P0720 OUTPUT SPEED SENSORTM-165
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 6.
2.CHECK OUTPUT SPEED SENSOR GROUND CIRCUIT
Check continuity between output speed sensor harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning parts.
3.CHECK CIRCUIT BETWEEN OUTPUT SPEED SENSOR AND TCM (PART 1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check continuity between output speed sensor harness connector terminal and TCM harness connector
terminal.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace malfunctioning parts.
4.CHECK CIRCUIT BETWEEN OUTPUT SPEED SENSOR AND TCM (PART 2)
Check continuity between output speed sensor harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace malfunctioning parts.
5.CHECK TCM INPUT SIGNALS
1. Connect all of disconnected connectors.
2. Lift the vehicle.
3. Start the engine.
4. Check frequency of output speed sensor.
+
−Voltag e
Output speed sensor
Connector Terminal F41 3 Ground 10 – 16 V
Output speed sensor
— Continuity
Connector Terminal
F41 1 Ground Existed
Output speed sensor TCM
Continuity
Connector Terminal Connector Terminal
F41 2F44 24 Existed
Output speed sensor
—Continuity
Connector Terminal
F41 2 Ground Not existed
Revision: August 2015 2016 Versa Note

cardiagn.com

P0740 TORQUE CONVERTERTM-167
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0740 TORQUE CONVERTER
DTC LogicINFOID:0000000012431099
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Be careful of the driving speed.
1.PREPARATION BEFORE OPERATION (PART 1)
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.PREPARATION BEFORE OPERATION (PART 2)
With CONSULT
1. Start the engine.
2. Select “Data Monitor” in “TRANSMISSION”.
3. Select “FLUID TEMP”.
4. Confirm that the CVT fluid temper ature is in the following range.
With GST
1. Start the engine.
2. Set the CVT fluid to 10 °C (50° F) or more.
NOTE:
When the ambient temperature is 20 °C (68° F), the CVT fluid usually increases to 50 to 80 °C (122 to
176° F) with driving in an urban area for approximately 10 minutes.
Is the CVT fluid 10
°C (50°F) or more?
YES >> GO TO 3.
NO >> 1. Warm the transaxle. 2. GO TO 3.
3.CHECK DTC DETECTION
1. Drive the vehicle.
2. Maintain the following conditions for 10 seconds or more.
3. Stop the vehicle.
4. Check the first trip DTC.
Is
“P0740” detected?
YES >> Go to TM-168, "Diagnosis Procedure".
NO >> INSPECTION END
DTC Trouble diagnosis name DTC detection conditionPossible causes
P0740 Torque Converter Clutch Cir-
cuit/Open The TCM torque converter clutch solenoid
valve current monitor reading is 200 mA or
less continuously for 5 seconds or more under
the following diagnosis conditions:
• Diagnosis conditions
- Solenoid valve output current: 750 mA or
more
- GND short diagnosis of the solenoid valve
circuit is not satisfied.
- TCM power supply voltage: More than 11 V • Harness or connector
(Torque converter clutch solenoid
valve circuit is open or shorted to pow-
er supply)
• Torque converter clutch solenoid valve
FLUID TEMP : 10 °C (50 °F) or more
Selector lever : “D” position
Vehicle speed : 40 km/h (25 MPH) or more
Revision: August 2015 2016 Versa Note

cardiagn.com

P0743 TORQUE CONVERTERTM-169
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0743 TORQUE CONVERTER
DTC LogicINFOID:0000000012431102
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Be careful of the driving speed.
1.PREPARATION BEFORE OPERATION (PART 1)
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.PREPARATION BEFORE OPERATION (PART 2)
With CONSULT
1. Start the engine.
2. Select “Data Monitor” in “TRANSMISSION”.
3. Select “FLUID TEMP”.
4. Confirm that the CVT fluid temper ature is in the following range.
With GST
1. Start the engine.
2. Set the CVT fluid to 10 °C (58° F) or more.
NOTE:
When the ambient temperature is 20 °C (68° F), the CVT fluid usually increases to 50 to 80 °C (122 to
176° F) with driving in an urban area for approximately 10 minutes.
Is the CVT fluid 10
°C (58°F) or more?
YES >> GO TO 3.
NO >> 1. Warm the transaxle. 2. GO TO 3.
3.CHECK DTC DETECTION
1. Drive the vehicle.
2. Maintain the following conditions for 5 seconds or more.
3. Stop the vehicle.
4. Check the first trip DTC.
Is
“P0743” detected?
YES >> Go to TM-170, "Diagnosis Procedure".
NO >> INSPECTION END
DTC Trouble diagnosis name DTC detection conditionPossible causes
P0743 Torque Converter Clutch Cir-
cuit Electrical The TCM torque converter clutch solenoid
valve current monitor reading is 200 mA or
less continuously for 480 msec or more under
the following diagnosis conditions:
• Diagnosis conditions
- Solenoid valve output current: 750 mA or
more
- GND short circuit diagnosis occurs in the
solenoid valve drive circuit.
- TCM power supply voltage: More than 11 V • Harness or connector
(Torque converter clutch solenoid
valve circuit is shorted to ground)
• Torque converter clutch solenoid valve
FLUID TEMP : 10 °C (50 °F) or more
Selector lever : “D” position
Vehicle speed : 40 km/h (25 MPH) or more
Revision: August 2015 2016 Versa Note

cardiagn.com

P0744 TORQUE CONVERTERTM-171
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0744 TORQUE CONVERTER
DTC LogicINFOID:0000000012431105
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Be careful of the driving speed.
1.PREPARATION BEFORE OPERATION 1
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.PREPARATION BEFORE OPERATION 2
With CONSULT
1. Start the engine.
2. Select “Data Monitor” in “TRANSMISSION”.
3. Select “FLUID TEMP”.
4. Confirm that the CVT fluid temperature is in the range below.
With GST
1. Start the engine.
2. Set the CVT fluid to 20 °C (68° F) or more.
NOTE:
When the ambient temperature is 20 °C (68° F), the CVT fluid usually increases to 50 to 80 °C (122 to
176° F) with driving in an urban area for approximately 10 minutes.
Is the CVT fluid 20
°C (68°F) or more?
YES >> GO TO 3.
NO >> 1. Warm the transaxle. 2. GO TO 3.
3.CHECK DTC DETECTION
1. Drive the vehicle.
2. Maintain the following conditions for 40 seconds or more.
DTC Trouble diagnosis name DTC detection conditionPossible causes
P0744 Torque converter clutch circuit
intermittent The torque converter slip speed is at or above
a set value (40 rpm + (Vehicle speed / 2) con-
tinuously for 30 seconds or more under the fol-
lowing diagnosis conditions:
• Diagnosis conditions
- Selector lever:
“D” position
- Accelerator pedal position: 1.0/8 or more
- Vehicle speed: 10 km/h (6 MPH) or more
- Engine speed: 450 rpm or more
- CVT fluid temperature: 20 °C (68 °F) ≤ CVT
fluid temperature ≤ 180 °C (356 °F)
- Lockup command is being given (except for slip lockup).
- LU PRS: More than 0.2 MPa
- TCM power supply voltage: More than 11 V • Torque converter clutch solenoid valve
• Control valve assembly
• Torque converter
FLUID TEMP : 20
°C (68 °F) or more
Selector lever : “D” position
Accelerator pedal position : 1.0/8 or more
Vehicle speed : 40 km/h (25 MPH) or more
Revision: August 2015 2016 Versa Note

cardiagn.com

P0746 PRESSURE CONTROL SOLENOID ATM-173
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0746 PRESSURE CONTROL SOLENOID A
DTC LogicINFOID:0000000012431108
DTC DETECTION LOGIC
NOTE:
DC stands for "DRIVING CYCLE" and indicates a seri es of driving cycle of "Ignition switch OFF → ON → driv-
ing → OFF".
DTC CONFIRMATION PROCEDURE
CAUTION:
Be careful of the driving speed.
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
1. Start the engine.
2. Drive the vehicle.
3. Maintain the following conditions for 10 seconds or more.
DTC Trouble diagnosis name DTC detection conditionPossible causes
P0746 Pressure Control Solenoid A
Performance/Stuck Off The detecting condition A or detection condi-
tion B is detected twice or more (1 second or
more later after detection of the first) in the
same DC under the following diagnosis condi-
tions:
• Diagnosis conditions
- After the ignition switch is ON, 500 msec or
more have passed.
- Selector lever: Other than “P” and “N” posi-
tions
- Idle is not being detected.
- Engine speed: 600 rpm or more
- Primary pulley speed: 500 rpm or more
- Auxiliary gearbox shifting is not in progress.
- Acceleration/deceleration speed: −0.05 G
or more
- The primary pulley speed experienced 306
rpm or more and the secondary pulley
speed experienced 230 rpm or more at
least once.
- The output speed is 107 rpm or less or the
secondary pulley speed exceeds 61 rpm.
• Detection condition A
- Status with the shifting ratio of the primary pulley speed/secondary pulley ratio ex-
ceeding 2.55 is 200 msec or more continu-
ously.
• Detection condition B
- Status with the shifting ratio of the primary pulley speed/secondary pulley ratio ex-
ceeding 3.35 is 100 msec or more continu-
ously. • Line pressure solenoid valve
• Control valve assembly
Selector lever
: “D” position
Accelerator pedal position : 0.1/8 or more
Vehicle speed : 40 km/h (25 MPH) or more
Revision: August 2015 2016 Versa Note

cardiagn.com

P0846 TRANSMISSION FLUID PRESSURE SEN/SW BTM-175
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0846 TRANSMISSION FLUI D PRESSURE SEN/SW B
DTC LogicINFOID:0000000012431111
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Be careful of the driving speed.
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
1. Start the engine.
2. Shift the selector lever to “D” position.
3. Drive the vehicle at a constant velocity of 40 km/h (25 MPH) at lease for 10 seconds.
CAUTION:
At the same time, the accelerator pedal angle must be maintained constant.
4. Stop the vehicle.
5. Check the first trip DTC.
Is
“P0846”detected?
YES >> Go to TM-175, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431112
1.CHECK TCM INPUT SIGNAL
1. Start the engine.
2. Check voltage between TCM connector terminal and ground.
DTC Trouble diagnosis name DTC detection conditionPossible causes
P0846 Transmission Fluid Pressure
Sensor/Switch B Circuit
Range/Performance The detection conditions continuously for 5
seconds or more under the following diagno-
sis conditions:
• Diagnosis conditions
- Selector lever:
“D” position
- The primary pulley speed experienced 306 rpm or more and the secondary pulley
speed experienced 230 rpm or more at
least once.
- Wheel spin is not being detected.
- The rate of change in pulley ratio: Between −0.09 and +0.09 inclusive
- Solenoid valve output current: 750 mA or more
- GND short diagnosis of the solenoid valve circuit is not satisfied.
- TCM power supply voltage: More than 11 V
• Detection conditions
- After the value of “Actual secondary pres-
sure − Target secondary pressure” exceeds
0.675 MPa:
• The rate of change in vehicle speed [km/h (MPH)]: Between −49 ( −30) and +49 (+30)
inclusive
• The rate of change in accelerator pedal an- gle: Between −1.3/8 and +1.3/8 inclusive • Secondary pressure sensor
• Control valve assembly
Revision: August 2015
2016 Versa Note

cardiagn.com

TM-176
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F11A]
P0846 TRANSMISSION FLUID PRESSURE SEN/SW B
Is the inspection result normal?
YES >> Check intermittent incident. Refer to
GI-42, "Intermittent Incident".
NO >> There is a malfunction of secondary pressure sensor value. Replace control valve assembly.
Refer to TM-242, "
Removal and Installation".
+
−Condition Voltage
TCM
Connector Terminal
F44 16 Ground • After engine warm up
• Selector lever:
“N” position
• At idle 0.88 – 0.92 V
Revision: August 2015
2016 Versa Note

cardiagn.com

P0847 TRANSMISSION FLUID PRESSURE SEN/SW BTM-177
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0847 TRANSMISSION FLUI D PRESSURE SEN/SW B
DTC LogicINFOID:0000000012431113
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT
1. Start the engine.
2. Select “Data Monitor” in “TRANSMISSION”.
3. Select “FLUID TEMP”.
4. Maintain the following conditions for 10 seconds or more.
5. Check the first trip DTC.
With GST
1. Start the engine and wait for at least 10 seconds. CAUTION:
When the ambient temperature is −20° C (−4 °F) or less and the engine is cold, warm up the engine
for approximately 5 minutes.
2. Check the first trip DTC.
Is
“P0847”detected?
YES >> Go to TM-177, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431114
1.CHECK CIRCUIT BETWEEN TC M AND CVT UNIT (PART 1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector and CVT unit connector.
3. Check continuity between TCM harness connector terminals and CVT unit harness connector terminals.
Is the inspection result normal?
DTC Trouble diagnosis name DTC detection conditionPossible causes
P0847 Transmission Fluid Pressure
Sensor/Switch B Circuit Low The secondary pressure sensor voltage is
0.09 V or less continuously for 5 seconds or
more under the following diagnosis condi-
tions:
• Diagnosis conditions
- CVT fluid temperature:
−20 °C ( −4 °F) or
more
- TCM power supply voltage: More than 11 V • Harness or connector
(Secondary pressure sensor circuit is
open or shorted to ground)
• Secondary pressure sensor
• Control valve assembly
FLUID TEMP : −19 °C ( −2.2 °F) or more
TCM CVT unit
Continuity
Connector Terminal Connector Terminal
F44 11
F46 18
Existed
16 14
26 22
Revision: August 2015 2016 Versa Note

cardiagn.com
