P0711 TRANSMISSION FLUI D TEMPERATURE SENSOR A
DTC LogicINFOID:0000000012431086
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.INSPECTION START
Is it necessary to erase permanent DTC?
YES >> GO TO 3.
NO >> GO TO 7.
3.CHECK DTC (ECM AND TCM)
Check the DTC.
Is any DTC other than
“P0711” detected?
YES >> Check DTC detect ed item. Refer to EC-87, "DTCIndex" (ECM), TM-110, "DTC Index" (TCM).
NO >> GO TO 4.
DTC Trouble diagnosis name DTC detection conditionPossible causes
P0711 Transmission Fluid Tempera-
ture Sensor A Circuit Range/
Performance When any of 1 or 2 is satisfied:
1. Under the following diagnosis conditions,
CVT fluid temperature does not rise to
10°C (50 °F) after driving for a certain pe-
riod of time with the TCM-received fluid
temperature sensor value between −
40 °C ( −40 °F) and 9 °C (48.2 °F).
- Diagnosis condition
• Selector lever: “D” position
• Vehicle speed: 10 km/h (7 MPH) or more
• Engine speed: 450 rpm or more
• Accelerator pedal position: 1.0/8 or more
• TCM power supply voltage: More than 11 V
• CVT fluid temperature: Less than 10 °C
2. When the condition of the final judgment is satisfied after satisfying that of the pro-
visional judgment:
- Provisional judgment: All of the following conditions are satisfied within 2 seconds
after the ignition switch is turned ON.
• U0073, U0100, P0712 and P0713 are not detected.
• CAN communication is normal.
• TCM power supply voltage: More than 11
V
• The difference between CVT fluid tem-
perature and engine coolant temperature
is 37°C (98.6 °F) or more, or −27 °C ( −
16 °F) or less.
- Final judgment: When all of the following conditions are satisfied and this state is
maintained for 300 seconds:
•ECM is normal.
• Provisional judgment is satisfied. CVT fluid temperature sensor
Revision: August 2015
2016 Versa Note

cardiagn.com

TM-154
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F11A]
P0711 TRANSMISSION FLUID
TEMPERATURE SENSOR A
4.PERFORM DTC CONFIRMATION PROCEDURE (PART 1)
TESTING CONDITION:
• While performing the following procedure, do not add fuel.
• Before performing the followin g procedure, check that fuel level is between 1/4 and 4/4.
• Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
With CONSULT
1. Move the vehicle to a cool place.
NOTE:
Cool the vehicle in an environment of ambient air temperature between −10° C (14° F) and 35 °C (95 °F).
2. Turn ignition switch OFF and leave the vehicle for 12 hours.
CAUTION:
Never turn ignition switch ON during this procedure.
NOTE:
The vehicle must be cooled with the food open.
3. Turn ignition switch ON. CAUTION:
Never start the engine.
4. Select “Data Monitor” in “TRANSMISSION”.
5. Select “FLUID TEMP”.
6. Record CVT fluid temperature.
7. Start engine and let it idle for 5 minutes or more. CAUTION:
Never turn ignition switch OFF during idling.
8. Check 1st trip DTC.
With GST
1. Move the vehicle to a cool place. NOTE:
Cool the vehicle in an environment of ambient air temperature between −10° C (14° F) and 35 °C (95 °F).
2. Turn ignition switch OFF and leave the vehicle for 12 hours. CAUTION:
Never turn ignition switch ON during this procedure.
NOTE:
The vehicle must be cooled with the food open.
3. Start engine and let it idle for 5 minutes or more. CAUTION:
Never turn ignition switch OFF during idling.
4. Check 1st trip DTC.
Is
“P0711” detected?
YES >> Go to TM-156, "Diagnosis Procedure".
NO-1 (With CONSULT)>>GO TO 5.
NO-2 (With GST)>>GO TO 6.
5.CHECK CVT FLUID TEMPERATURE
With CONSULT
1. Select “Data Monitor” in “TRANSMISSION”.
2. Select “FLUID TEMP”.
Is the value of
“FLUID TEMP” 10°C (50°F) or more?
YES >> INSPECTION END
NO >> GO TO 6.
6.PERFORM DTC CONFIRMATION PROCEDURE (PART 2)
With CONSULT
1. Drive the vehicle for the total minutes specified in the Driving time column below with the following condi-
tions satisfied.
Selector lever : “D” position
Accelerator pedal position : 1.0/8 or more
Vehicle speed : 10 km/h (7 MPH) or more
Revision: August 2015 2016 Versa Note

cardiagn.com

P0711 TRANSMISSION FLUID TEMPERATURE SENSOR ATM-155
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
2. Stop the vehicle.
3. Check the first trip DTC. With GST
1. Drive the vehicle and maintain the following conditions for 18 minutes or more.
2. Stop the vehicle.
3. Check the first trip DTC.
Is
“P0711” detected?
YES >> Go to TM-156, "Diagnosis Procedure".
NO >> INSPECTION END
7.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT
1. Turn ignition switch OFF and cool the engine.
2. Turn ignition switch ON. CAUTION:
Never start the engine.
3. Select “Data Monitor” in “TRANSMISSION”.
4. Select “FLUID TEMP”.
5. Record CVT fluid temperature.
6. Start the engine and wait for at least 2 minutes.
7. Drive the vehicle for the total minutes specified in the Driving time column below with the following condi- tions satisfied.
8. Stop the vehicle.
9. Check the first trip DTC. With GST
1. Turn ignition switch OFF and cool the engine.
2. Start the engine and wait for at least 2 minutes.
3. Drive the vehicle and maintain the following conditions for 18 minutes or more.
CVT fluid temperature before engine start Driving time
− 40 °C ( −40 °F) – −31 °C ( −23.8 °F) 18 minutes or more
− 30 °C ( −22 °F) – −21 °C ( −5.8 °F) 16 minutes or more
− 20 °C ( −4°F) – −11 °C ( −12.2 °F) 13 minutes or more
− 10 °C (14 °F) – −1 °C (30.2 °F) 9 minutes or more
0 °C (32 °F) – 9 °C (48.2 °F) 6 minutes or more
Selector lever : “D” position
Accelerator pedal position : 1.0/8 or more
Vehicle speed : 10 km/h (7 MPH) or more
Selector lever : “D” position
Accelerator pedal position : 1.0/8 or more
Vehicle speed : 10 km/h (7 MPH) or more
CVT fluid temperature before engine start Driving time
− 40 °C ( −40 °F) – −31 °C ( −23.8 °F) 18 minutes or more
− 30 °C ( −22 °F) – −21 °C ( −5.8 °F) 16 minutes or more
− 20 °C ( −4°F) – −11 °C ( −12.2 °F) 13 minutes or more
− 10 °C (14 °F) – −1 °C (30.2 °F) 9 minutes or more
0 °C (32 °F) – 9 °C (48.2 °F) 6 minutes or more
Other than the above — (Go to “8.CHECK CVT FLU-
ID TEMPERATURE SENSOR”)
Revision: August 2015
2016 Versa Note

cardiagn.com

P0712 TRANSMISSION FLUID TEMPERATURE SENSOR ATM-157
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0712 TRANSMISSION FLUI D TEMPERATURE SENSOR A
DTC LogicINFOID:0000000012431089
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine and wait for 10 seconds or more.
2. Check the first trip DTC.
Is
“P0712” detected?
YES >> Go to TM-157, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431090
1.CHECK CIRCUIT BETWEE N TCM AND CVT UNIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector and CVT unit connector.
3. Check continuity between TCM harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning part.
2.CHECK CVT FLUID TEMPERATURE SENSOR
Check CVT fluid temperature sensor. Refer to TM-157, "
Component Inspection (CVT Fluid Temperature Sen-
sor)".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> Repair or replace malfunctioning parts.
Component Inspection (CVT Fluid Temperature Sensor) INFOID:0000000012431091
1.CHECK CVT FLUID TEMPERATURE SENSOR
Check resistance between CVT unit connector terminals.
DTC Trouble diagnosis name DTC detection conditionPossible causes
P0712 Transmission Fluid Tempera-
ture Sensor A Circuit Low The CVT fluid temperature identified by the
TCM is 180
°C (356 °F) or more continuously
for 5 seconds or more under the following di-
agnosis conditions:
• Diagnosis conditions
- Ignition switch: ON
- TCM power supply voltage: More than 11 V • Harness or connector
(CVT fluid temperature sensor circuit is
shorted to ground)
• CVT fluid temperature sensor
TCM —Continuity
Connector Terminal
F44 12Ground Not existed
Revision: August 2015 2016 Versa Note

cardiagn.com

P0713 TRANSMISSION FLUID TEMPERATURE SENSOR ATM-159
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0713 TRANSMISSION FLUI D TEMPERATURE SENSOR A
DTC LogicINFOID:0000000012431092
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Maintain the following condition for 10 seconds or more.
3. Stop the vehicle.
4. Check the first trip DTC.
Is
“P0713” detected?
YES >> Go to TM-159, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431093
1.CHECK CIRCUIT BETWEEN TC M AND CVT UNIT (PART 1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector and CVT unit connector.
3. Check continuity between TCM harness connector terminals and CVT unit harness connector terminals.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning part.
2.CHECK CIRCUIT BETWEEN TC M AND CVT UNIT (PART 2)
1. Turn ignition switch ON.
2. Check voltage between TCM harness connector terminal and ground.
DTC Trouble diagnosis name DTC detection conditionPossible causes
P0713 Transmission Fluid Tempera-
ture Sensor A Circuit High The CVT fluid temperature identified by the
TCM is
−40 °C (− 40°F) or less continuously for
5 seconds or more under the following diagno-
sis conditions:
• Diagnosis conditions
- Ignition switch: ON
- Vehicle speed: More than 10 km/h (7 MPH)
- TCM power supply voltage: More than 11 V • Harness or connector
(CVT fluid temperature sensor circuit is
open or shorted to power supply)
• CVT fluid temperature sensor
Vehicle speed : 20 km/h (12 MPH) or more
TCM CVT unit
Continuity
Connector Terminal Connector Terminal
F44 12
F46 12
Existed
11 1 8
Revision: August 2015 2016 Versa Note

cardiagn.com

P0715 INPUT SPEED SENSOR ATM-161
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0715 INPUT SPEED SENSOR A
DTC LogicINFOID:0000000012431095
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Be careful of the driving speed.
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
1. Start the engine.
2. Drive the vehicle.
3. Maintain the following conditions for 10 seconds or more.
4. Stop the vehicle.
5. Check the first trip DTC.
Is
“P0715” detected?
YES >> Go to TM-161, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431096
1.CHECK PRIMARY SPEED SENSOR POWER CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect primary speed sensor connector.
3. Turn ignition switch ON.
4. Check voltage between primary speed sensor harness connector terminal and ground.
Is the inspection result normal?
DTC Trouble diagnosis name DTC detection conditionPossible causes
P0715 Input/Turbine Speed Sensor A
Circuit The primary speed sensor value is less than
150 rpm continuously for 5 seconds or more
under the following diagnosis conditions:
• Diagnosis conditions
- Secondary pulley speed: 1,000 rpm or more
- TCM power supply voltage: More than 11 V
• Harness or connector
(Primary speed sensor circuit is open
or shorted)
• Primary speed sensor
The primary speed sensor value is 240 rpm or
less continuously for 500 msec or more under
the following diagnosis conditions:
• Diagnosis conditions
- 10-msec-ago primary pulley speed: 1,000
rpm or more
- TCM power supply voltage: More than 11 V
Selector lever : “L” POSITION
Vehicle speed : 40 km/h (25 MPH) or more
+ −Vol tag e
Primary speed sensor
Connector Terminal F50 3 Ground 10 – 16 V
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-162
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F11A]
P0715 INPUT SPEED SENSOR A
YES >> GO TO 2.
NO >> GO TO 6.
2.CHECK PRIMARY SPEED SENSOR GROUND CIRCUIT
Check continuity between primary speed s ensor harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning parts.
3.CHECK CIRCUIT BETWEEN PRIMARY SPEED SENSOR AND TCM (PART 1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check continuity between primary speed sensor harness connector terminal and TCM harness connector terminal.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace malfunctioning parts.
4.CHECK CIRCUIT BETWEEN PRIMARY SPEED SENSOR AND TCM (PART 2)
Check continuity between primary speed s ensor harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace malfunctioning parts.
5.CHECK TCM INPUT SIGNALS
1. Connect all of disconnected connectors.
2. Lift the vehicle.
3. Start the engine.
4. Check frequency of pr imary speed sensor.
Is the inspection result normal?
Primary speed sensor —Continuity
Connector Terminal
F50 1 Ground Existed
Primary speed sensor TCM
Continuity
Connector Terminal Connector Terminal
F50 2 F44 35 Existed
Primary speed sensor —Continuity
Connector Terminal
F50 2 Ground Not existed
+
− Condition Frequency
(Approx.)
TCM
Connector Terminal
F44 35 Ground • Selector lever: “L” position
• Vehicle speed: 20 km/h (12 MPH) 1,100 Hz
JSDIA1906GB
Revision: August 2015
2016 Versa Note

cardiagn.com

TM-164
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F11A]
P0720 OUTPUT SPEED SENSOR
P0720 OUTPUT SPEED SENSOR
DTC LogicINFOID:0000000012431097
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Be careful of the driving speed.
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
1. Start the engine.
2. Drive the vehicle.
3. Maintain the following conditions for 10 seconds or more.
4. Stop the vehicle.
5. Check the first trip DTC.
Is
“P0720” detected?
YES >> Go to TM-164, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431098
1.CHECK OUTPUT SPEED SENSOR POWER CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect output speed sensor connector.
3. Turn ignition switch ON.
4. Check voltage between output speed sensor harness connector terminal and ground.
DTC Trouble diagnosis name DTC detection conditionPossible causes
P0720 Output Speed Sensor Circuit The output speed sensor value is less than
150 rpm continuously for 10 seconds or more
under the following diagnosis conditions:
• Diagnosis conditions
- Selector lever: “D”, “L” or “R” position
- Auxiliary gearbox shifting is not in progress.
- When the “D” position
switch, “L” position
switch or “R” position switch is ON, the out-
put speed has not experienced 250 rpm or
more.
- After shifting the selector lever, the input
speed has experienced less than 300 rpm.
- Secondary pulley speed: 1,500 rpm or more
- TCM power supply voltage: More than 11 V • Harness or connector
(Output speed sensor circuit is open or
shorted)
• Output speed sensor
The output speed sensor value is 90 rpm or
less continuously for 500 msec or more under
the following diagnosis conditions:
• Diagnosis conditions
- 10-msec-ago output speed: 730 rpm or more
- TCM power supply voltage: More than 11 V
Selector lever : “D” position
Vehicle speed : 55 km/h (34 MPH) or more
Revision: August 2015 2016 Versa Note

cardiagn.com
