2016 NISSAN NOTE warning

DLK-102
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY WARNING BUZZER
INTELLIGENT KEY WARNING BUZZER
Component Function CheckINFOID:0000000012542553
1.CHECK FUNCTION
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT.
2. Select “OUTSIDE BUZZER ” in “ACTIVE TEST” mode.
3. Touch “On” or “Off” to check that it works normally.
Is the inspection result normal?
YES >> Intelligent Key warning buzzer is OK.
NO >> Refer to DLK-102, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012542554
Regarding Wiring Diagram information, refer to DLK-46, "Wiring Diagram".
1.CHECK FUSE
1. Turn ignition switch OFF.
2. Check 10 A fuse [No. 8, located in fuse block (J/B)].
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace the blown fuse after repairing the affected circuit if a fuse is blown.
2.CHECK INTELLIGENT KEY WARNING BUZZER POWER SUPPLY CIRCUIT
1. Disconnect Intelligent Key warning buzzer connector.
2. Check voltage between Intelligent Key warning buzzer harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK INTELLIGENT KEY WARNING BUZZER CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between BCM harness connector and Intelligent Key warning buzzer harness connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4.CHECK INTELLIGENT KEY WARNING BUZZER
(+)
(–)Vol tag e
(Approx.)
Intelligent Key warning buzzer
Connector Terminal
E70 1Ground Battery voltage
BCM Intelligent Key warning buzzer
Continuity
Connector TerminalConnector Terminal
M98 93E70 3Yes
BCM GroundContinuity
Connector Terminal
M98 93 No
Revision: August 2015 2016 Versa Note

cardiagn.com

INTELLIGENT KEY WARNING BUZZERDLK-103
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Refer to DLK-103, "Component Inspection".
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> Replace Intelligent Key warning buzzer. Refer to DLK-186, "
Removal and Installation".
Component InspectionINFOID:0000000012542555
1.CHECK INTELLIGENT KEY WARNING BUZZER
1. Turn ignition switch OFF.
2. Disconnect Intelligent Key warning buzzer connector.
3. Connect battery power supply directly to Intelligent Key warning buzzer terminals and check the opera- tion.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace Intelligent Key warning buzzer. Refer to DLK-186, "
Removal and Installation".
Intelligent Key warning buzzer
Operation
Te r m i n a l
(+) (− )
1 3Buzzer sounds
Revision: August 2015 2016 Versa Note

cardiagn.com

KEY WARNING LAMPDLK-105
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
KEY WARNING LAMP
Component Function CheckINFOID:0000000012430044
1.CHECK FUNCTION
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT.
2. Select “INDICATOR” in “Active Test”.
3. Touch “KEY IND” or “KEY ON” to check that it works normally.
Is the inspection result normal?
YES >> Key warning lamp is OK.
NO >> Refer to DLK-105, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430045
1.CHECK KEY WARNING LAMP
Refer to DLK-27, "
WARNING FUNCTION : System Description".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace harness.
2.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
Revision: August 2015 2016 Versa Note

cardiagn.com

SHIFT P WARNING LAMPDLK-111
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
SHIFT P WARNING LAMP
Component Function CheckINFOID:0000000012430049
1.CHECK FUNCTION
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT.
2. Select “LCD” in “Active Test”.
3. Touch “SET P” to chec k that it works normally.
Is the inspection result normal?
YES >> Shift P warning lamp is OK.
NO >> Refer to D L K - 111 , "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430050
1.CHECK SHIFT P WARNING LAMP
Refer to TM-220, "
Component Parts Function Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
Revision: August 2015 2016 Versa Note

cardiagn.com

IGNITION POSITION WARNING FUNCTION DOES NOT OPERATE
DLK-119
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
IGNITION POSITION WARNING FUNCTION DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012430069
1.CHECK POWER DOOR LOCK OPERATION
Check power door lock operation.
Does door lock/unlock with driver side door lock knob and door key cylinder?
YES >> GO TO 2.
NO >> Refer to DLK-115, "
Diagnosis Procedure".
2.CHECK DOOR SWITCH
Check door switch.
Refer to DLK-98, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
Revision: August 2015 2016 Versa Note

cardiagn.com

HAZARD AND BUZZER REMINDER DOES NOT OPERATEDLK-123
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
HAZARD AND BUZZER REMI NDER DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012430073
1.CHECK HAZARD ANSWER BACK SETTING IN WORK SUPPORT
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT.
2. Select “HAZARD ANSWER BACK” in “Work support”.
3. Check the “HAZARD ANSWER BA CK” setting in “Work support”.
Refer to BCS-22, "
INTELLIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Set the “Lock Only”, “Unlock Only” or “Lock/Unlock” in “HAZARD ANSWER BACK”.
2.CHECK ANS BACK I-KEY LOCK SETTING IN WORK SUPPORT
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT.
2. Select “ANS BACK I-KE Y LOCK” in “Work support.
3. Check the “ANS BACK I-KEY LOCK” setting in “Work support”. Refer to BCS-22, "
INTELLIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Set the “Horn Chirp” or “Buzzer” in “ANS BACK I-KEY LOCK”.
3.CHECK ANS BACK I-KEY UNLOCK SETTING IN WORK SUPPORT
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT.
2. Select “ANS BACK I-KEY UNLOCK” in “Work support”.
3. Check the “ANS BACK I-KEY UNLOCK” setting in “Work support”. Refer to BCS-22, "
INTELLIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Set the “On” in “ANS BACK I-KEY UNLOCK”.
4.CHECK HAZARD FUNCTION
Check hazard function.
Refer to DLK-101, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CHECK INTELLIGENT KEY WARNING BUZZER
Check Intelligent Key warning buzzer.
Refer to DLK-102, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace the malfunctioning parts.
6.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
Revision: August 2015 2016 Versa Note

cardiagn.com

OFF POSITION WARNING DOES NOT OPERATEDLK-125
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
OFF POSITION WARNIN G DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012430075
1.CHECK DTC WITH BCM
Check that DTC is not detected with BCM.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform trouble diagnosis relevant to DTC indicated.
2.CHECK DTC WITH COMBINATION METER
Check that DTC is not detected with combination meter.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Perform trouble diagnosis relevant to DTC indicated.
3.CHECK DOOR SWITCH
Check front door switch LH.
Refer to DLK-98, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK COMBINATION METER BUZZER
Check combination meter buzzer.
Refer to DLK-78, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CHECK INTELLIGENT KEY WARNING BUZZER
Check Intelligent Key warning buzzer.
Refer to DLK-102, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace the malfunctioning parts.
6.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-126
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
P POSITION WARNING DOES NOT OPERATE
P POSITION WARNING DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012430076
1.CHECK DTC WITH BCM
Check that DTC is not detected with BCM.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform trouble diagnosis relevant to DTC indicated.
2.CHECK DTC WITH COMBINATION METER
Check that DTC is not detected with combination meter.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Perform trouble diagnosis relevant to DTC indicated.
3.CHECK INTELLIGENT KEY WARNING BUZZER
Check Intelligent Key warning buzzer.
Refer to DLK-102, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK COMBINATION METER BUZZER
Check combination meter buzzer.
Refer to DLK-78, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CHECK DOOR SWITCH
Check front door switch LH.
Refer to DLK-98, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace the malfunctioning parts.
6.CHECK KEY WARNING LAMP
Check key warning lamp.
Refer to DLK-105, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace the malfunctioning parts.
7.CHECK SHIFT P WARNING LAMP
Check shift P warning lamp.
Refer to D L K - 111 , "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair or replace the malfunctioning parts.
8.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
Revision: August 2015 2016 Versa Note

cardiagn.com
