BRAKE WARNING LAMP
Component Function CheckINFOID:0000000012430911
1.CHECK BRAKE WARNING LAMP FUNCTION (1)
Check that brake warning lamp in combination mete r turns ON for approximately 2 seconds after ignition
switch is turned ON.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Proceed to diagnosis procedure. Refer to BRC-129, "
Diagnosis Procedure".
2.CHECK BRAKE WARNING LAMP FUNCTION (2)
Check that brake warning lamp in combination meter turns ON/OFF when parking brake is operated.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check parking brake switch system. Refer to BRC-124, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430912
1.PERFORM THE SELF DIAGNOSTIC
With CONSULT.
Perform “Self Diagnostic Result”.
Are any DTCs detected?
YES >> Refer to BRC-43, "DTC Index".
NO >> GO TO 2.
2.CHECK COMBINATION METER
Check if indication and operation of combination meter are normal. Refer to MWI-10, "
METER SYSTEM : Sys-
tem Description" (TYPE A) or MWI-61, "METER SYSTEM : System Description" (TYPE B).
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-144, "Removal and Installa-
tion".
NO >> Replace combination meter. Refer to MWI-54, "
Removal and Installation" (TYPE A) or MWI-115,
"Removal and Installation" (TYPE B).
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-132
< SYMPTOM DIAGNOSIS >[VDC/TCS/ABS]
VDC/TCS/ABS
SYMPTOM DIAGNOSIS
VDC/TCS/ABS
Symptom TableINFOID:0000000012430917
If ABS warning lamp and SLIP indicator
lamp turn ON, perform self diagnostic.
NOTE:
• 1: The ABS does not operate when the speed is 10 km/h (6 MPH) or less.
• 2: Under the following conditions, ABS is activated and vibration is felt when brake pedal is lightly depressed (just place a foot on it).
However, this is normal:
- When shifting gears
- When driving on slippery road
- During cornering at high speed
- When passing over bumps or grooves [approximately 50 mm (1.97 in) or more]
- When pulling away just after starting engine [at approximately 10 km/h (6 MPH) or higher] Symptom
Check itemReference
Excessive ABS function operation fre-
quency Brake force distribution
BRC-133, "
Diag-
nosis Procedure"Looseness of front and rear axle
Wheel sensor and rotor system
Unexpected pedal reaction Brake pedal stroke
BRC-134, "
Diag-
nosis Procedure"Make sure the braking force is sufficient when the ABS is not operating.
The braking distance is long Check stopping distance when the ABS is not operating. BRC-135, "
Diag-
nosis Procedure"
ABS function does not operate (Note 1) ABS actuator and electric
unit (control unit)BRC-136, "Diag-
nosis Procedure"
Pedal vibration or ABS operation sound
occurs (Note 2)Brake pedal
BRC-137, "Diag-
nosis Procedure"ABS actuator and electric unit (control unit)
Vehicle jerks during VDC/TCS/ABS con-
trol ABS actuator and electric unit (control unit)
BRC-138, "
Diag-
nosis Procedure"TCM
ECM
Revision: August 2015 2016 Versa Note

cardiagn.com

EXCESSIVE ABS FUNCTION OPERATION FREQUENCYBRC-133
< SYMPTOM DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
EXCESSIVE ABS FUNCTION OPERATION FREQUENCY
Diagnosis ProcedureINFOID:0000000012430918
1.CHECK START
Check front and rear brake force di stribution using a brake tester.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check brake system.
2.CHECK FRONT AND REAR AXLE
Make sure that there is no excessive play in the front and rear axles. Refer to front: FA X - 7 , "
Inspection", rear:
RAX-5, "
Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning components.
3.CHECK WHEEL SENSOR AND SENSOR ROTOR
Check the following:
• Wheel sensor installation for damage
• Sensor rotor installation for damage
• Wheel sensor connector
• Wheel sensor harness
Is the inspection result normal?
YES >> GO TO 4.
NO >> • Replace wheel sensor BRC-140, "
FRONT WHEEL SENSOR : Removal and Installation" (front)
or BRC-141, "
REAR WHEEL SENSOR : Removal and Installation" (rear).
• Replace sensor rotor BRC-143, "
FRONT SENSOR ROTOR : Removal and Installation" (front)
or BRC-143, "
REAR SENSOR ROTOR : Removal and Installation" (rear).
• Repair harness.
4.CHECK ABS WARNING LAMP DISPLAY
Make sure that the ABS warning lamp is turned off af ter the ignition switch is turned ON or when driving.
Is the inspection result normal?
YES >> Inspection End.
NO >> Perform “Self Diagnostic Result”. Refer to BRC-31, "
CONSULT Function (ABS)".
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-136
< SYMPTOM DIAGNOSIS >[VDC/TCS/ABS]
ABS FUNCTION DOES NOT OPERATE
ABS FUNCTION DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012430921
CAUTION:
ABS does not operate when speed
is 10 km/h (6 MPH) or lower.
1.CHECK ABS WARNING LAMP DISPLAY
Make sure that the ABS warning lamp turns OFF af ter ignition switch is turned ON or when driving.
Is the inspection result normal?
YES >> Inspection End.
NO >> Perform “Self Diagnostic Result”. Refer to BRC-31, "
CONSULT Function (ABS)".
Revision: August 2015 2016 Versa Note

cardiagn.com

NORMAL OPERATING CONDITIONBRC-139
< SYMPTOM DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000012430924
Symptom Result
Slight vibrations are felt on the brake pedal and operation noises occur when VDC, TCS or ABS is activated. This is a normal condi-
tion due to the VDC,
TCS or ABS activation.
Stopping distance is longer than that of vehicles without ABS when the vehicle drives on rough, gravel, or
snow-covered (fresh, deep snow) roads.
The brake pedal moves and generates noises when TCS or VDC is activated due to rapid acceleration or
sharp turn.
The brake pedal vibrates and motor operation noises occur from the engine room after the engine starts and
just after the vehicle starts.
This is normal, and it is
caused by the ABS op-
eration check.
Depending on the road conditions, the driver may experience a sluggish feel in the brake pedal. This is normal, because
TCS places the highest
priority on the optimum
traction (stability).
TCS may activate momentarily if wheel speed changes when driving where road friction coefficient varies,
when downshifting, or when fully depressing accelerator pedal.
The ABS warning lamp and SLIP
indicator lamp may turn ON when the vehicle is subject to strong shaking
or large vibration, such as when the vehicle is rotating on a turntable or located on a ship while the engine
is running. In this case, restart the
engine on a normal
road. If the normal con-
dition is restored, there
is no malfunction. At
that time, erase the self-
diagnostic result memo-
ry.
VDC may not operate normally or th
e ABS warning lamp, and SLIP indicato r lamp may illuminate when driv-
ing on a road that is extremely slanted (e.g., bank in a circuit course).
A malfunction may occur in the yaw rate/side/decel G sensor system when the vehicle turns sharply, such
as during a spin turn, axle turn, or drift driving, while the VDC function is OFF (VDC OFF indicator lamp illu-
minated).
The vehicle speed will not increase even though the accelerator pedal is depressed, when inspecting the
speedometer on a 2-wheel chassis dynamometer. Normal (Deactivate the
VDC/TCS function be-
fore performing an in-
spection on a chassis
dynamometer.)
SLIP indicator lamp may simultaneously turn ON when low tire pressure warning lamp turns ON. This is not a VDC sys-
tem error but results
from characteristic
change of tire.
Revision: August 2015
2016 Versa Note

cardiagn.com

CHG
PRECAUTIONSCHG-3
< PRECAUTION >
C
DE
F
G H
I
J
K L
B A
O P
N
PRECAUTION
PRECAUTIONS
Precaution for Supplemental
Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012431235
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Un it or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or el ectric power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the
battery and wait at least three mi nutes before performing any service.
Precaution for Power Generation Voltage Variable Control SystemINFOID:0000000012431236
CAUTION:
For model with power generation voltage variable control system, the battery current sensor that is
installed to the battery cable at the negative te rminal measures the charging/discharging current of
the battery, and performs various controls. If the electrical component or the ground wire is connected
directly to the battery terminal, the current othe r than that being measured with the battery current
sensor is charging to or discharging from the battery. This cond ition causes the malfunction of the
control, and then the battery discharge may occur. Do not connect the electrical component or the
ground wire directly to the battery terminal.
Revision: August 2015 2016 Versa Note

cardiagn.com

CHG-6
< SYSTEM DESCRIPTION >
COMPONENT PARTS
Component Description
INFOID:0000000012431240
No. Component part Description
1 IPDM E/R The IPDM E/R converts the received power generation com-
mand value into a pulse width modulated (PWM) command sig-
nal and sends it to the IC regulator.
2ECM The battery current sensor detects the charging/discharging
current of the battery. The ECM judges the battery condition
based on this signal.
The ECM judges whether to request more output via the power
generation voltage variable control according to the battery
condition.
When performing the power generation voltage variable con-
trol, the ECM calculates the target power generation voltage
according to the battery condition and sends the calculated val-
ue as the power generation command value to the IPDM E/R.
3 Battery current sensor The battery current sensor is located on the negative battery
cable terminal. The battery current sensor detects the charg-
ing/discharging current of the battery and sends a voltage sig-
nal to the ECM according to the current value detected.
4 Generator (IC regulator) The IC regulator controls the power generation voltage by the
target power generation voltage based on the received PWM
command signal.
When there is no PWM command signal, the generator per-
forms the normal power generation according to the character-
istic of the IC regulator.
5 Combination meter (charge warning lamp) The IC regulator warning function activates to illuminate the
charge warning lamp if any of the following symptoms occur
while generator is operating:
• Excessive voltage is produced.
• No voltage is produced.
Revision: August 2015
2016 Versa Note

cardiagn.com

CHG
SYSTEMCHG-7
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
J
K L
B A
O P
N
SYSTEM
CHARGING SYSTEM
CHARGING SYSTEM : System DiagramINFOID:0000000012431241
CHARGING SYSTEM : System DescriptionINFOID:0000000012431242
The generator provides DC voltage to operate the vehicl
e's electrical system and to keep the battery charged.
The voltage output is controlled by the IC regulator.
CHARGING SYSTEM : Component DescriptionINFOID:0000000012431243
AWMIA1334GB
Component part Description
Generator Terminal “1”
Refer to CHG-23, "
Description".
Terminal “2” Refer to CHG-24, "
Description".
Terminal “3” Refer to CHG-27, "
Description".
Terminal “4” Used for the power generation voltage variable control system.
Refer to CHG-8, "
System Description".
Combination meter (C harge warning lamp) The IC regulator warning function activates to illuminate the
charge warning lamp if any of the following symptoms occur while
generator is operating:
• Excessive voltage is produced.
• No voltage is produced.
IPDM E/R Used for the power generation voltage variable control system.
Refer to CHG-8, "
System Description".
Revision: August 2015
2016 Versa Note

cardiagn.com
