2016 NISSAN QUEST Owners Manual


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
SSS1149
3RD ROW SEATSGUID-8B174BCB-55A9-4070-AE4A-06F3342E7335
RecliningGUID-6FD9F8E0-B172-4C02-918D-29C8C54903D6Pull the strap on the seatback*Aand lean
back. Release the strap at the desired angle.
The reclining feature allows adjustment of the
seatback for occupants of different sizes to help
obtain proper seat belt fit. (See ªPrecautions on
seat belt usageº (P.1-15) .) The seatback may
also be reclined to allow occupants to rest when
the vehicle is parked.
WARNING
. After adjustment, check to be sure
the seat is securely locked.
. Do not ride in a moving vehicle
when the seatback is reclined. This
can be dangerous. The shoulder belt
will not be against your body. In an
accident, you could be thrown into it
and receive neck or other serious
injuries. You could also slide under
the lap belt and receive serious
internal injuries.
. For the most effective protection
when the vehicle is in motion, the
seat should be upright. Always sit
well back and upright in the seat
with both feet on the floor and
adjust the seat belt properly. See
ªPrecautions on seat belt usageº
(P.1-15) .
SPA1456
Front and 2nd row seats
ARMRESTSGUID-16EF2763-6783-4401-9358-77E5AC3DEC94
Front and 2nd row seatsGUID-3495E38D-4395-4737-9E1B-ABC7A43B6E87To use the armrests on any seat, pull them down
to the resting position.
Safety Ð Seats, seat belts and supplemental restraint system1-7
&RQGLWLRQ


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
1-8Safety Ð Seats, seat belts and supplemental restraint system
SSS1162
The armrest angle can be adjusted freely.
*1Pull the armrest between*Aand*B.
*2Pull it down to*C.
*3Pull up the armrest slowly, it can be secured
between
*Band*C.
FLEXIBLE SEATINGGUID-66453B23-9B97-441E-8F66-55F330B008AD
WARNING
. Never allow anyone to ride in the
cargo area or on the rear seats
when they are in the fold-down
position. In a collision, people riding
in these areas without proper re-
straints are more likely to be ser-
iously injured or killed.
. Do not allow people to ride in any
area of your vehicle that is not
equipped with seats and seat belts.
Be sure everyone in your vehicle is
in a seat and using a seat belt
properly.
. Do not fold down the rear seats
when occupants are in the rear seat
area or any cargo is on the rear
seats.
. Head restraints and headrests
should be adjusted properly as they
may provide significant protection
against injury in an accident. Always
replace and adjust them properly if
they have been removed for any
reason. .
If the head restraints/headrests are
removed for any reason, they should
be securely stored to prevent them
from causing injury to passengers
or damage to the vehicle in case of
sudden braking or an accident.
. When returning the seatbacks to the
upright position, be certain they are
completely secured in the latched
position. If they are not completely
secured, passengers may be injured
in an accident or sudden stop.
. Properly secure all cargo to help
prevent it from sliding or shifting.
Do not place cargo higher than the
seatbacks. In a sudden stop or
collision, unsecured cargo could
cause personal injury.
&RQGLWLRQ


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
SSS1163
Folding the 2nd row seatsGUID-3B7D99A2-3421-40DA-8D4B-AC4F06EF9D93
Before folding the rear seats:GUID-D73A39BF-43C8-459F-9C24-47B7F579C407Secure the seat belts on the seat belt hooks on
the side wall. (See ªSeat belt hooksº (P.1-23) .)
To fold down the seatbacks:
GUID-D73A39BF-43C8-459F-9C24-47B7F579C407Pull the lever on the 2nd row seat.
To return the seatbacks:
GUID-D73A39BF-43C8-459F-9C24-47B7F579C407Lift up each seatback and push it to the upright
position until it is latched.
CAUTION
When folding the 2nd row seat for
maximum cargo hauling, be sure that
cargo does not contact the center
console of the 2nd row seat to avoid
possible damage to the console.
Folding the 3rd row seatsGUID-B00DC0B2-8166-4AA2-B328-836A43E43FB6
Before folding the 3rd row seats:GUID-D73A39BF-43C8-459F-9C24-47B7F579C407.Secure the seat belts on the seat belt hooks
on the side wall. (See ªSeat belt hooksº
(P.1-23) .)
. Disconnect and stow the center seat belt
and tongue into the retractor base. (See
ª3rd row center seat beltº (P.1-20) .)
. Always reconnect the center seat belt when
the seat is returned to the upright position.
. Remove drink containers from the rear cup
holder.SSS1149
Third row seatback
SSS1150
Back side of the third row seatback
Safety Ð Seats, seat belts and supplemental restraint system1-9
&RQGLWLRQ


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
1-10Safety Ð Seats, seat belts and supplemental restraint system
Manual folding:GUID-D73A39BF-43C8-459F-9C24-47B7F579C407Pull the strap on the seatback*Aor on the
back side of the seatback
*Band fold the
seatback.
SSS1151
Power folding (if so equipped):GUID-D73A39BF-43C8-459F-9C24-47B7F579C407Push the front side of the switch*Alocated on
the right side or left side of the cargo area. The
corresponding 3rd row seatback will be folded
down automatically.
Push and hold the rear side of the switch
*B.
The 3rd row seatback will be returned auto-
matically. A beep sounds and the rear seatback
will rise up while holding the switch. A beep
sounds when the seatback is fully returned in
position.
GUID-D3AB025F-F8D3-4E68-B9EC-18DE1462D6A0
WARNING
Head restraints/headrests supplement
the other vehicle safety systems. They
may provide additional protection
against injury in certain rear end colli-
sions. Adjustable head restraints/head-
rests must be adjusted properly, as
specified in this section. Check the
adjustment after someone else uses
the seat. Do not attach anything to the
head restraint/headrest stalks or re-
move the head restraint/headrest. Do
not use the seat if the head restraint/
headrest has been removed. If the head
restraint/headrest was removed, rein-
stall and properly adjust the head
restraint/headrest before an occupant
uses the seating position. Failure to
follow these instructions can reduce the
effectiveness of the head restraint/
headrest. This may increase the risk of
serious injury or death in a collision.
HEAD RESTRAINTS/HEADRESTS
&RQGLWLRQ


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
JVR0269X
The illustration shows the seating positions
equipped with head restraint/headrest.
Indicates the seating position is equipped
with a head restraint.
Indicates the seating position is equipped
with a headrest.
+ Indicates the seating position is not equipped
with a head restraint or headrest. (if applicable)
. Your vehicle is equipped with a head
restraint/headrest that may be integrated,
adjustable or non-adjustable.
. Adjustable head restraints/headrests have
multiple notches along the stalk to lock them
in a desired adjustment position. .
The non-adjustable head restraints/head-
rests have a single locking notch to secure
them to the seat frame.
. Proper Adjustment:
Ð For the adjustable type, align the head
restraint/headrest so the center of your
ear is approximately level with the center
of the head restraint/headrest.
Ð If your ear position is still higher than the recommended alignment, place the head
restraint/headrest at the highest position.
. If the head restraint/headrest has been
removed, ensure that it is reinstalled and
locked in place before riding in that desig-
nated seating position.
SSS0992
ADJUSTABLE HEAD RESTRAINT/
HEADREST COMPONENTS
GUID-5C119838-4038-49C0-9346-9010437E97BF1. Removable head restraint/headrest
2. Multiple notches
3. Lock knob
4. Stalks
Safety Ð Seats, seat belts and supplemental restraint system1-11
&RQGLWLRQ


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
1-12Safety Ð Seats, seat belts and supplemental restraint system
JVR0203X
NON-ADJUSTABLE HEAD RE-
STRAINT/HEADREST COMPONENTS
GUID-27CA7AD9-B2AB-43C3-B7A0-D0C6FC3C25BC1. Removable head restraint/headrest
2. Single notch
3. Lock knob
4. Stalks
SSS1037
REMOVEGUID-CEE94709-EBFB-4E0C-9DBE-D1237155CA80Use the following procedure to remove the head
restraint/headrest.
1. Pull the head restraint/headrest up to thehighest position.
2. Push and hold the lock knob.
3. Remove the head restraint/headrest from the seat.
4. Store the head restraint/headrest properly in a secure place so it is not loose in the
vehicle.
5. Reinstall and properly adjust the head
restraint/headrest before an occupant uses
the seating position.
SSS1038
INSTALLGUID-5EFE2FCB-BFE5-4BAD-B0D6-E956D9CA4E9C1. Align the head restraint/headrest stalks with
the holes in the seat. Make sure that the
head restraint/headrest is facing the correct
direction. The stalk with the adjustment
notch
*1must be installed in the hole with
the lock knob
*2.
2. Push and hold the lock knob and push the head restraint/headrest down.
3. Properly adjust the head restraint/headrest before an occupant uses the seating posi-
tion.
&RQGLWLRQ


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
SSS0997
ADJUSTGUID-190BD67C-B579-4C85-ADDB-04626518D897For adjustable head restraint/headrest
Adjust the head restraint/headrest so the center
is level with the center of your ears. If your ear
position is still higher than the recommended
alignment, place the head restraint/headrest at
the highest position.
JVR0259X
For non-adjustable head restraint/head-
rest
Make sure the head restraint/headrest is posi-
tioned so the lock knob is engaged in the notch
before riding in that designated seating position.
SSS1035
RaiseGUID-74830AF6-A511-4C15-A2B7-D47C98FFFDEDTo raise the head restraint/headrest, pull it up.
Make sure the head restraint/headrest is posi-
tioned so the lock knob is engaged in the notch
before riding in that designated seating position.
Safety Ð Seats, seat belts and supplemental restraint system1-13
&RQGLWLRQ


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
1-14Safety Ð Seats, seat belts and supplemental restraint system
SSS1036
LowerGUID-D3639830-36D2-4C81-AAE6-B3DF4B846E5CTo lower, push and hold the lock knob and push
the head restraint/headrest down.
Make sure the head restraint/headrest is posi-
tioned so the lock knob is engaged in the notch
before riding in that designated seating position.
SSS0508
FRONT-SEAT ACTIVE HEAD RE-
STRAINT
GUID-AEB6FB97-A306-48D9-B169-12C2DFABF9A6The Active Head Restraint moves forward
utilizing the force that the seatback receives
from the occupant in a rear-end collision. The
movement of the head restraint helps support
the occupant's head by reducing its backward
movement and helping absorb some of the
forces that may lead to whiplash-type injuries.
Active Head Restraints are effective for colli-
sions at low to medium speeds in which it is said
that whiplash injury occurs most.
Active Head Restraints operate only in certain
rear-end collisions. After the collision, the head
restraints return to their original position.Adjust the Active Head Restraints properly as
described earlier in this section.
