TM-226
< SYMPTOM DIAGNOSIS >[CVT: RE0F11A]
CVT CONTROL SYSTEM
Symptom diagnosis chart 2-1
SymptomCheck under on board condition (repair
and part replacement) Replace the transaxle assembly.
Engine system
Incorrect adjustment of CVT fluid level
Line pressure is out of the standard value.
Control cable
Electric system
TCM
Overdrive control switch
Primary speed sensor (P0715)
Secondary speed sensor (P2765)
Output speed sensor (P0720)
Transmission position switch (P0705, P0706)
Secondary pressure sensor (P0846, P0847, P0848)
Primary pressure soleno
id valve (P17BA, P17BB)
Line pressure solenoid valve (P0746, P0962, P0963)
Lock-up solenoid valve
(P0740, P0743, P0744)
High clutch &reverse brake solenoid valve
(P1739, P173C, P17B7, P17B8)
Low brake solenoid valve
(P173A, P173B, P17B4, P17B5)
CVT fluid temperature sensor (P0711, P0712, P0713)
EC-120
TM-229TM-131TM-232TM-99TM-217TM-110
Shock vi-
bration
Noise Shock at start is large in “D”,
“L”, or “R” position.
12
11
Shock is large when the aux-
iliary gearbox is shifted from
1GR → 2GR. 212
22 11
Shock in lockup is large dur-
ing driving in “D ” or “L” posi-
tion. 11
Shock is large when the lever
is shifted from “N” → “D” and
“N” → “R” positions. 1 12111 11111
Shock is large when the lever
is shifted from “D” → “L” posi-
tion.
Vibration occurs in “D”, “L”, or
“R” position during driving. 1111 12 111
Noise occurs during driving. 1
Noise occurs in idling. 1 1
Other Starter operates in “D”, “L”, or
“R” position.
11
1
Starter does not operate in
“P” or “N” position. 11
1
Engine stall occurs in “D”, “L”,
or “R” position during stop. 111 1
Engine stall occurs in “P” or
“N” position during stop. 111 1
Parking lock does not oper-
ate in “P” position. 11
Parking lock cannot be can-
celled when the selector le-
ver is shifted from “P” position
to other position. 11
Revision: August 2015
2016 Versa Note

cardiagn.com

TM-228
< PERIODIC MAINTENANCE >[CVT: RE0F11A]
CVT FLUID
PERIODIC MAINTENANCE
CVT FLUID
InspectionINFOID:0000000012431172
FLUID LEAKAGE
• Check transaxle surrounding area (oil seal and plug etc.)for fluid
leakage.
• If anything is found, repair or replace damaged parts and adjust
CVT fluid level. Refer to TM-229, "
Adjustment".
ReplacementINFOID:0000000012431173
CAUTION:
• Use only Genuine NISSAN CVT Fluid NS-3. Using transmission fluid other than Genuine NISSAN
CVT Fluid NS-3 will damage the CVT, which is not covered by the (NISSAN new vehicle limited) war-
ranty.
• Always use shop paper. Never use shop cloth.
• Replace a drain plug gasket with new ones at the final stage of the operation when installing.
• Use caution when looking into the drain hole as th ere is a risk of dripping fluid entering the eye.
• After replacement, always perform CVT fluid leakage check.
1. Select “Data Monitor” in “T RANSMISSION” using CONSULT.
2. Select “FLUID TEMP” and confirm t hat the CVT fluid temperature is 40°C (104° F) or less.
3. Check that the selector lever is in the “P ” position, then completely engage the parking brake.
4. Lift up the vehicle.
5. Remove the drain plug and overflow tube and drain the CVT fluid from the oil pan. TM-242, "
Removal and
Installation".
6. Install the charging pipe set (KV311039S0) (A) into the drain hole.
CAUTION:
Tighten the charging pipe by hand.
7. Install the ATF changer hose (B) to the charging pipe. CAUTION:
Press the ATF changer hose all the way onto the charging
pipe until it stops.
8. Fill approximately 3 liter (2-5/8 lmp qt) of the CVT fluid.
9. Remove the ATF changer hose and charging pipe, then install the drain plug.
NOTE:
Perform this work quickly because CVT fluid leaks.
10. Lift down the vehicle.
11. Start the engine.
12. While depressing the brake pedal, shift the selector lever to the entire position from “P” to “L”, and shift it to the “P” position.
NOTE:
SMA146B
CVT fluid : Refer to TM-265, "General Specification".
Fluid capacity : Refer to TM-265, "
General Specification".
JSDIA1876ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

CVT FLUIDTM-229
< PERIODIC MAINTENANCE > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Hold the lever at each position for 5 seconds.
13. Check that the CONSULT “Data monitor” in “FLUID TEMP” is 35°C (95°F) to 45 °C (113 °F).
14. Stop the engine.
15. Lift up the vehicle.
16. Remove the drain plug, and then drain CVT fluid from oil pan.
17. Repeat steps 6 to 16 (one time).
18. Install the overflow tube. Refer to TM-242, "
Removal and Installation".
CAUTION:
Be sure to tighten to the specified torque. If it is not tightened to the specified torque, the tube may
be damaged.
19. Install the charging pipe set (KV311039S0) (A) into the drain hole.
CAUTION:
Tighten the charging pipe by hand.
20. Install the ATF changer hose (B) to the charging pipe. CAUTION:
Press the ATF changer hose all the way onto the charging
pipe until it stops.
21. Fill approximately 3 liter (2-5 /8 lmp qt) of the CVT fluid.
22. Remove the ATF changer hose and charging pipe, then install the drain plug.
NOTE:
Perform this work quickly because CVT fluid leaks.
23. Lift down the vehicle.
24. Start the engine.
25. While depressing the brake pedal, shift the selector leve r to the entire position from “P” to “L”, and shift it
to the “P” position.
NOTE:
Hold the lever at each position for 5 seconds.
26. Check that the CONSULT “Data monitor” in “FLUID TEMP” is 35°C (95°F) to 45 °C (113 °F).
27. Lift up the vehicle.
28. Remove the drain plug and confirm that the CV T fluid is drained from the overflow tube.
CAUTION:
Perform this work with the vehicle idling.
NOTE:
If the CVT fluid is not drained, refer to “Adjustment” and refill with the CVT fluid.
29. When the flow of CVT fluid slows to a drip, tighten the drain plug to the specified torque. TM-242,
"Removal and Installation".
CAUTION:
Never reuse drain plug gasket.
30. Lift down the vehicle.
31. Select “Work Support” in “T RANSMISSION” using CONSULT.
32. Select “CONFORM CVTF DETERIORTN”.
33. Select “Erase”.
34. Stop the engine.
AdjustmentINFOID:0000000012431174
CAUTION:
• Use only Genuine NISSAN CVT Fluid NS-3. Using transmission fluid other than Genuine NISSAN CVT Fluid NS-3 will damage the CVT, which is not covered by the (NISSAN new vehicle limited) war-
ranty.
JSDIA1876ZZ
CVT fluid : Refer to TM-265, "General Specification".
Fluid capacity : Refer to TM-265, "
General Specification".
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-230
< PERIODIC MAINTENANCE >[CVT: RE0F11A]
CVT FLUID
• During adjustment of the CVT fluid level, check CO
NSULT so that the oil temperature may be main-
tained from 35 to 45 °C (95 to 113 °F).
• Use caution when looking into the drain hole as th ere is a risk of dripping fluid entering the eye.
1. Check that the selector lever is in the “P ” position, then completely engage the parking brake.
2. Start the engine.
3. Adjust the CVT fluid temperature to be approximately 40 °C (104° F).
NOTE:
The CVT fluid is largely affected by temperature. Therefore be sure to use CONSULT and check the
“FLUID TEMP” under “TRANSMISSION” in “Data Monitor” while adjusting.
4. While depressing the brake pedal, shift the selector lever to the entire position from “P” to “L”, and shift it to the “P” position.
NOTE:
Hold the lever at each position for 5 seconds.
5. Lift up the vehicle.
6. Check that there is no CVT fluid leakage.
7. Remove the drain plug. Refer to TM-242, "
Removal and Installation".
8. Install the charging pipe set (KV311039S0) (A) into the drain plug hole.
CAUTION:
Tighten the charging pipe by hand.
9. Install the ATF changer hose (B) to the charging pipe. CAUTION:
Press the ATF changer hose all the way onto the charging
pipe until it stops.
10. Fill approximately 0.5 liter (1/2 lmp qt) of the CVT fluid.
11. Remove the ATF changer hose from the charging pipe, and check that the CVT fluid drains out from the charging pipe. If it
does not drain out, perform charging again.
CAUTION:
Perform this work with the vehicle idling.
12. When the flow of CVT fluid slows to a drip, remove the charging pipe from the oil pan.
13. Tighten the drain plug to the specified torque. Refer to TM-242, "
Removal and Installation".
CAUTION:
Never reuse drain plug gasket.
14. Lift down the vehicle.
15. Stop the engine.
JSDIA1876ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

WATER HOSETM-253
< REMOVAL AND INSTALLATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
InspectionINFOID:0000000012431209
INSPECTION AFTER INSTALLATION
Start the engine and check visually that there is no leakage of engine coolant.
Water hose (1) Installation side
tube (2) Hose clamp (3)
Dieection of tab Clamping position
Water hose A Water outlet Upward
5 - 7 mm (0.20 - 0.28
in) (A) from hose end
CVT oil warmer Frontward
Water hose B CVT oil warmer Leftward
Water bypass pipe Rightward
Water hose C Water bypass pipe
Upward and 45
°
frontward
Water outlet Upward and 45
°
frontward
JSDIA2424ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-256
< REMOVAL AND INSTALLATION >[CVT: RE0F11A]
CVT OIL WARMER
CVT OIL WARMER
Exploded ViewINFOID:0000000012431217
Removal and InstallationINFOID:0000000012431218
REMOVAL
WARNING:
Never remove the radiator cap when the engine is hot. Serious burns coul
d occur from high pressure
engine coolant escaping from the radiator. Wrap a thick cloth ar ound the cap. Slowly turn it a quarter
turn to allow built-up pressure to escape. Carefully remove the cap by turning it all the way.
CAUTION:
Perform these steps after the coolant temperature has cooled sufficiently.
1. Pull out water hose from CVT oil warmer. Refer to TM-251, "
Removal and Installation".
2. Pull out fluid cooler hose from CVT oil warmer. Refer to TM-254, "
Removal and Installation".
3. Remove CVT oil warmer.
4. Remove O-ring from CVT oil warmer.
INSTALLATION
Note the followings and install in the reverse order of removal.
CAUTION:
• Never reuse O-ring.
• Apply CVT fluid to O-ring.
InspectionINFOID:0000000012431219
INSPECTION AFTER INSTALLATION
Start the engine and check visually that ther e is no leakage of CVT fluid and engine coolant.
ADJUSTMENT AFTER INSTALLATION
Adjust CVT fluid level. Refer to TM-229, "Adjustment".
1. Transaxle assembly 2. CVT oil warmer 3. O-ring
: Always replace after every disassembly.
: N·m (kg-m, in-lb)
: Apply CVT fluid
JSDIA5447GB
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-258
< REMOVAL AND INSTALLATION >[CVT: RE0F11A]
CVT FLUID FILTER
3. Turn fluid filter cover (1) counterclockwise and remove it from
transaxle.
CAUTION:
Do not reuse fluid filter cover.
4. Remove CVT fluid filter (1) from transaxle. CAUTION:
Do not reuse CVT fluid filter.
INSTALLATION
Note the following and install in the reverse order of removal.
NOTE:
Inspect the CVT fluid level. Refer to TM-228, "
Inspection".
CAUTION:
• Never reuse CVT fluid filter and fluid filter cover.
• Apply CVT fluid to O-ring of fluid filter cover.
InspectionINFOID:0000000012431222
INSPECTION AFTER INSTALLATION
Start the engine and check visually that there is no leakage of CVT fluid.
ADJUSTMENT AFTER INSTALLATION
Adjust CVT fluid level. Refer to TM-229, "Adjustment".
JSDIA5048ZZ
JSDIA5049ZZ
JSDIA5450ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-260
< UNIT REMOVAL AND INSTALLATION >[CVT: RE0F11A]
TRANSMISSION ASSEMBLY
• Primary speed sensor harness connector
• Secondary speed sensor harness connector
• Output speed sensor harness connector
• Ground
3. Rotate the crankshaft and remove the nuts that secure the drive plate to the torque converter from the sta- tor motor mount.
CAUTION:
When turning crankshaft, turn it clockwise as viewed from the front of the engine.
4. Remove the bolts (engine to transaxle) that fasten the transaxle assembly and engine assembly.
5. Remove transaxle assembly from engine. CAUTION:
• Secure torque converter to prevent it from dropping.
• Secure transaxle assembly to a suitable jack.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Do not reuse O-rings.
• Apply Genuine NISSAN CVT Fluid NS-3 to the O-rings.
• When installing the transaxle assembly onto the engine assembly,
check the engagement of the dowel pins ( ).
• When using suitable tool (A) for alignment, install it to the align- ment stud bolt used to align the torque converter to the drive plate.
JSDIA1839ZZ
Bolt position ABC D
Direction of insertion Transaxle assembly
⇒
Engine assembly Engine assembly
⇒ Transaxle assembly
Q ua ntit y 2213
JSDIA1184ZZ
JPDIA0683ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com
