3376-1. Using the air conditioning system and defogger
6
Interior features
CAMRY_HV_U (OM33C35U)n
Location of air outlets
The air outlets and air volume
change according to the
selected airflow mode.
*: If equipped
n
Adjusting the position of and opening and closing the air out-
lets
Direct air flow to the left or right, up or down.
Turn the knob to open or close the vent.
Air outlets
*
FrontRear (if equipped)
1
2

3386-1. Using the air conditioning system and defogger
CAMRY_HV_U (OM33C35U)
nOperation of the air conditioning system in Eco drive mode
In Eco drive mode, the air conditioning system is controlled as follows to pri-
oritize fuel efficiency:
lEngine speed and compressor operation controlled to restrict heating/cool-
ing capacity
l Fan speed restricted when automatic mode is selected
To improve air conditioning performance, perform the following operations:
l Adjust the fan speed
l Turn off Eco drive mode
n Using automatic mode
Fan speed is adjusted automatically according to the temperature setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow
immediately after is pressed.
n Fogging up of the windows
lThe windows will easily fog up when the humidity in the vehicle is high.
Turning on will dehumidify the air from the outlets and defog the wind-
shield effectively.
l If you turn off, the windows may fog up more easily.
l The windows may fog up if the recirculated air mode is used.
n Windshield fog detection function
When automatic mode is set, the humidity sensor (P. 340) detects fog on
the windshield and controls the air conditioning system to prevent fog.
n Outside/recirculated air mode
lWhen driving on dusty roads such as tunnels or in heavy traffic, set the out-
side/recirculated air mode button to recirculated air mode. This is effective in
preventing outside air from entering the vehicle interior. During cooling oper-
ation, setting the recirculated air mode will also cool the vehicle interior
effectively.
l Outside/recirculated air mode may automatically switch depending on the
temperature setting or the inside temperature.
n When the outside temperature exceeds 75°F (24°C) and the air condition-
ing system is on
lIn order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically. This may also
reduce fuel consumption.
l Recirculated air mode is selected as a default mode when the power switch
is turned to ON mode.
l It is possible to switch to outside air mode at any time by pressing .

3396-1. Using the air conditioning system and defogger
6
Interior features
CAMRY_HV_U (OM33C35U)n
When the outside temperature is low
The dehumidification function may not operate even when is pressed.
n Ventilation and air conditioning odors
lTo let fresh air in, set the air conditioning system to the outside air mode.
l During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.
l To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air
mode prior to turning the vehicle off.
• The start timing of the blower may be delayed for a short period of time
immediately after the air conditioning system is started in automatic
mode.
n Air conditioning filter
P. 423
n Customization
The air conditioning control of Eco drive mode can be changed to the same
setting as that used in normal drive mode.
(Customizable features P. 536)
WARNING
nTo prevent the windshield from fogging up
lDo not use during cool air operation in extremely humid weather.
The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.
n To prevent burns
Do not touch the rear view mirror surfaces when the outside rear view mirror
defoggers are on.
lDo not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers
from defogging.

3406-1. Using the air conditioning system and defogger
CAMRY_HV_U (OM33C35U)
NOTICE
nHumidity sensor
n To prevent 12-volt battery discharge
Do not leave the air conditioning system on longer than necessary when the
hybrid system is off.
In order to detect fog on the windshield, a
sensor which monitors the temperature
of the windshield, the surround humidity,
etc. is installed. ( P. 338)
Follow these points to avoid damaging
the sensor:
l Do not disassemble the sensor
l Do not spray the glass cleaner on the
sensor or subject it to strong impacts
l Do not stick anything on the sensor

3416-1. Using the air conditioning system and defogger
6
Interior features
CAMRY_HV_U (OM33C35U)
Turns the seat heater on
The indicator light comes on.
Adjusts the seat temperature
The further you move the dial for-
ward, the warmer the seat
becomes.
lThe seat heaters can be used when the power switch is in ON mode.
l When not in use, move the dial fully backward. The indicator light will turn
off.
Seat heaters
: If equipped
WARNING
l Care should be taken to prevent injury if anyone in the following categories
comes in contact with the seats when the heater is on:
• Babies, small children, the elderly, the sick and the physically chal-
lenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping drugs, cold remedies, etc.)
l Observe the following precautions to prevent the minor burns or overheat-
ing
• Do not cover the seat with a blanket or cushion when using the seat
heater.
• Do not use seat heater more than necessary.
NOTICE
l Do not put heavy objects that have an uneven surface on the seat and do
not stick sharp objects (needles, nails, etc.) into the seat.
l To prevent 12-volt battery discharge, do not use the functions when the
power is off.
1
2

342
CAMRY_HV_U (OM33C35U)
6-2. Using the interior lights
Rear interior/personal lights (vehicles with moon roof) (P. 343)
Interior light (vehicles without moon roof) ( P. 343)
Front interior/personal lights (vehicles with moon roof) or personal
lights (vehicles without moon roof) ( P. 343)
Shift lever light (vehi cles with moon roof)
Power switch light
Door courtesy lights
Interior li ghts list
1
2
3
4
5
6

3436-2. Using the interior lights
6
Interior features
CAMRY_HV_U (OM33C35U)
Turns the lights on/off
Interior lights
Vehicles without moon roofVehicles with moon roof
Turns the lights on
Turns the lights on/off linked to
door positions.
Turns the lights off Turns the lights on/off linked to
door positions.
Turns the lights on/off
The rear interior lights will turn on/
off together with the front interior
lights.
1
2
3
1
2
Personal lights
FrontRear (vehicles with moon roof)

3446-2. Using the interior lights
CAMRY_HV_U (OM33C35U)
lIlluminated entry system:
The lights automatically turn on/off according to the power switch mode, the
presence of the electronic key, whet her the doors are locked/unlocked, and
whether the doors are open/closed.
l If the following lights are left on when the power switch is turned off, the
lights will go off automatically after 20 minutes:
• Interior lights
• Personal lights
• Door courtesy lights
l Setting (e.g. the time elapsed before lights turn off) can be changed.
(Customizable features: P. 536)
