To shift fromToProcedureVehicles with manual transmissionVehicles with automatic transmission2H4HThe drive mode-selector can be operated while the ve-
hicle is either moving or stationary.
When the vehicle is not in motion, shift the gearshift
lever to the “N” (Neutral) position before operating
the drive mode-selector.
When the vehicle is moving, and only while it can be steered straight ahead, release the accelerator pedal
before operating the drive mode-selector.The drive mode-selector can be operated while the
vehicle is either moving or stationary.
When the vehicle is not in motion, shift the selector
lever to the “N” (NEUTRAL) position before oper-
ating the drive mode-selector.
When the vehicle is moving, and only while it can
be steered straight ahead, shift the selector lever to
the “D” (DRIVE) position, and release the accelera- tor pedal before operating the drive mode-selector.
4H2H
4H4L
Stop the vehicle, depress the clutch pedal to the floor
and operate the drive mode-selector.
Keep depressing the clutch pedal while 2WD/4WD
operation indication lamp continues to blink.
Stop the vehicle, shift the selector lever to the “N”
(NEUTRAL) position, and operate the drive mode-
selector.
If operation is made with the selector lever placed
in any other position than “N” (NEUTRAL) posi-
tion, a gear noise may be generated, with a possible
failure to shift into a proper gear.
4L4H
NOTEl Shifting of setting of the drive mode-selector
between “2H” ↔ “4H” should only be doneat speeds below 100 km/h (62 mph).
l During driving, never attempt to shift from
“4H” to “4L”.
l When shifting from “2H” to “4H” in cold
weather while the vehicle is in motion, the transfer gear may make some noise. In cold
weather, try to shift the gear while the vehi-
cle is stopped.
l When shifting between “4H” and “4L”, the
transfer gear may make some noise.NOTEl When the drive mode-selector is set between
“2H” ↔ “4H” while the vehicle is stopped,
the 2WD/4WD operation indication lamp blinks while the selection is in process.
Drive slowly and normally after confirming that the lamp is illuminated. Refer to “2WD/4WD operation indication lamp and
low-range indication lamp” on page 6-38.
l When the drive mode-selector is set between
“2H” ↔ “4H” while the cruise control is ac-
tivated, the transfer gear may make some
noise.NOTEl When the drive mode-selector is set be-
tween“4H” ↔ “4L” in cold weather, its se-
lection may not complete. Return the drive mode-selector to its previous position. After
the engine is warmed up, make the range se- lection again.
Easy select 4WD*
6-37OKTE17E1Starting and driving6

CAUTIONlDo not operate the drive mode-selector
while the rear wheels of the vehicle are slip-
ping on snow or ice.2WD/4WD operation indica-
tion lamp and low-range indi- cation lamp
E00641300041
When the ignition switch is in the “ON” posi-
tion or the operation mode is put in ON, the
2WD/4WD operation indication lamp (1) andthe low-range indication lamp (2) shows the
shifting condition. The 2WD/4WD operation
indication lamp comes on at each drive mode-selector position as follows:
“2H” ↔ “4H”Drive mode-selector
positionIndication lamp
2HDrive mode switch-ing in progress4H
: Blink
: Illuminate
: Remain off
NOTEl When the drive mode-selector is set between
2H ↔ 4H, the 2WD/4WD operation indica-tion lamp blinks while the selection is in
process. Take the following precautions
when the indication lamp is blinking.NOTE• Keep the steering wheel in the straight
ahead position while making range selec-
tions. If you attempt to drive forward with the steering wheel turned, gear rattling or
shock may occur and the desired range may not actually be selected.
• When the drive mode-selector is set be-
tween “2H” ↔ “4H” while the vehicle isstopped, the 2WD/4WD operation indica-
tion lamp blinks while the selection is in
process. Drive slowly and normally after confirming that the lamp is switched.
• If the 2WD/4WD operation indication
lamp continues blinking after a “2H” ↔ “4H” selection has been made with thevehicle moving, hold the steering wheel in the straight ahead position and slowly
depress the accelerator pedal several
times.
“4H” ↔ “4L”
Drive mode-se-
lector positionIndication lamp
4HEasy select 4WD*
6-38OKTE17E1Starting and driving6

Drive mode-se-lector positionIndication lamp
Drive mode
switching in pro- gress
and
4Landand
: Blink
: Illuminate
: Remain off
NOTElThe 2WD/4WD operation indication lamp
will blink during shifting process from “4H”to “4L” or vice versa, as the transfer passes
through the neutral position.
Be sure to operate the drive mode-selector
until the 2WD/4WD operation indication lamp illuminates again.
l When parking, apply the parking brake be-
fore stopping the engine and make sure that the 2WD/4WD operation indicator and the
low range lamp are not blinking during shift- ing process between “4H” ↔ “4L”. Other- wise, the vehicle could unexpectedly move
even if the automatic transmission is in the “P” (PARK) position.
l If, after a “4H” ↔ “4L” selection has been
made, the 2WD/4WD operation indicator continues blinking and the desired range isnot actually selected, return the drive mode- selector to its previous position. Place the
steering wheel in the straight ahead position, drive the vehicle forward, and release the ac-
celerator pedal. Next, hold down the clutch pedal (with manual transmission) or place
the selector lever in the “N” (NEUTRAL)
position (with automatic transmission) and make the range selection again.NOTEl If the low range lamp blinks when you at-
tempt to make a “4H” ↔ “4L” selection, a
“4H” ↔ “4L” selection cannot be made.
Stop the vehicle and release the accelerator pedal. Next, hold down the clutch pedal(with manual transmission) or place the se-lector lever in the “N” (NEUTRAL) position(with automatic transmission) and make the
range selection again.
l The Active Stability Control function is sus-
pended while “4L” is selected.
indication
lamp is illuminated while these functions are suspended. It does not indicate a problem.
When “2H” or “4H” is selected, this lamp goes out and function again. Refer to “ASTCindication lamp, ASTC OFF indication
lamp” on page 6-62.
CAUTIONl If a problem is detected in the transfer sys-
tem, a safety device will activate. The 2WD/4WD operation indicator blinks (twiceper second), and transfer shifting will be-
come impossible. Park your vehicle in a safe place, turn off the engine for a few moments.Restart the engine. The lamp should resume normal operation. If the lamps continue to
blink, have the vehicle checked by a MITSUBISHI MOTORS Authorized Serv-
ice Point as soon as possible.
Easy select 4WD*
6-39OKTE17E1Starting and driving6

Super select 4WD II*E00605701253
Shifting to rear-wheel drive or 4-wheel drive can be made by operating the drive mode-se-lector (A). Set the drive mode-selector to an
appropriate position according to the road surface conditions. In addition, the 2WD/4WD operation indication lamp andlow-range indication lamp indicates the drive
mode-selector setting state. Refer to “2WD/4WD operation indication lamp and
low-range indication lamp” on page 6-42.Drive mode-selector position
and 2WD/4WD operation indi- cation lamp
E00605801371
Drive mode-selec- tor positionIndicationlampDriving
conditions
2H
Rear-
wheel driveWhen
driving on
dry paved road.
4H
Full-time 4-wheel drive
The basic
position
for super select
4WD II.
When
driving on
dry paved
or slippery roads.
4HLc
Centre dif- ferentiallock en-
gaged 4- wheeldriveWhen
driving on
rough,
sand or snow cov-ered roads.Drive mode-selec- tor positionIndicationlampDriving
conditions
4LLc
Low range centre dif- ferentiallock en-
gaged 4- wheeldrive
and
When
driving up
or down steep hills,on rough or muddy
roads (es- pecially
when in-
creased
torque is required).
: Illuminate
: Remain off
CAUTIONl The “4LLc” range gives maximum torque
for low-speed driving on steep slopes, as
well as sandy, muddy, and other difficult
surfaces. On vehicles with A/T, do not ex-
ceed speeds of approximately 70 km/h
(43 mph) in “4LLc” range.
Super select 4WD II*
6-40OKTE17E1Starting and driving6

CAUTIONlDo not drive your vehicle in the “4HLc” or
“4LLc” position on dry paved roads and highways. Doing so may result in excessivetyre wear, increased fuel consumption, and
possible noise generation. It may also in-
crease the differential oil temperature, which
may damage the drive system. Further, the drive train will be subjected to excessive loading, resulting in oil leakage, component
seizure, or other serious problems. On dry
paved roads and highways, drive the vehicle
in “2H” or “4H” only.Drive mode-selector operation
E00605901402
The drive mode is shown on the drive mode-
selector knob.
: Turn the drive mode-selector
: Turn the drive mode-selector while hold-
ing it down
The drive mode-selector should be positioned
in accordance with the following operating conditions:To shift fromToProcedureVehicles with manual transmissionVehicles with automatic transmission2H4HThe drive mode-selector can be operated while the ve-
hicle is either moving or stationary.
When the vehicle is not in motion, shift the gearshift
lever to the “N” (Neutral) position before operating the
drive mode-selector.
When the vehicle is moving, and only while it can be
steered straight ahead, release the accelerator pedal be- fore operating the drive mode-selector.The drive mode-selector can be operated while the ve-
hicle is either moving or stationary.
When the vehicle is not in motion, shift the selector
lever to the “N” (NEUTRAL) position before operating
the drive mode-selector.
When the vehicle is moving, and only while it can be
steered straight ahead, shift the selector lever to the “D”
(DRIVE) position, and release the accelerator pedal be-
fore operating the drive mode-selector.4H2H or 4HLc
4HLc4H4HLc4LLc
Stop the vehicle, depress the clutch pedal to the floor
and operate the drive mode-selector.
Keep depressing the clutch pedal while the 2WD/4WD
operation indication lamp continues to blink.Stop the vehicle, shift the selector lever to the “N”
(NEUTRAL) position, and operate the drive mode-se-
lector.
If operation is made with the selector lever placed in any other position than “N” (NEUTRAL) position, a
Super select 4WD II*
6-41OKTE17E1Starting and driving6

To shift fromToProcedureVehicles with manual transmissionVehicles with automatic transmission4LLc4HLcgear noise may be generated, with a possible failure to
shift into a proper gear.NOTEl Setting of the drive mode-selector between
“2H”, “4H” and “4HLc” should only bedone at speeds below 100 km/h (62 mph).
l During driving, never attempt to shift from
“4HLc” to “4LLc”.
l When shifting between “2H”, “4H” and
“4HLc” in cold weather while the vehicle is
in motion, the transfer gear may make some noise. In cold weather, try to shift the gearwhile the vehicle is stopped.
l When shifting between “4LLc” and “4HLc”,
the transfer gear may make some noise.
l When the drive mode-selector is set between
“2H”, “4H” and “4HLc” while the vehicle is
stopped, the 2WD/4WD operation indication lamp blinks while the selection is in process. Drive slowly and normally after confirmingthat the lamp is illuminated. (Refer to “2WD/4WD operation indication lamp and
low-range indication lamp” on page 6-42.)
l When the drive mode-selector is set between
“2H”, “4H” and “4HLc” while the cruise
control is activated, the transfer gear may
make some noise.NOTEl When the drive mode-selector is set be-
tween“4HLc” ↔ “4LLc” in cold weather, its selection may not complete. Return the drivemode-selector to its previous position. After
the engine is warmed up, make the range se-
lection again.CAUTIONl Do not operate the drive mode-selector
while the rear wheels of the vehicle are slip-
ping on snow or ice.2WD/4WD operation indica-
tion lamp and low-range indi- cation lamp
E00606001309
A- Front wheel lamp B- Centre differential lock lamp
C- Rear wheel lamp
D- Low-range indication lamp
Super select 4WD II*
6-42OKTE17E1Starting and driving6

When the ignition switch is in the “ON” posi-
tion or the operation mode is put in ON, the 2WD/4WD operation indication lamp and the
low-range indication lamp shows the shifting condition. The 2WD/4WD operation indica-tion lamp comes on at each drive mode-selec-
tor position as follows:
“2H” ↔ “4H”Drive mode-selector positionIndication lamp
2H
Drive mode switch-ing in progress
4H
: Blink
: Illuminate
: Remain off
“4H” ↔ “4HLc”Drive mode-selector positionIndication lamp
4H
Drive mode switch-ing in progress
4HLc
: Blink
: Illuminate
: Remain off
“4HLc” ↔ “4LLc”Drive mode-
selector posi- tion
Indication lamp
4HLc
Drive mode
switching in progressand
4LLcandand
: Blink
: Illuminate
: Remain off
Super select 4WD II*
6-43OKTE17E1Starting and driving6

NOTElWhen the drive mode-selector is set between
“2H”, “4H” and “4HLc”, the front wheel
and/or centre differential lock lamps blink
while the selection is in process. Take the following precautions when the indicationlamp is blinking.
• Keep the steering wheel in the straight
ahead position while making range selec- tions. If you attempt to drive forward with
the steering wheel turned, gear rattling or
shock may occur and the desired range may not actually be selected.
• When the drive mode-selector is set be-
tween “2H”, “4H” and “4HLc”, while the
vehicle is stopped, the front wheel and/or centre differential lock lamps blink whilethe selection is in process. Drive slowly and normally after confirming that the
lamp is switched.
• If the front wheel and/or centre differen-
tial lock lamps blinking after a “2H” ↔
“4H” ↔ “4HLc” selection has been made with the vehicle moving, hold the steering wheel in the straight ahead position and
slowly depress the accelerator pedal sev-
eral times.
l The front and the rear wheel lamps will
blink during shifting process from “4HLc”
to “4LLc” or vice versa, as the transfer pass-
es through the neutral position. Be sure to operate the drive mode-selector until the
front and the rear wheel lamps illuminate
again.NOTEl When parking, apply the parking brake be-
fore stopping the engine and make sure that the front and the rear wheel lamps and the low range lamp are not blinking during shift-ing process between “4HLc” ↔ “4LLc”.
Otherwise, the vehicle could unexpectedly move even if the automatic transmission is
in the “P” (PARK) position.
l If, after a “4HLc” ↔ “4LLc” selection has
been made, front and the rear wheel lamps continue blinking and the desired range isnot actually selected, return the drive mode-selector to its previous position. Place the
steering wheel in the straight ahead position, drive the vehicle forward, and release the ac-
celerator pedal. Next, hold down the clutch pedal (with manual transmission) or place
the selector lever in the “N” (NEUTRAL)
position (with automatic transmission) and make the range selection again.
l If the low range lamp blinks when you at-
tempt to make a “4HLc” ↔ “4LLc” selec-
tion, a “4HLc” ↔ “4LLc” selection cannot
be made. Stop the vehicle and release the ac- celerator pedal. Next, hold down the clutch pedal (with manual transmission) or placethe selector lever in the “N” (NEUTRAL)
position (with automatic transmission) and make the range selection again.NOTEl The Active Stability Control function is sus-
pended while “4LLc” is selected. indica-
tion lamp is illuminated while these func-
tions are suspended. It does not indicate a
problem. When “2H” or “4H” or “4HLc” is selected, this lamp goes out and function
again. Refer to “ASTC indication lamp, ASTC OFF indication lamp” on page 6-62.
Super select 4WD II*
6-44OKTE17E1Starting and driving6
