2016 NISSAN NOTE warning

DLK-26
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
SYSTEM (INTELLIGENT KEY SYSTEM)
HAZARD AND BUZZER REMINDER FUNCTION
For the operation check, BCM blinks hazard warning lamps (lock: 2 times, unlock: 1 time) and sounds Intelli-
gent Key warning buzzer (lock: 1 time) when door lock or unlock operates by each remote controller button
operation of Intelligent Key.
How to Change Hazard and Buzzer Reminder Mode
Refer to
BCS-22, "INTELLIGENT KEY : CONSULT Func tion (BCM - INTELLIGENT KEY)".
AUTO DOOR LOCK FUNCTION
After door is unlocked by Intelligent Key button operati on and if 30 seconds or more passes without performing
the following operation, all doors are automatically locked. However, operation check function does not acti-
vate.
Auto door lock mode can be changed by the “AUTO LOCK SET” in “Work support”. Refer to BCS-22, "
INTEL-
LIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)".
LIST OF OPERATION RELATED PARTS
Parts marked with × are the parts related to operation.
KEY REMINDER FUNCTION
Remote controller operation Operation condition
Lock • All door are closed.
• Ignition switch is in the LOCK or OFF position.
• P position warning is not activated.
Unlock • Ignition switch is in the LOCK or OFF position.
• Intelligent Key is outside the vehicle.
• P position warning is not activated.
Operating condition
• Door switch is ON. (door is open)
• BCM receives lock signal.
• Push switch is pressed.
Remote keyless entry functions
Intelligent Key
Remote keyless entry receiver
Door switch
Door lock actuator
Push-button ignition switch
Intelligent Key warning buzzer
CAN communication system
BCM
Combination meter
Hazard warning lamp
IPDM E/R
Horn
Door lock/unlock function by remote control button
××××××
Hazard and buzzer reminder function ×××××××
Auto door lock function ××××××
Revision: August 2015 2016 Versa Note

cardiagn.com

SYSTEM (INTELLIGENT KEY SYSTEM)DLK-27
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
KEY REMINDER FUNCTION : System DescriptionINFOID:0000000012429986
System Diagram
BASIC OPERATION
Key reminder is the function that prevents the key from being left in the vehicle.
Key reminder has the following 3 functions:
*:When closing the door if something comes into contact with the door lock switch it might activate the door locks accidentally , but the
unlock operation will override this.
NOTE:
The above function operates when the Intelligent Key is in side the vehicle. However, there may be times when
the Intelligent Key cannot be detected, and this func tion does not operate when the Intelligent Key is on the
instrument panel, rear parcel shelf, or in the glove box. Also, this system sometimes does not operate if the
Intelligent Key is in the door pocket for the open door.
WARNING FUNCTION
WARNING FUNCTION : System DescriptionINFOID:0000000012429987
OPERATION DESCRIPTION
The warning function are as per the following items and are given to the user as warning information and
warnings using combinations of Intelligent Key warni ng buzzer, combination meter buzzer, KEY warning lamp,
shift P warning lamp and engine start operation indicator lamp:
• Intelligent Key system malfunction
• OFF position warning
• P position warning
• ACC warning
• Take away warning
• Door lock operation warning
• Engine start information
ALKIA3196GB
Key reminder function Operation condition Operation
Driver side door closed* Right after driver side door is closed under the following conditions:
• Intelligent Key is inside the vehicle.
• Driver side door is opened.
• Driver side door is in unlock state. All doors unlock
Door is open or closed Right after all doors are closed under the following conditions:
• Door lock/unlock switch or driver side door lock knob are operated.
• Intelligent Key is inside the vehicle.
• Any door is opened.
• All doors are locked. • All doors unlock
• Honk Intelligent Key warn-
ing buzzer
Back door is closed Right after Back door is closed under the following conditions:
• Intelligent Key is inside trunk room.
• All doors are closed.
• All doors are locked. • Back door open
• Honk Intelligent Key warn-
ing buzzer
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-28
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
SYSTEM (INTELLIGENT KEY SYSTEM)
• Intelligent Key low battery warning
• Key ID warning
OPERATION CONDITION
Operation condition of warning and information is as per the following table:
WARNING METHOD
The following table shows the alarm or warning methods with chime:
Warning/Information functions
Operation procedure
Intelligent Key system malfunction A malfunction is detected on BCM and key warning lamp turns ON
OFF position warning When condition A, B or condition C is satisfied:
• Condition A
- Ignition switch: ACC position
- Door switch (driver side
): ON (Door is open)
• Condition B
- Turn ignition switch from ON to OFF while door is open.
• Condition C
- Intelligent Key backside is contacted to push-button ignition switch while brake pedal is depressed and ignition switch is LOCK or OFF. (When the
Intelligent Key battery is discharged.)
- Door switch (driver side ): ON (Door is open)
P position warning For internal
• Shift position: Other than P
• Engine is stopped. (Ignition switch is turned from ON to OFF.)
For external • P position warning (For internal) operates.
• Door switch: ON to OFF (Door is open to close.)
• Intelligent Key cannot be detected inside the vehicle.
ACC warning • After P position warning operates, or when ignition switch is turned ON
immediately after P position warning operates.
• Ignition switch: ACC
Ta k e a w a y w a r n i n g Door status changes
from open to close
• Ignition switch: Other than LOCK and OFF.
• Door switch: ON to OFF (Door status changes from open to close.)
• Registered Intelligent Key is not detected inside the vehicle.
Door status is open • Ignition switch: Other than LOCK and OFF.
• Door switch: ON (Door is open.)
• Registered Intelligent Key is not detected inside the vehicle during Key
ID verification for 5 seconds.
Push-button ignition
switch operation • Ignition switch: Other than LOCK position.
• Push-button ignition switch is pressed.
• Registered Intelligent Key is not detected inside the vehicle.
Door lock operation warning Door lock operation is requested while door lock operation condition of
door request switch is not satisfied.
Engine start information Ignition switch is ON po-
sition
• Ignition switch: ON position
• Shift position: P
• Engine is stopped.
Ignition switch is other
than ON position • Ignition switch: Other than ON.
• Shift position: P
• Intelligent Key is in the passenger room after driver door is opened and
closed.
Ignition switch is ON po-
sition to OFF position • Ignition switch: ON position to OFF position.
• Shift position: P position
NOTE:
Engine start information turns ON for several seconds and then turns OFF,
when ignition switch is turned to the ON position from the OFF position. En-
gine start information does not turn ON until opening and closing of driver
door is detected again.
Intelligent Key low battery warning BCM detects that Intelligent Key is low battery, after ignition switch is turned
ON.
Key ID warning • Push-button ignition switch is pressed.
• Registered Intelligent Key is not detected inside the vehicle.
Revision: August 2015
2016 Versa Note

cardiagn.com

SYSTEM (INTELLIGENT KEY SYSTEM)DLK-29
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
LIST OF OPERATION RELATED PARTS
Parts marked with × are the parts related to operation.
Warning/Information functions “KEY” warning
lamp Shift P
warning lamp Warning chime
Engine start
operation in- dicator lamp
Combination
meter buzzer Intelligent
Key warn-
ing buzzer
Intelligent Key system malfunction Indicate ————
OFF position warning For internal
—— Activate — —
For external ——— Activate —
P position warning For internal
Blink (yellow)Indicate Activate —
—
For external ——Active —
ACC warning —— Activate — —
Ta k e a w a y w a r n i n g Door is open to close
Blink (yellow)—ActivateActivate—
Door is open —— ——
Push-ignition switch oper-
ation —Activate — —
Door lock operation warning ——— Activate —
Engine start information ——— — Indicate
Intelligent Key low battery warning Blink (green) ————
Key ID warning Blink (yellow) ————
Function
Intelligent Key
Push-button ignition switch
Door switch
Door request switch
Inside key antenna
Outside key antenna
Intelligent Key warning buzzer
Combination meter buzzer
CAN communication system
BCM
Shift P warning lamp
Engine start operation indicator lamp
“KEY” warning lamp
Intelligent Key system malfunction ×× ×
OFF position warning For internal
××××
For external ×××
P position warning ××××× ×
ACC warning ××××
Ta k e a w a y w a r n i n g Door is open or close
××××××× ×
Door is open ××× ×× ×
Push-button ignition
switch operation ×× × ××× ×
Door lock operation warning × ××××× ×
Key ID warning ×× ×××
Engine start information ×× ××× ×
Intelligent Key low battery warning ×××××
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-30
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT Fu
nction (BCM - COMMON ITEM)INFOID:0000000012542542
APPLICATION ITEM
CONSULT performs the following functions via CAN communication with BCM.
SYSTEM APPLICATION
BCM can perform the following functions.
Direct Diagnostic Mode Description
ECU Identification The BCM part number is displayed.
Self Diagnostic Result The BCM self diagnostic results are displayed.
Data Monitor The BCM input/output data is displayed in real time.
Active Test The BCM activates outputs to test components.
Work support The settings for BCM functions can be changed.
Configuration • The vehicle specification can be read and saved.
• The vehicle specification can be written when replacing BCM.
CAN DIAG SUPPORT MNTR The result of transmit/receive diagnosis of CAN communication is displayed.
System Sub System Direct Diagnostic Mode
ECU Identification
Self Diagnostic Result
Data Monitor
Active Test
Work support
Configuration
CAN DIAG SUPPORT MNTR
Door lock
DOOR LOCK ×××
Rear window defogger REAR DEFOGGER ××
Warning chime BUZZER ××
Interior room lamp timer INT LAMP ×××
Exterior lamp HEAD LAMP ×××
Wiper and washer WIPER ×××
Turn signal and hazard warning lamps FLASHER ×××
Air conditioner AIR CONDITIONER ×
Intelligent Key system INTELLIGENT KEY ××××
Combination switch COMB SW ×
BCM BCM× × ×××
Immobilizer IMMU ××××
Interior room lamp battery saver BATTERY SAVER ×××
Vehicle security system THEFT ALM ××
RAP system RETAINED PWR ×
Signal buffer system SIGNAL BUFFER ×
TPMS AIR PRESSURE MONITOR ××××
Panic alarm system PANIC ALARM ×
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-32
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
DATA MONITOR
ACTIVE TEST
Monitor Item [Unit]
Main Description
REQ SW -DR [On/Off] ×Indicates condition of door request switch LH.
REQ SW -AS [On/Off] ×Indicates condition of door request switch RH.
REQ SW -BD/TR [On/Off] ×Indicates condition of back door request switch.
PUSH SW [On/Off] Indicates condition of push-button ignition switch.
CLUCH SW [On/Off] ×Indicates condition of clutch interlock switch.
BRAKE SW 1 [On/Off] ×Indicates condition of brake switch.
BRAKE SW 2 [On/Off] Indicates condition of brake switch.
DETE/CANCL SW [On/Off] ×Indicates condition of P (park) position.
SFT PN/N SW [On/Off] ×Indicates condition of P (park) or N (neutral) position.
UNLK SEN -DR [On/Off] ×Indicates condition of door unlock sensor.
PUSH SW -IPDM [On/Off] Indicates condition of push-button ignition switch received from IPDM E/R on
CAN communication line.
IGN RLY1 -F/B [On/Off] Indicates condition of ignition relay 1 received from IPDM E/R on CAN commu-
nication line.
DETE SW -IPDM [On/Off] Indicates condition of detent switch received from TCM on CAN communication
line.
SFT PN -IPDM [On/Off] Indicates condition of P (park) or N (neutral) position from TCM on CAN com-
munication line.
SFT P -MET [On/Off] Indicates condition of P (park) position from TCM on CAN communication line.
SFT N -MET [On/Off] Indicates condition of N (neutral) position from IPDM E/R on CAN communica-
tion line.
ENGINE STATE [Stop/Start/Crank/Run] ×Indicates condition of engine state from ECM on CAN communication line.
VEH SPEED 1 [mph/km/h] ×Indicates condition of ve
hicle speed signal receiv ed from ABS on CAN commu-
nication line.
VEH SPEED 2 [mph/km/h] ×Indicates condition of vehicle speed signal received from combination meter on
CAN communication line.
DOOR STAT -DR [LOCK/READY/UNLK] ×Indicates condition of driver side door status.
DOOR STAT -AS [LOCK/READY/UNLK] ×Indicates condition of passenger side door status.
ID OK FLAG [Set/Reset] Indicates condition of Intelligent Key ID.
PRMT ENG STRT [Set/Reset] Indicates condition of engine start possibility.
RKE OPE COUN1 [0-19] ×When remote keyless entry receiver receives the signal transmitted while oper-
ating on Intelligent Key, the numerical value start changing.
RKE OPE COUN2 [0-19] ×When remote keyless entry receiver receives the signal transmitted while oper-
ating on Intelligent Key, the numerical value start changing.
RKE-LOCK [On/Off] Indicates condition of lock signal from Intelligent Key.
RKE-UNLOCK [On/Off] Indicates condition of unlock signal from Intelligent Key.
RKE-PANIC [On/Off] Indicates condition of panic signal from Intelligent Key.
RKE-MODE CHG [On/Off] Indicates condition of mode change signal from Intelligent Key.
Test Item Description
INSIDE BUZZER This test is able to check combination meter warning chime operation [Take Out/Knob/Key/
Off].
LCD This test is able to check combination meter display in
formation [Off/LK WN/OUTKEY/NO
KY/BATT/INSRT/SFT P/ROTAT/ID NG/B&P I/B&P N].
BATTERY SAVER This test is able to check battery saver operation [On/Off].
Revision: August 2015 2016 Versa Note

cardiagn.com

DIAGNOSIS SYSTEM (BCM)DLK-33
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
WORK SUPPORT
ENGINE SW ILLUMI This test is able to check push-button ignition switch START indicator operation [On/Off].
PUSH SWITCH INDICATOR This test is able to check push-button ignition switch indicator operation [On/Off].
INT LAMP This test is able to check interior room lamp operation [On/Off].
INDICATOR This test is able to check combination mete r warning lamp operation [KEY ON/KEY IND/Off].
FLASHER This test is able to check hazard lamp operation [LH/RH/Off].
OUTSIDE BUZZER This test is able to check Intelligent Key warning buzzer operation [On/Off].
HORN This test is able to check horn operation [On].
P RANGE This test is able to check CVT shift selector illumination operation [On/Off].
Test Item
Description
Support ItemSetting Description
LOCK/UNLOCK BY I-KEY On*
Door lock/unlock function from Intelligent Key ON.
Off Door lock/unlock function from Intelligent Key OFF.
ANTI KEY LOCK IN FUNCTI On*
Anti lock out setting ON.
Off Anti lock out setting OFF.
ANS BACK I-KEY UNLOCK Off
No buzzer reminder when doors are unlocked with request switch.
On* Buzzer reminder when doors are unlocked with request switch.
ANS BACK I-KEY LOCK Horn Chirp
Horn chirp reminder when doors are locked with request switch.
Buzzer* Buzzer reminder when doors are locked with request switch.
Off No reminder when doors are locked with request switch.
HORN WITH KEYLESS LOCK Off
Horn chirp reminder when doors are locked with Intelligent Key.
On* No horn chirp reminder when doors are locked with Intelligent Key.
HAZARD ANSWER BACK Lock/Unlock*
Hazard warning lamp activation when doors are locked/unlocked
with Intelligent Key or request switch.
Unlock Only Hazard warning lamp activation when doors are unlocked with Intel-
ligent Key or request switch.
Lock Only Hazard warning lamp activation when doors are locked with Intelli-
gent Key or request switch.
Off No hazard warning lamp activation when doors are locked/unlocked
with Intelligent Key or request switch.
INSIDE ANT DIAGNOSIS —This function allo ws inside key antenna self-diagnosis.
CONFIRM KEY FOB ID —Intelligent Key ID code can be checked.
SHORT CRANKING OUTPUT Start70 msec
Starter motor operation duration time setting.
100 msec
200 msec
End —
PANIC ALARM SET MODE 3 1.5 sec
Intelligent Key panic alarm button setting.
MODE 2 OFF
MODE 1* 0.5 sec
LO- BATT OF KEY FOB WARN On*
Intelligent Key low battery warning ON.
Off Intelligent Key low battery warning OFF.
Revision: August 2015 2016 Versa Note

cardiagn.com

HAZARD FUNCTIONDLK-101
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
HAZARD FUNCTION
Component Function CheckINFOID:0000000012430040
1.CHECK FUNCTION
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT.
2. Select “FLASHER” in “Active Test.
3. Touch “LH” or “RH” to check that it works normally.
Is the inspection result normal?
YES >> Hazard warning lamp circuit is OK.
NO >> Refer to DLK-101, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430041
1.CHECK HAZARD SWITCH CIRCUIT
Refer to EXL-85, "
Component Function Check".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace harness.
2.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
Revision: August 2015 2016 Versa Note

cardiagn.com
