AVERTISSEMENT
■Modification et mise au rebut des composants du système de coussins
gonflables SRS
Ne mettez pas votre véhicule au rebut et n’effectuez aucune des modifica-
tions suivantes sans d’abord consulter votre concessionnaire Toyota. Les
coussins gonflables SRS pourraient fonctionner de manière incorrecte ou
se déployer (gonfler) accidentellement, ce qui serait susceptible d’occasion-
ner des blessures graves, voire mortelles.
● Installation, retrait, démontage et réparation des coussins gonflables SRS
● Réparations, modifications, retrait ou remplacement du volant, du tableau
de bord, de la planche de bord, des sièges ou du capitonnage des sièges,
des montants avant, latéraux et arrière ou des brancards de pavillon
● Réparations ou modifications de l’aile avant, du pare-chocs avant ou du
côté de l’habitacle
● Installation d’une protection de calandre (barre safari, barre kangourou,
etc.), de lames de déneigement, de treuils ou d’un porte-bagages de toit
● Modifications du système de suspension du véhicule
● Installation d’appareils électroniques tels qu’un émetteur-récepteur radio
ou un lecteur de CD
● Modifications à votre véhicule pour une personne aux capacités physiques
réduites

642
RAV4-HV_OM_OM42A56U_(U)

643
RAV4-HV_OM_OM42A56U_(U)
Index
What to do if... (Troubleshooting) .................... 644
Alphabetical index ..................... 647
For vehicles with Entune Premium Audio with Naviga-
tion or Entune Audio Plus, refer to the “NAVIGATION
AND MULTIMEDIA SYSTEM OWNER’S MANUAL” for
information regarding the equipment listed below.
• Navigation system
• Audio system
• Rear view monitor system
• Toyota parking assist monitor
• Panoramic view monitor

644What to do if... (Troubleshooting)
RAV4-HV_OM_OM42A56U_(U)
What to do if... (Troubleshooting)
●If you lose your mechanical keys, new mechanical keys can be made by
your Toyota dealer. (P. 105)
●If you lose your electronic keys, the risk of vehicle theft increases signifi-
cantly. Contact your Toyota dealer immediately. ( P. 106)
●Is the electronic key battery weak or depleted? (P. 506)
●Is the power switch in ON mode?
When locking the doors, turn the power switch off. ( P. 189)
●Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.
●The function may not operate properly due to the condition of the radio
wave. (P. 128)
●Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. (P. 1 1 0 )
If you have a problem, check the following before contacting
your Toyota dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked
The rear door cannot be opened

645What to do if... (Troubleshooting)
RAV4-HV_OM_OM42A56U_(U)
●Did you press the power switch while firmly depressing the brake pedal?
( P. 188)
●Is the shift lever in P? ( P. 188)
●Is the electronic key anywhere detectable inside the vehicle? ( P. 126)
●Is the steering wheel unlocked? (P. 191)
●Is the electronic key battery weak or depleted?
In this case, the hybrid system can be started in a temporary way.
( P. 580)
●Is the 12-volt battery discharged? ( P. 581)
●Is the power switch in ON mode?
If you cannot release the shift lever by depressing the brake pedal with the
power switch in ON mode: P. 578
●It is locked automatically to prevent theft of the vehicle. ( P. 191)
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. (P. 151)
●The auto power off function will be operated if the vehicle is left in ACCES-
SORY or ON mode (the hybrid system is not operating) for a period of
time. (P. 190)
If you think something is wrong
The hybrid system does not start
The shift lever cannot be shifted from P even if you depress
the brake pedal
The steering wheel cannot be tu rned after the hybrid system
is stopped
The windows do not open or close by operating the power
window switches
The power switch is turned off automatically

646What to do if... (Troubleshooting)
RAV4-HV_OM_OM42A56U_(U)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? (P. 537)
●The brake system warning light is on
Is the parking brake released? (P. 200)
Depending on the situation, other types of warning buzzer may also sound.
(  P. 535, 544)
●Is the message displayed on the multi-information display?
Check the message on the multi-information display. ( P. 544)
●When a warning light turns on or a warning message is displayed, refer to
P. 535, 544.
●Stop the vehicle in a safe place and replace the flat tire with the spare tire.
( P. 564)
●Try the procedure for when the vehicle becomes stuck in mud, dirt, or
snow. ( P. 591)
A warning buzzer sounds during driving
A warning buzzer sounds when leaving the vehicle
A warning light turns on or a warning message is displayed
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

647Alphabetical index
RAV4-HV_OM_OM42A56U_(U)
Alphabetical index
A/C ............................................ 414Air conditioning filter ............. 504
Automatic air conditioning
system ......... ....................... 414
Micro dust and pollen filter .... 416
ABS (Anti-lock Brake System) .................................. 296Function ................................ 296
Warning light ......................... 536
Air conditioning filter .............. 504
Air conditioning system.......... 414 Air conditioning filter ............. 504
Automatic air conditioning system ......... ....................... 414
Micro dust and pollen filter .... 416
Airbags ....................................... 36 Airbag operating conditions .... 44
Airbag precautions for
your child .............................. 39
Airbag warning light .............. 535
Correct driving posture ........... 26
Curtain shield airbag operating conditions ............. 44
Curtain shield airbag precautions ........................... 41
Front passenger occupant classification syst em............. 49
General airbag precautions .... 39
Locations of airbags................ 36
Modification and disposal of airbags.............................. 43
Side airbag operating conditions ............................. 44
Side airbag precautions .......... 41
Side and curtain shield airbags operating
conditions ............................. 44
Side and curtain shield airbags precautions .............. 41 SRS airbag instructions for
Canadian owners ............... 633
SRS airbags ........................... 36
All-wheel drive system............ 297
Anchor brackets ........................ 62
Antenna Radio .................................... 338
Smart key system ................. 126
Anti-lock brake system (ABS) ...................................... 296Function ................................ 296
Warning light......................... 536
Armrest..................................... 443
Assist grips .............................. 444
Audio input ...................... 322, 356
Audio system ........................... 317 Audio input.................... 322, 356
AUX port/USB port ....... 322, 356
Bluetooth
® audio .................. 369
CD player.............................. 339
iPod ...................................... 346
MP3/WMA disc ..................... 339
Optimal use .......................... 336
Portable music player ........... 322
Radio .................................... 337
Steering wheel audio switch ................................. 321
USB memory ........................ 351
Automatic air conditioning system
Air conditioning filter ............. 504
Automatic air conditioning system .......... ...................... 414
Automatic High Beam ............. 205
Automatic light control system.................................... 204
Auxiliary box ............................ 430
AUX port ........................... 322, 356
