2016 TOYOTA RAV4 HYBRID Owners Manual

RAV4-HV_OM_OM42A56U_(U)
6179-1. Specifications
9
Vehicle specifications
*: Table 1  Occupant loading and distribution for vehicle normal load for
various designated seating capacities
Section width
The linear distance between the exteriors of
the sidewalls of an inflated tire, excluding ele-
vations due to labeling, decoration, or protec-
tive bands
SidewallThat portion of a tire between the tread and
bead
Sidewall separationThe parting of the rubber compound from the
cord material in the sidewall
Snow tire
A tire that attains a traction index equal to or
greater than 110, compared to the ASTM E-
1136 Standard Reference Test Tire, when
using the snow traction test as described in
ASTM F-1805-00, Standard Test Method for
Single Wheel Driving Traction in a Straight
Line on Snow-and Ice-Covered Surfaces, and
which is marked with an Alpine Symbol ( )
on at least one sidewall
Test rim
The rim on which a tire is fitted for testing, and
may be any rim listed as appropriate for use
with that tire
TreadThat portion of a tire that comes into contact
with the road
Tread ribA tread section running circumferentially
around a tire
Tread separationPulling away of the tread from the tire carcass
Treadwear indicators
(TWI)The projections within the principal grooves
designed to give a visual indication of the
degrees of wear of the tread
Wheel-holding fixtureThe fixture used to hold the wheel and tire
assembly securely during testing
Tire related termMeaning

618
RAV4-HV_OM_OM42A56U_(U)
9-1. Specifications
Designated seating
capacity, Number of occupantsVehicle normal load,
Number of occupantsOccupant distribution in a normally loaded vehicle
2 through 422 in front
5 through 1032 in front, 1 in second seat
11 through 155
2 in front, 1 in second
seat, 1 in third seat, 1 in fourth seat
16 through 207
2 in front, 2 in second
seat, 2 in third seat, 1 in fourth seat

619
RAV4-HV_OM_OM42A56U_(U)
9-2. Customization
9
Vehicle specifications
Customizable features
When customizing vehicle features, ensure that the vehicle is parked
in a safe place with the shift lever in P and the parking brake set.
Various setting can be changed. Refer to the list of settings that can be\
changed for details.
■
Changing using Entune Premiu m Audio with Navigation or
Entune Audio Plus
Press the “APPS” button.
Select “Setup” on the “Apps” screen and select “Vehicle”.
■Changing using Entune AudioPress the “SETUP” button.
Select “Vehicle” on the “Setup” screen.
■Changing using the multi-information display
Press or of the meter control switch and select on
the multi-information display.
Press or of the meter control switch and then press .
Your vehicle includes a variety of electronic features that can be
personalized to your preferences. The settings of these features
can be changed by using the mu lti-information display, Entune
Premium Audio with Navigation or Entune Audio, or at your
Toyota dealer.
Some function settings are change d simultaneously with other func-
tions being customized. Contact your Toyota dealer for further
details.
Customizing vehicle features
1
2
1
2
1
2

620
RAV4-HV_OM_OM42A56U_(U)
9-2. Customization
Vehicles with Entune Premium Audio with Navigation or Entune
Audio: Settings that can be changed using Entune Premium Audio
with Navigation or Entune Audio
Settings that can be changed using the multi-information display
Settings that can be changed by your Toyota dealer
Definition of symbols: O = Available, — = Not available
■
Instrument cluster ( P. 86, 96)
*: The default setting varies according to countries.
Customizable features
1
2
3
FunctionDefault
settingCustomized setting
Language*English French
OO—
Spanish
Units*miles
(MPG US)
miles
(MPG Impe- rial)
OO—
km (L/100 km)
km (km/L)
EV indicator On Off
—O—
Pop-up displayOnOff—O—
Accent colorLight blue
Blue
OO—Orange
Yellow
123

RAV4-HV_OM_OM42A56U_(U)
6219-2. Customization
9
Vehicle specifications
■LDA (Lane Departure Alert with steering control) (if equipped)
(  P. 243)
■PCS (Pre-Collision System) (if equipped) ( P. 228)
■Power back door (if equipped) ( P. 1 1 3 )
*: The open position is set by the power back door switch ( P. 1 1 7 )
FunctionDefault
settingCustomized setting
Steering AssistOnOff—O—
Alert sensitivityStandardHigh—O—
Vehicle sway warningOnOff—O—
Vehicle sway warning
sensitivityStandardLow—O—High
123
FunctionDefault settingCustomized setting
Alert timing
(Middle)

(Far)
—O—

(Near)
123
FunctionDefault settingCustomized setting
Opening angle5
1 to 4
—O—User setting*
Operation buzzer volume31—O—2
Operation buzzerOnOff——O
123

622
RAV4-HV_OM_OM42A56U_(U)
9-2. Customization
■Door lock (P. 107, 579)
FunctionDefault
settingCustomized setting
Unlocking using a mechanical
key
On (Driver’s
door unlocked
in one step, all
doors
unlocked in two steps)
Off (All doors unlocked
in one step)
——O
Speed linked door locking
functionOffOnO—O
Shift position linked door lock-
ing functionOnOffO—O
Shift position linked door
unlocking functionOnOffO—O
Driver’s door linked door
unlocking functionOffOnO—O
123

RAV4-HV_OM_OM42A56U_(U)
6239-2. Customization
9
Vehicle specifications
■Smart key system and wireless remote control (P. 107)
*: The default setting varies according to on some models.
■
Smart key system ( P. 107)
*: Settings that can be changed by electronic key ( P. 1 1 1 )
FunctionDefault
settingCustomized setting
Operation signal (buzzer)*Level 5OffO—OLevel 1 to 7
Operation signal (emergency
flashers)OnOffO—O
Adjust the time elapsed before
the automatic door lock func-
tion is activated if a door is not
opened after being unlocked
60 seconds
30 seconds
——O
120 seconds
Open door reminder buzzer
(When locking the vehicle)OnOff——O
Unlocking operation
Driver’s door unlocked in
one step, all doors
unlocked in
two steps
All doors
unlocked in
one step
O—O
Alarm (panic mode)OnOff——O
123
FunctionDefault settingCustomized setting
Smart key systemOnOffO—O
Select doors to unlock*Driver’s doorAll the doorsO—O
Number of consecutive door
lock operations2 timesAs many as desired——O
123

624
RAV4-HV_OM_OM42A56U_(U)
9-2. Customization
■Wireless remote control (P. 107)
*: If equipped
■
Moon roof ( P. 154)
■Turn signal lever ( P. 199)
FunctionDefault
settingCustomized setting
Wireless remote controlOnOff——O
Power back door unlocking
operation
*
Press and hold
Off
——OOne short press
Push twice
123
FunctionDefault settingCustomized setting
Automatic operationOnOff——O
123
FunctionDefault
settingCustomized setting
Time of flashing of the lane
change signal flashers3
Off
——O
4
5
6
7
123
