in a
TZEV state except Hybrid batteries
and Hybrid A/C compressors, which
are covered for 10 years/
150,000 miles, whichever comes first. Powertrain Control System
Accelerator Pedal Position Sensor
Camshaft Position Actuator *
Camshaft Position Actuator Valve
Coolant Sensor
Data Link Connector
Engine Control Module (ECM) **
Engine Temperature Sensor
Flex Fuel Sensor
Fuel Control Module **
Humidity Sensor
Intake Air Temperature Sensor
Malfunction Indicator Lamp
Manifold Absolute Pressure Sensor
Mass Air Flow Sensor
Oil Pressure Sensor
Outside Air Temperature Sensor
Oxygen Sensor(s)
Powertrain Control Module (PCM) **
Thermostat
Throttle Position Sensor
Vehicle Speed SensorIgnition System
Camshaft Position Sensor(s)
Crankshaft Position Sensor(s)
Glow Plug(s) (Diesel)
Glow Plug Controller (Diesel)
Ignition Coil(s)
Ignition Control Module
Knock Sensor
Spark Plug Wires
Spark Plugs
Transmission Controls and Torque
Management
Clutch Solenoids and Switches
Control Solenoids and Pressure
Switches
Internal Mode Switch
Park/Neutral Switch
Transmission Control Module **
Transmission Fluid Temperature
Sensor
Transmission Speed Sensors

Cadillac Limited Warranty and Owner Assistance Information (GMNA-
Localizing-U.S.-11348300) - 2018 - crc - 2/6/17
EMISSION WARRANTY PARTS LIST 23
Vehicle Control System
Integrated Chassis Control Module **
(ETRS and Corvette only)
Vehicle Control Module (VCM) **
Fuel Management System
AFM Exhaust Valves and Controller
Diesel Fuel Injection Pump *
Diesel Direct Fuel Injector and Rail *
HD Duramax Fuel Pressure Regulator *
HD Duramax Fuel Pipes *
Fuel Injector
Fuel Pressure Regulator
Fuel Pressure Sensor
Fuel Pump Power Module
Fuel Rail Assembly
Fuel Tank Fuel Pump
Fuel Temperature Sensor
High Pressure Fuel Pump (SIDI)
Air Management System
Active Aero Shutters and Controller
Air Cleaner
Air Intake DuctsCharge Air Cooler *
Charge Air Cooler Control
Idle Air Control Valve
Idle Speed Control Motor
Intake Air Heater
Intake Manifold
Intake Manifold Gasket
Intake Manifold Tuning Valve
Supercharger *
Throttle Body
Turbocharger *
Turbocharger Pressure Sensor
Turbocharger Vane Position Sensor *
Turbocharger Vane Position Solenoid *
Secondary Air Injection System
Air Pump and Check Valves
Catalytic Converter System
Catalytic Converter(s) * **
Diesel Exhaust Emission Reduction
Fluid (DEF) Tank
Diesel Exhaust Aftertreatment
Actuators and Sensors
Diesel Particulate Filter (DPF) *
Exhaust Manifold and Gasket
Positive Crankcase Ventilation
(PCV) System
Oil Filler Cap
PCV Filter
PCV Oil Separator
PCV Valve
Exhaust Gas Recirculation (EGR)
System
EGR Feed and Delivery Pipes
EGR Temperature Sensor
EGR Valve
EGR Valve Cooler *
Evaporative Emission Control
System (Gasoline Engines)
Canister
Canister Solenoids and Valves
Fuel Feed and Return Pipes and Hoses
Fuel Filler Cap
Fuel Level Sensor
Fuel Limiter Vent Valve

Cadillac Limited Warranty and Owner Assistance Information (GMNA-
Localizing-U.S.-11348300) - 2018 - crc - 2/6/17
24 EMISSION WARRANTY PARTS LIST
Fuel Tank(s) *
Fuel Tank Filler Pipe (with restrictor)
Fuel Tank Vacuum or Pressure Sensor
Start/Stop System
Auxiliary Battery or Ultra Capacitor
Battery Isolator
Battery Control Module
Multifunction Power Supply Converter
Transmission Fluid Accumulator and
Solenoid
Hybrid
ACCM Hood Switch
Auxiliary Transmission Fluid Pump
Battery Control Module **
Battery Cooling Circuit
Battery Pack Current Sensor
Brake Pedal Travel Sensor
Charge Port
Charge Port Switches and Sensors
Drive Motor/Generator Control
Module **
Drive Motors and Resolvers *Eboost Brake Control Module **
Electro-Hydraulic Brake Control
Module **
Energy Storage Control Module **
Exhaust Heat Exchanger
Fuel Fill Door Sensors
High Voltage Battery Contactor
Hybrid Batteries *
Hybrid Battery Temperature and
Voltage Sensors
Hybrid EVAP Canister Assembly
Hybrid RESS Thermal Management:
Air and Coolant Sensors
Battery Coolant Pumps and
Cooling Fans
Battery High Voltage Heater
Battery Temperature Sensors
E-compressor * **
Power Electronics Coolant Pump
Port Valves
Rfg. Temperature and Pressure
Sensors
Internal Mode Switch (IMS)
Onboard Charger * ** SGCM Coolant Circuit (fan,
relay, pump)
Starter Generator *
Starter Generator Control Module **
Starter Generator Drive Belt
Traction Power Inverter
Module (TPIM) **
Vehicle Interface Control Module **
Wheel Speed Sensor
Miscellaneous Items Used with
Above Components and Certain
Tires are Covered
Belts
Boots
Clamps
Connectors
Ducts
Fittings
Gaskets
Grommets
Hoses
Housings
Mounting Hardware

Cadillac Limited Warranty and Owner Assistance Information (GMNA-
Localizing-U.S.-11348300) - 2018 - crc - 2/6/17
EMISSION WARRANTY PARTS LIST 25
Pipes
Pulleys
Sealing Devices
Springs
Tubes
Wiring and Relays
High Voltage Wiring
Tires (Heavy Duty Applications only 2
yr/24,000 mile Federal Emission
Defect Warranty)
Parts specified in your maintenance
schedule that require scheduled
replacement are covered up to their
first replacement interval or the
applicable emission warranty coverage
period, whichever comes first.
If failure of one of these parts results
in failure of another part, both will be
covered under the Emission Control
System Warranty.
For detailed information concerning
specific parts covered by these
emission control system warranties,
ask your dealer.Replacement Parts
The emission control systems of your
vehicle were designed, built, and
tested using genuine GM parts* and
the vehicle is certified as being in
conformity with applicable federal and
California emission requirements.
Accordingly, it is recommended that
any replacement parts used for
maintenance or for the repair of
emission control systems be new,
genuine GM parts.
The warranty obligations are not
dependent upon the use of any
particular brand of replacement parts.
The owner may elect to use
non-genuine GM parts for
replacement purposes. Use of
replacement parts which are not of
equivalent quality may impair the
effectiveness of emission control
systems.
If other than new, genuine GM parts
are used for maintenance
replacements or for the repair of parts
affecting emission control, the owner
should assure himself/herself that
such parts are warranted by theirmanufacturer to be equivalent to
genuine GM parts in performance and
durability.
*
“Genuine GM parts,” when used in
connection with GM vehicles, means
parts manufactured by or for GM,
designed for use on GM vehicles, and
distributed by any division or
subsidiary of GM.
Maintenance and Repairs
Maintenance and repairs can be
performed by any qualified service
outlet; however, warranty repairs must
be performed by an authorized dealer
except in a situation where the vehicle
owner is significantly inconvenienced
and a warranted part or a warranty
station is not reasonably available to
the vehicle owner.
In a situation where the vehicle owner
is significantly inconvenienced, and an
authorized dealer is not reasonably
available, repairs may be performed at
any available service establishment or
by the owner, using any replacement
part. Cadillac will consider
reimbursement for the expense
incurred, including diagnosis, not to
exceed the manufacturer's suggested

Cadillac Limited Warranty and Owner Assistance Information (GMNA-
Localizing-U.S.-11348300) - 2018 - crc - 2/6/17
26 EMISSION WARRANTY PARTS LIST
retail price for all warranted parts
replaced and labor charges based on
Cadillac's recommended time
allowance for the warranty repair and
the geographically appropriate labor
rate. A part not being available within
10 days or a repair not being
completed within 30 days constitutes
a significant inconvenience. Retain
receipts and failed parts in order to
receive compensation for warranty
repairs reimbursable due to these
situations.
If you are in a situation where you are
significantly inconvenienced and it is
necessary to have repairs performed
by other than a Cadillac dealer and
you believe the repairs are covered by
emission warranties, take the replaced
parts and your receipt to a Cadillac
dealer for reimbursement
consideration. This applies to both the
Federal Emission Defect Warranty and
Federal Emission Performance
Warranty.
Receipts and records covering the
performance of regular maintenance
or other repairs (such as those
outlined earlier) should be retained in
the event questions arise concerningmaintenance. These receipts and
records should be transferred to each
subsequent owner. GM will not deny
warranty coverage solely on the
absence of maintenance records.
However, GM may deny a warranty
claim if a failure to perform scheduled
maintenance resulted in the failure of
a warranty part.
Claims Procedure
As with the other warranties covered
in this booklet, take your vehicle to
any authorized Cadillac dealer facility
to obtain service under the emission
warranty. This should be done as soon
as possible after failing an
EPA-approved I/M test or a California
smog check test, or at any time you
suspect a defect in a part.
Those repairs qualifying under the
warranty will be performed by any
Cadillac dealer at no charge. Repairs
which do not qualify will be charged
to you. You will be notified as to
whether or not the repair qualifies
under the warranty within a
reasonable time, not to exceed 30 days
after receipt of the vehicle by the
dealer, or within the time period
required by local or state law.
The only exceptions would be if you
request or agree to an extension, or if
a delay results from events beyond the
control of your dealer or GM. If you
are not so notified, GM will provide
any required repairs at no charge.
In the event a warranty matter is not
handled to your satisfaction, see
Customer Satisfaction Procedure
028.
For further information or to report
violations of the Emission Control
System Warranty, you may contact
the EPA at:
U.S. Environmental Protection Agency
Office of Transportation and Air
Quality
Compliance Division, Light-Duty
Vehicle Group
Attn: Warranty Complaints
2000 Traverwood Drive
Ann Arbor, MI 48105
Email:
[email protected]

Cadillac Limited Warranty and Owner Assistance Information (GMNA-
Localizing-U.S.-11348300) - 2018 - crc - 2/6/17
EMISSION WARRANTY PARTS LIST 27
For a vehicle subject to the California
Exhaust Emission Standards, you may
contact the:
State of California Air Resources
Board
Mobile Source Operations Division
P.O. Box 8001
El Monte, CA 91731-2990
