2016 TOYOTA CAMRY HYBRID Owners Manual

105
3
Operation of
each component
CAMRY_HV_U (OM33C35U) 3-1. Key information
Keys .................................. 106
3-2. Opening, closing and locking the doors
Doors ................................ 110
Trunk ................................. 117
Smart key system ............. 121
3-3. Adjusting the seats Front seats ........................ 128
Rear seats......................... 130
Head restraints.................. 132
3-4. Adjusting the steering wheel and mirrors
Steering wheel .................. 134
Inside rear view mirror ...... 136
Outside rear view mirrors ............................. 138
3-5. Opening and closing the windows
Power windows ................. 140
Moon roof .......................... 143

106
CAMRY_HV_U (OM33C35U)
3-1. Key information
The following keys are provided with the vehicle.Electronic keys
• Operating the smart key system( P. 121)
• Operating the wireless remote control function
Mechanical keys
Key number plate
Locks all the doors ( P. 1 1 0 )
Unlocks all the doors ( P. 1 1 0 )
Pressing the button unlocks the
driver’s door. Pressing the button
again within 5 seconds unlocks the
other doors.
Opens the driver’s window and
moon roof (if equipped)
( P. 110)
*
Opens the trunk ( P. 1 1 7 )
Sounds the alarm ( P. 107)
*: This setting must be customized at your Toyota dealer.
Keys
The keys
1
2
3
Wireless remote control
1
2
3
4
5

1073-1. Key information
3
Operation of each component
CAMRY_HV_U (OM33C35U)
To take out the mechanical key,
push the release button and take
the key out.
The mechanical key can only be
inserted in one direction, as the
key only has grooves on one side.
If the key cannot be inserted in a
lock cylinder, turn it over and re-
attempt to insert it.
After using the mechanical key, store it in the electronic key. Carry the
mechanical key together with the electronic key. If the electronic key bat-
tery is depleted or the entry function does not operate properly, you will
need the mechanical key. (P. 487)
nPanic mode
n When required to leave the vehicle’s key with a parking attendant
Lock the glove box as circumstances demand. ( P. 346)
Remove the mechanical key for your own use and provide the attendant with
the electronic key only.
n If you lose your keys
New genuine keys can be made by your Toyota dealer using the other
mechanical key and the key number stamped on your key number plate.
Keep the plate in a safe place such as your wallet, not in the vehicle.
n When riding in an aircraft
When bringing an electronic key onto an aircraft, make sure you do not press
any button on the electronic key while inside the aircraft cabin. If you are car-
rying an electronic key in your bag etc., ensure that the buttons are not likely
to be pressed accidentally. Pressing a button may cause the electronic key to
emit radio waves that could interfere with the operation of the aircraft.
n Conditions affecting operation
P. 124
Using the mechanical key
When is pressed for longer than
about one second, an alarm will sound
intermittently and the vehicle lights will
flash to deter any person from trying to
break into or damage your vehicle.
To stop the alarm, press any button on the
electronic key.

1083-1. Key information
CAMRY_HV_U (OM33C35U)n
Electronic key battery depletion
lThe standard battery life is 1 to 2 years.
l If the battery becomes low, an alarm will sound in the cabin when the hybrid
system stops. ( P. 469)
l As the electronic key always receives radio waves, the battery will become
depleted even if the electronic key is not used. The following symptoms indi-
cate that the electronic key battery may be depleted. Replace the battery
when necessary. ( P. 425)
• The smart key system or the wireless remote control does not operate.
• The detection area becomes smaller.
• The LED indicator on the key surface does not turn on.
l To avoid serious deterioration, do not leave the electronic key within 3 ft. (1
m) of the following electrical appl iances that produce a magnetic field:
•TVs
• Personal computers
• Cellular phones, cordless phones and battery chargers
• Recharging cellular phones or cordless phones
• Table lamps
• Induction cookers
n Replacing the battery
P. 425
n Confirmation of the registered key number
The number of keys already registered to the vehicle can be confirmed. Ask
your Toyota dealer for details.
n If a wrong key is used
The key cylinder rotates freely to isolate inside mechanism.
n Customization
Settings (e.g. wireless remote control system) can be changed.
(Customizable features: P. 529)
n Certification for the wi reless remote control
P. 127

1093-1. Key information
3
Operation of each component
CAMRY_HV_U (OM33C35U)
NOTICE
nTo prevent key damage
lDo not drop the keys, subject them to strong shocks or bend them.
l Do not expose the keys to high temperatures for long periods of time.
l Do not get the keys wet or wash them in an ultrasonic washer etc.
l Do not attach metallic or magnetic materials to the keys or place the keys
close to such materials.
l Do not disassemble the keys.
l Do not attach a sticker or anything else to the surface of the electronic key.
l Do not place the keys near objects that produce magnetic fields, such as
TVs, audio systems and induction cooker s, or medical electrical equip-
ment, such as low-frequency therapy equipment.
n Carrying the electronic key on your person
Carry the electronic key 3.9 in. (10 cm) or more away from electric appli-
ances that are turned on. Radio waves emitted from electric appliances
within 3.9 in. (10 cm) of the electronic key may interfere with the key, caus-
ing the key to not function properly.
n In case of a smart key system malfunction or other key-related prob-
lems
Take your vehicle with all the electronic keys provided with your vehicle to
your Toyota dealer.
n When an electronic key is lost
If the electronic key remains lost, the risk of vehicle theft increases signifi-
cantly. Visit your Toyota dealer imm ediately with all remaining electronic
keys that were provided with your vehicle.

110
CAMRY_HV_U (OM33C35U)
3-2. Opening, closing and locking the doors
uSmart key system
Carry the electronic key to enable this function.Grip the driver’s door handle
to unlock the door. Grip the
front passenger’s door han-
dle to unlock all the doors.*
Make sure to touch the sensor
on the back of the handle.
The doors cannot be unlocked
for 3 seconds after the doors are
locked.
*: The door unlock settings can be changed. ( P. 115)
Touch the lock sensor (the indentation on the side of the door
handle) to lock the doors.
Check that the door is securely locked.
uWireless remote control
Locks all the doors
Check that the door is securely
locked.
Unlocks all the doors
Pressing the button unlocks the
driver’s door. Pressing the but-
ton again within 5 seconds
unlocks the other doors.
Press and hold to open the
driver’s window and moon roof
(if equipped).
* (P. 140, 144)
*: This setting must be customized at your Toyota dealer.
Doors
Unlocking and locking the doors from the outside
1
2
1
2

1113-2. Opening, closing and locking the doors
3
Operation of each component
CAMRY_HV_U (OM33C35U)
nOperation signals
Doors:
A buzzer sounds and the emergency flashers flash to indicate that the doors
have been locked/unlocked. (Locked: Once; Unlocked: Twice)
Driver’s window and moon roof:
A buzzer sounds to indicate that the driver’s window and moon roof are open-
ing.
n Security feature
If a door is not opened within approximately 60 seconds after the vehicle is
unlocked, the security feature automatically locks the vehicle again.
n When the door cannot be locked by the lock sensor on the side of the
door handle
n Door lock buzzer
If an attempt to lock the doors is made when a door is not fully closed, a
buzzer sounds for 5 seconds. Fully close the door to stop the buzzer, and
lock the doors again.
n Alarm (if equipped)
Locking the doors will set the alarm system. ( P. 80)
n If the smart key system or the wireless remote control does not operate
properly
Use the mechanical key to lock and unlock the doors. ( P. 487)
Replace the battery with a new one if it is depleted. ( P. 425)
If the door will not lock even when the
side sensor area is touched, try using
your palm to touch the lock sensor.

1123-2. Opening, closing and locking the doors
CAMRY_HV_U (OM33C35U)
uDoor lock switchesLocks all the doors
Unlocks all the doors
uInside lock buttonsLocks the door
Unlocks the door
The front doors can be opened
by pulling the inside handle
even if the lock buttons are in
the lock position.
Move the inside lock button to the lock position.
Close the door.
The door cannot be locked if the pow er switch is in ACCESSORY or
ON mode, or the electronic key is left inside the vehicle.
The key may not be detected correctly and the door may be locked.
Unlocking and locking the doors from the inside
1
2
1
2
Locking the front doors from the outside without a key
1
2
